Medias Mediatrix 1204 Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Corporation
A Division of
®
Mediatrix
1204
Reference Manual
SIP Version
Product Version 5.0
Document Revision 16
June 11, 2007
Pb
RoHS
COMPLIANT
2002/95/EC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mediatrix 1204 and is the answer not in the manual?

Questions and answers

Summary of Contents for Medias Mediatrix 1204

  • Page 1 Corporation A Division of ® Mediatrix 1204 Reference Manual SIP Version Product Version 5.0 Document Revision 16 June 11, 2007 RoHS COMPLIANT 2002/95/EC...
  • Page 2 Mediatrix Telecom, a Division of Media5 Corporation Reference Manual Mediatrix Telecom, a Division of Media5 Corporation 4229 Garlock Street Sherbrooke, Québec, Canada J1L 2C8 ® Mediatrix 1204 Reference Manual (SIP Version) © 2007, Mediatrix Telecom, a Division of Media5 Corporation All rights reserved.
  • Page 3 Mediatrix Telecom, a Division of Media5 Corporation Reference Manual Supplementary Copyright Information CMU/UCD copyright notice: (BSD like) Copyright 1989, 1991, 1992 by Carnegie Mellon University Derivative Work - 1996, 1998-2000 Copyright 1996, 1998-2000 The Regents of the University of California All Rights Reserved Permission to use, copy, modify and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both that copyright...
  • Page 4 Mediatrix Telecom, a Division of Media5 Corporation Reference Manual OpenSSL License Copyright (c) 1998-2002 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1.
  • Page 5 Mediatrix Telecom, a Division of Media5 Corporation Reference Manual THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
  • Page 6 Mediatrix Telecom, a Division of Media5 Corporation Reference Manual...

  • Page 7: Table Of Contents

    Wall-Mounting ................................10 Stacking Units ................................11 Condensation ................................12 Cleaning ..................................12 Hardware Connection ..........................12 Reserving an IP Address............................12 Installing the Mediatrix 1204............................13 Starting the Mediatrix 1204 for the First Time.....................14 Initial Provisioning Sequence ............................ 14 Mediatrix 1204...
  • Page 8 Verifying the Installation..........................23 Chapter 2 Web Interface – Introduction.................... 25 Introduction ..............................25 Using the Web Interface ..........................25 System Status of the Mediatrix 1204......................... 26 Menu Frame ................................27 Content Frame ................................28 Submitting Changes ...........................28 Syslog Monitoring ............................29 Configuring the Syslog Daemon Application ......................30 Chapter 3 Web Interface –...
  • Page 9 Fax Parameters ................................. 88 Miscellaneous .............................91 Country Selection ..............................91 Chapter 6 Web Interface – Advanced....................93 Quality of Service (QoS) ..........................93 802.1q Configuration ..............................93 DiffServ Configuration ............................... 96 Emergency Page ............................97 Emergency Call Configuration........................... 97 STUN Configuration............................98 Mediatrix 1204...
  • Page 10 Generic Variables ..............................114 Variables for Administrative Commands ......................... 115 SNMP Service Agent ..........................116 Current MIB Version ..........................116 Sending Configuration Data to the Mediatrix 1204 ...................116 Configuration File ..............................116 Management Information Base – MIB ........................116 Chapter 8 IP Address and Network Configuration ................ 117 IP Addresses ............................117...
  • Page 11 DNS SRV Configuration....................145 What is a DNS SRV?..........................145 Priority vs Weight ..............................145 DNS SRV Call Flow..............................146 Enabling DNS SRV on the Mediatrix 1204 ....................146 DNS SRV Record Lock..........................147 DNS SRV-Oriented Settings........................147 Chapter 11 Country-Specific Configuration ..................149 Caller ID Information..........................149...
  • Page 12 Special Case: Automatic Call ..........................187 Line Properties............................187 Dial Tone Detection..............................187 Line Fault Detection ..............................188 Incoming Call Not Allowed ............................188 Detecting a Far End Disconnect .......................189 How to Solve the Problem............................189 Mediatrix 1204 Configuration ..........................190 Mediatrix 1204...
  • Page 13 Fax Transmission......................215 Introduction ...............................215 Fax Calling Tone Detection ........................215 Clear Channel Fax............................216 T.38 Fax..............................217 T.38 No-Signal ................................ 218 Chapter 18 SIP Protocol Features ..................... 219 User Agents ..............................219 SIP User Agent Header ............................220 Session Timers ............................220 Mediatrix 1204 xiii...
  • Page 14 Background Information ............................221 Authentication ............................222 Authentication Request Protection .......................... 222 SIP Trusted Sources..........................223 NAT Traversal............................223 Mediatrix 1204 Configuration ..........................223 NAT System Configuration............................224 SIP Transport Type...........................224 Transport Parameter ............................... 225 UDP Source Port Behaviour............................ 225 SIP Penalty Box............................226 Penalty Box vs Transport Types ..........................
  • Page 15 IP Address Call Service ..........................257 Enabling IP Address Calls............................257 Dialing an IP Address.............................. 257 PIN Dialing..............................258 Remote Line Extension..........................259 Delayed Hot Line ............................261 Chapter 24 Management Server Configuration................263 Using the Management Server .........................263 Configuration Source............................... 263 Mediatrix 1204...
  • Page 16 How are Statistics Collected?..........................273 Statistics by Syslog ..............................274 Example .................................. 275 Chapter 28 Maximum Transmission Unit (MTU) ................277 What is MTU? ............................277 Mediatrix 1204 MTU ..........................277 Possible Hardware Problem ........................277 Chapter 29 Troubleshooting ......................279 General Operation Issues.........................279 Calling Issues ............................282 Fax Issues ..............................285...
  • Page 17 DTMF Tone Detection ..........................303 DTMF Tone Generation..........................304 MTBF Value..............................304 Power Consumption ..........................304 Measurements at the DC input..........................304 Operating Environment..........................304 Dimensions and Weight..........................305 Warranty ..............................305 Appendix C Cabling Considerations ....................307 RJ-45 Cable..............................307 Straight Through Cable ............................307 Mediatrix 1204 xvii...
  • Page 18 New Zealand.............................331 North America............................332 North America 1 ..............................332 Russia...............................333 Spain.................................334 Sweden..............................335 Switzerland ...............................336 Thailand ..............................337 UK................................338 Appendix E Glossary ........................... 339 Appendix F List of Acronyms ......................347 Appendix G List of MIB Parameters ....................349 xviii Mediatrix 1204...

  • Page 19: Preface

    Thank you for purchasing the Mediatrix 1204 from Mediatrix. The Mediatrix 1204 is a SIP Gateway that connects up to four SCN lines or analog PBX extensions to a Local Area Network (LAN) with access to an Intranet or the Internet to permit high-quality, full duplex, audio/fax communications over IP Packet Networks.

  • Page 20: Intended Audience

    From the perspective of the LAN administrator, a Mediatrix 1204 presents itself like another device to add to the LAN. It requires the same kind of TCP/IP addressing. The Mediatrix 1204 can also use a DHCP server on the LAN to automatically receive its IP configuration assignment.
  • Page 21 Describes the Mediatrix 1204’s behaviour with a DNS page 145 SRV. “Chapter 11 - Country-Specific Configuration” on Describes how to set the Mediatrix 1204 with the page 149 proper country settings. “Chapter 12 - Configuration File Download” on Describes how to use the configuration file download page 153 feature to update the Mediatrix 1204 configuration.
  • Page 22 Preface - About this Manual Document Structure Table 2: Mediatrix 1204 Reference Manual Chapter/Appendices (Continued) Title Summary “Chapter 23 - Telephony Attributes” on page 255 Describes the telephony attributes available on the Mediatrix 1204. “Chapter 24 - Management Server Describes how to configure the Mediatrix 1204 to Configuration”...

  • Page 23: Document Conventions

    Document Conventions Reference Manual (SIP Version) Document Conventions The following information provides an explanation of the symbols that appear on the Mediatrix 1204 and in the documentation for the product. Warning Definition Warning: Means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, you must be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents.

  • Page 24: Obtaining Documentation

    The demo version of the Unit Manager Network is available on the Mediatrix Download Portal at: https:// support.mediatrix.com/DownloadPlus/Download.asp. See the Unit Manager Network Administration Manual for more details on how to use it to configure any Mediatrix 1204 unit on the network. xxiv Mediatrix 1204...

  • Page 25: End User Technical Support

    Reference Manual (SIP Version) End User Technical Support In order to maximize technical support resources, Mediatrix works through its partners to resolve technical support issues. All end users requiring technical support are encouraged to contact their vendor directly. Mediatrix 1204...
  • Page 26 Preface - About this Manual End User Technical Support xxvi Mediatrix 1204...

  • Page 27: Installation And Web

    Installation and Web Page Configuration...
  • Page 28 Page Left Intentionally Blank...

  • Page 29: Chapter 1 Installation

    The Mediatrix 1204 package contains the following items: the Mediatrix 1204 unit four rubber feet a power cord for the country in which you are using the Mediatrix 1204 a printed Quick Start booklet a printed Flyer You also need a 10/100 BaseT Ethernet RJ-45 cable.

  • Page 30: Overview

    You can place a call from a SCN telephone by dialing the number corresponding to one of the SCN lines or analog PBX extensions connected to the Mediatrix 1204. The unit plays a second dial tone. You can then dial the number to reach on the IP side.

  • Page 31: Management Choices

    Overview Reference Manual (SIP Version) Management Choices The Mediatrix 1204 offers various management options to configure the unit. Table 4: Management Options Management Choice Description Web Interface The Mediatrix 1204 web interface offers the following options: • Password-protected access via basic HTTP authentication, as described in RFC 2617 •...

  • Page 32: Panels

    Indicator Description Ready When lit, the Mediatrix 1204 is ready to initiate or receive a call. The unit does not have to be registered to a server. In Use When lit, at least one of the FXO lines is in use.

  • Page 33: Rear Connectors

    Panels Reference Manual (SIP Version) Rear Connectors The Mediatrix 1204 has several connections that must be properly set. Figure 2 shows the back panel of the Mediatrix 1204. Figure 2: Back Panel Connectors Factory Default Universal Power Settings Supply Input...

  • Page 34: Choosing A Suitable Installation Site

    To prevent fire or shock hazard do not expose the unit to rain or moisture. The Mediatrix 1204 is suited for use in an office environment where it can be wall-mounted, mounted on a standard 48.26 cm (19 in.) equipment rack, or free standing on its rubber feet. In addition, the Mediatrix 1204 can be rack-mounted in a wiring closet or equipment room.

  • Page 35: Rack-Mounting

    Choosing a Suitable Installation Site Reference Manual (SIP Version) Rack-Mounting The Mediatrix 1204 is 5.5 cm (2.2 in.) high and fits in most standard 48.26 cm (19 in.) racks. Mediatrix recommends to use a rack compliant EIA-310-D. To rack-mount the Mediatrix 1204: Disconnect all of the cables from the Mediatrix 1204.

  • Page 36: Wall-Mounting

    Place the Mediatrix 1204 right side up on the wall-mounting bracket, with the front facing toward you. Place the Mediatrix 1204 screw holes on the side over the mounting holes of the wall bracket. See Figure 5 for the location of the wall-mounting pieces.

  • Page 37: Stacking Units

    “Hardware Connection” on page Stacking Units For free-standing Mediatrix 1204 units, you can stack up to four units on top of each other. If you are mixing a variety of hub units, position the smaller units at the top. To stack units: Use the supplied rubber feet by inserting them into the tabs on either sides of the Mediatrix 1204.

  • Page 38: Condensation

    If this occurs, allow the unit to acclimatize for an hour before powering it on. Cleaning To clean the Mediatrix 1204, wipe with a soft dry cloth. Do not use volatile liquids such as benzine and thinner that are harmful to the unit casing.

  • Page 39: Installing The Mediatrix 1204

    Connect the power cord to the Mediatrix 1204 and then connect the other end to an electrical outlet. The Mediatrix 1204 powers up. You do not need to wait for the unit to complete its power up cycle before proceeding to the next step.

  • Page 40: Starting The Mediatrix 1204 For The First Time

    “Recovery Mode” on page Initial Provisioning Sequence When starting the Mediatrix 1204 for the first time, it needs to be configured before it can support calls. This process is known as provisioning. This sequence assumes that you have installed the Mediatrix 1204 hardware as per “Hardware Connection”...

  • Page 41: Led Behaviour In Starting Mode

    LED Behaviour in Starting Mode When the Mediatrix 1204 starts and it is not configured to use a DHCP server, it uses static IP addresses. If the static information is not valid, the Power and Ready LEDs blink at 1 Hz with 75% duty cycle. This lets you know that you must perform a Factory reset or Recovery mode operation.

  • Page 42: Led Patterns

    DHCP until it receives valid values. If the configuration is static, the LED pattern indicates that the unit must be reset to default settings or put into recovery mode for maintenance and correction of network values. Mediatrix 1204...

  • Page 43: Booting Led Pattern Description

    See the corresponding LED pattern in “NormalMode LED Pattern Description” on page Booting LED Pattern Description While in the Booting state, the LEDs of the Mediatrix 1204 behave independently; the following table indicates the behaviour for each LED. Table 11: LED Patterns in Booting Mode...

  • Page 44: Adminmode Led Pattern Description

    Chapter 1 - Installation LED Indicators AdminMode LED Pattern Description While in the AdminMode state, the LEDs of the Mediatrix 1204 behave independently; the following table indicates the behaviour for each LED. Table 13: LED Patterns in AdminMode Pattern Meaning...

  • Page 45: Default Settings Switch

    Reconfigure a unit. At Run-Time The Default Settings switch can be used at run-time – you can press the switch while the Mediatrix 1204 is running without powering the unit off. Table 14 describes the actions you can perform in this case.

  • Page 46: Recovery Mode

    Recovery Mode The recovery mode restarts the Mediatrix 1204 in a known, static, and minimal state. It is used to recover from a basic configuration error that prevents you to reach the unit through the network. It may serve as a last resort before the Factory reset command.

  • Page 47: Factory Reset

    The Factory reset creates a new configuration file with the default factory values. It should be performed with the Mediatrix 1204 connected to a network with access to a DHCP server. If the unit cannot find a DHCP server, it sends requests indefinitely.

  • Page 48: Software Restart

    You can disable the factory reset procedure, even if users depress the Default Settings switch. Disabling the factory reset means that users will not be able to revert the Mediatrix 1204 back to its factory settings if there are configuration problems.

  • Page 49: Verifying The Installation

    Verifying the Installation Reference Manual (SIP Version) Verifying the Installation There are two ways to verify that the Mediatrix 1204 is properly connected to the IP network and is working: By contacting it with a SNMP Browser By pinging it These two procedures assume that you know the IP address of the Mediatrix 1204 you want to verify.
  • Page 50 Chapter 1 - Installation Verifying the Installation Mediatrix 1204...

  • Page 51: Web Interface - Introduction

    Internet Explorer web browser to properly access the web interface. To use the web interface configuration: In your web browser’s address field, type the IP address of the Mediatrix 1204 (if you have performed a recovery mode, this is 192.168.0.1). The following opens: Figure 9: Login Window The Mediatrix 1204 uses Digest Authentication to grant access to web-based interface.

  • Page 52: System Status Of The Mediatrix 1204

    Click OK. The Device Info web page displays. It has three sub-pages: Info, Statistics, and Monitoring. It stays accessible for as long as the Internet browser used to access the Mediatrix 1204 web interface is opened. Figure 10: Device Info Web Page System Status of the Mediatrix 1204 The Device Info –...

  • Page 53: Menu Frame

    SIP: Links to the SIP sub-page of the SIP web page, which allows you to configure the SIP server and SIP user agent parameters of the Mediatrix 1204. “SIP Servers Configuration” on page 65 for more details.

  • Page 54: Content Frame

    Most changes are not dynamic and require to restart the Mediatrix 1204. The Reboot page then opens. You must click Reboot. This restarts the Mediatrix 1204. If the unit is in use when you click Reboot, all calls are terminated. Mediatrix 1204...

  • Page 55: Syslog Monitoring

    Syslog daemon address is provided by a DHCP server or specified by the administrator, no messages are sent. For instance, if you want to download a new software into the Mediatrix 1204, you can monitor each step of the software download phase. Furthermore, if the unit encounters an abnormal behaviour, you may see accurate messages that will help you troubleshoot the problem.

  • Page 56: Configuring The Syslog Daemon Application

    The software update failed. error and has not been completed Configuring the Syslog Daemon Application You shall configure the Syslog daemon to capture those messages. Refer to your Syslog daemon’s documentation to learn how to properly configure it to capture messages. Mediatrix 1204...

  • Page 57: Web Interface - Management

    RFC 2617 – HTTP Authentication: Basic and Digest Access Authentication The Change HTTP Server ADMINISTRATOR Username/Password section allows you to modify the default password to access the web interface. The Mediatrix 1204 supports basic HTTP authentication, as described in RFC 2617. To change the username/password: In the web interface, click the Management link, then the Admin sub-link.
  • Page 58 Table 20: Case 2 Issue Item Description Wanted Behaviour The password to use is the password modified via the web interface in the older software version. Current Behaviour Same as the wanted behaviour. Workaround None required. Mediatrix 1204...

  • Page 59: System Management

    • Disable: SNMP connections are forbidden. If you are exclusively using the web page to configure the Mediatrix 1204, you could disable the SNMP service agent and forbid any SNMP connection to the unit. If the SNMP agent is disabled and the unit enters into recovery mode, SNMP connections are allowed during that time.

  • Page 60: Group Port Management

    Click Submit if you do not need to set other parameters. Interface Management You can set the administrative state of a line that will be kept until the Mediatrix 1204 restarts. To set the interface management parameters: In the Interface Management section of the Admin page, select the proper command to execute in the Command column.

  • Page 61: Network Settings

    Ethernet Network Settings SNTP Ethernet Connection Speed You can set the speed of the Mediatrix 1204’s Ethernet connection. You can also set this parameter via SNMP, as described in “Ethernet Connection Speed” on page 135. To set the Ethernet connection speed: In the web interface, click the Management link, then the Network Settings sub-link.
  • Page 62 The Mediatrix 1204 has the possibility to force the desired Ethernet link speed and duplex mode by disabling the auto-negotiation and selecting the proper setting. When forcing a link speed at one end, be sure that the other end (a hub, switch, etc.) has the same configuration.

  • Page 63: Network Settings

    The Network Settings section allows you to set the IP information the Mediatrix 1204 needs to work properly. This section is vital to the proper operation of the Mediatrix 1204. If a field of this group is not properly set, the Mediatrix 1204 may not be able to restart and be contacted after it has restarted.

  • Page 64: Sntp Settings

    Table 27: Network Settings Configuration Sources Source Description Static You manually enter the value and it remains the same every time the Mediatrix 1204 restarts. Use the static configuration if you are not using a DHCP server or if you want to bypass it. DHCP The value is obtained at start-time by querying a DHCP server and using standard DHCP fields or options.
  • Page 65 Sunday of October (5 indicates the last z day). It does not matter if the Sunday is in the 4th or 5th week. M10.1.6 is the first week with a Saturday (thus the first Saturday). It does not matter if the Saturday is in the first or second week. Mediatrix 1204...
  • Page 66 Eastern Time Canada & US) EST5EDT4,M3.2.0/02:00:00,M11.1.0/02:00:00 Atlantic Time (Canada) AST4ADT3,M3.2.0/02:00:00,M11.1.0/02:00:00 GMT Standard Time GMT0DMT-1,M3.5.0/01:00:00,M10.5.0/02:00:00 W. Europe Standard Time WEST-1DWEST-2,M3.5.0/02:00:00,M10.5.0/03:00:00 China Standard Time CST-8 Tokyo Standard Time TST-9 Central Australia Standard Time CAUST-9:30DCAUST-10:30,M10.5.0/02:00:00,M3.5.0/02:00:00 Australia Eastern Standard Time AUSEST-10AUSDST-11,M10.5.0/02:00:00,M3.5.0/02:00:00 UTC (Coordinated Universal Time) UTC0 Mediatrix 1204...

  • Page 67: Configuration File Download

    153. Configuration File Download Server The service allows to download a unique file for each Mediatrix 1204, and/or a file shared among many units. These configuration files may be encrypted or not. You have the choice to perform the configuration file download by using the TFTP protocol or the HTTP protocol.

  • Page 68: Configuration File Server Settings

    Configuration File Download Configuration File Server Settings The Mediatrix 1204 must know the IP address and port number of its configuration file server. This server contains the configuration file the Mediatrix 1204 will download. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself.

  • Page 69: Setting Up The Configuration File Download

    The password in the Configuration File Password field. The Mediatrix 1204 supports basic and digest HTTP authentication, as described in RFC 2617. Set the path, on the remote server, of the directory where the configuration files are located in the Configuration File Path field.
  • Page 70 • Cut and paste the path and/or name of the directory that contains the extracted files into the configuration file path of the Mediatrix 1204 (you may have to convert “\” into “/ ”) to eliminate typographical errors. Note that you can define the C:/Root/Download part as you want. The file names may also differ from the example shown above.
  • Page 71 If valid configuration files are successfully downloaded, then the Mediatrix 1204 automatically restarts to apply all the new settings. If the Mediatrix 1204 does not restart, this could mean the download failed or that the configuration in the file is the same as the configuration in the unit.

  • Page 72: Configuration Files Encryption

    Configuration File Download Configuration Files Encryption You can secure the exchange of configuration files between the server and the Mediatrix 1204. A privacy key allows the unit to decrypt a previously encrypted configuration file. To encrypt a configuration file (generic or specific), you must use the MxCryptFile application. MxCryptFile is a command line tool that encrypts files before sending them to the Mediatrix 1204 unit.

  • Page 73: Configuration Download Procedure

    Configuration File Download” on page Initiate the configuration file download by setting the System Command drop-down menu of the System – Admin Web Page to updateConfiguration. The Mediatrix 1204 immediately downloads the configuration files. See “System Management” on page 33 for more details on the system commands.

  • Page 74: Automatic Configuration Update

    Click Submit if you do not need to set other parameters. Automatic Update at a Specific Time Interval You can configure the Mediatrix 1204 to download new configuration files at a specific day and/or time. To set the automatic update at a specific time interval: Set the configuration file server host and port as defined in “Configuration File Server Settings”...
  • Page 75 14h00, then the second download two days later at the same hour, and so on. Available values are -1, and from 0 to 23. Entering -1 means that the time of the day at which the Mediatrix 1204 first downloads the configuration files is randomly selected.

  • Page 76: Error Handling

    Send a syslog warning message including the decrypted. A badly encrypted file location/name and the transfer server file is detected if the header or address: the padding is invalid. The fetched configuration file \”%s\”, from server \”%s\”, can not be decrypted. Mediatrix 1204...
  • Page 77 Received a 404 Not Found from Send a syslog warning message including the the HTTP server. file location/name with the HTTP server address: The configuration file “XXX” was not found on the HTTP server “XXX”. Set sysAdminDownloadConfigFileStatus to fail. Mediatrix 1204...
  • Page 78 401 and 404) from the file location/name with the HTTP server HTTP server. address and port: Error in the HTTP transfer of the configuration file “XXX” from host “XXX” and port number XXX. Set sysAdminDownloadConfigFileStatus to fail. Mediatrix 1204...

  • Page 79: Firmware Download

    Transfer Protocol) server running on the PC designated as the firmware file server. This PC must not have a firewall running. Mediatrix also recommends to place the PC and the Mediatrix 1204 in the same subnet. It is assumed that you know how to set the TFTP root path. If not, refer to your TFTP server’s documentation.

  • Page 80: Firmware Servers Configuration

    Firmware Download Firmware Servers Configuration The Mediatrix 1204 must know the IP address and port number of its Primary and Secondary firmware servers. These servers contain the files required for the firmware update. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself.

  • Page 81: Setting Up The Firmware Download

    The Mediatrix 1204 first downloads a file called “setup.inf”. This file contains the list of all the other files to download, depending on the product. The “setup.inf” file and all the other files must be in the same directory.
  • Page 82 This is the location of the “setup.inf” file that contains the list of the files to download into the Mediatrix 1204. The “setup.inf” file and all the other files must be in the same directory. In other words, this is the path from the root TFTP/HTTP folder down to the files extracted from the zip file.
  • Page 83 Cut and paste the path and/or name of the directory that contains the extracted files into the image path of the Mediatrix 1204 (you may have to convert “\” into “/”) to eliminate typographical errors. Note that you can define the C:/Root/Download part as you want. The file names may also differ from the example shown above.
  • Page 84 When receiving HTTP response #500 or #501. HTTP image transfer of file: xxx from host: xxx was refused because of a server error. Warning When receiving HTTP response #503. HTTP image transfer of file: xxx from host: xxx was refused because service is unavailable. Mediatrix 1204...

  • Page 85: Firmware Download Procedure

    Image transfer. Access to file: xxx on host: xxx is unauthorized response #401. LED States When the Mediatrix 1204 initiates a firmware download, the LEDs located on the front panel indicate the status of the process. Table 41: LED States in Firmware Download Event...

  • Page 86: Automatic Firmware Update

    Mediatrix 1204 may experience momentary loss of Internet connectivity. Automatic Firmware Update You can configure the Mediatrix 1204 to automatically update its firmware. This update can be done: Every time the Mediatrix 1204 restarts. At a specific time interval you can define.
  • Page 87 Click Submit if you do not need to set other parameters. Automatic Update at a Specific Time Interval You can configure the Mediatrix 1204 to download a new firmware at a specific day and/or time. To set the automatic update at a specific time interval: If not already done, setup the Image server used to download the firmware (see “Before...

  • Page 88: Spanning Tree Protocol (Stp)

    14h00, then the second download two days later at the same hour, and so on. Available values are -1, and from 0 to 23. Entering -1 means that the time of the day at which the Mediatrix 1204 first downloads the firmware is randomly selected.

  • Page 89: Firmware Downgrade

    Reference Manual (SIP Version) In this case, the Mediatrix 1204 tries to contact the primary image server. As it is not available, the Mediatrix 1204 retries for two minutes. It contacts the secondary server after that period and starts the firmware download.
  • Page 90 Chapter 3 - Web Interface – Management Firmware Download If the emergency firmware download still fails, the Mediatrix 1204 tries to initiate the firmware download again by doubling the delay between each attempt up to a maximum of 16 minutes: •...

  • Page 91: Web Interface - Sip Parameters

    H A P T E R Web Interface – SIP Parameters The SIP page allows you to configure the various SIP-related parameters of the Mediatrix 1204: General SIP configuration parameters SIP Interop parameters Security parameters SIP Servers Configuration Standards Supported •...

  • Page 92: Sip Configuration

    SIP Servers Configuration SIP Configuration The Mediatrix 1204 must know the IP address and port number of the SIP servers. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself. You can also set these parameters via SNMP, as described in “Chapter 9 - SIP Servers”...

  • Page 93: Sip User Agent

    A user agent is a logical entity that can act as both client and server for the duration of a dialog. Each line (also known as endpoint) of the Mediatrix 1204 is a user agent. You can set information for each user agent such as its telephone number and friendly name. This information is used to dynamically create the To, From and Contact headers used in the request the user agent sends.

  • Page 94: Sip Publication

    When a host is in the penalty box, it is never used to try to connect to a remote host unless it is the last choice for the Mediatrix 1204 and there are no more options to try after this host.
  • Page 95 The Mediatrix 1204 skips over UDP and tries the next target, which is TCP. Again, TCP is still in the penalty box, but this time, it is the last target the Mediatrix 1204 can try, so penalty box or not, TCP is used all the same to try to contact endpoint “B”.

  • Page 96: Sip Transport Type

    RFC 3261 – SIP: Session Initiation Protocol You can globally set the transport type for all the lines of the Mediatrix 1204 to either UDP (User Datagram Protocol) or TCP (Transmission Control Protocol). The Mediatrix 1204 will include its supported transports in its registrations.

  • Page 97: Sip Authentication

    Standards Supported Basic and Digest authentication as per RFC 3261 Authentication information allows you to add some level of security to the Mediatrix 1204 lines by setting user names and passwords. You can also set these parameters via SNMP, as described in “Authentication”...
  • Page 98 Chapter 4 - Web Interface – SIP Parameters SIP Authentication Mediatrix 1204...

  • Page 99: Web Interface - Telephony

    Shortcut to local number at other corporate sites 91xxxxxxxxxx Long distance numbers 9011 + up to 15 digits International number The solution to this problem is to load the Mediatrix 1204 with a digit map that corresponds to the dial plan. Mediatrix 1204...

  • Page 100: Special Characters

    Chapter 5 - Web Interface – Telephony Digit Maps A Mediatrix 1204 that detects digits or timers applies the current dial string to the digit map, attempting a match to each regular expression in the digit map in lexical order.
  • Page 101 It indicates that if users have not dialed a digit for the time defined, it is likely that they have finished dialing and the Mediatrix 1204 can make the call. A digit map for this could be:...

  • Page 102: General Parameters

    The timer starts when the dial tone is played. When the timer expires, the receiver off-hook tone is played. This value is expressed in milliseconds (ms). Values range from 1000 ms to 180000 ms. Click Submit if you do not need to set other parameters. Mediatrix 1204...

  • Page 103: Allowed Digit Maps

    Reference Manual (SIP Version) Allowed Digit Maps You can create/edit ten digit maps for the Mediatrix 1204. Digit map rules are checked sequentially. If a telephone number potentially matches two of the rules, the first rule encountered is applied. To set up digit maps: In the Allowed Digit Map section –...

  • Page 104: Blocked Digit Maps

    Blocked Digit Maps A blocked digit map forbids to call specific numbers; for instance, you want to accept all 1-8xx numbers except 1-801. You can create/edit ten blocked digit maps for the Mediatrix 1204. To set up blocked digit maps: In the Blocked Digit Map section –...

  • Page 105: Fxo Port

    The dial prefix is a DTMF sequence to dial on the SCN before dialing the destination phone number. For instance, this allows to configure the Mediatrix 1204 in offices that require to dial a specific digit such as “9” before receiving a dial tone.

  • Page 106: Voice & Fax Codecs

    Voice & Fax Codecs Voice & Fax Codecs The four lines of the Mediatrix 1204 can simultaneously use the same codec (for instance, G.711 PCMA), or a mix of any of the supported codecs. Set and enable these codecs for each line.
  • Page 107 The Mediatrix 1204 cannot use G.723 and G.726 at the same time due to memory size limitation. You must restart the Mediatrix 1204 when enabling or disabling these two codecs. If both G.723 and G.726 are enabled when you restart the Mediatrix 1204, G.723 is the codec used.

  • Page 108: General Parameters

    Chapter 5 - Web Interface – Telephony Voice & Fax Codecs The Mediatrix 1204 supports G.729A and G.729AB for encoding and G.729, G.729A and G.729AB for decoding. Table 51: G.729 Features Feature Description Packetization time Range of 10 ms to 100 ms with increment of 10 ms. See “G.729 Codec...
  • Page 109 The jitter buffer allows better protection against packet loss, but increases the voice delay. If the network to which the Mediatrix 1204 is connected suffers from a high level of congestion, the jitter buffer protection level should be higher. If the network to which the Mediatrix 1204 is connected suffers from a low level of congestion, the jitter buffer protection level should be lower.
  • Page 110 Set the RTP Base Port field with the port number you want to use as RTP/RTCP base port. The RTP/RTCP ports are allocated starting from the base port. The Mediatrix 1204 may use two or four RTP/RTCP ports for each FXS interface: •...

  • Page 111: G.711 Codec Parameters

    Enable the G.711 Voice Activity Detection (VAD) by selecting Enable in the G.711 VAD choice. VAD defines how the Mediatrix 1204 sends information pertaining to silence. This allows the unit to detect when the user talks, thus avoiding to send silent RTP packets. This saves on network resources.

  • Page 112: Codec Parameters

    Enable the G.729 Voice Activity Detection (VAD) by selecting Enable in the G.729 VAD choice. VAD defines how the Mediatrix 1204 sends information pertaining to silence. This allows the unit to detect when the user talks, thus avoiding to send silent RTP packets. This saves on network resources.

  • Page 113: G.723 Codec Parameters

    The Mediatrix 1204 cannot use G.723 and G.726 at the same time due to memory size limitation. You must restart the Mediatrix 1204 when enabling or disabling these two codecs. If both G.723 and G.726 are enabled when you restart the Mediatrix 1204, G.723 is the codec used.

  • Page 114: Fax Parameters

    Upon fax termination, if the call is not BYE, the previous voice codec is recovered with another re- INVITE. All lines of the Mediatrix 1204 can simultaneously use the same codec (for instance, T.38), or a mix of any of the supported codecs. Set and enable these codecs for each line.
  • Page 115 The Mediatrix 1204 can send faxes in T.38 mode over UDP or TCP. T.38 is used for fax if both units are T.38 capable; otherwise, transmission in clear channel over G.711 as defined is used (if G.711 µ-law and/or G.711 A-law are enabled).
  • Page 116 For additional reliability, define the number of times T.38 packets are retransmitted in the T.38 Final Frames Redundancy field. This only applies to the T.38 packets where the PrimaryUDPTL contains the following T.38 data type: • HDLC_SIG_END, • HDLC_FCS_OK_SIG_END, Mediatrix 1204...

  • Page 117: Miscellaneous

    The Misc sub-page of the Telephony page allows you to configure the country in which the unit is located. Country Selection It is very important to set the country in which the Mediatrix 1204 is used because a number of parameter values are set according to this choice. These parameters are:...
  • Page 118 Caller ID Country Selection field Mapping British Telecom Bellcore uk-bellcore uk-cca ETSI-FSK uk-etsi-fsk Bellcore france France ETSI-FSK france-etsi-fsk ETSI-DTMF france-etsi-dtmf Bellcore austria1 Austria1 ETSI-FSK austria-etsi-fsk Bellcore austria2 Austria2 ETSI-FSK austria2-etsi-fsk “Caller ID Information” on page 149 for more details. Mediatrix 1204...

  • Page 119: Web Interface - Advanced

    H A P T E R Web Interface – Advanced The Advanced page allows you to configure various system and network parameters of the Mediatrix 1204. Quality of Service (QoS) QoS (Quality of Service) features enable network managers to decide on packet priority queuing. The Mediatrix 1204 supports the Differentiated Services (DS) field and 802.1q taggings.
  • Page 120 Enable this option only on compatible LAN with equipment supporting the VLAN tagging. Otherwise, the Mediatrix 1204 may be unreachable. In this case, use the Default Settings button to access and disable VLAN tagging – in the recovery mode, tagging is not permitted.
  • Page 121 When the filter for signalling protocol is disabled and the VLAN option is enabled, the Mediatrix 1204 uses the default user priority defined in the VLAN Default Priority field. Otherwise, the user priority set for signalling has precedence over the VLAN default user priority.

  • Page 122: Diffserv Configuration

    RFC 3168 now defines the state in which to set the two least significant bits in the TOS byte. On the other hand, this RFC only applies to TCP transmissions and the bits are thus set to “0” in the Mediatrix 1204.

  • Page 123: Emergency Page

    73). Dialing this digit map does not have any effect unless the service's status is “enabled”. The activating sequence is set for all the lines of the Mediatrix 1204. You cannot have different sequences for each line. Mediatrix 1204...

  • Page 124: Stun Configuration

    For a unit to work properly behind a firewall, it must keep a pinhole opened by sending keepalive packets through the firewall. The Mediatrix 1204 only sends keepalive packets to the last destination for a specific socket. When a unit is not configured with an outbound proxy, it can send, through its SIP socket, messages to various destinations, such as a SIP redirect server, another SIP unit, or a MWI server.

  • Page 125: Stun Client Configuration

    Reference Manual (SIP Version) STUN Client Configuration The STUN sub-page of the Advanced page allows you to configure the STUN client of the Mediatrix 1204. You can also set these parameters via SNMP, as described in “Chapter 19 - STUN Configuration” on page 237.

  • Page 126: Sip Custom Nat Traversal

    SIP Custom NAT Traversal The Mediatrix 1204 may be used in a private domain that is not directly connected to the IP network. For instance, this may be the case for ITSP (Internet Telephony Service Provider) clients that have a small private network.

  • Page 127: Snmp Configuration

    SNMP Configuration...
  • Page 128 Page Left Intentionally Blank...

  • Page 129: Mib Structure And Snmp

    H A P T E R MIB Structure and SNMP This chapter describes how the Mediatrix 1204 uses the SNMP protocol for its configuration. SNMP Overview The Mediatrix 1204 uses the Simple Network Management Protocol (SNMP) for initial software configuration provisioning and subsequent software configuration.

  • Page 130: Snmp Versions

    Chapter 7 - MIB Structure and SNMP SNMP Overview SNMP Versions The Mediatrix 1204 supports three versions of SNMP: SNMPv1, SNMPv2c and SNMPv3. SNMP defines a few types of messages that are exchanged between the manager and agent. SNMPv1 Messages The following messages are specific to SNMPv1.

  • Page 131: Snmp Behaviour

    Always exercise great caution when changing your password or encryption key. Note that you can use the factory reset to clear the SNMPv3 password. See “Factory Reset” on page 21 for more details. See also the Unit Manager Network Administration Manual. Mediatrix 1204...

  • Page 132: Snmpv3 Special Behaviour

    In this case, you should manually disable SNMPv1 / SNMPv2 so that SNMPv3 works properly. The Mediatrix 1204 thus refuses any SNMPv1 or SNMPv2 request it receives. You can disable / enable SNMPv1 / SNMPv2 by using the MIB Browser included in the Mediatrix Unit Manager Network (or any other MIB Browser) to modify the permissions related to SNMPv1 / SNMPv2 (security model).

  • Page 133: Snmp Configuration Via A Configuration File

    The vacmContextTable is not saved under any condition. SNMP Configuration via a Configuration File You can modify the SNMP configuration of the Mediatrix 1204 by inserting an SNMP Agent section in a configuration file and then transferring this configuration file into the unit. This configuration replaces any configuration set in a profile.
  • Page 134 <vacmGroupName ValueType="OCTET_STRING" Value="AuthNoPrivGrp"/> <vacmSecurityToGroupStorageType ValueType="UINT32" Value="4"/> <vacmSecurityToGroupStatus ValueType="UINT32" Value="1"/> </g> <h> <vacmSecurityModel ValueType="UINT32" Value="3"/> <vacmSecurityName ValueType="OCTET_STRING" Value="NoAuthNoPrivUser"/> <vacmGroupName ValueType="OCTET_STRING" Value="NoAuthNoPrivGrp"/> <vacmSecurityToGroupStorageType ValueType="UINT32" Value="4"/> <vacmSecurityToGroupStatus ValueType="UINT32" Value="1"/> </h> </vacmSecurityToGroupTable> <vacmAccessTable> <a> <vacmAccessContextPrefix ValueType="OCTET_STRING" Value="AuthPrivGrp"/> <vacmAccessSecurityModel ValueType="UINT32" Value="3"/> <vacmAccessSecurityLevel ValueType="UINT32" Value="3"/> Mediatrix 1204...
  • Page 135 <vacmAccessContextPrefix ValueType="OCTET_STRING" Value="Snmpv2cRWPrivateGrp"/> <vacmAccessSecurityModel ValueType="UINT32" Value="2"/> <vacmAccessSecurityLevel ValueType="UINT32" Value="1"/> <vacmAccessContextMatch ValueType="UINT32" Value="1"/> <vacmAccessReadViewName ValueType="OCTET_STRING" Value="PublicView"/> Enable/Disable SNMPv2 <vacmAccessWriteViewName ValueType="OCTET_STRING" Value="PublicView"/> Enable/Disable SNMPv2 <vacmAccessNotifyViewName ValueType="OCTET_STRING" Value="PrivateView"/> <vacmAccessStorageType ValueType="UINT32" Value="4"/> <vacmAccessStatus ValueType="UINT32" Value="1"/> </g> </vacmAccessTable> </vacmMIBObjects> </snmpVacmMIB> </snmpModules> </snmpV2> </SnmpAgentConfig> Mediatrix 1204...
  • Page 136 The SNMP Agent section provides default Mediatrix credentials for SNMPv3. You can change these credentials. To change SNMPv3 credentials: Change the password in the following fields: • usmUserAuthPassword (section Md5DesUser) • usmUserPrivPassword (section Md5DesUser) • usmUserAuthPassword (section ShaDesUser) • usmUserPrivPassword (section ShaDesUser) Mediatrix 1204...

  • Page 137: Mib Structure

    All parameters in the MIBs have been configured by default upon start up. However, if you need to modify some of these parameters (for example, parameters related to the country in which you are), use a MIB browser. Mediatrix 1204...

  • Page 138: Textual Conventions

    Event An event is sent to tell what type of data will be received, but not the data itself. This is used to “warn” in advance what is coming. Mediatrix 1204...

  • Page 139: Ip Addresses

    The Mediatrix 1204 software parameters are fully programmable by using the SNMP protocol. There are two ways to set up and configure a unit: By using a SNMP browser to contact the MIBs of the Mediatrix 1204. It is assumed that you have basic knowledge of TCP/IP network administration.

  • Page 140: Tables

    Voice FXS Voice FXS Voice FXS Voice FXS (24) Figure 54 shows a table built in the Unit Manager Network from the voiceifTable parameters. Figure 54: voiceIftable Example You can perform GET and SET operations on these parameters. Mediatrix 1204...

  • Page 141: Variables For Administrative Commands

    The usage state of the current interface. It indicates the running state of a voice component. Available states are idle, active, busy, and idle-unusable. ifAdminParentType The parents type of this interface. ifAdminParent The index of the parent of this interface. Mediatrix 1204...

  • Page 142: Snmp Service Agent

    • disable: SNMP connections are forbidden. If you are exclusively using the web page to configure the Mediatrix 1204, you could disable the SNMP service agent and forbid any SNMP connection to the unit. If the SNMP agent is disabled and the unit enters into recovery mode, SNMP connections are allowed during that time.

  • Page 143: Ip Address And Network Configuration

    The Mediatrix 1204 must be provisioned with various IP addresses and network parameters to be fully functional. This occurs each time the Mediatrix 1204 is started or when an IP address value is changed in the MIB. The Mediatrix 1204 can use static network parameters as well as parameters provided by a DHCP server or even a DNS.

  • Page 144: Provisioning Source

    Description Static You manually enter the value and it remains the same every time the Mediatrix 1204 restarts. If you do not specify a value, a default static value applies. DHCP The value is obtained at start-time by querying a DHCP server and using standard DHCP fields or options.

  • Page 145: Services

    Dial “*#*0” and listen for the IP address that is given. Static Configuration Using static IP addresses allows you to bypass the DHCP server or still be able to use the Mediatrix 1204 if you are not running a DHCP server.

  • Page 146: Local Host

    The ipAddressConfigLocalHost group allows you to set the IP information the Mediatrix 1204 needs to work properly. This group is vital to the proper operation of the Mediatrix 1204. If a variable of this group is not properly set, the Mediatrix 1204 may not be able to restart and be contacted after it has restarted.
  • Page 147 In the Unit Manager Network Administration Manual, refer to chapter Working with SNMP, section Setting Unit SNMP Preferences. The Mediatrix 1204 uses the SNMP protocol for software configuration. Set the following SNMP-related variable to properly use the protocol. Table 68: SNMP Configuration Variables...

  • Page 148: Static Dns

    Chapter 8 - IP Address and Network Configuration Services Static DNS By default, the Mediatrix 1204 receives DNS IP addresses according to the configuration source you have defined in the localHostSelectConfigSource variable. In general, these addresses are provided by an ISP (Internet Service Provider) via DHCP.

  • Page 149: Image

    The ipAddressConfigImage group provides the configuration necessary to download applications into the Mediatrix 1204. This includes emergency downloads in case of repetitive failure to start the main application. In the Unit Manager Network Administration Manual, refer to chapter Administration Parameters, section Software and Emergency Download.

  • Page 150: Management Server

    Note: If you change the value of the msStaticTrapPort variable, change the port used in the management server. Not doing so will prevent you from viewing the received traps from the unit. Mediatrix 1204...

  • Page 151: Configuration File Fetching

    StaticHost configFileFetching Static Port Restart the Mediatrix 1204 so that the changes may take effect. Syslog The ipAddressConfigSyslog group provides the configuration necessary for contacting a Syslog server. In the Unit Manager Network Administration Manual, refer to chapter Administration Parameters, section Syslog Daemon.

  • Page 152: Sip Servers

    If not specified (0), use option 43, sub-option 203, bytes 0-3. sipRegistrarPort Use option specified in variable sipRegistrarDhcpSiteSpecificCode, bytes 4-5. If not specified (0), use option 43, sub-option 203, bytes 4-5. If bytes 4-5 are not present, use the default static value. Mediatrix 1204...

  • Page 153: Sntp

    DHCP server already has options that can be set to provide time server addresses, and the order in which clients use them to attempt to discover servers. The Mediatrix 1204 uses Option 42 to specify the IP address corresponding to the server that provides NTP/ SNTP (RFC 1769).

  • Page 154: Dhcp Configuration

    Many network switches use the Spanning Tree Protocol (STP) to manage Ethernet ports activity. If the Mediatrix 1204 is connected to such a switch, the switch may shut down the matching Ethernet port for at least one minute. This shutdown on the switch side can prevent proper communication. It may thus take up to three minutes before the unit receives an answer to its request for DHCP options.

  • Page 155: Changing The Size Of Dhcp Requests

    4 seconds delay seventh request: 8 seconds delay etc. The Mediatrix 1204 stops broadcasting as soon as it receives at least one reply. If the offer is valid, the Mediatrix 1204 takes it and continues its initialization procedure. Note: If the localHostSelectConfigSource variable is set to static and any other xxSelectConfigSource variable is set to dhcp, the Mediatrix 1204 makes its DHCP request that will be released immediately.

  • Page 156: Network Configuration

    Data Data Data … Figure 56: Layout for Encapsulated Vendor Specific Options Code1 Len1 Data1 Data1 … Code2 Len2 Data2 Data2 … Figure 57 is an example of a vendor specific option containing an msHost IP address (192.168.1.2). Mediatrix 1204...

  • Page 157: Site Specific Options

    Vendor Class ID When using the vendor specific option, first define a Vendor Class ID for the Mediatrix 1204 (not supported in Windows NT servers). A Vendor Class ID can be used by DHCP clients to identify their vendor type and configuration.

  • Page 158: Option Codes

    The vendor specific options must be encapsulated because more than one information can be stored in this option: [code][length][4-6 bytes address][another code][another length][another address]... The site specific options can have only one information per option: [4-6 bytes address] The DHCP server adds the proper code and length in the packet it sends out. Mediatrix 1204...

  • Page 159: Settings Example

    Option 43 (vendor specific option) contains the hexadecimal sequence 0xC80x40xA0x30x20xC9 inserted among other sequences. Table 81: Hexadecimal Sequence - Option 43 Hexadecimal Part Corresponding Information 0xC8 code 200 (management server) size of 4 bytes 0xA0x30x20xC9 IP address 10.3.2.201 Mediatrix 1204...

  • Page 160: Error Handling

    This assumes that the Mediatrix 1204 is set to get its IP information via a DHCP server. If the Mediatrix 1204 is configured to request some DHCP options but does not require an IP address from the server, the amount of time it will wait for an answer before proceeding further is configurable as defined in “Appendix - DHCP Options Waiting Time”...

  • Page 161: Ethernet Connection Speed

    This protocol can only detect the connection speed; the duplex mode cannot be detected. In this case, the connection may not be established. The Mediatrix 1204 has the possibility to force the desired Ethernet link speed and duplex mode by disabling the auto-negotiation and selecting the proper setting (sysConfigNetworkEthernetSpeed variable). When forcing a link speed at one end, be sure that the other end (a hub, switch, etc.) has the same configuration.
  • Page 162 Chapter 8 - IP Address and Network Configuration Ethernet Connection Speed Mediatrix 1204...

  • Page 163: Chapter 9 Sip Servers

    SIP Configuration Window. Configuration Source The Mediatrix 1204 must know the IP address and port number of the proxy server. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself with the static variables.
  • Page 164 To use static information: In the ipAddressConfig folder, locate the sipServerSelectConfigSource variable (under the ipAddressConfigSipServer group). This variable defines whether or not the Mediatrix 1204 must get its proxy server configuration through a DHCP server. Set the sipServerSelectConfigSource variable to static.

  • Page 165: Outbound Proxy Server

    0.0.0.0. Configuration Source The Mediatrix 1204 must know the IP address and port number of the outbound proxy. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself with the static variables.
  • Page 166 To use static information: In the ipAddressConfig folder, locate the sipServerSelectConfigSource variable (under the ipAddressConfigSipServer group). This variable defines whether or not the Mediatrix 1204 must ask for its outbound proxy settings through a DHCP server. Set the sipServerSelectConfigSource variable to static.

  • Page 167: Loose Router Configuration

    (section 6) for processing of the Route header field. These procedures separate the destination of the request (present in the Request-URI) from the set of proxies that need to be visited along the way (present in the Route header field). A proxy compliant to these mechanisms is also known as a loose router. Mediatrix 1204...

  • Page 168: Presence Compositor Server

    MIB is 0.0.0.0. Configuration Source The Mediatrix 1204 must know the IP address and port number of the Presence Compositor server. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself with the static variables.
  • Page 169 To use static information: In the ipAddressConfig folder, locate the sipServerSelectConfigSource variable (under the ipAddressConfigSipServer group). This variable defines whether or not the Mediatrix 1204 must get its Presence Compositor server configuration through a DHCP server. Set the sipServerSelectConfigSource variable to static.
  • Page 170 Chapter 9 - SIP Servers Presence Compositor Server Mediatrix 1204...

  • Page 171: Chapter 10 Dns Srv Configuration

    H A P T E R DNS SRV Configuration This chapter describes the configuration required for the Mediatrix 1204 to work with a DNS SRV. What is a DNS SRV? Standards Supported • RFC 2782 – A DNS RR for specifying the location of services (DNS SRV) •...

  • Page 172: Dns Srv Call Flow

    To enable DNS SRV: In the ipAddressConfig folder, locate the sipServerSelectConfigSource variable (under the ipAddressConfigSipServer group). This variable defines whether the Mediatrix 1204 must get its proxy server configuration through a DHCP server or not. Set the sipServerSelectConfigSource variable to static.

  • Page 173: Dns Srv Record Lock

    DNS SRV Record Lock You can configure the Mediatrix 1204 to always use the same DNS SRV record for a SIP call ID. As a result, a call or registration always uses the same destination until the destination is unreachable or the unit receives a different DNS SRV result.
  • Page 174 Chapter 10 - DNS SRV Configuration DNS SRV-Oriented Settings Mediatrix 1204...

  • Page 175: Country-Specific Configuration

    Bellcore GR-30-CORE (Caller ID type 2 is not supported) ETSI 300 659-1 The Mediatrix 1204 detects a caller ID sent on the line by the CO (Central Office) if the following conditions are met: The caller ID must be generated according to a caller ID standard implementing Bell-202 or ITU-T V.23 voice band data transmission standards.

  • Page 176: Adsi

    Caller ID Detection Range The standard used to detect the caller ID on a Mediatrix 1204 requires that the full range of the signal (12 mV RMS to 476 mV RMS) be supported. Because of a limitation to the Mediatrix 1204, it cannot detect a caller ID signal on the whole range defined by the standard.

  • Page 177: Setting The Location (Country)

    Reference Manual (SIP Version) Setting the Location (Country) It is very important to set variables according to the country in which the Mediatrix 1204 is used because a number of parameter values are set according to this choice. These parameters are:...

  • Page 178: Caller Id Selection

    Mapping British Telecom Bellcore uk-bellcore uk-cca ETSI-FSK uk-etsi-fsk Bellcore france France ETSI-FSK france-etsi-fsk ETSI-DTMF france-etsi-dtmf Bellcore austria1 Austria 1 ETSI-FSK austria-etsi-fsk Austria 2 Bellcore austria2 ETSI-FSK austria2-etsi-fsk “Caller ID Information” on page 149 for more details. Mediatrix 1204...

  • Page 179: Configuration File Download

    Configuration File Download Server The service allows to download a unique file for each Mediatrix 1204, and/or a file shared among many units. These configuration files may be encrypted or not. You have the choice to perform the configuration file download by using the TFTP protocol or the HTTP protocol.
  • Page 180 To use DHCP-assigned information: In the ipAddressConfig folder, locate the configFileFetchingSelectConfigSource variable (under the ipAddressConfigFileFetching group). This variable defines whether the Mediatrix 1204 must ask for its configuration file server settings through a DHCP server or not. Set the configFileFetchingConfigSource variable to dhcp.

  • Page 181: Setting Up The Configuration File Download

    • Cut and paste the path and/or name of the directory that contains the extracted files into the configuration file path of the Mediatrix 1204 (you may have to convert “\” into “/ ”) to eliminate typographical errors. Note that you can define the C:/Root/Download part as you want. The file names may also differ from the example shown above.

  • Page 182: Configuration Update Status

    If valid configuration files are successfully downloaded, then the Mediatrix 1204 automatically restarts to apply all the new settings. If the Mediatrix 1204 does not restart, this could mean the download failed or that the configuration in the file is the same as the configuration in the unit.
  • Page 183 (e.g., because of bad OIDs). Informational A fetched configuration file was Parameter values defined in the configuration file \”%s\” were successfully applied. successfully applied. Informational All necessary fetched configuration files The unit is restarting to complete the configuration update. were successfully applied. Mediatrix 1204...

  • Page 184: Configuration Files Encryption

    Configuration File Download Server Configuration Files Encryption You can secure the exchange of configuration files between the server and the Mediatrix 1204. A privacy key allows the unit to decrypt a previously encrypted configuration file. This applies to files downloaded via TFTPor HTTP.

  • Page 185: Configuration Download Via Tftp

    In the configFileFetchingMIB, set the configFileTransferProtocol variable to tftp. In the groupAdminMIB, set the groupSetAdmin variable to ForceLock. All activities in progress on the Mediatrix 1204 are terminated immediately and the unit enters the maintenance mode (the value of the groupAdminState variable is “locked”). The configuration file download may take place.

  • Page 186: Configuration Download Via Http

    The password in the configFileTransferPassword variable. In the groupAdminMIB, set the groupSetAdmin variable to ForceLock. All activities in progress on the Mediatrix 1204 are terminated immediately and the unit enters the maintenance mode (the value of the groupAdminState variable is “locked”). The configuration file download may take place.

  • Page 187: Automatic Configuration Update

    Configuration File Download Server Reference Manual (SIP Version) Automatic Configuration Update You can configure the Mediatrix 1204 to automatically update its configuration. This update can be done: Every time the Mediatrix 1204 restarts. At a specific time interval you can define.
  • Page 188 Configuration File Download Server Automatic Update at a Specific Time Interval You can configure the Mediatrix 1204 to download new configuration files at a specific day and/or time. To set the automatic update at a specific time interval: Set the configuration file server host and port as defined in “Configuration File Server Settings”...

  • Page 189: Error Handling

    14h00, then the second download two days later at the same hour, and so on. Available values are -1, and from 0 to 23. Setting the variable to -1 means that the time of the day at which the Mediatrix 1204 first downloads the configuration files is randomly selected.
  • Page 190 “XXX” and port number XXX. Set sysAdminDownloadConfigFileStatus to fail. File size too big Downloading a file with a size Abort the transfer by sending error code 3 (disk exceeding 512000 bytes. full or allocation exceeded) to the TFTP client. Mediatrix 1204...
  • Page 191 401 and 404) from the file location/name with the HTTP server HTTP server. address and port: Error in the HTTP transfer of the configuration file “XXX” from host “XXX” and port number XXX. Set sysAdminDownloadConfigFileStatus to fail. Mediatrix 1204...

  • Page 192: Management Server

    Chapter 12 - Configuration File Download Management Server Management Server You can set the Mediatrix 1204 so that it asks the management server to send it a configuration file. Note: Downloading a configuration file from the management server can only be performed through the TFTP protocol.

  • Page 193: Error Handling

    Committing a file with an invalid Send a syslog warning message including the format. file name and the TFTP client address: The configuration file “XXX” pushed to the unit by the TFTP client “XXX” has an invalid format. No recorded settings applied. Mediatrix 1204...

  • Page 194: Syslog Messages

    Restarting the unit... Warning No parameter value from the downloaded None of the parameter values defined in the configuration file configuration file was successfully applied (e.g., was successfully committed. because of bad OIDs). Mediatrix 1204...

  • Page 195: Configuration File Example

    123 {, open curly bracket <, less than \, backslash 124 |, vertical bar =, equals ], close square bracket 125 }, close curly bracket 126 ~, tilde All other ASCII codes will result in an invalid configuration file. Mediatrix 1204...
  • Page 196 Chapter 12 - Configuration File Download Configuration File Example Mediatrix 1204...

  • Page 197: Chapter 13 Software Download

    Transfer Protocol) server running on the PC designated as the software file server. This PC must not have a firewall running. Mediatrix also recommends to place the PC and the Mediatrix 1204 in the same subnet. It is assumed that you know how to set the TFTP root path. If not, refer to your TFTP server’s documentation.

  • Page 198: Software Servers Configuration

    Software Servers Configuration Software Servers Configuration The Mediatrix 1204 must know the IP address and port number of its Primary and Secondary software servers. These servers contain the files required for the software update. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself in static variables.

  • Page 199: Static Configuration

    Use the static configuration if you are not using a DHCP server or if you want to bypass it. To use static information: In the ipAddressConfig folder, locate the imageSelectConfigSource variable. This variable defines whether the Mediatrix 1204 must ask for its Image server settings through a DHCP server or not. Set the imageSelectConfigSource variable to static.

  • Page 200: Download Procedure

    The Mediatrix 1204 first downloads a file called “setup.inf”. This file contains the list of all the other files to download, depending on the product. The “setup.inf” file and all the other files must be in the same directory.
  • Page 201 This is the location of the “setup.inf” file that contains the list of the files to download into the Mediatrix 1204. The “setup.inf” file and all the other files must be in the same directory. In other words, this is the path from the root TFTP/HTTP folder down to the files extracted from the zip file.

  • Page 202: Software Download Status

    You can validate the status of the software download in various ways. Syslog Messages If you are using a Syslog daemon, you will receive messages that inform you of the software update status. The following are the syslog messages the Mediatrix 1204 sends: Table 109: Software Update Syslog Messages Level...
  • Page 203 Image transfer. Access to file: xxx on host: xxx is unauthorized response #401. LED States When the Mediatrix 1204 initiates a software download, the LEDs located on the front panel indicate the status of the process. Table 110: LED States in Software Download Event...

  • Page 204: Download Via Tftp

    Set the imageTransferProtocol variable to tftp. Set the groupSetAdmin variable (in the groupAdminMIB) to ForceLock. All activities in progress on the Mediatrix 1204 are terminated immediately and the unit enters the maintenance mode (the value of the groupAdminState variable is “locked”). The software upgrade may take place.

  • Page 205: Download Via Http

    The password in the imageTransferPassword variable. Set the groupSetAdmin variable (in the groupAdminMIB) to ForceLock. All activities in progress on the Mediatrix 1204 are terminated immediately and the unit enters the maintenance mode (the value of the groupAdminState variable is “locked”). The software upgrade may take place.

  • Page 206: Automatic Software Update

    Chapter 13 - Software Download Download Procedure Automatic Software Update You can configure the Mediatrix 1204 to automatically update its software version. This update can be done: Every time the Mediatrix 1204 restarts. At a specific time interval you can define.
  • Page 207 Reference Manual (SIP Version) Automatic Update at a Specific Time Interval You can configure the Mediatrix 1204 to download a software version at a specific day and/or time. To set the automatic update at a specific time interval: If not already done, setup the Image server used to download the software (see “Before...

  • Page 208: Spanning Tree Protocol (Stp)

    The secondary image server is up and running well. In this case, the Mediatrix 1204 tries to contact the primary image server. As it is not available, the Mediatrix 1204 retries for two minutes. It contacts the secondary server after that period and starts the software download.

  • Page 209: Software Downgrade

    Software Downgrade Reference Manual (SIP Version) Software Downgrade It is possible to downgrade a Mediatrix 1204 from the current version (for instance, v5.0rx.x) to an older version (for instance, v4.4rx.x). Note: If you perform a default reset on the Mediatrix 1204, you must download the current version into the unit before performing the software downgrade procedure.
  • Page 210 Chapter 13 - Software Download Emergency Software Procedure If the emergency software download still fails, the Mediatrix 1204 tries to initiate the software download again by doubling the delay between each attempt up to a maximum of 16 minutes: •...

  • Page 211: Gateway Configuration

    Restart the Mediatrix 1204 so that the changes may take effect. Dialing Settings Dialing settings allow you to configure how the Mediatrix 1204 dials numbers. These settings apply only to IP network to SCN calls. You can also set these parameters via the web interface, as described in “FXO Port”...

  • Page 212: Answering Delay

    Restart the Mediatrix 1204 so that the changes may take effect. Answering Delay The answering delay is the period the Mediatrix 1204 waits before answering an incoming SCN call. To configure the answering delay: In the fxoMIB, set the answering delay in the fxoPreAnswerDelay variable.

  • Page 213: Special Case: Automatic Call

    This mechanism helps to avoid collisions between incoming and outgoing SCN calls. When enabling the dial tone detection, the Mediatrix 1204 waits for a dial tone on the SCN before initiating the dialing sequence. If the unit does not detect a dial tone, it considers the line as busy with an incoming SCN call.

  • Page 214: Line Fault Detection

    440 Hz Set the dial tone detection timeout in the fxoDialtoneDetectionTimeout variable. This indicates how long the Mediatrix 1204 waits, in milliseconds (ms), for a dial tone before it considers the line is busy with an incoming SCN call. Restart the Mediatrix 1204 so that the changes may take effect.

  • Page 215: Detecting A Far End Disconnect

    Most PBXs/ACDs/COs offer the possibility to introduce a Current Drop as part of the far end disconnect signal. The Mediatrix 1204 will detect a Current Drop if this signal is maintained for at least 600 ms with an open circuit or has a current drop lower than 0.4 mA.

  • Page 216: Mediatrix 1204 Configuration

    The silence detection feature applies when two parties are in communication and one of them hangs up. It allows the Mediatrix 1204 to close a line when no voice activity or silence is detected for a specified amount of time.
  • Page 217 SCN side. • With the G.711 and G.726 codecs, activate the VAD feature of the remote IP device. The Mediatrix 1204 interprets lack of incoming packets as a period of silence and activates the silence detection feature. •...
  • Page 218 Restart the Mediatrix 1204 so that the changes may take effect. Forced End of Call on Far End Tone Detection The Mediatrix 1204 can monitor special tones that indicate the remote SCN user has hung up. You can use the default value for a selected country or customize a tone.
  • Page 219 Force end of call on tone detection is disabled. countryTone The Mediatrix 1204 tries to detect the tone specified for this purpose in the current country’s tone specification. Some country specifications omit this information. In that case, the unit behaves as if fxoFeocOnToneDetectionMode is “disable”.
  • Page 220 Chapter 14 - Gateway Configuration Detecting a Far End Disconnect Mediatrix 1204...

  • Page 221: Chapter 15 Line Configuration

    Temporary Administrative State You can set the administrative state of a line that will be kept until the Mediatrix 1204 restarts. Once the unit restarts, it uses the permanent state defined for each line. See “Permanent Administrative State”...

  • Page 222: Permanent Administrative State

    An algorithm allows to choose the line to use upon a new incoming call. Currently, there is only one group that contains all the FXO lines. Future versions of the Mediatrix 1204 will allow you to define additional groups.

  • Page 223: Examples Of Source Line Selection Use

    With such a configuration, a call made from line #2 of a Mediatrix 1104 is processed on line #2 of the Mediatrix 1204. On the other hand, if a caller from the SCN calls line #3 of the Mediatrix 1204, the call is automatically redirected to line #3 of the Mediatrix 1104.

  • Page 224: Line Selection Algorithm

    Line Selection Algorithm Upon receiving a call, you can define in which way the Mediatrix 1204 selects a line to distribute the call load across all lines. Before accepting to use a line, the Mediatrix 1204 must check the following: The line’s administrative status is idle.

  • Page 225: Chapter 16 Voice Transmissions

    Codec Descriptions The four lines of the Mediatrix 1204 can simultaneously use the same codec (for instance, G.711 PCMA), or a mix of any of the supported codecs. Set and enable these codecs for each line. Table 123: Codecs Comparison...
  • Page 226 The Mediatrix 1204 cannot use G.723 and G.726 at the same time due to memory size limitation. You must restart the Mediatrix 1204 when enabling or disabling these two codecs. If both G.723 and G.726 are enabled when you restart the Mediatrix 1204, G.723 is the codec used.

  • Page 227: Preferred Codec

    G.729 Annex A. A G.729 or G.729 Annex A frame contains 10 octets, while the G.729 Annex B comfort noise frame occupies 2 octets. The Mediatrix 1204 supports G.729A and G.729AB for encoding and G.729, G.729A and G.729AB for decoding.

  • Page 228: Enabling Individual Codecs

    The Mediatrix 1204 cannot use G.723 and G.726 at the same time due to memory size limitation. You must restart the Mediatrix 1204 when enabling or disabling these two codecs. If both G.723 and G.726 are enabled when you restart the Mediatrix 1204, G.723 is the codec used.

  • Page 229: Packetization Time

    Longest packetization period allowed for the 30, 60, 90, 120 G.723 codec. Authorized values go up to 120 ms, in discrete steps of 30 ms, and start at the one specified by the voiceIfCodecG723MinPTime variable. Default Value: 120 Mediatrix 1204...
  • Page 230 Longest packetization period allowed for the 10-100, with increments PTime G.726-40kbps codec. Authorized values go up of 10 to 100 ms, in discrete steps of 10 ms, and start at the one specified by the voiceIfCodecG72640kbpsMinPTime variable. Default Value: 100 Mediatrix 1204...

  • Page 231: Dtmf Transport Type

    DTMF sequence back by re- generating the true tones. Such a mechanism is known as out-of-band DTMF. The Mediatrix 1204 receives and sends out-of-band DTMFs as per RFC 2833 using RTP. DTMFs supported are 0-9, A-D, *, #.

  • Page 232: Dtmf Transport Using Sip Info

    When the feature is enabled: The Mediatrix 1204 sends a separate SIP INFO method every time a digit is entered during the call. The Mediatrix 1204 plays each DTMF sent in a separate message upon receiving a valid SIP INFO message.

  • Page 233: Dtmf Payload Type

    205), or the variable telephonyAttributesHookFlashProcessing to outOfBandUsingRtp (“Hook Flash Processing” on page 256), the Mediatrix 1204 will advertise the support for events 0-15; it will assume support for events 0-15 when support for RFC 2833 is received in an announcement. disable This creates a deliberate deviance to RFC 2833 as support of basic events is not automatic.

  • Page 234: Dtmf Transport Over The Sip Protocol

    Set an inter-digit dial delay in the analogScnGwInterDigitDial Delay variable. This is the delay, in milliseconds (ms), between two DTMFs when dialing the destination phone number. This is useful when the Mediatrix 1204 receives DTMFs out-of-band faster than it can signal them.

  • Page 235: Adaptative Jitter Buffer

    Mediatrix 1204 is connected suffers from a high level of congestion, the jitter buffer protection level should be higher. If the network to which the Mediatrix 1204 is connected suffers from a low level of congestion, the jitter buffer protection level should be lower.

  • Page 236: Voice Activity Detection

    Voice Activity Detection Voice Activity Detection The Voice Activity Detection (VAD) defines how the Mediatrix 1204 sends information pertaining to silence. This allows the unit to detect when the user talks, thus avoiding to send silent RTP packets. This saves on network resources.

  • Page 237: Echo Cancellation

    Table 135: G.729 VAD Settings Setting Description disable G.729 uses annex A only. The Mediatrix 1204 does not send G.729 Annex B comfort noise frames. enable G.729 annex A is used with annex B. The Mediatrix 1204 sends G.729 Annex B comfort noise frames during silence periods.

  • Page 238: User Gain

    You can compensate with the user gain if there is no available configuration for the country in which the Mediatrix 1204 is located. Because the user gain is in dB, you can easily adjust the loss plan (e.g., if you need an additional 1 dB for analog to digital, simply put 1 for user gain input).
  • Page 239 +3.00 dB Malaysia 0.00 dB +3.00 dB +3.00 dB North America1 0.00 dB +3.00 dB +3.00 dB Russia 0.00 dB +3.00 dB +3.00 dB Sweden +2.00 dB +2.75 dB +4.75 dB Thailand -3.50 dB +6.50 dB +3.00 dB Mediatrix 1204...
  • Page 240 Chapter 16 - Voice Transmissions User Gain Mediatrix 1204...

  • Page 241: Chapter 17 Fax Transmission

    Upon fax termination, if the call is not BYE, the previous voice codec is recovered with another re- INVITE. All lines of the Mediatrix 1204 can simultaneously use the same codec (for instance, T.38), or a mix of any of the supported codecs. Set and enable these codecs for each line.

  • Page 242: Clear Channel Fax

    Chapter 17 - Fax Transmission Clear Channel Fax Clear Channel Fax The Mediatrix 1204 can send faxes in clear channel. The following is a clear channel fax call flow: Figure 63: Clear Channel Fax Call Flow INVITE […] […] m=audio 5006 RTP/AVP 18 0 13...

  • Page 243: T.38 Fax

    The Mediatrix 1204 can send faxes in T.38 mode over UDP or TCP. T.38 is used for fax if both units are T.38 capable; otherwise, transmission in clear channel over G.711 as defined is used (if G.711 µ-law and/or G.711 A-law are enabled).

  • Page 244: T.38 No-Signal

    Restart the Mediatrix 1204 so that the changes may take effect. T.38 No-Signal You can set the Mediatrix 1204 to send no-signal packets during a T.38 fax transmission. The Mediatrix 1204 sends no-signal packets if no meaningful data have been sent for a user-specified period of time.

  • Page 245: Chapter 18 Sip Protocol Features

    A user agent is a logical entity that can act as both client and server for the duration of a dialog. Each line (also known as endpoint) of the Mediatrix 1204 is a user agent. You can set information for each user agent such as its telephone number and friendly name. This information is used to dynamically create the To, From and Contact headers used in the request the user agent sends.

  • Page 246: Sip User Agent Header

    User-Agent header could be something like the following: User-Agent: Softphone Beta1.5 You can specify if the Mediatrix 1204 sends this information or not when establishing a communication. To enable sending the SIP User Agent header: In the sipInteropMIB, set the sipInteropSendUAHeaderEnable variable to enable.

  • Page 247: Session Timer Version

    • draft-ietf-sip-session-timer-04.txt (expired) You can select the version of the session timer draft that the Mediatrix 1204 uses. Session timer versions other than those provisioned may not work because of backward compatibility issues between the versions. This feature is currently located under the mediatrixExperimental branch of the MIB structure. See “MIB...

  • Page 248: Authentication

    You can also set these parameters via the web interface, as described in “SIP Authentication” on page You can define up to five user names and five passwords for each group of the Mediatrix 1204. A group can thus register with five different realms. Keep in mind that:...

  • Page 249: Sip Trusted Sources

    SIP Trusted Sources You can configure the Mediatrix 1204 so that it only accepts SIP messages coming from one of six trusted IP addresses. All other SIP messages are ignored. This source address validation takes place at the IP level and does not depend on the SIP header or body.

  • Page 250: Nat System Configuration

    RFC 3261 – SIP: Session Initiation Protocol You can globally set the transport type for all the lines of the Mediatrix 1204 to either UDP (User Datagram Protocol) or TCP (Transmission Control Protocol). The Mediatrix 1204 will include its supported transports in its registrations.

  • Page 251: Transport Parameter

    UDP Source Port Behaviour You can configure if the Mediatrix 1204 always uses the same local port (the port on which it is listening for incoming packets) when sending SIP traffic over UDP. This is called symmetric UDP source port. Symmetric UDP ports are sometimes needed to traverse NAT/Firewall devices.

  • Page 252: Sip Penalty Box

    The Mediatrix 1204 skips over UDP and tries the next target, which is TCP. Again, TCP is still in the penalty box, but this time, it is the last target the Mediatrix 1204 can try, so penalty box or not, TCP is used all the same to try to contact endpoint “B”.

  • Page 253: Publication Parameters

    “expires” is a suggestion the entity makes. The “expires” parameter indicates how long, in seconds, the user agent would like the binding to be valid. You can configure the “expires” parameter the Mediatrix 1204 sends. To configure the publications expiration: In the sipMIB, set the sipPublicationProposedExpirationValue variable with the suggested expiration delay, in seconds, of a publication in the PUBLISH request.

  • Page 254: Default Publication Expiration

    This allows you to control how the Mediatrix 1204 interoperates with other vendor’s products and older Mediatrix units.
  • Page 255 REFER without Replaces to the Transferee. Note: A side effect is that the Mediatrix 1204 will release the line, then take it again. Note that the Mediatrix 1204 might not use the same line as before. This is a design flaw in the SIP transfer method, which is currently in the known issues of the SIPPING workgroup.

  • Page 256: Transmission Timeout

    RFC 3261 – SIP: Session Initiation Protocol If a DNS SRV answer contains more than one entry, the Mediatrix 1204 will try these entries if the entry initially selected does not work. You can configure the maximum time, in seconds, to spend waiting for answers to messages, from a single source.

  • Page 257: Referred-By Field

    RFC 3264 – An Offer/Answer Model with Session Description Protocol (SDP) The Mediatrix 1204 can provide the direction attribute and the meaning of the connection address “0.0.0.0” sent in the SDP when an endpoint is put on hold. To define the direction attribute when putting a call on hold: In the sipInteropMIB, set the sipInteropOnHoldSdpStreamDirection variable to the proper value.
  • Page 258 Protocol (SDP) You can define: if the SDP direction attribute is present in the initial INVITE sent by the Mediatrix 1204 if the direction attribute present in the SDP received from the peer is ignored or not To define if the direction attribute is present: In the sipInteropMIB, set the sipInteropSdpDirectionAttributeEnable variable to the proper value.

  • Page 259: Local Ring Behaviour On Provisional Response

    Reference Manual (SIP Version) Local Ring Behaviour on Provisional Response You can set the Mediatrix 1204 so that it starts or not the local ring upon receiving a “18x Provisional” response without SDP. This setting does not affect the behaviour when the “18x Provisional” response contains SDP, which allows to establish an early media session before the call is answered.

  • Page 260: Branch Parameter Settings

    The branch ID is used to facilitate its use as a transaction ID. It must always begin with the characters “z9hG4bK”. If this is not the case, the Mediatrix 1204 uses the branching method as described in RFC 3261, section 17.2.3.

  • Page 261: Unsupported Info Request

    Reference Manual (SIP Version) Unsupported INFO Request You can define the Mediatrix 1204’s behaviour upon reception of an unknown type of INFO request. To define the unsupported INFO request behaviour: In the sipInteropMIB, set the sipInteropAckUnsupportedInfoRequests variable with the proper behaviour.

  • Page 262: Offer/Answer Model

    RFC 3264 – An Offer/Answer Model with the Session Description Protocol (SDP) You can define whether the Mediatrix 1204 requires strict adherence to RFC 3264 from the peer when negotiating capabilities for the establishment of a media session. To define how to process the Offer/Answer model: In the sipExperimentalMIB, set the sipEnforceOfferAnswerModel variable to the proper value.

  • Page 263: Chapter 19 Stun Configuration

    For a unit to work properly behind a firewall, it must keep a pinhole opened by sending keepalive packets through the firewall. The Mediatrix 1204 only sends keepalive packets to the last destination for a specific socket. When a unit is not configured with an outbound proxy, it can send, through its SIP socket, messages to various destinations, such as a SIP redirect server, another SIP unit, or a MWI server.

  • Page 264: Stun Client Configuration

    Chapter 19 - STUN Configuration STUN Client Configuration STUN Client Configuration The following describes how to configure the Mediatrix 1204 STUN client via SNMP. You can also use the web interface to configure the STUN parameters. See “STUN Configuration” on page 98 for more details.

  • Page 265: Chapter 20 Sntp Settings

    Standards Supported RFC 1769 – Simple Network Time Protocol (SNTP) You must enable the SNTP client of the Mediatrix 1204 to properly connect to a a SNTP or NTP server. To enable the SNTP feature: In the sntpMIB, set the sntpEnable variable to enable.

  • Page 266: Configuration Source

    Configuration Source Configuration Source The Mediatrix 1204 must know the IP address and port number of the SNTP server. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself with the static variables.

  • Page 267: Defining A Custom Time Zone

    Greenwich Mean Time (GMT) format (also known as Universal Time Coordinated - UTC), so it needs to convert this GMT time into the proper time zone. To do this, the Mediatrix 1204 offers time zone configuration with daylight saving settings.

  • Page 268: Example

    Eastern Time Canada & US) EST5EDT4,M3.2.0/02:00:00,M11.1.0/02:00:00 Atlantic Time (Canada) AST4ADT3,M3.2.0/02:00:00,M11.1.0/02:00:00 GMT Standard Time GMT0DMT-1,M3.5.0/01:00:00,M10.5.0/02:00:00 W. Europe Standard Time WEST-1DWEST-2,M3.5.0/02:00:00,M10.5.0/03:00:00 China Standard Time CST-8 Tokyo Standard Time TST-9 Central Australia Standard Time CAUST-9:30DCAUST-10:30,M10.5.0/02:00:00,M3.5.0/02:00:00 Australia Eastern Standard Time AUSEST-10AUSDST-11,M10.5.0/02:00:00,M3.5.0/02:00:00 UTC (Coordinated Universal Time) UTC0 Mediatrix 1204...

  • Page 269: Chapter 21 Digit Maps

    Because the Mediatrix 1204 cannot predict how many digits it needs to accumulate before transmission, you could use the digit map, for instance, to determine exactly when there are enough digits entered from the user to place a call.

  • Page 270: Special Characters

    International number The solution to this problem is to load the Mediatrix 1204 with a digit map that corresponds to the dial plan. A Mediatrix 1204 that detects digits or timers applies the current dial string to the digit map, attempting a match to each regular expression in the digit map in lexical order.

  • Page 271: Combining Several Expressions

    It indicates that if users have not dialed a digit for the time defined, it is likely that they have finished dialing and the Mediatrix 1204 can make the call. A digit map for this could be:...

  • Page 272: Validating A Digit Map

    Setting up Digit Maps Validating a Digit Map The Mediatrix 1204 validates the digit map as you are entering it and it forbids any invalid value. Setting up Digit Maps The variables related to the digit maps are located in tables. You can create/edit ten digit maps for each Mediatrix 1204.

  • Page 273: Digit Maps Timeouts

    This digit map rule checks for calls outside the country. Table 158: Digit Map Rules #1 Settings Variable Setting digitMapAllowedEnable Enable digitMapAllowedDigitMap (011x.#|001x.T) digitMapPrefixedDigitRemovalCount A valid telephone number must contain a country code, an area code, and a number – the “011” part is not required. Mediatrix 1204...
  • Page 274 ([235-9]xxxxxx|45[1-9]xxxx|4[0-469]xxxxx) digitMapPrependedString 1206 (country code and area code) A valid telephone number must contain a country code, an area code, and a number. The country code and area code are missing in this number and must be added. Mediatrix 1204...

  • Page 275: Digit Map Example 2 - Pbx Emulation

    (in North America). The two digits must be removed because they do not need to be expressed to the SIP Server. The SIP Server needs only to know the complete number of the called party (CC+AC+directory number). Mediatrix 1204...
  • Page 276 1819 (country code and area code) A valid telephone number must contain a country code, an area code, and a number. The country code and area code are missing in this number and must be added. Mediatrix 1204...

  • Page 277: Chapter 22 Telephony Features

    H A P T E R Telephony Features This chapter explains how to set the telephony variables of the Mediatrix 1204 to define the way the unit handles calls. Call Processes The Mediatrix 1204 is a gateway between the SCN world and IP world.
  • Page 278 Soft Phone IP phone Server A SCN user contacts the Mediatrix 1204, which reaches the corresponding LAN endpoint on the IP network. Such endpoints could be: an access device such as a Mediatrix 1102, a Mediatrix 1104, etc. a Soft Phone an IP phone directly connected to the IP network LAN Endpoint ->...

  • Page 279: Making Calls

    Dialing depends on whether you are on the SCN side or the IP side. Complete Dialing Sequence There are three ways to indicate the dialed number sequence is complete and the Mediatrix 1204 can dial the number: The administrator has set up the dialing process so that you must end the telephone number with a particular character to indicate it is complete, e.g., a “#”.

  • Page 280: Emergency Call

    243). Dialing this digit map does not have any effect unless the service's status is “enabled”. The activating sequence is set for all the lines of the Mediatrix 1204. You cannot have different sequences for each line. Set the number to reach for an urgent call in the emergencyCallUrgentGatewayTargetAddress variable.

  • Page 281: Chapter 23 Telephony Attributes

    This string is used literally, so cosmetic symbols (such as the dash in “555-xxxx”) should not be present. Because this variable is located in a table, you can define a different number for each line of the Mediatrix 1204. Enable the automatic call feature by setting the telephonyAttributesAutomaticCallEnable variable to enable.

  • Page 282: Call Direction Restriction

    Allows incoming and outgoing calls. scnToIpOnly Allows only calls from the SCN to the IP network. The Mediatrix 1204 answers incoming calls but does not allow outgoing calls. ipToScnOnly Allows only calls from the IP network to the SCN. The Mediatrix 1204 allows outgoing calls but does not answer incoming calls.

  • Page 283: Ip Address Call Service

    How to contact such a line depends on how your system has been set up. Usually, you only have to dial the number of the SCN line connected to the FXO connector of the Mediatrix 1204. The call is answered and a second dial tone (IP dial tone) is presented to the SCN user.

  • Page 284: Pin Dialing

    This feature could be used in the case where a user makes an automatic call to an IVR system, and after a pre-defined delay, the Mediatrix 1204 sends the DTMF tones (PIN) to indicate where the call is coming from.

  • Page 285: Remote Line Extension

    Mediatrix FXS device. If applicable, you can instruct the Mediatrix 1204 to wait until the called party answers the phone before it picks up the SCN line. You can do so in the fxoMIB by setting the fxoWaitForCalleeToAnswerEnable variable to enable.
  • Page 286 “Hook Flash Processing” on page 256. Setting the telephonyAttributesHookFlashProcessing variable to outOfBandUsingRtp means the following: Table 169: Hook Flash Processing Mediatrix 1204 Mediatrix FXS Device The hook-flash event received via an RFC The hook-flash event is relayed as telephone- 2833 RTP packet is executed.

  • Page 287: Delayed Hot Line

    The destination specified in Step 2 is called upon expiration of the timeout. disable A user beginning to dial a telephone number but failing to complete the operation before expiration of the digitMapTimeoutCompletion timeout hears the Receiver Off- Hook tone. Mediatrix 1204...
  • Page 288 Chapter 23 - Telephony Attributes Delayed Hot Line Mediatrix 1204...

  • Page 289: Management Server Configuration

    Using the Management Server You have the choice of setting up Mediatrix 1204 units directly with a SNMP browser or with the Management Server. If you want to use the Management Server to setup the units, you shall tell these units how to reach the Management Server.
  • Page 290 Use the static configuration if you are not using a DHCP server or if you want to bypass it. To use static information: In the ipAddressConfig folder, locate the msSelectConfig Source variable. This variable defines whether the Mediatrix 1204 shall get its Management Server configuration through a DHCP server or not. Set the msSelectConfigSource variable to static.

  • Page 291: Chapter 25 Quality Of Service (Qos)

    – one variable for signalling (SIP) and one variable for each of voice, T.38 and VBD (Voice Band Data) media. The Mediatrix 1204 supports the Real Time Control Protocol (RTCP), which is used to send packets to convey feedback on quality of data delivery.

  • Page 292: Ieee 802.1Q

    RFC 3168 now defines the state in which to set the two least significant bits in the TOS byte. On the other hand, this RFC only applies to TCP transmissions and the bits are thus set to “0” in the Mediatrix 1204.

  • Page 293: Vlan

    • qosVlanIeee8021qDefaultUserPriority Set the value of these variables. Restart the Mediatrix 1204 so that the changes may take effect. For more information, please refer to the MIB Reference manual. VLANs VLANs are created with standard Layer 2 Ethernet. A VLAN Identifier (VID) is associated with each VLAN.
  • Page 294 Chapter 25 - Quality of Service (QoS) VLAN Mediatrix 1204...

  • Page 295: Chapter 26 Syslog Daemon

    Syslog daemon address is provided by a DHCP server or specified by the administrator, no messages are sent. For instance, if you want to download a new software into the Mediatrix 1204, you can monitor each step of the software download phase. Furthermore, if the unit encounters an abnormal behaviour, you may see accurate messages that will help you troubleshoot the problem.

  • Page 296: Configuration Source

    Syslog Daemon Configuration Configuration Source The Mediatrix 1204 must know the IP address and port number of the Syslog server. You can assign these information to the Mediatrix 1204 through a DHCP server or manually enter them yourself with the static variables.

  • Page 297: Customizing Syslog Messages

    Default Value: 514 Customizing Syslog Messages You can display additional information in the prefix of syslog messages the Mediatrix 1204 sends. This allows you to later filter the messages. The following is the additional information you can enable: MAC address...
  • Page 298 Chapter 26 - Syslog Daemon Syslog Daemon Configuration Mediatrix 1204...

  • Page 299: Chapter 27 Statistics

    H A P T E R Statistics The Mediatrix 1204 collects meaningful statistics that can be read via the RTP MIB. RTP Statistics RTP statistics are related to the transmission of information and include, but are not limited to: Number of octets transmitted/received...

  • Page 300: Statistics By Syslog

    This resets all cumulated call statistics. Statistics by Syslog You can configure the Mediatrix 1204 to send the RTP and T.38 statistics by syslog message. You will thus be able to see them by using your syslog daemon. The RTP statistics are sent at the end of a call.

  • Page 301: Example

    130. 50 total octets transmitted in the sixth 5-minutes period. The previous statistics are transferred to the corresponding cumulated statistics variable. The statistics for the second 5-minutes period are dropped, for a cumulated total octets transmitted of 200. Mediatrix 1204...
  • Page 302 Chapter 27 - Statistics RTP Statistics Mediatrix 1204...

  • Page 303: Maximum Transmission Unit (Mtu)

    The Mediatrix 1204 MTU is 1500 bytes, which is the Ethernet typical value. Possible Hardware Problem The implementation of the IEEE Standard 802.1q in the Mediatrix 1204 may have a minor problem because of hardware limitations. 802.1q increases the Ethernet frame header by 4 bytes, adding a Virtual LAN ID and a user_priority. This is useful to limit broadcasts that cross bridges, and it may also prioritize frames in the queuing algorithm of switches.
  • Page 304 MTU. Values smaller than 68 will result in the transport using an MTU of 68. To validate that the changes are correct, try to ping the Mediatrix 1204 with large packets once restarted: ping -l 2000 This will cause IP fragmentation, the first fragment being as large as the interface allows it.

  • Page 305: Chapter 29 Troubleshooting

    DHCP server cannot be reached, even if most other settings are set to “static”. This delay is caused by the Mediatrix 1204 that cannot function as configured if part of its configuration (the DHCP information) is unavailable.
  • Page 306 See “Adaptative Jitter Buffer” on page 209 for more details. : I have set the analog lines type of the Mediatrix 1204 to Ground StartMediatrix 1204, but it does ESCRIPTION not work.
  • Page 307 : When I set values such as the User Name and Display Name, the value is not accepted and is ESCRIPTION reset to its default value once the Mediatrix 1204 restarts. : When you enter values that contain non-standard English characters in entries that...

  • Page 308: Calling Issues

    PC doing the capture. Caution: Enabling PCM traces on the Mediatrix 1204. You must disable G.723 and enable the G.726 codecs to load the PCM code into the Mediatrix 1204. For more details on the PCM traces, refer to Technical Bulletin 0598 - PCM Traces.
  • Page 309 This feature is currently located under the mediatrixExperimental branch of the MIB structure. See “MIB Structure” on page 111 for more details. : Unable to establish a call from the Mediatrix 1204 to a user agent such as an IP phone, a ESCRIPTION gateway or another access device.
  • Page 310 There may be several possible causes to the issue. • For each SCN port on the Mediatrix 1204, there are two directions of voice traffic. In one direction, voice signals from a remote VoIP gateway arrive at the Mediatrix 1204 as IP packets and are converted to analog signals which are transmitted by the Mediatrix 1204 to the SCN device attached to its SCN port.

  • Page 311: Fax Issues

    : When the dial tone detection feature and/or the line fault detection feature is disabled, OSSIBLE AUSE the Mediatrix 1204 sends the DTMFs too quickly on the SCN or to another device. The DTMFs are thus not recognized. : This problem is equipment-dependent. You must modify the pre-dial delay (in the OLUTION analogScnGwPreDialDelay variable) so that the DTMFs are not sent too quickly.

  • Page 312: Tested Fax Models

    Mediatrix 1204. Tested Fax Models The following table lists the fax models tested with the Mediatrix 1204 for the T.38 protocol. Each of these fax ® models has been emulated and tested with each other by using the FaxLab fax/telephony testing tool.

  • Page 313: Issues Arising From Specific Combinations/Scenarios

    SSUE the test sheet used: Figure 67: Test Sheet Used : T.38 with FaxLab – When sending faxes from an FXS access device to the Mediatrix 1204, ESCRIPTION there are warnings on the receiving Mediatrix 1204. : During automated fax testing, a few warning messages were given by the testing tool but the SSUE faxes were still successful.
  • Page 314 • Hewlett Packard LaserJet 3200 (Answering: RX 3 Pg, best ECM, best encoding, V.17, 9600 bps, best resolution). : When using the Mediatrix 1204 with the Cyberguard SG530 broadband router, the router ESCRIPTION blocks fax transmissions. : Cyberguard Version 2.0.2 seems to be the problem.

  • Page 315: Configuration Issues

    : If none of the xxxConfigSource variables (in the ipAddressStatus folder) are set to OSSIBLE AUSE dhcp, then the Mediatrix 1204 does not send a DHCP REQUEST message. This is the case if: • you set all xxxSelectConfigSource variables to something other than dhcp and you restart the Mediatrix 1204, or •...
  • Page 316 This delay is caused by the Mediatrix 1204 that cannot function as configured if part of its configuration (the DHCP information) is unavailable. Furthermore, there is an issue with switches that use the Spanning Tree Protocol.

  • Page 317: Snmp Management Software Issues

    SNMP Management Software Issues Reference Manual (SIP Version) SNMP Management Software Issues The following are issues you may encounter when trying to contact the Mediatrix 1204 with a SNMP management software. : The SNMP network management software cannot access the Mediatrix 1204.
  • Page 318 OSSIBLE AUSE the unit is an embedded device with limited processing power. : Is it possible for a hacker to change the content of SNMPv3 variables once the Mediatrix 1204 ESCRIPTION is in secure mode management? : In secure management mode, the Mediatrix 1204 works in SNMPv1 read-only,...
  • Page 319 Appendices...
  • Page 320 Page Left Intentionally Blank...

  • Page 321: Standards Compliance And Safety Information

    P P E N D I X Standards Compliance and Safety Information This Appendix lists the various standards compliance of the Mediatrix 1204. Standards Supported The Mediatrix 1204 complies to the following standards: Table 182: Standards Compliance Category Specification Agency approvals •...

  • Page 322: Disclaimers

    AS/ACIF S002 - 2001 • AS/ACIF S003 - 2001 Note: The standards compliance of the Mediatrix 1204 are printed on a sticker located on the bottom of the unit. Disclaimers The following are the disclaimers related to the Mediatrix 1204.

  • Page 323: Industry Canada

    For a copy of the original signed Declaration Of Conformity please contact Mediatrix at the above address. Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Mediatrix 1204...

  • Page 324: Jate

    The Mediatrix 1204 equipment is guaranteed to respect the JATE requirements as long as it is programmed with an approved Mediatrix software. Translated Warning Definition The following information provides an explanation of the symbols which appear on the Mediatrix 1204 and in the documentation for the product. Warning: Means danger.

  • Page 325: Safety Warnings

    300V between conductors or is subject to lightning strikes. Socket Outlet Warning Warning: The socket outlet, if used, shall be located near the equipment and shall be easily accessible by the user. Mediatrix 1204...

  • Page 326: Pft (Power Fail Transfer) Warning

    Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. • Do not use the telephone to report a gas leak in the vicinity of the leak. Mediatrix 1204...

  • Page 327: Standard Hardware Information

    Mediatrix sales representative to obtain the latest version of the technical specifications. Industry Standard Protocols The Mediatrix 1204 has been designed to support all major industry standards used today, as well as those that will eventually be implemented at a later date. Because of this specific design characteristic, the Mediatrix 1204 can be integrated with existing telephone, fax and data equipment such as PCs and routers.

  • Page 328: Hardware Features

    Automatic selection between voice and fax. Table 184: Fax Technical Specifications Parameter Description Protocols Group 3 Fax Clear channel (G.711), G.726, or T.38 Real Time Fax Over IP protocol Stack Fax Data Compression Fax Transmission Up to 14.4 kbps Mediatrix 1204...

  • Page 329: Pstn Interface (Fxo)

    Dynamic Range -35 dBm to +3 dBm per tone Frequency Accept ± 1.5% of nominal frequencies Minimum Tone Duration 40 ms, can be increased with software configuration Interdigit Timing Detects like digits with a 40 ms interdigit delay Mediatrix 1204...

  • Page 330: Dtmf Tone Generation

    Less than 1% MTBF Value The Mean Time Before Failure (MTBF) value of the Mediatrix 1204 is 440 000 hours at 25 degrees Celsius ambient temperature. It has been defined using RelCalc v5.0, Bellcore method (LimitedStress - Method I, Case 3), Desktop unit .

  • Page 331: Dimensions And Weight

    5.5 cm x 26.2 cm x 17.8 cm – 2.2 x 10.3 x 7.0 in. (approx.) Weight 750 g (1.7 lb) Warranty All Mediatrix products carry Mediatrix Telecom, a Division of Media5 Corporation's standard three-year hardware and software warranty. An extended warranty is available. Mediatrix 1204...
  • Page 332 Appendix B - Standard Hardware Information Warranty Mediatrix 1204...

  • Page 333: Cabling Considerations

    P P E N D I X Cabling Considerations This Appendix describes the pin-to-pin connections for cables used with the Mediatrix 1204. Warning: To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. RJ-45 Cable The RJ-45 connector is commonly used for network cabling and for telephony applications.

  • Page 334: Crossover Cable

    A crossover cable is sometimes called a null modem. The coloured wires at either end are put into different pin numbers, or crossed over. Figure 70: Crossover Connectivity 1- TX+ TX+ -1 2- TX- TX- -2 3- RC+ RC+ -3 6- RC- RC- -6 Mediatrix 1204...

  • Page 335: Rj-11 (Telephone) Cable

    The RJ-11 pair of wires is wired so that pins 3 and 4 are connected to the Ring and Tip, which meets the following requirements: EIA/TIA-IS 968 CS-03 Issue 8, Part III requirements. Warning: The RJ-11 cable should comply with UL 1863 and CSA C22.2 No 233 standards. Mediatrix 1204...
  • Page 336 Appendix C - Cabling Considerations RJ-11 (Telephone) Cable Mediatrix 1204...

  • Page 337: Country-Specific Parameters

    When representing an impedance, the following applies: Symbol “//” means parallel. Symbol “+” means serial. Furthermore, there are two types of impedances: Input Impedance Terminal Balance Return Loss (TBRL) Impedance Mediatrix 1204...
  • Page 338 Appendix D - Country-Specific Parameters Definitions Input Impedance Impedance of the Mediatrix 1204 at the Tip and Ring wires. Terminal Balance Return Loss (TBRL) Impedance Balance return loss attributable to transmission loss between two points. It is used to characterize an impedance balancing property of the 2-wire analog equipment port.

  • Page 339: Distinctive Ring

    <http://127.0.0.1/Bellcore-dr4> Bellcore-dr4 0.3 – 0.2, 1.0 – 0.2, 0.3 – 4.0 The Mediatrix 1204 plays the default ring of the country selected if the Alert-Info value is not present or the value is not supported. Note: Since the first pause of the distinctive ring is lower that 1 second, a splash ring followed by an Off of 1 second precedes the distinctive ring pattern.

  • Page 340: Australia

    FXO Line Attenuation (Input) +0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 2 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) a. The Australia 2 choice in the MIB is exactly the same as Australia 1. Mediatrix 1204...

  • Page 341: Austria

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 450 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 342: Austria 2

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 450 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial Tone 4 seconds Detection) Mediatrix 1204...

  • Page 343: Brazil

    0.2 – 0.2 -10 dBm 600 Ω Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) 6 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 344: China

    0.7 – 0.7 -10 dBm 600 Ω Input Impedance FED Tone 450 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 345: Czech Republic

    220 Ω + 820 Ω // 115 nF Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 346: France

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 440 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 347: Germany

    FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) a. The Germany 2 choice in the MIB is exactly the same as Germany 1. Mediatrix 1204...

  • Page 348: Germany 3

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 349: Hong Kong

    0.25 – 0.25 -13 dBm 600 Ω Input Impedance FED Tone 440 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 350: Indonesia

    0.25 – 0.25 -9 dBm 600 Ω Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) -3.5 dBr FXO Line Attenuation (Output) -3.5 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 351: Israel

    0.25 – 0.25 -15 dBm 600 Ω Input Impedance FED Tone 400 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 352: Italy

    Input Impedance FED Tone 425 Hz 0.2 – 0.2, 0.6 – 1.0 FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 353: Japan

    0.5 – 0.5 -13 dBm 600 Ω Input Impedance FED Tone 400 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 2 seconds Delay Before Dialing (No Dial 3 seconds Tone Detection) Mediatrix 1204...

  • Page 354: Malaysia

    Network Congestion Tone 425 Hz 0. – 0.25 -18 dBm 600 Ω Input Impedance FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 355: Mexico

    0.25 – 0.25 -18 dBm 600 Ω Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 second Delay Before Dialing (No Dial 0 second Tone Detection) Mediatrix 1204...

  • Page 356: Netherlands

    0.25 – 0.25 -17 dBm 600 Ω Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 357: New Zealand

    -17 dBm 600 Ω Input Impedance FED Tone 400 Hz 0.5 – 0.5 FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 358: North America

    Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) a. The North America 2 choice in the MIB is exactly the same as North America 1. b. TBRL-Impedance for “on-premise" or short loop ports. Mediatrix 1204...

  • Page 359: Russia

    0.2 – 0.2 -10 dBm 600 Ω Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) 0 dBr FXO Line Attenuation (Output) 0 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...

  • Page 360: Spain

    220 Ω + 820 Ω // 120 nF Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 361: Sweden

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +2 dBr FXO Line Attenuation (Output) -3 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 362: Switzerland

    270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 425 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...

  • Page 363: Thailand

    0.3 – 0.3 -10 dBm 600 Ω Input Impedance FED Tone 400 Hz FXO Line Attenuation (Input) -3.5 dBr FXO Line Attenuation (Output) -3.5 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 0 seconds Tone Detection) Mediatrix 1204...
  • Page 364 270 Ω + 750 Ω // 150 nF Input Impedance FED Tone 440 Hz FXO Line Attenuation (Input) +6 dBr FXO Line Attenuation (Output) -1 dBr Delay Before Answering 0 seconds Delay Before Dialing (No Dial 4 seconds Tone Detection) Mediatrix 1204...
  • Page 365 Geographical (regional) zone of the number (in France, there are five zones). It has two digits. ABPQ First four digits corresponding to a local zone defined by central offices. 12 34 Unique number to reach a specific destination. Mediatrix 1204...

  • Page 366: Appendix E Glossary

    A network-provided service in which a telephone in a given local exchange area is connected, via a private line, to a central office in another, i.e., “foreign”, exchange, rather than the local exchange area’s central office. This is the office end of an FX circuit (frequently a PBX). Mediatrix 1204...
  • Page 367 Layer 2 refers to the Data Link Layer of the commonly-referenced multilayered communication model, Open Systems Interconnection (OSI). The Data Link Layer is concerned with moving data across the physical links in the network. The Data-Link Layer contains two sublayers that are described in the IEEE-802 LAN standards: Media Access Control (MAC) Mediatrix 1204...
  • Page 368 A line condition caused when a telephone handset is resting in its cradle. Packet Includes three principal elements: control information (such as destination, origin, length of packet), data to be transmitted, and error detection. The structure of a packet depends on the protocol. Mediatrix 1204...
  • Page 369 An IETF standard for streaming realtime multimedia over IP in packets. Supports transport of real-time data like interactive voice and video over packet switched networks. Registrar Server A server that accepts REGISTER requests. A registrar is typically co-located with a proxy or redirect server and MAY offer location services. Mediatrix 1204...
  • Page 370 TCP/IP networks. T.38 An ITU-T Recommendation for Real-time fax over IP. T.38 addresses IP fax transmissions for IP-enabled fax devices and fax gateways, defining the translation of T.30 fax signals and Internet Fax Protocols (IFP) packets. Mediatrix 1204...
  • Page 371 Internet or a corporate Intranet. Wide Area Network (WAN) A large (geographically dispersed) network, usually constructed with serial lines, that covers a large geographic area. A WAN connects LANs using transmission lines provided by a common carrier. Mediatrix 1204...
  • Page 372 Appendix E - Glossary Wide Area Network (WAN) Mediatrix 1204...

  • Page 373: Appendix F List Of Acronyms

    Local Area Network Liquid Crystal Display Light Emitting Diode Media Access Control Mb/s Megabits Per Second Management Information Base Maximum Transmission Unit Name Address Translation Open Systems Interconnection Private Branch eXchange Personal Identification Number PSTN Public Switched Telephone Network Mediatrix 1204...
  • Page 374 TCP/IP Transmission Control Protocol/Internet Protocol Twisted-Pair Ethernet User Datagram Protocol Underwriters Laboratories Incorporated Universal Time Coordinated Unshielded Twisted pair Voice Activity Detection Voice Band Data VLAN Virtual Local Area Network VoIP Voice over Internet Protocol eXtensible Markup Language Mediatrix 1204...

  • Page 375: Appendix G List Of Mib Parameters

    ..........................218 dataIfT38NoSignalEnable ............................218 dataIfT38NoSignalTimeout ............................218 digitMapAllowedDigitMap ............................. 246 digitMapAllowedEnable ..............................246 digitMapPrefixedDigitRemovalCount .......................... 246 digitMapPrependedString ............................. 246 digitMapRefusedDigitMap ............................246 digitMapRefusedEnable ..............................247 digitMapSuffixStringToRemove ........................... 246 digitMapTimeoutCompletion ............................247 digitMapTimeoutFirstDigit ............................. 247 digitMapTimeoutInterDigit ............................247 Mediatrix 1204...
  • Page 376 ................................ 174, 175 imageLocationProvisionSource ........................... 174 imagePrimaryHost ............................20, 123, 172 imagePrimaryPort ............................20, 123, 172 imageSecondaryHost ............................20, 123, 172 imageSecondaryPort ............................20, 123, 172 imageSelectConfigSource ............................ 123, 172 imageSelectionFileLocation ..........................174, 175 imageStaticPrimaryHost ............................... 173 Mediatrix 1204...
  • Page 377 ..........................263 mxDebugPcmCaptureEnable ............................282 mxDebugPcmCaptureIpAddress ..........................282 pinDialingDelay ................................258 pinDialingEnable ................................258 pinDialingPin ................................... 258 qosSignalingDiffServ ..............................265 qosSignalingIeee8021qEnable ............................ 266 qosSignalingIeee8021qUserPriority ........................... 266 qosT38FaxDiffServ ................................ 265 qosT38FaxIeee8021qEnable ............................266 qosT38FaxIeee8021qUserPriority ..........................266 qosVbdDiffServ ................................266 Mediatrix 1204...
  • Page 378 ..............................147, 226 sipPort ....................................219 sipPresenceCompositorDhcpSiteSpecificCode ....................... 142 sipPresenceCompositorHost ..........................127, 142 sipPresenceCompositorPort ..........................127, 142 sipPresenceCompositorStaticHost ..........................143 sipPresenceCompositorStaticPort ..........................143 sipPublicationCmdRefresh ............................227 sipPublicationProposedExpirationValue ........................227 sipPublicationRefreshTime ............................227 sipRegistrarDhcpSiteSpecificCode ..........................126 sipRegistrarHost ................................126 Mediatrix 1204...
  • Page 379 ................................. 20 syslogDhcpSiteSpecificCode ..........................125, 270 syslogHost ................................. 20, 125, 270 syslogMsgDisplayLocalHost ............................271 syslogMsgDisplayMacAddress ............................ 271 syslogMsgDisplayTime ..............................271 syslogMsgMaxSeverity ............................269, 283 syslogPort ................................20, 125, 270 syslogSelectConfigSource ........................... 125, 270 syslogStaticHost ................................270 syslogStaticPort ................................271 Mediatrix 1204...
  • Page 380 ..............................201 voiceIfDtmfEnforceDefaultEvents ..........................207 voiceIfDtmfPayloadType ............................... 207 voiceIfDtmfTransport ........................202, 205, 206, 207, 208 voiceIfG711ComfortNoiseGenerationEnable ......................211 voiceIfG711VoiceActivityDetectionEnable ........................ 210 voiceIfG729VoiceActivityDetectionEnable ........................ 210 voiceIfMaxJitterBufferLength ..........................209, 280 voiceIfTargetJitterBufferLength ........................... 209, 280 voiceIfUserInputGainOffset ............................212 voiceIfUserOutputGainOffset ............................212 Mediatrix 1204...
  • Page 381 46, placing defined 46, restriction on direction example standard HTTP, downloading via 47, type of management server, downloading from caller ID syslog messages 45, ADSI TFTP, downloading via 47, country-specific, selecting 92, web interface, configuring via detection Mediatrix 1204...
  • Page 382 IP address call 253, RFC 2833 events sequence transport type 83, 88, settings over the SIP protocol DTMF duration value payload type 84, inter-digit dial delay using SIP INFO method standard call web interface, configuring via 83, telephone number Mediatrix 1204...
  • Page 383 G.726 80, DHCP server comfort noise DHCP, using defined DNS, primary 37, enabling static packetization time DNS, secondary 37, payload type 87, static voice activity detection download server 42, G.729 81, entering defined Image server 54, enabling locating Mediatrix 1204...
  • Page 384 88, conformance clear channel fax description clear channel, enabling 89, mediatrixAdmin clear channel, preferred 91, mediatrixConfig enabling mediatrixExperimental fax calling tone detection mediatrixIpTelephonySignaling T.38 89, 217, mediatrixMgmt dial tone detection mediatrixModules echo cancellation mediatrixProducts Mediatrix 1204...
  • Page 385 124, RFC 2543 141, 232, 234, RTCP, setting range of RFC 2543bis RTP, setting range of RFC 2616 SIP 66, 67, RFC 2617 31, SIP outbound proxy 67, 126, RFC 2705 73, SIP Presence Compositor 67, RFC 2782 Mediatrix 1204...
  • Page 386 Presence Compositor server downgrading, procedure 63, DHCP information, using downloading static information, using automatic update 60, proxy server configuration source 54, DHCP information, using 66, emergency procedure 63, static information, using 66, HTTP server, configuring 53, Mediatrix 1204...
  • Page 387 RFC 2782 enabling 90, RFC 2833 82, 205, 207, negotiation syntax RFC 2976 206, not supported by other endpoint RFC 3164 29, 269, number of redundancy packets RFC 3261 70, 71, 141, 220, 222, 224, 230, 234, Mediatrix 1204...
  • Page 388 DNS when viewing table, unit does not respond SIP custom NAT traversal wrong value error message SIP outbound proxy server software download SIP penalty box cannot communicate with image server SIP proxy server downgrade fails Mediatrix 1204...
  • Page 389 Reference Manual (SIP Version) web interface (continued) SIP publication refresh SIP registrar server SIP transport type SIP user agents SNTP status, system STUN subnet mask system management user name, modify what’s new in this version Mediatrix 1204...
  • Page 390 Index Mediatrix 1204...

Table of Contents
