Summary of Contents for Polario RG51F
- Page 1 REMOTE CONTROLLER OWNER’S MANUAL IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 2: Table Of Contents
Table of Contents Remote Controller Specifications ............02 Handling the Remote Controller ............03 Buttons and Functions ..............04 Remote Screen Indicators ..............08 How to Use Basic Functions ............09 How to Use Advanced Functions ..........11... -
Page 3: Remote Controller Specifications
Remote Controller Specifications RG51F/EF, RG51F2(1)/EFU1, RG51F4/E, RG51F5(1)/EU1, RG51H(1)/EF, RG51H1(1)/EF, RG51H2(1)/EFU1-M, Model RG51H3(1)/EU1-M Rated Voltage 3.0V( Dry batteries R03/LR03×2) Signal Receiving Range Environment -5°C~60°C(23°F~140°F) Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH SELECT FAN SPEED... -
Page 4: Handling The Remote Controller
Handling the Remote Controller Inserting and Replacing Batteries CAUTIONS FOR USING REMOTE CONTROL Your air conditioning unit may come with two The device could comply with the local national batteries(some units). Put the batteries in the regulations. remote control before use. In Canada, it should comply with •... -
Page 5: Buttons And Functions
Buttons and Functions Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the How to Use Basic Functions section of this manual. - Page 6 : Decreases temperate in 1°F increments. TEMP Min. temperature is 62°F. Increases temperate in 1°F increments. TEMP Max. temperature is 86°F. ON/OFF: Turns the unit on or off. FAN SPEED: Selects fan speeds in the following order: AUTO LOW MED HIGH MODE: Scrolls through operation modes as follows: AUTO ...
- Page 7 : Decreases temperate in 1°F increments. TEMP Min. temperature is 62°F. Increases temperate in 1°F increments. TEMP Max. temperature is 86°F. ON/OFF: Turns the unit on or off. FAN SPEED: Selects fan speeds in the following order: AUTO LOW HIGH MODE: Scrolls through operation modes as follows: AUTO ...
- Page 8 : Decreases temperate in 1°C increments. TEMP Min. temperature is 17°C. Increases temperate in 1°C increments. TEMP Max. temperature is 30°C. NOTE: Press together & buttons at the same time for 3 seconds will alternate the temperature display between the °C &...
-
Page 9: Remote Screen Indicators
Remote Screen Indicators Information are displayed when the remote controller is power up. Mode display COOL AUTO AUTO HEAT Displayed when data transmitted. COOL HIGH Displayed when remote controller is ON. HEAT Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Shows set temperature or room temperature, or time under TIMER setting Indicated all the current settings are... -
Page 10: How To Use Basic Functions
How to Use Basic Functions ATTENTION Before operation, please ensure the unit is plugged in and power is available. AUTO Mode Select AUTO mode Set your desired temperature Turn on the air conditioner MODE ON/OFF NOTE: 1. In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT function based on the set temperature. - Page 11 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button to Press Temp. up or down button for Point remote to unit and wait 1sec, initiate the ON time sequence.
-
Page 12: How To Use Advanced Functions
How to Use Advanced Functions Swing function(some units) Press Swing button SWING SWING The horizontal louver will swing up and down Keep pressing this button more than 2 seconds, automatically when pressing Swing button. the vertical louver swing function is activated. Press again to make it stop. - Page 13 SHORTCUT function(some units) SHORT CUT Used to restore the current settings or resume previous settings. Push this button when remote controller is on, the system will automatically revert back to the previous settings including operating mode, setting temperature, fan speed level and sleep feature(if activated).
- Page 14 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
