Summary of Contents for MALA ANGLERSOL 20
- Page 1 USER MANUAL ANGLERSOL 20 SOLAR PORTABLE LIGHT & POWER BANK WITH USB CHARGER MANUFACTURER/IMPORTER: MALATECH WATER, LTD. 1/E Vanyi way, Alsonemedi, 2351 Hungary +36 30 377 8089 info@malatechsolar.com...
- Page 3 LED power: 20 W at full capacity Luminous flux: 2 000 lumen at full capacity LED chip data: Philips COB LED chip Light color: Cold white, 6000K 4 V/4 W monocrystalline solar integrated Solar Panel: on the back Li-battery: 3.2 V/12 Ah 18650 ternary Lithium battery Waterproof IP rating: IP65 Body material:...
- Page 4 PRODUCT STRUCTURE, CONTENT OF THE BOX Content of the box: 1. AnglerSOL 20 light 2. USB cable for charging (without 230V adapter!) Product structure: High CRI Chip-On-Board LED Adjustable 3 power modes Die-cast Aluminium shell Power bank function for charging USB devices...
- Page 5 USER INSTRUCTIONS 1. Instructions, and information about using the battery, and maximizing its life span ATTENTION! The life span of the battery depends on you as well! Please keep using the product as described in this manual to maximize its life span for your pleasure: •...
- Page 6 USER INSTRUCTIONS b) Charging with the solar panel: • Please pay attention to keep the solar panel clean. Please follow “Cleaning instructions” below for cleaning your light! • In case of sunny weather, you can charge your light outdoors, as well as indoors with the solar panel well-positioned, if you have direct sunlight coming through a window.
- Page 7 FUNCTIONS OF THE LIGHT, USER’S INSTRUCTIONS Chargeable with Easy to carry USB cable Built-in Li-ion Power bank battery function Portable solar Chargeable LED light by solar energy Using the ON/OFF button: • The ON/OFF button is located on the side of the shell. Once you finished charging, and you disconnected the USB cable, press the ON/OFF button shortly once to turn on your light.
- Page 8 • The Type-C interface is the port of the USB charging cable on the light. The other end of the cable is conventional USB. • The conventional external USB port on the shell is for using the light’s battery as a power bank. When battery charge is sufficient, you can connect your USB devices for charging (smartphones, tablets etc.).
-
Page 9: Cleaning Instructions
CLEANING INSTRUCTIONS For preserving the aesthetical outlook, and maintaining the maximum functionality, and efficiency of your light, cleaning is recommended from time to time. Since the light is operated by solar energy, keeping the solar panel clean & free of dust is key-essential to ensure its efficiency, and maximize discharging time. -
Page 10: Waste Disposal
WASTE DISPOSAL The WEEE (Waste Electrical and Electronic Equipment) sign means that every electrical, and electronic wastes must be collected, and treated separately. According to The Waste Electrical and Electronic Equipment Directive (WEEE Directive), the European Community Directive 2012/19/ EU on waste electrical and electronic equipment (WEEE) which, together with the RoHS Directive 2011/65/EU lights, and light bodies are electrical, and electronical wastes, and cannot be disposed, and treated together with municipal waste. -
Page 11: Warranty Terms
prohibited by users. Please let certified specialists do this job instead, and handle your wasted light preferably in a perfect, non-damaged condition. For more information on electric, and electronic waste disposal locations, please visit www.electro-coord.hu, or www.malatechsolar.com. WARRANTY TERMS Malatech Water, Ltd. provides all-inclusive, attractive, customer-oriented warranty terms and services for its products during the warranty period for all of our customers in the following countries (by alphabetical order): Austria... - Page 12 WARRANTY TERMS video as a proof made by for example your cell phone about the issue. If you can do the video, please attach in low resolution to your e-mail, or upload it to a free file sharing platform, and send us the link. We examine your case as soon as possible, and contact you with a solution.
- Page 13 purchase depending on product. The warranty period for each product is defined in the specification sheet of the product. Our product warranties are valid in the European Union, Great Britain, Switzerland, and Norway Required documents for warranty claims Warranty is only valid for all of our products once the original invoice, or the copy of the original invoice of the purchase is presented by our customer.
- Page 14 Manufacturer/Importer: Malatech Water, Ltd. 1/E Vanyi way, Alsonemedi, 2351 Hungary Customer service: +36 30 377 8089 info@malatechsolar.com www.malatechsolar.com Issue warranty claims: service@malatechsolar.com CE Confirmation: Malatech Water, Ltd. confirms that this light meets with the competent EU directives, legislation, and harmonized acts.
