Owner's Manual
MEDLINE
MOBILE 100 RECLINER
USER:
Before using the Mobile 100 Recliner,
read this manual and save for future reference.
FURN10100BLC/BEC
(GPI248)
Revised: 1/18/2011
FURN10100BLC/BEC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOBILE 100 RECLINER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Medline MOBILE 100 RECLINER

Summary of Contents for Medline MOBILE 100 RECLINER

  • Page 1 Owner’s Manual MEDLINE MOBILE 100 RECLINER USER: Before using the Mobile 100 Recliner, read this manual and save for future reference. FURN10100BLC/BEC (GPI248) Revised: 1/18/2011 FURN10100BLC/BEC...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PROTECTING YOUR INVESTMENT....................3 SPECIFICATIONS........................... 4 OPERATING PRECAUTIONS......................5 GENERAL WARNINGS........................5 WEIGHT LIMITATIONS........................5 TILT AND/OR RECLINE OPTION OPERATED BY AN ATTENDANT..........5 SAFETY INSPECTION CHECKLIST....................6 ASSEMBLING THE RECLINER....................... 7 OPERATING INSTRUCTIONS......................10 RECLINING THE CHAIR USING THE POSITION LOCK LEVER............10 RECLINING THE CHAIR WITHOUT USING THE POSITION LOCK LEVER........

  • Page 3: Protecting Your Investment

    Medline’s Mobile 100 Recliner has not been designed and/or tested for seating surfaces or vehicle chairs for occupant use within any type of vehicle. Medline recommends that at no time or for any reason is the Mobile 100 Recliner to be used in a transport vehicle.

  • Page 4: Specifications

    SPECIFICATIONS MEDLINE MOBILE 100 RECLINER FURN10100BLC/BEC PHYSICAL DIMENSIONS Overall Height: 46 inches (116 cm) Overall Width: 29 ½ inches (75 cm) Overall Depth: 39 inches (99 cm) (Upright) Overall Depth: 68 inches (172.75 cm) (Recline) Seat Width: 20 ½ inches (52 cm) Seat Depth: 19 ½...

  • Page 5: Operating Precautions

    • DO NOT traverse, climb or go down ramps or slopes GREATER than 9 degrees. • DO NOT use parts, accessories, or adapters other than those authorized by Medline. WEIGHT LIMITATIONS WARNINGS The weight limitation for Medline’s Mobile 100 Recliner is 300 lbs.

  • Page 6: Safety Inspection Checklist

    Physical limitations of a user and larger occupants of the recliner can present conditions that can injure the assistant. When in doubt, assure that additional assistants are present before operating the tilt and/or recline feature. SAFETY INSPECTON CHECKLIST NOTE: Once a year or as necessary take your mobile recliner to a qualified technician for a thorough inspection and servicing.

  • Page 7: Assembling The Recliner

    ASSEMBLING THE RECLINER The components of the FURN10100BL series 3-Position Recliner are as follows: 1. Chair Base 2. Reclining Back Assembly 3. Casters, 2 Locking, 2 Non-locking 4. IV Pole Holder 5. Wrench & Hardware 1. Attach the casters to the base, commonly set-up with the locking casters in the back, and secure with nut and bolts provided.
  • Page 8 2. Attach the IV Pole holder to the Right rear Caster receiver, the bottom screw is the same fastener that secures the caster in place. 3. Next, insert the Reclining Back posts into the base receivers (WHITE SQUARE) and secure with Allen Screws (WHITE CIRCLES).
  • Page 9 4. If you have the tray assembly, attach it to the right side of the Recliner for stowaway until it is needed. (GPI248) Revised: 1/18/2011 FURN10100BLC/BEC...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS CAUTION Ensure that there is adequate room to operate the Medline Mobile 100 Recliner. There must be at least 3 feet clearance between the top of the recliner back and the surrounding objects, otherwise damage to the recliner and/or surrounding property may occur.

  • Page 11: Positoning The Articulating Headrest On All Models

    POSITIONING THE ARTICULATING HEADREST 1. To position the articulating headrest, simply grasp the headrest and push or pull it into the desired position. LOCKING/UNLOCKING THE REAR WHEELS 1. Push down on the wheel lock mechanism to engage the wheel locks. 2.

  • Page 12: Installing Tray Into Position

    5. Push the alignment rods completely into the frame until the tray locks into place. ADJUSTING THE TRAY POSITION There are seven (7) tray positions on the Medline Mobile 100 Recliner. They range from 9-inches to 15-inches in 1-1/2-inch increments.

  • Page 13: Cleaning The Upholstery

    CLEANING THE UPHOLSTERY NOTE: A variety of solvents may be used to clean the upholstery on the recliner dependant upon the severity of the stain. The following list should be helpful: • Ordinary dirt stains: Clean upholstery with warm water and mild detergent to remove superficial soil. •...

  • Page 14: Warranty

    Some products may not be available for sale in Mexico or Canada. Please contact your Account Representative for additional information. We reserve the right to correct any errors that may occur within this owner’s manual. ©2009 Medline Industries, Inc. Medline is a registered trademark of Medline Industries, Inc.
