- Page 1 Translation ORIGINAL MANUAL ATEMAG Control 4.0...
-
Page 2: Table Of Contents
5.1.3 Call up and download history and telemetry data ................10 Assembly and connection ......................11 Retrofit aggregate ...........................11 Dysfunction ............................12 Disposal............................12 Extract from the EC declaration of conformity ................12 Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 2 von 13... -
Page 3: General
Ignoring this indication result in severe injuries or death! ATTENTION! Possibly danger situation! Ignoring this indication cause medium or light injuries! CAUTION! Possibly danger situation! Ignoring this indication cause damage to property or pollution! Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 3 von 13... -
Page 4: Applied Symbols
Indication: Describes general information and recommendation. Guarantee and liability Basically, the „General conditions of sale and delivery“ apply to ATEMAG. 1.3.1 Wireless functionality disclaimer The chip unit is a wireless device that operates in the 2.4 GHz radio spectrum. The wireless functionality in the AC4.0 module is used to send and receive information to and from the module for configuration and... -
Page 5: General Safety Instruction
Furthermore, the status of the module is transmitted wirelessly during operation so that each monitor (e.g. tablet or PC) can collect data and, in certain cases, respond. Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 5 von 13... -
Page 6: Operating Modes
A self-diagnostic process or reset after a system failure is performed. Single flash -> no internal error; multiple flash -> system error is present Function chip unit performed Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 6 von 13... -
Page 7: Battery Replacement
Mount O-ring (3) and battery cover (2). There must be no gap. Screw in Phillips screws (1) with No. 2 Phillips screwdriver. Battery is replaced. Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 7 von 13... -
Page 8: Communication
In general, the following areas can be considered as range: Client-hardware Transmission range Connecting range USB dongle - type A USB dongle - type B Tab 9: Übersicht Signalreichweite Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 8 von 13... -
Page 9: Cloud Functionality
Call up dashboard and select aggregate from the list. The associated diagrams are displayed under the aggregate list. The illustration may differ depending on the degree of approval and the number of aggregates Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 9 von 13... -
Page 10: Call Up And Download History And Telemetry Data
Click Update button (7) to display data. Use the download button (8) to download the selected time window as an Excel file. History data/telemetry data downloaded. Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 10 von 13... -
Page 11: Assembly And Connection
Secure the chip unit (5) to the intended position with cylinder head screws (7). Seal bearing surfaces and gaps with silicone. Secure the cable to the housing (8) with the supplied mounting material. The aggregate is retrofitted. Translation Original Manual ATEMAG Control 4.0 06.09.2019 I00 11 von 13... -
Page 12: Dysfunction
Tab 11: Disposal Extract from the EC declaration of conformity The ATEMAG Control 4.0 chip unit fulfills the requirements of the following EC directives: Directive 2006/42/EC (Machinery Directive) Safety: EN 60950-1:2006 + A 11:2009 + A 1:2010 + A 12:2011 + A2:2013 ... - Page 13 ATEMAG Mühlenmatten 2 D-77716 Hofstetten Telefon +49 (0) 78 32 99 97-0 Fax +49 (0) 78 32 99 97-12 info@atemag.de www.atemag.de I00 - 09/2019...
