Castle Creations Mamba X Quick Start Manual page 2

MAMBA X SPECIFICATIONS
• 1:10th scale buggies, stadium trucks, touring cars,
crawlers and short course trucks weighing up to 7lbs.
Application
Guidelines
• 1:8th scale buggies, geared for off-road racing, weighing
up to 9lbs.
Input Voltage
Min: 2S LiPo, Max: 6S LiPo, 25.2V
Range
BEC Specifications Adjustable: 5.5V, 6.0V, 7.5V, or 8.0V (8A Peak), default 5.5V
Waterproof Yes*
Sensors Yes, including Smart Sense
• Applying voltages higher than 25.2V will cause irreparable
damage to your controller.
• Recommended battery capacity for 1:8th and 1:10th scale
vehicles is 5000mAh or larger. We recommend using 30C
continuous discharge or higher LiPo batteries (or high
quality 25C batteries such as Traxxas® Power Cell).
Product Use
Statement**
• The Mamba X has 4.0mm bullet connectors directly on the
ESC and the battery input wires are bare. You must add the
connector of choice to the battery leads. We recommend a
high-current connector rated for 70+ amps.
• The Mamba X is not intended for human or animal
propulsion.
RECEIVER CONNECTION
Plug the RX wire into the throttle (#2) channel on your
RX Wire
receiver.
The AUX wire allows you to adjust a setting "on-the-fly"
using an auxiliary channel on your receiver. The AUX wire
function is disabled by default and is programmable via
AUX Wire
Castle Link. Plug this wire into the auxiliary (#3/#4) channel
on your receiver. If you are not utilizing the Aux wire
function you can leave it disconnected from your receiver.
*Not intended for operation while submerged in liquid. If unit is operated in wet conditions, rinse with fresh
water to remove dirt or corrosives, then fully dry unit.
**Failure to adhere to the Product Use Statement constitutes a violation of the warranty agreement, and will
result in non-warranty service fees to repair or replace damaged products.
feature.
™
TRANSMITTER PROGRAMMING REFERENCE
1.Brake/Reverse Type
• With Reverse*
• Without Reverse
• Crawler Reverse
2.Voltage Cutoff
• Auto-Lipo*
• None
AUDIBLE ALERT REFERENCE
• •
Start Fail
• –
Low Voltage Cutoff
– •
Over-Current
• • •
Sensors Lost
• • –
Radio Glitch
• – •
Over-Temperature
• – –
Excessive Load
– • •
AUX Wire Radio Glitch
– • –
BEC Over-Temperature
• • • •
Data Log Full Warning
Contact
Castle Creations, Inc.
540 North Rogers Road
Olathe, KS 66062
(913) 390-6939 (ext. #1 Support, #3 Sales)
Product Support: support@castlecreations.com
Sales: sales@castlecreations.com
Website: www.castlecreations.com
3. Brake Amount 5. Motor Type
• 25% • Brushless*
• 50%* • Brushed Reversing
• 75% • Brushed High Power
• 100%
4. Drag Brake See Driver's Ed
• Disabled* Guide, "Transmitter
• 10% Programming".
• 20%
• 30%
• Crawler Full On
*Default Setting
