Summary of Contents for SPATIAL ArcGIS
- Page 1 1Integrate for ArcGIS Quick Start Guide Product version: v 1.6 Document version: v 1.2.3 Document date: 13/10/2017...
- Page 2 Copyright 2017 1Spatial plc and its affiliates. All rights reserved. Other trademarks are registered trademarks and the properties of their respective owners. US Patent Number 9542416 B2 (2017-01-10) No part of this document or any information appertaining to its content may be used, stored, reproduced or transmitted in any form or by any means, including photocopying, recording, taping, information storage systems, without the prior permission of 1Spatial plc.
-
Page 3: Table Of Contents
Contents 1 Quick Start Guide 2 Free Rulesets Uploading and Publishing a Free Ruleset Using a Free Ruleset 3 Validating and Enhancing Data Using the Web AppBuilder Widget Running Rules Viewing Validation Results Using the ArcMap Add-in Running Rules Viewing Validation Results Quick Start Guide - iii - v 1.2.3... -
Page 4: Quick Start Guide
1Integrate for ArcGIS using some free rulesets. Note: This guide assumes that you have already installed and configured 1Integrate for ArcGIS. If this is not the case, please refer to the 1Integrate for ArcGIS Installation Guide. Before proceeding, ensure that you have the following information:... -
Page 5: Free Rulesets
Free Rulesets A free ruleset is provided as a backup (.rules) file so that you can quickly get started with 1Integrate for ArcGIS. Uploading and Publishing a Free Ruleset In order to use a free ruleset with a data service, it must first be uploaded and then published. - Page 6 Chapter 2 Free Rulesets Figure 2-2: Select a ruleset to upload 4. Either drag and drop your .rules file onto the Upload Ruleset box, or click on the box and navigate to your file. 5. Click Upload. A confirmation message is displayed once the ruleset has been successfully uploaded.
-
Page 7: Using A Free Ruleset
If the Ruleset fails validation, an error will be displayed. Note: Ensure that you have configured your data service to use the correct ruleset. See the 1Integrate for ArcGIS Installation Guide. Using a Free Ruleset Once uploaded and published, your free ruleset will be available within your data service. -
Page 8: Validating And Enhancing Data
Add-in or widget you are using. Using the Web AppBuilder Widget The following steps outline how to use 1Integrate for ArcGIS to run validation and enhancement rules within the Web AppBuilder for ArcGIS. Note: For general information on using the Web AppBuilder, please refer to the ArcGIS documentation. -
Page 9: Running Rules
Chapter 3 Validating and Enhancing Data Figure 3-1: Widget logo Running Rules Rules can be run across a specific area of your dataset, or the visible extent. Note: When running rules in the Web AppBuilder Widget, the default extent to be processed is limited to the data visible within your data frame. -
Page 10: Viewing Validation Results
Chapter 3 Validating and Enhancing Data Run rules over a selected region: 1. Select one or more rules by clicking on their checkboxes. Packages (groups) of rules can be selected using the group checkbox. 2. Use the Draw tool to define an area of your data to be processed (an "extent"). - Page 11 Chapter 3 Validating and Enhancing Data Figure 3-4: Validation results A traffic light next to each rule will also indicate where large numbers of features failed (red) or where most features passed (green). Figure 3-5: Traffic light rating By hovering the mouse over each traffic light icon, a summary for than rule can be displayed.
-
Page 12: Using The Arcmap Add-In
Figure 3-8: Web AppBuilder Layer List Using the ArcMap Add-in The following steps outline how to use 1Integrate for ArcGIS to run validation and enhancement rules within ArcMap. Note: For general information on using ArcMap, please refer to the ArcGIS documentation. -
Page 13: Running Rules
Chapter 3 Validating and Enhancing Data 3. Open the 1Spatial Add-in via the menu button. Figure 3-9: ArcMap menu 4. Click Fetch Rules to display the rulesets that have been published for your dataset. Running Rules Validation and enhancement rules are run in the same way within ArcMap. Note: When running rules in ArcMap, the extent to be processed is limited to the data visible within your data frame. - Page 14 Chapter 3 Validating and Enhancing Data Figure 3-11: Validation results All non-conformances are marked in your dataset with a pin. The non-conformances for each rule are grouped with a similar pin style. These groups are displayed as Layers within the Table of Contents window, and can be hidden or displayed as required.
