Summary of Contents for Dux Platinum 2700 Series
- Page 1 DUX Pressure Feed 2700 & 3000 Platinum Series PLATINUM PRESSURE FEED P r o d u c t M a n u a l For customer service call 888.389.2732 Page 1 P.O. Box 1314 Seahurst WA 98062 | Phone 888.389.2732 | Fax 888.876.1233 | www.DuxTechnologiesInc.com...
- Page 2 DUX Technologies Inc., a Washington corpora- ENGINES. tion. The relevant US Patent Numbers are: US Once again, DUX has reinvented the spray gun 6,793,157; US 6,425,533, and U.S. 7,004,404. from the inside out! Built upon the success of the original DUX Pressure Feed spray gun, the new DUX Technologies Inc.
-
Page 3: Table Of Contents
Removal of the fluid needle ............. 16 Replacement of the fluid needle ..........16 Troubleshooting ..................17 Pressure Feed 3K Platinum Series Exploded View ......18 Pressure Feed 2700 Series Exploded View ........... 19 Technical Specifications ................. 20 Dux Standard Warranty ................20 For customer service call 888.389.2732 Page 3... -
Page 4: Warnings
PLATINUM PRESSURE FEED WARNINGS Coatings and solvents may be extremely flammable or combustible. Always use the equipment in a properly ventilated area. Smoking must never be permitted in the spraying area. Make sure that all ignition sources are well out of range and always keep fire extinguishing equipment in the spraying area. -
Page 5: Quick Reference And Set-Up Guide
PLATINUM PRESSURE FEED Quick Reference and Set-Up Guide Fan Control Yoke Aircap Fluid Tip Fluid Control Knob Trigger Trigger Air Valve Fluid Inlet Air Inlet Figure 1: Gun Parts Step 1: Connect Step 2: Tighten fluid hose to fluid fluid hose with inlet on spray wrench to pre- vent leakage Step 3: Connect... -
Page 6: Operation Guide
Air Spray guns, very little air pressure is achieve approximately 5 psi at the base of the lost inside the DUX gun. It is not necessary spray gun when the gun is triggered. Keep in to begin with high pressure (30+ psi) at the mind that hoses cause a drop in air pressure, so gun inlet. -
Page 7: Operation Guide
Proper operation of the DUX Pressure Feed If you are using the DUX gun for the first time, requires the trigger handle to be pulled fully to or have recently changed your operations, we the rear of the spray gun while spraying. -
Page 8: Changing Fluid Tips
DUX offers a range of tips from 0.4mm to 2.2mm in .2mm increments. Due to the precision machining of DUX parts, no gasket or o-ring is re- quired between the tip and the fluid barrel. 12 O’Clock To change tips, follow these instructions: Ensure spray gun is depressurized. -
Page 9: Cleaning & Maintenance
Proper care and maintenance procedures thread the upper cleaning cap onto the gun just must be used with the DUX gun to maintain as you would an air cap. Hand tighten until the product warranty. To assist in the cleaning snug. -
Page 10: Lubrication Guide
DUX spray guns are shipped pre-lubricated and a tube of silicone-free PTFE grease lubricant is enclosed in each box. To ensure the quality and longevity of the DUX spray gun it must be lubricated before every use and after every cleaning. Follow the diagram in Figure 9 to ensure... -
Page 11: Periodic Maintenance
• Replace the trigger handle, nylon washers, and trigger spindle screws. • Lubricate according to the Dux Pres Piston Assembly sure Feed lubrication instructions on page 7 Figure 11: Air valve piston removal For customer service call 888.389.2732... -
Page 12: Platinum 3K Series: Fluid Packing
Replacing the wearable packing rotating it counter-clockwise components. using the Dux Multi-Tool Wrench Install the new packing cartridge, Replacing the packing cartridge is faster and (including the o-ring on the simpler, but requires the purchase of a complete cartridge) back into rear of the gun, re-placement cartridge. -
Page 13: Option #2: Replacing Packing Components
Using this method, you will need DUX Part Number #310130—the Wearable Packing Component Kit. Figure 14: Packing on tool... -
Page 14: 2700 Series: Fluid Packing
Dux Multi-Tool 5. Use a flat-blade screwdriver to remove the packing adjustment screw. 6. Use a DUX needle packing tool, dental pick, or similar tool to remove the fluid packing compo- nents. Be sure to remove all components from the fluid tube. -
Page 15: Fluid Packing Adjustment
Fluid Packing Adjustment Unlike many other spray guns that require a matched set of needles and fluid tips, the DUX Pressure Feed uses one standard needle that is compatible with all fluid tips. The packing in... -
Page 16: Fluid Needle Replacement
5. Needle Cap Figure 16: Exploded View of Fluid Needle Assembly The DUX Platinum Pressure Feed is provided with a brass trigger pin. This pin is manufactured from a relatively soft metal to reduce wear on the Stainless Steel trigger. -
Page 17: Troubleshooting
3. Ensure proper distance from surface is achieved , normally 6-8” Excessive The Dux Pressure Feed was designed to Reduce inlet air pressure eliminate excessive fog. If you find that you are having this problem, it may be that the air pressure too high For customer service call 888.389.2732... -
Page 18: Pressure Feed 3K Platinum Series Exploded View
PLATINUM PRESSURE FEED Pressure Feed 3K Platinum Series Exploded View Part Description Part Description 312051 Fluid Tip 0.8mm 310110 Fan Control Assembly 310252 Fluid Tip 1.0mm 310116 Fluid Control Assembly 310253 Fluid Tip 1.2mm 310117 Fluid Needle 310254 Fluid Tip 1.4mm 310125 Yoke 310255 Fluid Tip 1.6mm 310130 Platinum Fluid Needle Packing Kit... -
Page 19: Pressure Feed 2700 Series Exploded View
PLATINUM PRESSURE FEED Pressure Feed 2700 Series Exploded View Part Description Part Description 310110 Fan Control Assembly 310254 Fluid Tip 1.4mm 310116 Fluid Control Assembly 310255 Fluid Tip 1.6mm 310117 Fluid Needle 310256 Fluid Tip 1.8mm 310125 Yoke 310257 Fluid Tip 2.0mm 310128 Fluid Needle Packing Kit 310258 Fluid Tip 2.2mm 310126 Yoke Spring Assembly... -
Page 20: Technical Specifications
A2@ 10psi- 11.0 scfm Dux Standard Warranty DUX TECHNOLOGIES INC. WARRANTS TO CUSTOMER THAT ALL DUX TECHNOLOGIES INC. PRODUCTS (A) ARE FREE FROM DEFECTS IN MATERIALS OR WORKMANSHIP AND (B) MEET ALL APPLICABLE DUX TECHNOLOGIES INC. SPECIFICATIONS. THE FOREGOING WARRANTY WILL REMAIN IN EFFECT FOR ONE YEAR FROM THE DATE OF SALE. IN THE EVENT A PRODUCT FAILS TO MEET THE FOREGOING WARRANTY, CUSTOMER SHALL NOTIFY DUX TECHNOLOGIES INC.
