LINCOS STD-3550 Manual

Two post lift with electrical release
Hide thumbs
Table of Contents

Advertisement

Quick Links

Ékszíjas meghajtású, olajkenésű, dugatt
Two Post Lift - Electrical Release
LINCOS d.o.o.
CELOVŠKA CESTA 492
SI-1000 LJUBLJANA
TEL.+386 31 390 850
EMAIL: shop@lincos.si
WEB: www.lincos.si
LINCOS Slovenia
STD-3550
TWO POST LIFT
WITH ELECTRICAL RELEASE
LOAD
Max hoist height
Min hoist height
Raising time
Voltage
STD-3550
5500 kg
1900 mm
100 mm
50 s
230V
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STD-3550 and is the answer not in the manual?

Questions and answers

Summary of Contents for LINCOS STD-3550

  • Page 1 Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 STD-3550 TWO POST LIFT WITH ELECTRICAL RELEASE LOAD 5500 kg LINCOS d.o.o. CELOVŠKA CESTA 492 Max hoist height 1900 mm SI-1000 LJUBLJANA TEL.+386 31 390 850 Min hoist height 100 mm EMAIL: shop@lincos.si...

  • Page 2: Table Of Contents

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 Dear customer! Thank you for choosing our product! Please read this manual carefully before unpacking and using the product for the first time. To ensure the safe use and operation of the machine, you must read this manual thoroughly and be aware of the dangers of using the machine.

  • Page 3: Safety Instructions

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 SAFETY INSTRUCTIONS 1. Do not install the lift on any asphalt surface. 2. Read and understand all safety warning procedures before operating the lift 3. The lift, in its standard version, is not designed for outdoor use 4.

  • Page 4: Warning Signs

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 WARNING SIGNS All safety warning signs presented on the machine with the purpose to draw the operator’s attention from dangerous or unsafe situations. The labels must be kept clean and they have to be replaced if detached or damaged. Read the...

  • Page 5: Introduction

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 1 INTRODUCTION This guide has been made to supply the owner as well the user with the basic instructions for a correct use of the machine. Read this guide carefully before using...

  • Page 6: Installation

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 Power supply: single phase/three phase (Please see nameplate before connecting) 3 INSTALLATION 3.1 TOOLS AND EQUIPMENT • Appropriate lifting equipment • AW 32.46 or other good quality garage hydraulic oil •...
  • Page 7 Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 STEP TWO: MOUNTING TWO COLUMNS, POWER UNIT COLUMN FIRST THEN THE OTHER. 1. Drill each anchor hole in the concrete using a rotary hammer drill. To assure full holding power, do not ream the hole or allow drill to wobble.
  • Page 8 Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 terminal board. Cut and Connect Power wire to the terminal board D1, D2, D3 5. Fix the rubber ring to protect the wires, at last mount Electromagnet cover. 6. MOUNTING CHAIN COVER. Chain cover parts inside spare parts box, fix from the bottom with screw and upside with hook.

  • Page 9: Operation

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 WARNING: THE WIRING MUST COMPLY WITH LOCAL CODE. HAVE A CERTIFIED ELECTRICIAN MAKE THE ELECTRICAL HOOK UP TO THE POWER UNIT. 4 OPERATION WARNING: DO NOT PLACE ANY VEHICLE ON THE LIFT BEFORE TRIAL OPERATION.

  • Page 10: Manintenance

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 Press LOCK button to make the lift in safe condition then perform maintenance or repair work. B) LOWERING THE LIFT Clean all the obstacles before lowering the vehicle. Press the down button and the carriage will raise up a little, then go down.

  • Page 11: Monthly Maintenance

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 • Check hydraulic fluid level as follow: let the trolleys go up completely and in case they do not reach maximum height, add oil. • Check and tighten bolts, nuts and screws.
  • Page 12 Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 C) Bad capacitor. Call electrician for checking. D) Low voltage call electrician for checking. E) Lift overloaded. LIFT JERKS GOING UP AND DOWN A) Air in hydraulic system. Raise lift all the way to the top and return to floor.

  • Page 13: Overall Diagram

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 7 OVERALL DIAGRAM LINCOS Slovenia...

  • Page 14: Space Required

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 SPACE REQUIRED LINCOS Slovenia...

  • Page 15: Hydraulic Diagram

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 9 HYDRAULIC DIAGRAM LINCOS Slovenia...

  • Page 16: Hydraulic Connecting

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 10 HYDRAULIC CONNECTING 1. Main Cylinder 7. Hose Joint 2. Assist Cylinder 8. Cylinder Hose 3. Hydraulic Hose 9. Fix Joint 4. Cylinder Joint 10. Pump Hose 5. Cylinder Joint 11.

  • Page 17: Wire Rope Installation

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 11 WIRE ROPE INSTALLATION 1. Top Plate 2. Carriage 3. Cable Wheel 4. Cable 5. M16 Nut 6. M16 Flat Washer 7. Cable Hanger LINCOS Slovenia...

  • Page 18: Wiring Diagram

    Ékszíjas meghajtású, olajkenésű, dugatt Two Post Lift - Electrical Release STD-3550 12 WIRING DIAGRAM LINCOS Slovenia...
