Nexus IB10

Quick User Guide v1.0

Disclaimer:

CONTACT DETAILS/ FIRST LINE SUPPORT

This Quick User Guide refers to CE-IVD

marked products based on the Nexus

IB10 technology. These products are

certified and approved for the Europe-

an Economic Area (EEA) only.

Human diagnostic use of such products

may be subject to local regulations.

This Quick User Guide does not replace

or substitute for the Instructions for

Use of the respective products. The

products may only be used for the in-

tended use defined in their respective

Instructions for Use.

022-00088 REV C

Table of Contents

Need help?

Do you have a question about the Nexus IB10 and is the answer not in the manual?

Questions and answers

Summary of Contents for SphingoTec Nexus IB10

Page 1 Nexus IB10 Quick User Guide v1.0 Disclaimer: CONTACT DETAILS/ FIRST LINE SUPPORT This Quick User Guide refers to CE-IVD marked products based on the Nexus IB10 technology. These products are certified and approved for the Europe- an Economic Area (EEA) only.
Page 2 How to use EQC Nexus IB10 EQC is for testing a performance check of the Nexus IB10 system. Performance checks of the system should ideally be carried out once on a daily basis prior to patient testing. NO SAMPLE PIPETTING...
Page 3 500 µL (for details see next page “how to pipette a sample“) Press “New Analysis” Nexus IB10 will detect the product type and run test IB10 sphingotest assay will run for 20 minutes; results can be recorded or printed out...
Page 4 How to pipette a sample Using a precision pipette (fixed or adjusted to 500 µL), slowly draw sample into the pipette tip, avoiding bubbles Positioning the tapered pipette tip at a 45 degree angle, pierce the X on the red dot to expose the sample channel inlet on the Test disc Slowly express the patient sample into the inlet applying minimum but continuous force on the pipette plunger Express sample to the First Stop on the pipette.
Page 5 Result interpretation guide for controls, EQC and real patient results Date and time LOT number of of measurement the test that was performed Person who runs the test Serial number of the instrument Patient ID or name Current software version on the Test type instrument Internal control line...
Page 6 Press “OK” Using a precision (fixed or adjustable)pipette, pipette 500μL onto disc Press “New Analysis” Nexus IB10 Instrument will detect the product type and run test Press “QC” Test results display/print in 20 minutes 5.10...
Page 7 How to exchange paper roll Open the paper lid (pull the lid upward by the handle) Close the lid and make sure that the paper is positioned between the lid and the front of the printer Remove the used roll Unwind a new paper roll so that the leading edge comes out from the bottom, facing the user...
Page 8 Key Technical Specifications CATEGORY ITEM SPECIFICATIONS Thermal Paper HANSOL PAPER 65GSM Paper width (58 (recommended) mm, 2.36”) Paper roll size: max. 40 mm (1.57”) weight 60g Input/Output Barcode Scanner USB-HID (Human Interface Device) (optional) Type 1D Barcode Scanner (rated current less than 500 mA) *Model# Hyperion 1300g made by Honey- well is recommended...
