  • Page 1 CCD110N CCD110N CCD110N PINSPOTTER # 27122 ® OWNER’S OWNER’S MANUAL MANUAL...
  • Page 2 Tech Service/Customer Service and provide proof of purchase date. If this product is returned to Duro Dyne, you agree to insure the Product or assume the risk of loss or damage in transit, to prepay shipping charges to the designated warranty service location and to ship the Product in the original shipping container or equivalent.

  • Page 3: Safety Precautions

    SAF ETY PRE CAUT IO NS SAF ETY PRE CAUT IO NS Users Responsibility This equipment will perform in conformity with the description and all the instructions contained in this manual provided. The equipment must be checked periodically. Defective equipment should NEVER be used with parts that are broken, missing, worn, distorted or contaminated and should be replaced immediately.

  • Page 4: Electrical Shock

    SAF ETY P RECAUTIONS SAF ETY P RECAUTIONS (continued) FUMES AND GASES **Don’t weld in locations near degreasing, cleaning or spraying operations. FIRES & EXPLOSION HAZARDS **Welding on closed containers, such as tanks, drums or pipes, can cause them to blow up. **Do not weld where flying sparks can strike flammable material.

  • Page 5: Electric And Magnetic Fields

    SAF ETY PRE CAUT IO NS (continued) bare wiring. Replace worn or damaged cables immediately; bare wiring can kill. Call Duro Dyne Tech Service to replace damaged parts at once. Maintain this unit according to the manual provided. **Do not use worn, damaged, undersized or poorly spliced cables.

  • Page 6: Equipment Maintenance

    EQUIPMENT MAINTENANCE Faulty or improperly maintained equipment can cause injury or death. Therefore: -Always have qualified personnel perform the installation. Call Duro Dyne Tech Service Department if service is required. Do not perform any electrical work. -Maintain cables, grounding wire, connections, power cord and power supply in safe working order;...

  • Page 7: Front Panel Controls

    F RONT PA NEL CONT R OL S F RONT PA NEL CONT R OL S POWER SWITCH: The POWER switch applies AC voltage to the power supply Hi/Lo causing the weld capacitors to charge to a voltage level determined by the setting of the VOLTAGE CONTROL. Also, the charge time is dependent on the setting of the VOLTAGE CONTROL, ranging from 1 to 3 seconds.

  • Page 8: Parts Location

    1515 Desoto Ave / Clarksdale, MS 38614 mm DIMENSIONS CHECKED DECIMALS ANGLES Tel:847-659-0100 Fax:847-659-0108 ±.10 ±1° MATERIAL MFG ENG DESCRIPTION Duro Dyne CD Pin Welder Assembly QUAL ENG FINISH SIZE DWG. NO. 11700-1 Clean REV. GROUND CLAMP WELD TIP DO NOT SCALE DRAWING 11700 PART NO.
  • Page 9 1515 Desoto Ave / Clarksdale, MS 38614 mm DIMENSIONS CHECKED DECIMALS ANGLES Tel:847-659-0100 Fax:847-659-0108 ±.10 ±1° MATERIAL DESCRIPTION MFG ENG Duro Dyne CD Pin Welder Assembly FINISH QUAL ENG SIZE DWG. NO. 11700-1 Clean REV. DO NOT SCALE DRAWING PART NO.

  • Page 10: Installation Instructions

    3) All cables and connections require continual inspection for broken insulation and other electrical hazards. Repair of these items should be done in compliance with the established safety precautions established for electrical equipment repair. Duro Dyne Tech Service Contact Information: Toll Free: 1-800-899-3876 Mon - Fri: 7:00 am - 7:00 pm EST...

  • Page 11: Troubleshooting Section

    WELDER TURNS ON BUT DOES NOT WELD WELD IS TOO HOT REGARDLESS OF VOLTAGE SETTING POOR OR INCONSISTENT WELDS If assistance is needed you may call Duro Dyne Technical Services Dept at 1-800-899-3876 between the hours of 7am - 7pm EST. -11-...
  • Page 12 (1) VARIFY RESET BUTTON IS IN THE NORMAL POSITION CIRCUIT TRIPS EACH TIME THE WELDER IS TURNED ON POSSIBLE CAUSES ACTION CONTACT DURO DYNE TECH SERVICE - see page 2 - DO NOT OPEN CASE CIRCUIT BREAKER TRIPS WHEN WELD IS MADE POSSIBLE CAUSES ACTION...

  • Page 13: Parts List

    PARTS LIST PARTS LIST 27082 CCD110N Foil Weld Tip 27083 CCD110N Standard Weld Tip 27087 CCD110N Weld Gun Complete 27088 CCD110N Ground Clamp Complete -13-...
  • Page 14 NOTES...
  • Page 15 NOTES...
  • Page 16 ® MACHINERY DIVISION © 2021 Duro Dyne Corporation Printed in USA 3/18/2021 Duro Dyne Corporate Headquarters, Bay Shore, NY 631-249-9000 • Fax: 631-249-8346 Duro Dyne Midwest • Duro Dyne West • Duro Dyne Canada www.durodyne.com • E-mail: durodyne@durodyne.com...
