uniqjazz Wireless Speaker
To understand correct operating of the speaker, please read this manual
carefully before using. Any content revise of the manual invalidates it. We are
not responsible for consequence caused by faulty usage or oversight of this
manual.

Features

1.
1.1CH outdoor Bluetooth Speaker with 4 inch subwoofer;
2.
Output very clear sound and dynamic sound effect;
3.
With A2DP Bluetooth, wireless stream music from any Bluetooth-enabled device
such as your mobile phone, notebook, iPhone or iPad;
4.
Secure simple pairing for user-friendly operating;
5.
10 meters operating range;
6.
With USB & Micro SD card supporting;
7.
With FM radio;
8.
With Line-in function, suitable for PC, MID, TV and other audio device;
9.
Built-in lithium rechargeable battery 1800mAh;
10.
With handle, easy to take out;

Specification

Bluetooth version:
Bluetooth range:
Tweeter Size:
Subwoofer Size:
Tweeter output:
Subwoofer output:
Power supply:
Recharge power:
Product size:
USER GUIDE
5.0 Support A2DP and AVRCP profile
up to 10 meters
2 inch
4 inch
1W, 4Ω
25W, 4Ω
3.5mm jack connection
Built-in rechargeable lithium battery 1800mAh
DC 5V 1A
352(W)*134(H)*180(L)MM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNIJAZZ and is the answer not in the manual?

Questions and answers

Summary of Contents for Uniq Surround UNIJAZZ

  • Page 1 USER GUIDE uniqjazz Wireless Speaker To understand correct operating of the speaker, please read this manual carefully before using. Any content revise of the manual invalidates it. We are not responsible for consequence caused by faulty usage or oversight of this manual.
  • Page 2 Control Panel Play/Pause(short press)/ On/Off button (Long press Backward(short press)/ volume up ( Long press) Forward(short press)/ volume down ( Long press) Mode (Switch Wireless, USB ,FM and AUX-IN )/TWS (Long press) Charging jack Wired microphone input USB port AUX-IN 3.5mm jack Playing music from USB disk Long press“Play/Pause”...
  • Page 3 AUX-IN For other compatible music devices or your MP3/MP4 players, use the supplied audio line cable to connect from the device’s “Line Out” to the “Aux In” of this devices. Then press the “M” button to switch to AUX-IN state. When using an external device, all functions will be controlled by the external devise except the “Play/Pause”...
  • Page 4 For your own safety, please do not open this speaker for any reason. Please do not use the product if any part of it is damaged. For more information about UNIQJazz(EAN: 8719273157145), please contact UNIQ Surround using the following contact information:...
