Summary of Contents for Jefferson Professional Tools & Equipment JEFWASE360-120
- Page 1 User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer User Manual v.1.2 120Bar • 1400W High Pressure Washer JEFWASE360-120 www.jeffersontools.com...
-
Page 3: General Safety Guidelines
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer Never use the appliance to clean objects containing hazardous substances (e.g. asbestos). 1. Introduction Be careful when cleaning vehicle tyres and tyre valves as these can be damaged by the high pressure jet and may burst if used incorrectly. -
Page 4: Specifications
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 3. Specifications Model Number JEFWASE360-120 Maximum Pressure 120bar (1750psi / 13.0MPa) Rated Pressure 100bar (1450psi / 10.0MPa) Effective Cleaning Power 205bar (2975psi / 20.7Mpa) Water Flow: 360L/Hr - 6.0L/Min... -
Page 5: Connecting The High Pressure Hose
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 4. Set-Up Connecting To The Water Supply Use a reinforced hose pipe with an internal diameter of 1/2" when connecting to the mains supply. Ensure that the hose is clean before connecting to the pressure washer by flushing out with clean water. -
Page 6: Operation
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer Release the handle safety catch and point the 5. Operation lance at the cleaning area and pull the trigger to release the jet. 1. Initial Checks Note: The Total Stop System (TSS) ensures... -
Page 7: Maintenance
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 6. Maintenance Warning: Turn off the appliance and remove the mains plug prior to carrying out any maintenance work. Ensure that nozzles are kept clean and free from dirt, grease & debris. - Page 8 User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 8a. Parts Diagram www.jeffersontools.com...
- Page 9 User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 8b. Parts List Description Description Right Sequin Power Cord Binder Plate Front Cover Hook Left Sequin Back Cover Base Cross Recessed Pan Head Screw Self-Tapping Screw Spring Pad Power Switch...
-
Page 10: Circuit Diagram
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer 9. Circuit Diagram www.jeffersontools.com... -
Page 11: Ec Declaration Of Conformity
Low Voltage Directive: 2004/108/EC (as amended) EMC Directive: Equipment Category: Electric Pressure Washer JEFWASE360-120 • 120Bar High Pressure Washer (1400w) Product Name/Model: The conformity assessment procedure followed was in accordance with Annex V of the Outdoor Noise Directive. Notified Body: SNCH Luxembourg GmbH. -
Page 12: Limited Warranty Statement
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer Limited Warranty Statement Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be free of defects in workmanship or material. Jefferson shall, upon suitable notification, correct any defects, by repair or replacement, of any parts or components of this product that are determined by Jefferson to be faulty or defective. -
Page 13: Warranty Limitations
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer Warranty Limitations Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers. Jefferson's liability under this warranty will not exceed the cost of correcting the defect of the Jefferson products. -
Page 14: Parts & Servicing
User Manual v.1.2 JEFWASE360-120 120Bar • 1400W - High Pressure Washer Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the customer (normally within 7 working days). Note: If the repair quotation is not accepted Jefferson Professional Tools &... - Page 16 IMPORTANT! SAFETY FIRST! Before attempting to use this product please read all the safety precautions and operating instructions outlined in this manual to reduce the risk of fire, electric shock or personal injury. This product must not be disposed with normal household waste. Jefferson Tools, Herons Way, Chester Business Park,...
