E700 Meter
Manual for Installation and Use
12.04.2006
v. 6.31
Item: 42640
Corresponds to E700 version 6.0
Filename: e700_GB_Manual_42640_v631.doc
ACTIVE INFORMATION MANAGEMENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enermet E700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aim Enermet E700

  • Page 1 E700 Meter Manual for Installation and Use 12.04.2006 v. 6.31 Item: 42640 Corresponds to E700 version 6.0 Filename: e700_GB_Manual_42640_v631.doc ACTIVE INFORMATION MANAGEMENT...
  • Page 2 Copyright Enermet Oy 2002 All rights reserved. The information in this document is subject to change without notice. Enermet Oy assumes no responsibility for errors in this material nor for any other damage, direct or indirect, caused by use of the same. Enermet Oy FIN - 40420 JYSKÄ...

  • Page 3: Table Of Contents

    C O N T E N T S Contents: METER TYPES ............................4 OPTION MODULES AND RESERVE BATTERY ..................5 ..........................5 PTION MODULE TYPES ......................5 HANGING THE OPTION MODULES ...........................7 ESERVE BATTERY INSTALLATION REQUIREMENTS ......................8 ......................8 NSTALLATION SITE CONDITIONS ..........................8 NSTALLATION PLACE ..........................8 OLTAGE SYSTEMS 3.3.1...

  • Page 4: Meter Types

    M E T E R T Y P E S 1 METER TYPES The type of the E700 meter is defined as follows: Product family Class 1 Class 0.5 Class 0.2 Terminal configuration according to DIN standard 3 elements for 4 wire network (with or without neutral), without N = two elements for 3 wire network Meter with current transformer connection Meter with current and voltage transformer connection...

  • Page 5: Option Modules And Reserve Battery

    O P T I O N M O D U L E S A N D R E S E R V E B A T T E R Y 2 OPTION MODULES AND RESERVE BATTERY 2.1 Option module types The following option cards can be used with the E700: •...
  • Page 6 O P T I O N M O D U L E S A N D R E S E R V E B A T T E R Y 3. Add, remove, or change the option cards. If you change into a full width option module (E7O6), remove the separation wall between the two option module slots.

  • Page 7: Reserve Battery

    O P T I O N M O D U L E S A N D R E S E R V E B A T T E R Y 2.3 Reserve battery A reserve battery for the real time clock can be attached to the meter.

  • Page 8: Installation Requirements

    I N S T A L L A T I O N R E Q U I R E M E N T S 3 Installation Requirements 3.1 Installation site conditions The installation site must meet the requirements of the meter’s protection class (IP54) and the operating temperature range (-20 °C ...

  • Page 9: Inputs

    I N S T A L L A T I O N R E Q U I R E M E N T S (max. 2,5 mm², which is the maximum size of the connector). Note! All relays must have the same supply voltage! 3.3.3 Inputs There are two types of inputs.

  • Page 10: Installation Sequence

    I N S T A L L A T I O N S E Q U E N C E 4 Installation Sequence 1. Make sure that the voltage is not on! 2. Make sure that the meter type is correct for the installation site (type V or J).

  • Page 11: Setting Date And Time

    S E T T I N G D A T E A N D T I M E 5 Setting date and time To set the meter’s date and time, you need both push buttons. To access the red button, remove the sliding cover. See chapter 2.3 Reserve battery.

  • Page 12: Ending Billing Period

    E N D I N G B I L L I N G P E R I O D 6 Ending billing period To end the meter’s billing period, make a short press on the red push button. To access the red button, remove the sliding cover. See chapter 2.3 Reserve battery.

  • Page 13: Maintenance

    M A I N T E N A N C E 7 Maintenance The reserve battery is the only component in the E700 that is maintained by the user. See Chapter 2.3 Reserve battery. The operating time of the reserve battery is ten years. Warning! Do not open the case when the device is connected to the electricity network.

  • Page 14: Push Buttons And Display

    P U S H B U T T O N S A N D D I S P L A Y 8 Push buttons and display 8.1 Push buttons The E700 has two push buttons. A black button is located in the bottom right corner of the nameplate and a red button is located under the sealable cover.
  • Page 15 P U S H B U T T O N S A N D D I S P L A Y Some display messages are presented in the following tables: Table 1. Display messages Message Meaning E700 ID EDIS ID UNIT ID 0.0.0 Unit ID...

  • Page 16: Scrolling The Display Using Push Buttons (Manual Scrolling)

    P U S H B U T T O N S A N D D I S P L A Y 14.24 Frequency 64.1.8 Life-time cum. AE+ 64.2.8 Life-time cum. AE- 64.3.8 Life-time cum. RE+ 64.4.8 Life-time cum. RE- 64.9.8 Life-time cum.
  • Page 17 P U S H B U T T O N S A N D D I S P L A Y Note! If the button is not used, the program goes back to the Auto Scrolling after the time period defined using the configuration program.

  • Page 18: An Example Of Manual Scrolling: Browsing All Load Profile Values

    P U S H B U T T O N S A N D D I S P L A Y 8.2.1.1 An example of manual scrolling: browsing all load profile values You can browse all load profile values on the display if the meter is version 5.00 or later and if you have ticked the All load profile values box in the User Interface (see E700 User Interface Manual, chapter Edit display).
  • Page 19 P U S H B U T T O N S A N D D I S P L A Y Auto Scrolling = short press (< 2 sec) = medium press (>2<5 sec) Display test P01.00 P02.00 P03.00 Menu level 1, END P02.00 23.08.2001 P02.00...

  • Page 20: Automatic Display Scrolling (Scrolling Mode)

    P U S H B U T T O N S A N D D I S P L A Y 8.2.2 Automatic display scrolling (Scrolling mode) In Auto Scrolling mode the meter automatically displays a selected scrolling sequence. Maximum number of items displayed in the scrolling sequence is 256.

  • Page 21: Led Indicators

    P U S H B U T T O N S A N D D I S P L A Y 8.3 LED indicators The E700 has eight LED indicators, which have the following purposes: LED indicator Purpose: V-type: Configurable, the Configurable Test-LED default is 5000 imp./kWh, kvarh...
  • Page 22 P U S H B U T T O N S A N D D I S P L A Y Five freely configurable LED indicators to indicate the operation of status and pulse inputs Error (red) Configurable meter test (yellow) Meter test (yellow)

  • Page 23: Troubleshooting

    (the clock is not on time). Update the unit's time using the push buttons, configuration program, or the AIM DGC system. 9.2 Phase indication symbol is blinking Phase symbols L1, L2 and L3 indicate electricity network’s line voltages.
  • Page 24 T R O U B L E S H O O T I N G • Err 003: measurement alarm (control of electricity network) After these, an eight digit hexadecimal number is displayed. This error code tells what error(s) the meter has detected. When you read the error registers with the E700UI, it shows the error codes as decimal values.
  • Page 25 T R O U B L E S H O O T I N G Err 002 Error Error Meaning Action Meter core message message error in UI on LCD Bit number: Decimal 0001 Non-volatile memory (EEPROM) Deliver meter to Enermet for was initialised.

  • Page 26: Technical Specifications

    T E C H N I C A L S P E C I F I C A T I O N S 10 TECHNICAL SPECIFICATIONS Table 5. Operating characteristics Operating characteristics Metrological requirements Instantaneous measurement • Class 0.2S and 0.5S according to EN60687, IEC •...
  • Page 27 T E C H N I C A L S P E C I F I C A T I O N S Energy measurements • +AE (I+IV) kWh • −AE (II+III) kWh • +RE (I+II) kvarh • −RE (III+IV) kvarh •...
  • Page 28 T E C H N I C A L S P E C I F I C A T I O N S Impulse voltage Vibration test • Network connections 12 kV • IEC 60068-2-6, 9.8 m/s (1 g) • Low voltage lines 6 kV Current •...
  • Page 29 T E C H N I C A L S P E C I F I C A T I O N S Option Module E7O5 Version E7O5.1 Outputs • Six (6) semiconductor relay outputs • Max 230 Vac/Vdc (all relays must have the same supply voltage!) •...

  • Page 30: Dimensions

    D I M E N S I O N S 11 Dimensions Figure 8. E700 dimensions © Enermet Oy E700 Manual for Installation and Use v. 6.31 ACTIVE INFORMATION MANAGEMENT...
  • Page 31 D I M E N S I O N S M 100- G M A DE IN EU G SM 230 V 50 Hz - 20 C 140.5 Figure 9. Installation dimensions with M100-G GSM modem. © Enermet Oy E700 Manual for Installation and Use v.

  • Page 32: Connections

    C O N N E C T I O N S 12 Connections 2 3 4 5 6 7 8 9 11 V 13115 Figure 10. Connections for E700 type J 2 3 4 5 6 7 8 9 11 V 13116 Figure 11.
  • Page 33 C O N N E C T I O N S 1 2 3 4 5 6 7 8 9 11 Figure 13. Connections for type J with 3 voltage transformers with neutral and 2 current transformers 1 2 3 4 5 6 7 8 9 11 Figure 14.
  • Page 34 C O N N E C T I O N S 3020 V11916 Figure 16. Connections for 2 element meters (DJQ and DJZ types) OM1: RS-232 1 2 3 Figure 17. Connections for E7O1 option module. OM2: RS-485 1 2 3 Figure 18.
  • Page 35 C O N N E C T I O N S E7O5 230 V(E705.1) S0-input 100 V(E705.2) output AC Input 11092 Figure 21. Connections for E7O5 option module. Figure 22. Connections for E7O6 option module Figure 23. Connections for E7O7 option module Figure 24.
