CROMMELINS™ PRESSURE CLEANERS
OPERATION & INSTRUCTION MANUAL
Thank you for your selection of a CROMMELINS™ Pressure Cleaner.
This Operation Manual explains its use, installation, checking and maintenance.
We highly recommend that you retain this manual for ready reference regarding
proper handling of the CROMMELINS™ Pressure Cleaner.
WA Metro 9350 5588
East Coast 1300 650 659
1
WA Regional 1800 655 588
sales@crommelins.com.au
Advertisement
Related Manuals for Crommelins CPV Series
Summary of Contents for Crommelins CPV Series
- Page 1 CROMMELINS™ PRESSURE CLEANERS OPERATION & INSTRUCTION MANUAL Thank you for your selection of a CROMMELINS™ Pressure Cleaner. This Operation Manual explains its use, installation, checking and maintenance. We highly recommend that you retain this manual for ready reference regarding proper handling of the CROMMELINS™ Pressure Cleaner.
-
Page 2: Table Of Contents
Thank you very much for purchasing a CROMMELINS™ PRESSURE CLEANER. This manual covers the operation and maintenance of the CROMMELINS™ PRESSURE CLEANER. Please take a moment to familiarise yourself with the proper operation and maintenance procedures to maximise the safe and efficient use of this product. - Page 3 SAFETY This manual contains important information on how to use the CPV and CPC Series Pressure Cleaners properly and safely. Please read through this manual before you attempt to operate this product. Ensure safe operation, this pressure cleaner is designed to give safe and dependable service if operated according to the instructions.
- Page 4 SAFETY PRECAUTIONS • NEVER point the spray gun at people, animals or plants. • NEVER put your hand or fingers over the spray tip. • NEVER try to stop or deflect leaks with your hand or body. • NEVER purchase and use chemicals or detergents that are toxic, flammable or high acidic/alkaline base, and always request a material safety data sheet (MSDS) for the product you are purchasing.
- Page 5 ENGINE PRECAUTIONS WARNING! Read engine owners/operators manual before using or attempting to service this machine. • DO NOT fill fuel tank while engine is running. Allow engine to cool before refuelling. • DO NOT operate the engine when an odour of fuel is present, or other explosive conditions exist.
-
Page 6: Pre-Operation Check List
PRE-OPERATION CHECK LIST • Be sure you understand all the safety precautions and have been instructed in the safe use of the machine. • Wear face, feet and eye protection to prevent injury from spray and flying debris. • Wear protective gloves, rubber boots, and other protective clothing as required. •... -
Page 7: Operation Instructions
Do not let the rope snap back) For high pressure spraying CPV Series – Select desired spray pattern (0°,15°, 40° or BLACK detergent nozzle). DO THIS ONLY WHEN THE TRIGGER IS NOT SQUEEZED AND THE GUN SAFETY LOCK IS ON. -
Page 8: Shutdown Instructions / Checks & Maintenance
OPERATION INSTRUCTIONS cont... You are now ready to start cleaning with your pressure cleaner. Hold the spray gun firmly and squeeze the trigger. Always begin high pressure cleaning with the nozzle at least 1 metre from the object being cleaned and gradually move the nozzle closer to the object until it is cleaned. - Page 9 SHUTDOWN INSTRUCTIONS cont..Turn off the water supply and remove the water supply hose from the pump. Pull the gun trigger to release any built up pressure (make sure you do not spray people or objects.) Disconnect the pressure hose from the pump and gun and store on the hooks provided on the trolley.
- Page 10 CPV SERIES PETROL SPECIFICATION CHART MODEL CPV2700X21 CPV3200X27 CPV4000X40 Pressure PSI max 2700 3200 4000 Bar (max) Water Flow (L/min max) 11.4L 14.0L 15.0L Water Flow (L/hr max) 684L 840L 840L Water Pump Triplex Triplex Triplex Fuel Type Petrol Petrol...
- Page 11 CPC SERIES DIESEL SPECIFICATION CHART MODEL CPC2000YDE CPC3000YDE Pressure PSI max 2000 3000 Bar (max) Water Flow (L/min max) Water Flow (L/hr max) 720L 900L Water Pump Triplex Triplex Fuel Type Diesel Diesel Engine Make Yanmar Yanmar Engine 4.7hp L48 10.0hp L100 Starting System Electric Start...
-
Page 12: Trouble Shooting
TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION 1. Turn engine switch to ON 1. Engine switch in OFF Engine won’t start position position 2. Turn throttle lever to ON 2. Throttle lever on/off position switch in OFF position 3. Fill fuel tank or turn on fuel 3. - Page 13 2. Blocked spray nozzle 2. Remove and clean nozzle tip CPV SERIES 1. High pressure nozzle 1. Fit black detergent nozzle No low pressure on wand detergent delivery 2. Syphon hose or hose 2.
- Page 14 TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION CPC SERIES 1. Twin lance not set to 1. Loosen off black side handle No low pressure low pressure to low pressure flow detergent delivery 2. Syphon hose or hose 2. Clean or unblock hose and filter blocked filter 3.
-
Page 15: Warranty (Faq)
A. Have you checked the nozzle for excessive wear? A. Check nozzle for blockages WARRANTY Consult the CROMMELINS Machinery warranty leaflet (supplied with your new product) for full details and a list of service dealers for this product, also available online at www.crommelins.com.au. - Page 16 SPARE PARTS & SERVICE Parts Hotline: 1300 554 524 Freecall Fax: 1800 636 281 spareparts@crommelins.com.au www.crommelins.com.au...
