IF THIS SMOKE ALARM SOUNDS
AGENCY PLACEMENT RECOMMENDATIONS
NFPA 72 (National Fire Code) Chapter 11
RESPONDING TO AN ALARM
During an alarm, you will hear a loud, repeating horn pattern:
"For your information, the National Fire Protection Association's Standard 72,
reads as follows:
3 beeps, pause, 3 beeps, pause. The red LED will flash rapidly.
"11.5.1 One- and Two-Family Dwelling Units."
•
If the unit alarms and you are not testing the unit, it is warning you
"11.5.1.1 Smoke Detection. Where required by applicable laws, codes, or
standards for the specified occupancy, approved single- and multiple-station
of a potentially dangerous situation that requires your immediate
attention. NEVER ignore any alarm. Ignoring the alarm may result in
Smoke Alarms shall be installed as follows: (1) In all sleeping rooms
injury or death.
Exception: Smoke Alarms shall not be required in sleeping rooms in existing
one- and two-family dwelling units. (2) Outside of each separate sleeping area,
•
Never remove the batteries from a battery operated Smoke Alarm to
in immediate vicinity of the sleeping rooms. (3) On each level of the dwelling
stop an unwanted alarm (caused by cooking smoke, etc.). Removing
unit, including basements Exception: In existing one- and two family dwelling
batteries disables the alarm so it cannot sense smoke, and removes
units, approved Smoke Alarms powered by batteries are permitted.
your protection. Instead open a window or fan the smoke away from
the unit. The alarm will reset automatically.
"A.11.8.3 Are More Smoke Alarms Desirable? The required number of
Smoke Alarms might not provide reliable early warning protection for those
•
If the unit alarms get everyone out of the house immediately.
areas separated by a door from the areas protected by the required Smoke
Alarms. For this reason, it is recommended that the householder consider
WHAT TO DO IN CASE OF FIRE
the use of additional Smoke Alarms for those areas for increased protection.
The additional areas include the basement, bedrooms, dining room, furnace
•
Don't panic; stay calm. Follow your family escape plan.
room, utility room, and hallways not protected by the required Smoke Alarms.
•
Get out of the house as quickly as possible. Don't stop to get dressed or
The installation of Smoke Alarms in kitchens, attics (finished or unfinished),
collect anything.
or garages is not normally recommended, as these locations occasionally
•
Feel doors with the back of your hand before opening them. If a door is
experience conditions that can result in improper operation."
cool, open it slowly. Don't open a hot door. Keep doors and windows
closed, unless you must escape through them.
•
Cover your nose and mouth with a cloth (preferably damp). Take short,
LOCATIONS TO AVOID FOR SMOKE ALARMS
shallow breaths.
For best performance, it is recommended you AVOID installing Smoke
•
Meet at your planned meeting place outside your home, and do a head
Alarms in these areas:
count to make sure everybody got out safely.
•
Where combustion particles are produced. Combustion particles form
•
Call the Fire Department as soon as possible from outside. Give your
when something burns. Areas to avoid include poorly ventilated kitchens,
address, then your name.
garages, and furnace rooms. Keep units at least 20 feet (6 meters) from
the sources of combustion particles (stove, furnace, water heater, space
•
Never go back inside a burning building for any reason.
heater) if possible. In areas where a 20-foot (6-meter) distance is not
•
Contact your Fire Department for ideas on making your home safer.
possible – in modular, mobile, or smaller homes, for example – it is
recommended the Smoke Alarm be placed as far from these fuel-burning
sources as possible. The placement recommendations are intended to
Alarms have various limitations. See "Limitations of Smoke Alarms" for
keep these Alarms at a reasonable distance from a fuel-burning source,
details.
and thus reduce "unwanted" alarms. Unwanted alarms can occur if a
Smoke Alarm is placed directly next to a fuel-burning source. Ventilate
USING THE SILENCE FEATURE
these areas as much as possible.
The Silence Feature can temporarily quiet an unwanted alarm for up to
•
In air streams near kitchens. Air currents can draw cooking smoke into
15 minutes. To use this feature, press the "Push to Test/Silence" button on the
the sensing chamber of a Smoke Alarm near the kitchen.
cover. If the unit will not silence and no heavy smoke is present, or if it
stays in silence mode continuously, it should be replaced immediately.
•
In very damp, humid or steamy areas, or directly near bathrooms with
The LED will continue to flash rapidly while in silence.
showers. Keep units at least 10 feet (3 meters) away from showers,
saunas, dishwashers, etc.
•
Where the temperatures are regularly below 40˚ F (4˚ C) or above 100˚ F
The Silence Feature does not disable the unit—it makes it temporarily
less sensitive to smoke. For your safety, if smoke around the unit is
(38˚ C), including unheated buildings, outdoor rooms, porches, or
unfinished attics or basements.
dense enough to suggest a potentially dangerous situation, the unit will
stay in alarm or may re-alarm quickly. If you do not know the source of
•
In very dusty, dirty, or greasy areas. Do not install a Smoke Alarm directly
the smoke, do not assume it is an unwanted alarm. Not responding to
over the stove or range. Keep laundry room Smoke Alarms free of dust or
an alarm can result in property loss, injury, or death.
lint.
•
Near fresh air vents, ceiling fans, or in very drafty areas. Drafts can blow
SILENCING THE LOW BATTERY WARNING
smoke away from the unit, preventing it from reaching the sensing chamber.
This silence feature can temporarily quiet the low battery warning "chirp" for
•
In insect infested areas. Insects can clog openings to the sensing chamber
up to 8 hours. You can silence the low battery warning "chirp" by pressing the
and cause unwanted alarms.
Test/Silence button on the alarm cover.
•
Less than 12 inches (305mm) away from fluorescent lights. Electrical
Once the low battery warning "chirp" silence feature is activated, the unit
"noise" can interfere with the sensor.
continues to flash the Green light twice a minute for 8 hours. After 8 hours, the
low battery "chirp" will resume. Replace the batteries as soon as possible;
•
In "dead air" spaces. "Dead air" spaces may prevent smoke from reaching
this unit will not operate without battery power!
the Smoke Alarm.
To deactivate this feature: Press the Test/Silence button again. The unit will
Avoiding Dead Air Spaces
go into Test Mode and the low battery warning will resume (LED flashes and
"Dead air" spaces may prevent smoke from reaching the Smoke Alarm.
unit sounds "chirp" once a minute).
To avoid dead air spaces, follow the installation recommendations below.
On ceilings, install Smoke Alarms as close to the center of the ceiling as
LATCHING FEATURES
possible. If this is not possible, install the Smoke Alarm at least 4 inches
Alarm Latch is activated after an Alarm is exposed to alarm levels of smoke.
(102 mm) from the wall or corner.
After smoke levels drop below alarm levels, the "Smoke Red LED will begin to
flash On for 2 seconds/Off for 2 seconds. It will continue to flash or "latch" for
For wall mounting (if allowed by building codes), the top edge of Smoke
Alarms should be placed between 4 and 12 inches (102 and 305 mm) from
about 15 minutes, to give you time to determine which unit initiated the alarm.
the wall/ceiling line, below typical "dead air" spaces.
Low Battery Latch is activated when the Alarm is in the "low battery condition".
When this occurs, the Power LED flashes Green On for 2 seconds/Off for 2
On a peaked, gabled, or cathedral ceiling, install the first Smoke Alarm
seconds for about 15 minutes. This feature is designed to help you identify
within 3 feet (0.9 meters) of the peak of the ceiling, measured horizontally.
which Alarm needs to have the battery replaced. Although, the Alarm will
Additional Smoke Alarms may be required depending on the length, angle, etc.
sound the low battery chirp approximately once every minute, sometimes dur-
of the ceiling's slope. Refer to NFPA 72 for details on requirements for sloped
ing the initial stages of "low battery", the Alarm will chirp in greater intervals
or peaked ceilings.
than one minute, sometimes up to several hours, until the battery reaches a
steady low battery level. This innovative feature eliminates the frustration of
waiting for and/or identifying which unit is chirping.
ABOUT SMOKE ALARMS
Battery (DC) operated Smoke Alarms: Provide protection even when
electricity fails, provided the batteries are fresh and correctly installed. Units
IF YOU SUSPECT A PROBLEM
are easy to install, and do not require professional installation.
Smoke Alarms may not operate properly because of dead, missing or weak
AC powered Smoke Alarms: Can be interconnected so if one unit senses
batteries, a build-up of dirt, dust or grease on the Smoke Alarm cover, or
smoke, all units alarm. They do not operate if electricity fails.
installation in an improper location. Clean the Smoke Alarm as described in
AC with battery (DC) back-up: will operate if electricity fails, provided the
"Regular Maintenance," and install a fresh battery, then test the Smoke Alarm
batteries are fresh and correctly installed. AC and AC/DC units must be
again. If it fails to test properly when you use the test button, or if the problem
installed by a qualified electrician.
persists, replace the Smoke Alarm immediately.
•
If you hear a "chirp" about once a minute, replace the battery.
ONELINK
®
Smoke Alarms with battery (DC) back-up: Interconnects with
all ONELINK
®
enabled Smoke and Smoke/CO Alarms without wires or con-
•
If you experience frequent non-emergency alarms (like those caused
nectors, so when one alarm sounds, they all sound. Will operate if electricity
by cooking smoke), try relocating the Smoke Alarm.
fails, provided the batteries are fresh and correctly installed. Units are easy to
•
If the alarm sounds when no smoke is visible, try cleaning or
install, and do not require professional installation.
relocating the Smoke Alarm. The cover may be dirty.
Smoke Alarms for Solar or Wind Energy users and battery backup power
•
If the alarm does not sound during testing, try installing a new
systems: AC powered Smoke Alarms should only be operated with true or
battery, and make sure it is snapped in securely.
pure sine wave inverters. Operating this Smoke Alarm with most battery-
powered UPS (uninterruptible power supply) products or square wave or
•
If the alarm sounds 3 rapid "chirps" every minute; LED flashes
"quasi sine wave" inverters will damage the Alarm. If you are not sure about
approximately once a minute. MALFUNCTION: the device is not
your inverter or UPS type, please consult with the manufacturer to verify.
working properly and needs to be replaced.
Smoke Alarms for the hearing impaired: Special purpose Smoke Alarms
Do not try fixing the alarm yourself – this will void your warranty!
should be installed for the hearing impaired. They include a visual alarm and
an audible alarm horn, and meet the requirements of the Americans With
If the Smoke Alarm is still not operating properly, and it is still under warranty,
Disabilities Act. Can be interconnected so if one unit senses smoke, all units
please see "How to Obtain Warranty Service" in the Limited Warranty.
alarm.
Smoke alarms are not to be used with detector guards unless the
combination has been evaluated and found suitable for that purpose.
RECOMMENDED LOCATIONS FOR
All these Smoke Alarms are designed to provide early warning of fires if located,
SMOKE ALARMS
installed and cared for as described in the user's manual, and if smoke reaches
Installing Smoke Alarms in Single-Family Residences
them. If you are unsure which type of Smoke Alarm to install, refer to Chapter 2
of the National Fire Protection Association (NFPA) Standard 72 (National Fire
The National Fire Protection Association (NFPA), recommends one Smoke
Alarm Code) and NFPA 101 (Life Safety Code). National Fire Protection
Alarm on every floor, in every sleeping area, and in every bedroom. In new
Association, One Batterymarch Park, Quincy, MA 02269-9101. Local building
construction, the Smoke Alarms must be AC powered and interconnected.
codes may also require specific units in new construction or in different areas
See "Agency Placement Recommendations" for details. For additional cover-
age, it is recommended that you install a Smoke Alarm in all rooms, halls,
of the home.
storage areas, finished attics, and basements, where temperatures normally
remain between 40˚ F (4˚ C) and 100˚ F (38˚ C). Make sure no door or other
obstruction could keep smoke from reaching the Smoke Alarms.
SPECIAL COMPLIANCE CONSIDERATIONS
More specifically, install Smoke Alarms:
•
On every level of your home, including finished attics and basements.
This Smoke Alarm alone is not a suitable substitute for complete fire
•
Inside every bedroom, especially if people sleep with doors closed.
detection systems in places housing many people—like apartment
buildings, condominiums, hotels, motels, dormitories, hospitals, long-
•
In the hall near every sleeping area. If your home has multiple sleeping
term health care facilities, nursing homes, day care facilities, or group
areas, install a unit in each. If a hall is over 40 feet (12 meters) long, install
homes of any kind—even if they were once single-family homes. It is not
an alarm at each end.
a suitable substitute for complete fire detection systems in warehouses,
•
At the top of the first-to-second floor stairway, and at bottom of basement
industrial facilities, commercial buildings, and special-purpose non-resi-
stairway.
dential buildings which require special fire detection and alarm systems.
Depending on the building codes in your area, this Smoke Alarm may be
used to provide additional protection in these facilities.
Specific requirements for Smoke Alarm installation vary from state to state
The following information applies to all four building types below:
and from region to region. Check with your local Fire Department for current
requirements in your area. It is recommended AC or AC/DC units be inter-
In new construction, most building codes require the use of AC or AC/DC
powered Smoke Alarms only. In existing construction, AC, AC/DC, or DC
connected for added protection.
powered Smoke Alarms can be used as specified by local building codes.
Refer to NFPA 101 (Life Safety Code) or NFPA 72 (National Fire Alarm Code),
local building codes, or consult your Fire Department for detailed fire protec-
tion requirements in buildings not defined as "households."
1. Single-Family Residence:
Single family home, townhouse. It is recommended Smoke Alarms be installed
on every level of the home, in every bedroom, and in each bedroom hallway.
2. Multi-Family or Mixed Occupant Residence:
Apartment building, condominium. This Smoke Alarm is suitable for use in
individual apartments or condos, provided a primary fire detection system
already exists to meet fire detection requirements in common areas like
lobbies, hallways, or porches. Using this Smoke Alarm in common areas may
not provide sufficient warning to all residents or meet local fire protection
ordinances/regulations.
3. Institutions:
Hospitals, day care facilities, long-term health care facilities. This Smoke Alarm
is suitable for use in individual patient sleeping/resident rooms, provided a
primary fire detection system already exists to meet fire detection require-
ments in common areas like lobbies, hallways, or porches. Using this Smoke
Alarm in common areas may not provide sufficient warning to all residents or
meet local fire protection ordinances/regulations.
4. Hotels and Motels:
Also boarding houses and dormitories. This Smoke Alarm is suitable for use
inside individual sleeping/resident rooms, provided a primary fire detection
system already exists to meet fire detection requirements in common areas
like lobbies, hallways, or porches. Using this Smoke Alarm in common areas
may not provide sufficient warning to all residents or meet local fire protection
ordinances/regulations.
5
LIMITATIONS OF SMOKE ALARMS
Smoke Alarms have played a key role in reducing deaths resulting from home
fires worldwide. However, like any warning device, Smoke Alarms can only
work if they are properly located, installed, and maintained, and if smoke
reaches them. They are not foolproof.
Smoke alarms may not waken all individuals. Practice the escape plan at
least twice a year, making sure that everyone is involved – from kids to grand-
parents. Allow children to master fire escape planning and practice before
holding a fire drill at night when they are sleeping. If children or others do not
readily waken to the sound of the smoke alarm, or if there are infants or family
members with mobility limitations, make sure that someone is assigned to
assist them in fire drill and in the event of an emergency. It is recommended
that you hold a fire drill while family members are sleeping in order to deter-
mine their response to the sound of the smoke alarm while sleeping and to
determine whether they may need assistance in the event of an emergency.
Smoke Alarms cannot work without power. Battery operated units cannot
work if the batteries are missing, disconnected or dead, if the wrong type of
batteries are used, or if the batteries are not installed correctly. AC units cannot
work if the AC power is cut off for any reason (open fuse or circuit breaker,
failure along a power line or at a power station, electrical fire that burns the
electrical wires, etc.). If you are concerned about the limitations of battery or
AC power, install both types of units.
Smoke Alarms cannot detect fires if the smoke does not reach them.
Smoke from fires in chimneys or walls, on roofs, or on the other side of closed
doors may not reach the sensing chamber and set off the alarm. That is why
one unit should be installed inside each bedroom or sleeping area—especially
if bedroom or sleeping area doors are closed at night—and in the hallway
between them.
Smoke Alarms may not detect fire on another floor or area of the home.
For example, a stand-alone unit on the second floor may not detect smoke
from a basement fire until the fire spreads. This may not give you enough time
to escape safely. That is why recommended minimum protection is at least
one unit in every sleeping area, and every bedroom on every level of your
home. Even with a unit on every floor, stand-alone units may not provide as
much protection as interconnected units, especially if the fire starts in a
remote area. Some safety experts recommend installing interconnected
AC powered units with battery back-up (see "About Smoke Alarms") or
professional fire detection systems, so if one unit senses smoke, all units
alarm. Interconnected units may provide earlier warning than stand-alone
units since all units alarm when one detects smoke.
Smoke Alarms may not be heard. Though the alarm horn in this unit meets or
exceeds current standards, it may not be heard if: 1) the unit is located outside
a closed or partially closed door, 2) residents recently consumed alcohol or
drugs, 3) the alarm is drowned out by noise from stereo, TV, traffic, air conditioner
or other appliances, 4) residents are hearing impaired or sound sleepers. Special
purpose units, like those with visual and audible alarms, should be installed for
hearing impaired residents.
Smoke Alarms may not have time to alarm before the fire itself causes
damage, injury, or death, since smoke from some fires may not reach
the unit immediately. Examples of this include persons smoking in bed,
children playing with matches, or fires caused by violent explosions
resulting from escaping gas.
Smoke Alarms are not foolproof. Like any electronic device, Smoke Alarms
are made of components that can wear out or fail at any time. You must test the
unit weekly to ensure your continued protection. Smoke Alarms cannot prevent
or extinguish fires. They are not a substitute for property or life insurance.
Smoke Alarms have a limited life. The unit should be replaced immediately
if it is not operating properly. You should always replace a Smoke Alarm after
10 years from date of purchase. Write the purchase date on the space provided
on back of unit.
LIMITED WARRANTY
BRK Brands, Inc., ("BRK") the maker of First Alert
®
brand products warrants
that for a period of ten years from the date of purchase, this product will be
free from defects in material and workmanship. BRK, at its option, will repair
or replace this product or any component of the product found to be defective
during the warranty period. Replacement will be made with a new or re-
manufactured product or component. If the product is no longer available,
replacement may be made with a similar product of equal or greater value.
This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial
retail purchase and is not transferable. Keep the original sales receipt. Proof
of purchase is required to obtain warranty performance. BRK dealers, service
centers, or retail stores selling BRK products do not have the right to alter,
modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from
any of the following: negligent use or misuse of the product, use on improper
voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than BRK or an authorized service center.
Further, the warranty does not cover Acts of God, such as fire, flood, hurricanes
and tornadoes or any batteries that are included with this unit.
BRK shall not be liable for any incidental or consequential damages caused by
the breach of any express or implied warranty. Except to the extent prohibited
by applicable law, any implied warranty of merchantability or fitness for a
particular purpose is limited in duration to the duration of the above warranty.
Some states, provinces or jurisdictions do not allow the exclusion or limitation
of incidental or consequential damages or limitations on how long an implied
warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights that vary from state to state or province to province.
How to Obtain Warranty Service
Service: If service is required, do not return the product to your retailer.
In order to obtain warranty service, contact the Consumer Affairs Division at
1-800-323-9005, 7:30 AM - 5:00 PM Central Standard Time, Monday through
Friday. To assist us in serving you, please have the model number and date of
purchase available when calling.
For Warranty Service return to:
BRK Brands, Inc., 25 Spur Drive, El Paso, TX 79906
Battery: BRK Brands, Inc. make no warranty, express or implied, written or
oral, including that of merchantability or fitness for any particular purpose with
respect to battery.
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Fire Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Install This Smoke Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Step By Step Guide To Programming This Alarm . . . . . . . . . . . . . . . . . . . .2
ONELINK
®
Alarm Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
What You Will See and Hear With This Alarm . . . . . . . . . . . . . . . . . . . . .2
Wireless Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
How To Install This Smoke Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Optional Locking Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Weekly Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
If This Smoke Alarm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
What To Do In Case Of Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using the Silence Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Silencing the Low Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Latching Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
If You Suspect A Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Recommended Locations For Smoke Alarms . . . . . . . . . . . . . . . . . . . . .5-6
Agency Placement Recommendations . . . . . . . . . . . . . . . . . . . . . . . . .6
Locations To Avoid For Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
About Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Special Compliance Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Limitations Of Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
First Alert
®
is a registered trademark of the First Alert Trust used under license.
ONELINK
®
is a registered trademark of BRK Brands, Inc.
Printed in Mexico M08-0194-000 Q 01/07
6
7
STEP BY STEP GUIDE TO PROGRAMMING
USER'S MANUAL
THIS ALARM
ONELINK
®
BATTERY
FOR FIRST TIME AND WHEN CHANGING BATTERIES
OPERATED SMOKE ALARM
Action:
Features:
1. Insert batteries (2, AA batteries).
ONELINK
®
Enabled
Voice with Programmable Location
Two Latching Features
Optipath 360 Technology
TM
Two Silence Features
2. Press & Hold Test Button if
you would like to program the
location or change the location of
the Alarm. Release button after
Alarm responds.
3. After you hear the location of
where you are placing the Alarm,
Press & Hold the Test Button.
UL STANDARD 217
Your Alarm has now been programmed for the location of your choice.
Available locations:
3055574
Model SA511
Basement
Living Room
Family Room
Printed in Mexico
Office
M08-0194-000 Q 01/07
ADDING AND LINKING ADDITIONAL ONELINK
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
NOTE: Steps 1 through 3 below need to be completed within two
This user's manual contains important information about your Smoke Alarm's
minutes. If more than two minutes pass, the Green power LED will
operation. If you are installing this Smoke Alarm for use by others, you must
stop blinking. Simply open the battery drawer of the second Alarm
leave this manual—or a copy of it—with the end user.
and repeat steps 1 through 3.
1. Insert the batteries into the battery
INTRODUCTION
drawer of the next Alarm.
DO NOT CLOSE THE DRAWER.
Thank you for choosing First Alert
®
for your Smoke Alarm needs. You have
purchased a state-of-the-art Smoke Alarm designed to provide you with early
2. Press and hold the test button and
warning of a fire. Key features include:
then close the battery drawer.
ONELINK
®
Enabled. Alarm automatically communicates with other ONELINK
®
3. Once you hear the unit chirp, release
enabled alarms when installed.
the test button. The Green power
LED will start to blink indicating the
Exclusive Voice Warning with Location will tell you the preprogrammed
ONELINK
®
Alarm is waiting for program data
location of the initiating unit and danger detected. Programmable up to 11
from one of the other setup ONELINK
locations (ex. "basement"). When alarms sounds, if programmed for basement
it will say "Warning, evacuate, smoke in basement" along with all other
4. Press and hold the test button on the first Alarm, until the second Alarm
installed ONELINK
®
Voice alarms.
chirps and its Green power LED stops blinking. Then release the test button.
Spread Spectrum Horn Tone. Lower and varying horn frequency makes it
5. If you purchased a Talking Smoke Alarm, you will now be prompted to set
easier for elderly with normal age related hearing loss to hear horn. Sweeps
the Alarm's location. Follow the directions given by the Alarm.
through the 2200 – 3400 Hz range.
6. If you have purchased the hardwired battery back-up ONELINK
RF Interconnect. Reliable and secure radio frequency communication
you can now connect the hardwired Alarm by installing the three-wire
between alarms. 915MHz frequency with 65,000 security codes and 3 channel
connector on the ceiling to the Alarm.
frequency hopping.
7.
Repeat steps 1-6 for additional ONELINK
Optipath 360 Technology
TM
provides 360 degrees of direct access to the
smoke sensor.
You have now successfully linked your new ONELINK
Single Button Test/Silence eliminates confusion. Depending on what mode
additional Alarms at a later time, follow steps 1 through 6.
the alarm is in, pushing the button provides different functions such as testing
the alarm, silencing the alarm, re-testing the alarm when in silence and clearing
the Latching features.
WHAT YOU WILL SEE AND HEAR WITH THIS ALARM
Two Silence Features. Temporarily silence low battery chirp for up to eight
hours before replacing low battery or silence an unwanted alarm for several
Under Normal Operations
minutes.
Voice: Silent
Two Latching Features. Alarm Latch: Easily identifies initiating alarm even
Horn: Silent
after alarm condition has subsided. Low Battery Latch: Identifies which unit is
Power LED: Flashes Green once/minute
in low battery condition.
Perfect Mount System includes a gasketless base for easy installation and a
When You Test the Alarm
mounting bracket that keeps the alarm secure over a wide rotation range to
Voice: "Testing." Horn: 3 beeps, pause, 3 beeps; Voice: "Warning,
allow for perfect alignment.
evacuate smoke in [Location, example: "Basement"]. Evacuate."
Smoke LED: Flashes Red in sync with the horn pattern
© 2007 BRK Brands, Inc., a Subsidiary of Jarden Corporation
All rights reserved.
If Battery Becomes Low or is Missing
BRK Brands, Inc., 3901 Liberty Street Road, Aurora, IL 60504-8122
Voice: "Replace battery in [Location, example "Basement"]."
Consumer Affairs: (800) 323-9005 • www.firstalert.com
Repeated every 5 hours
Horn: chirps once a minute
*All First Alert
®
Smoke Alarms conform to regulatory requirements,
Power LED: Flashes Green On for 2 seconds/Off for 2 seconds.
including UL217 and are designed to detect particles of combustion.
Low Battery Latch is now engaged.
Smoke particles of varying number and size are produced in all fires.
If Alarm is Not Operating Properly (MALFUNCTION SIGNAL)
Ionization technology is generally more sensitive than photoelectric
technology at detecting small particles, which tend to be produced in
Voice: "Detector error in [Location, example "Basement"], please see
greater amounts by flaming fires, which consume combustible materials
manual." Repeated every 5 hours
rapidly and spread quickly. Sources of these fires may include paper burning in
Horn: Three rapid chirps every minute
a wastebasket, or a grease fire in the kitchen.
Smoke LED: Flashes approximately once a minute
Photoelectric technology is generally more sensitive than ionization
technology at detecting large particles, which tend to be produced in
Smoke is Detected
greater amounts by smoldering fires, which may smolder for hours
Horn: 3 beeps, pause, repeating 3 times
before bursting into flame. Sources of these fires may include cigarettes
Voice: "Warning, evacuate smoke in [Location, example: "Basement"].
burning in couches or bedding.
Evacuate."
For maximum protection, use both types of Smoke Alarms on each level
Smoke LED:
and in every bedroom of your home.
During Alarm: Flashes Red in sync with the horn pattern.
After Alarm: Flashes Red On for 2 seconds/Off for 2 seconds.
Smoke Alarm Latch is now engaged.
FIRE SAFETY TIPS
Smoke Alarm is Silenced
Follow safety rules and prevent hazardous situations:
Horn: Off
1) Use smoking materials properly. Never smoke in bed. 2) Keep matches or
lighters away from children; 3) Store flammable materials in proper containers;
Smoke LED: Flashes Red
4) Keep electrical appliances in good condition and don't overload electrical
circuits; 5) Keep stoves, barbecue grills, fireplaces and chimneys grease-
and debris-free; 6) Never leave anything cooking on the stove unattended;
7) Keep portable heaters and open flames, like candles, away from flammable
WIRELESS OPERATION
materials; 8) Don't let rubbish accumulate.
Keep alarms clean, and test them weekly. Replace alarms immediately if they
First Alert
®
ONELINK
®
Technology is the easy, cost-effective way to provide
are not working properly. Smoke Alarms that do not work cannot alert you to a
your family with whole-home safety. All ONELINK
fire. Keep at least one working fire extinguisher on every floor, and an additional
each other without wires or connectors. When one Alarm sounds, they all
one in the kitchen. Have fire escape ladders or other reliable means of escape
sound. This provides your family with an earlier warning of potential danger,
and gives you more time to react.
from an upper floor in case stairs are blocked.
The communication distance (range) between any two ONELINK
BEFORE YOU INSTALL THIS SMOKE ALARM
typically 50 feet (15 meters) inside of a home. Some features of a home, such
as the number of floors, number/size of rooms, furniture and types of building
Important! Read "Recommended Locations for Smoke Alarms" and "Locations
materials used may reduce the range of the Alarms.
to Avoid for Smoke Alarms" before beginning. This unit monitors the air, and
Examples include: suspended ceilings, ductwork, large metallic appliances
when smoke reaches its sensing chamber, it alarms. It can give you more time
(refrigerators) and metal studs. A feature of ONELINK
to escape before fire spreads. This unit can ONLY give an early warning of
operate as a mesh network. All Alarms will repeat any alarm signal that is
developing fires if it is installed, maintained and located where smoke can
received to all other ONELINK
reach it, and where all residents can hear it, as described in this manual. This
can be overcome by adding additional Alarms to route the wireless signal
unit will not sense gas, heat, or flame. It cannot prevent or extinguish fires.
around obstructions.
Understand The Different Type of Smoke Alarms
Battery powered or electrical? Different Smoke Alarms provide different
•
The range and proper operation of any wireless device will vary
types of protection. See "About Smoke Alarms" for details.
depending on its surroundings. It is very important that each Alarm is
tested individually before and after installation to make sure that all
Know Where To Install Your Smoke Alarms
Alarms respond properly.
Fire Safety Professionals recommend at least one Smoke Alarm on every
level of your home, in every bedroom, and in every bedroom hallway or
•
The ONELINK
®
Alarms are not to be used outdoors or to transmit
separate sleeping area. See "Recommended Locations For Smoke Alarms"
between buildings. The Alarms will not communicate properly under
and "Locations To Avoid For Smoke Alarms" for details.
these conditions.
Know What Smoke Alarms Can and Can't Do
•
Metal objects and metallic wallpaper may interfere with signals from
A Smoke Alarm can help alert you to fire, giving you precious time to
wireless Alarms. Alarms should be tested after changes to your home
escape. It can only sound an alarm once smoke reaches the sensor.
such as remodeling, moving furniture, and with metal doors opened
See "Limitations of Smoke Alarms" for details.
and closed.
Check Your Local Building Codes
Your First Alert
®
ONELINK
®
Smoke Alarm will automatically communicate
This Smoke Alarm is designed to be used in a typical single-family home.
potential fires with all other First Alert
It alone will not meet requirements for boarding houses, apartment buildings,
FCC NOTICE: This device complies with Part 15 of the FCC Rules.
hotels or motels. See "Special Compliance Considerations" for details.
Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC ID: M7U5001L
•
This unit will not alert hearing impaired residents. It is recommended
that you install special units which use devices like flashing strobe
lights to alert hearing impaired residents.
Changes or modifications not expressly approved by BRK Brands, Inc.
•
Do not connect this unit to any other alarm or auxiliary device.
could void the user's authority to operate the equipment.
It is a single-station unit that cannot be linked to other devices.
Connecting anything else to this unit may prevent it from working
properly.
•
Unit will not operate without battery power. The Smoke Alarm
cannot work until you install the batteries in the correct position
(Match "+" to "+" and "-" to "-").
•
This Smoke Alarm has a battery drawer which resists closing
unless batteries are installed.
•
Do not install this unit over an electrical junction box. Air currents
around junction boxes can prevent smoke from reaching the sensing
chamber and prevent the unit from alarming. Only AC powered units
are intended for installation over junction boxes.
•
Do not stand too close to the unit when the alarm is sounding.
It is loud to wake you in an emergency. Exposure to the horn at
close range may harm your hearing.
•
Do not paint over the unit. Paint may clog the openings to the
sensing chamber and prevent the unit from operating properly.
1
HOW TO INSTALL THIS SMOKE ALARM
THE PARTS OF THIS SMOKE ALARM
Alarm Will Say:
1. Test/Silence button
"Welcome, First Alert Smoke Alarm."
"No location programmed" if first
2. Battery drawer
time or "[Location, example:
3. Power indicator LED
"Basement"] location programmed"
when changing batteries.
4. Smoke Alarm LED
"To select location, press and hold
test button now."
"To save location, press and hold
test button after location is heard."
TOOLS YOU WILL NEED:
Alarm will speak list of locations
(see below).
This unit is designed to be mounted
on the ceiling, or on the wall if necessary.
• Pencil
• Hammer
"[Location, example: "Basement"]
• Drill with 3/16" (5 mm) drill bit
• Pliers to activate optional
location saved."
"tamper-resistant" locking
• Phillips screwdriver
If no location is chosen:
features
"No location saved."
Kitchen
Child's Bedroom
If you want to lock the battery drawer, or lock the Smoke Alarm to the
Dining Room
Master Bedroom
mounting bracket, please read the "Optional Locking Features" section
No Location
Guest Bedroom
before you begin installation.
Hallway
Utility Room
®
ALARMS
The optional locking features are designed to prevent unauthorized removal of the battery or alarm. It is not necessary to activate the locks in
single-family households where unauthorized battery or alarm removal is not a concern.
These Smoke Alarms have two separate locking features: one to lock the battery compartment, and the other to lock the
Smoke Alarm to the mounting bracket. You can choose to use either feature independently, or use them both.
Tools you will need: • Needle-nose pliers • Standard flathead screwdriver.
Both locking features use locking pins, which are molded into the mounting bracket. Depending on which locking features you
use, remove one or both pins from the mounting bracket using needle-nose pliers.
To permanently remove either locking pin, insert a flathead screwdriver between the locking pin and the lock, and pry
the pin out of the lock.
®
Alarms.
TO LOCK THE BATTERY COMPARTMENT
Do not lock the battery compartment until you install the batteries and
test the Smoke Alarm.
®
Alarm,
If the unit does not alarm during testing,
DO NOT lock the battery compartment!
®
Alarms.
Install new batteries and test again. If the
Smoke Alarm still does not alarm, replace it
®
Alarms. To add
immediately.
1. Using needle-nose pliers, detach one
locking pin from the mounting bracket.
2. After batteries are inserted, then push
the locking pin through the hole near the
battery door latch on the back of the
Smoke Alarm.
TO LOCK THE MOUNTING BRACKET
1. Using needle-nose pliers, detach one
locking pin from the mounting bracket.
2. Insert the locking pin through the hole on
the back of the Smoke Alarm as shown in
the diagram.
3. When you attach the Smoke Alarm to the
mounting bracket, the locking pin's head
will fit into a notch on the bracket.
•
NEVER use an open flame of any kind to test this unit. You might
accidentally damage or set fire to the unit or to your home. The
built-in test switch accurately tests the unit's operation as required
by Underwriters Laboratories, Inc. (UL).
•
If the Alarm ever fails to test properly, replace it immediately.
Products under warranty may be returned to the manufacturer for
replacement. See "Limited Warranty" for details.
•
DO NOT stand close to the alarm when the horn is sounding.
Exposure at close range may be harmful to your hearing. When
testing, step away when horn starts sounding.
®
Alarms communicate with
®
Alarms is
This unit has been designed to be as maintenance free as possible, but there
are a few simple things you must do to keep it working properly.
Use only the replacement batteries listed below. The unit may not
®
Alarms is that they
operate properly with other batteries. Never use rechargeable batteries
since they may not provide a constant charge.
®
Alarms. Interference from structural conditions
•
Test it at least once a week.
•
Clean the Smoke Alarm at least once a month; gently vacuum off any
dust using your household vacuum's soft brush attachment, and test the
Smoke Alarm after cleaning. Never use water, cleaners or solvents since
they may damage the unit.
•
If the Smoke Alarm becomes contaminated by excessive dirt, dust and/or
grime, and cannot be cleaned to avoid unwanted alarms, replace the unit
immediately.
•
Relocate the unit if it sounds frequent unwanted alarms. See "Locations to
Avoid For Smoke Alarms" for details.
•
When the battery becomes weak, the Smoke Alarm unit will "chirp"
approximately once a minute (the low battery warning). This low battery
warning should last for up to 30 days, but you should replace the battery
immediately to continue your protection.
®
ONELINK
®
Smoke Alarms.
2
3
FOLLOW THESE SIMPLE STEPS!
1. Hold base firmly and twist the mounting bracket counterclockwise to
separate it from the base.
2. Hold the mounting bracket against the ceiling (or wall) so the vertical
mounting slot is aligned in the 12 o'clock position and trace around the
inside of the mounting slots (vertical and horizontal mounting).
3. Put the unit where it won't get covered with dust when you drill the
mounting holes.
4. Using a 3/16" (5 mm) drill bit, drill a hole through the center of the oval
outlines you traced.
5. Insert the plastic screw anchors (in the plastic bag with screws) into the
holes. Tap the screw anchors gently with a hammer, if necessary, until
they are flush with the ceiling or wall.
6. Line the mounting bracket up
over the plastic screw anchors.
7.
Screw the mounting bracket to
the ceiling or wall through the
mounting slots using the two
screws provided.
8. Attach the Smoke Alarm to the mounting bracket. Line up the guides on
the alarm's base with the guides on the mounting bracket. When guides
are lined up, turn the base clockwise (right) until it snaps into place.
NOTE: Once the Smoke Alarm is snapped onto the mounting
bracket, you can rotate the Smoke Alarm to adjust the alignment.
9. Test the Smoke Alarm. See "Weekly Testing."
OPTIONAL LOCKING FEATURES
TO UNLOCK THE BATTERY COMPARTMENT
1. Remove the Smoke Alarm from the
mounting bracket. If the unit is locked to
the bracket, see the section "To Unlock
the Mounting Bracket."
2. Insert a flathead screwdriver under the
head of the locking pin, and gently pry
it out of the battery compartment lock.
(If you plan to relock the battery
compartment, save the locking pin.)
3. To relock the battery compartment,
close the battery door and reinsert
locking pin in lock.
4. Reattach the Smoke Alarm to the
mounting bracket.
When replacing the batteries, always test
the Smoke Alarm before relocking the
battery compartment.
TO UNLOCK THE MOUNTING BRACKET
1. Insert a flathead screwdriver into the
rectangular cut-out on the mounting
bracket nearest to the locking pin.
2. Pry the Smoke Alarm away from
the bracket by pushing up on the
screwdriver and turning the Smoke
Alarm counterclockwise (left) at the
same time.
WEEKLY TESTING
It is important to test this unit every week to make sure it is working
properly. Using the test button is the recommended way to test this Smoke
Alarm. Press and hold the test button on the cover of the unit until the alarm
sounds (the unit may continue to alarm for a few seconds after you release
the button). If it does not alarm, make sure the unit is receiving power (LED
will flash approximately once a minute indicating it has power); and test it
again. If it still does not alarm, replace it immediately. During testing you will
hear a loud, repeating horn pattern: 3 beeps, pause, 3 beeps, pause.
REGULAR MAINTENANCE
Choosing a replacement battery:
Your Smoke Alarm requires 2 "AA" Energizer E91 batteries. These batteries
are available at many local retail stores.
Actual service life depends on the Smoke Alarm and the environment in which
it is installed. All the batteries specified above are acceptable replacement
batteries for this unit. Regardless of the manufacturer's suggested battery life,
you MUST replace the battery immediately once the unit starts "chirping" (the
"low battery warning").
To replace the batteries (without removing Alarm from the ceiling
or wall):
1. Open the battery compartment.
2. Press tabs A and B as shown in the
diagram and remove each battery.
3. Insert the new batteries, making sure
they snap completely into the battery
compartment. Match the terminals
A B
on the ends of the batteries with the
terminals on the unit.
4. Close the battery compartment, and
then test the unit by pressing the
Test/Silence button.
4
Advertisement
