- Page 1 SLSPSKT200 2 Pcs. Portable Mono Solar Panel Starter Kit 100W with 3 ft. 11AWG Cable Set and 30A PWM Controller with LCD Screen...
-
Page 2: Safety Precautions
Please read the manual carefully before installing or operating the Portable Mono Solar Panel Starter Kit to prevent personal injury or damage to the components. Contact Technical support for any questions concerning the installation. INTRODUCTION This manual provides the installation and operation instructions for users: •... -
Page 3: Packing List
PACKING LIST Mounting brackets Wire xer Controller *2set *10pcs 30A*1pc 100W Solar Panel A *1 100W Solar Panel B *1 Extension lead Fuse Battery lead 11AWG * 20ft 15A*1pc 11AWG * 8ft INSTALLATION WITH ROOF RACK Z-shape bracket Double nut Ø8 Bolt (M8*16) *4pcs aluminum plate... - Page 4 Step1: The connection of solar panel and Z-shape bracket. INSTALLING HOLE Step2: Connection of Z-shape bracket, double nut aluminum plate and roof rack. Roof Rack www.SereneLifeHome.com...
-
Page 5: Application Cases
Step3: System Wiring as follows 100W Solar Panel A *1 100W Solar Panel B *1 See controller manual P6-P8 Controller Fuse Battery Output INSTALLATION WITHOUT ROOF RACK Refer to the above installation guide, and double nut plate are not used. APPLICATION CASES Our solar system can be widely used in RV, 4WD, tourist car, yacht and roof power generation system, etc. -
Page 6: Maintenance
MAINTENANCE • Solar panels are generally self-cleaning, but in particularly dry areas or where panel tilt is minimal, dust and other substances such as bird droppings can build up over time and impact on the electricity amount generated by the panels. Clean the panel surface with a soft cloth or sponge using clean and neutral water. -
Page 7: Controller Manual
CONTROLLER MANUAL SAFETY INSTRUCTIONS • This controller is a 12V/24V controller. Make sure your battery has enough voltage (12V/24V) for the controller to identify the correct battery type before rst installation. • Install the controller as close as possible to the battery to avoid voltage drop caused by long wire and a ect normal voltage judgment. -
Page 8: System Connection
MENU: Switch between di erent interface, or to enter/exit parameter setting by pressing and hold. Press to increase value DOWN: Press to decrease value SYSTEM CONNECTION • Connect the battery to the controller with the correct polarity. • Connect the solar module to the controller with the correct polarity. •... - Page 9 Charging current interface. Discharging current interface. Charging voltage adjustment interface. When the battery voltage rises to the set voltage, it will maintain constant voltage charging. Press and hold the MENU key to make the number icker, and press UP/DOWN to the required voltage, then long press MENU key to exit. Low-voltage recovery adjustment interface.
- Page 10 D2D trigger delay value (Unit: second) When the controller detects that the voltage of solar panel is lower than the set trigger value, it delays 10S to turn on the load. This time value can be used to prevent the night car lights or lightning interference leading to wrong judgment and turn o the lights.
- Page 11 Why won't my solar panel display charging when connected? A: Check whether the connection of solar panels is correct, whether there is reverse connection, whether the voltage of solar panels is higher than that of batteries, and whether solar panels are blocked that causes voltage drop. Under normal circumstances, 12V batteries should use solar panels with rated voltage of 18V.
-
Page 12: Technical Parameter
TECHNICAL PARAMETER • All grey color voltage X2, while using 24V system. • Product speci cations are subject to change without prior notice. What's in the Box: • (2) 100W Mono Solar Panel • (2) Sets of Mounting Brackets • (10) Wire Fixers •... - Page 13 Features: • Includes 30A PWM Controller with LCD Screen • Portable and Easy Set-Up • Sleek Design for Aesthetic Quality • Grade A Mono Solar Cells • Higher Module Conversion E ciency • Optimally Generate about 67Ah in 12V Battery or 800WH per Day •...
- Page 14 Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
