shopPOPdisplays 14100 Assembly Instructions

Adjustable Floor Standing Sneeze Guard
ASSEMBLY INSTRUCTIONS
PARTS LIST:
Divider
Panel
(1 pc)
*TWO PERSON ASSEMBLY RECOMMENDED
*TOOLS REQUIRED: PHILLIPS HEAD SCREWDRIVER (NOT INCLUDED), (2x) 5mm HEX KEYS (SUPPLIED)
STEP 1:
Stand up
one of the Legs
on a flat surface.
Align Brace with
pocket on inside
bottom face of
Leg and attach
Brace to Leg with
(2) of the
supplied Brace
screws through
side Leg pre-
drilled holes.
Screw until snug.
STEP 3:
Determine what height you would like to install your Divider Panel at. Once decided upon,
insert supplied Barrels into corresponding hole locations at top of Legs. Place one barrel into the top-
most hole in each Leg, and then the other two barrels into the hole locations which align with the
bottom-most holes of your Panel.
shopPOPdisplays makes no claim that these assembly instructions cover all details, conditions or variations, or that they cover all possible contingencies in connection with the assembly or installation of
this product. It is the Purchaser's responsibility to ensure that all components of this product are properly assembled and installed in accordance with these instructions. shopPOPdisplays assumes no
obligation or liability on account of any third-party recommendations, opinions or advice as to the assembly or installation of this product.
READ ALL INSTRUCTIONS BEFORE YOU BEGIN. DO NOT JUMP AHEAD OF ANY STEP.
Leg
(2 pcs)
STEP 2:
other Leg and
align other side
of Brace with
pocket on inside
bottom face of
Leg. Attach
Brace to Leg with
remaining (2)
Brace screws
through pre-
drilled holes in
Leg. Screw until
snug.
Brace
(1 pc)
Hex Key
(2 pcs)
Stand up
1 2
page of
Brace
Screw
(4 pcs)
Barrel
(4 pcs)
Screw
(4 pcs)
Barrels
