Summary of Contents for Belkin F8H1500
- Page 1 Belkin Components G700 Portable PDA Keyboard User Guide For Pocket PC OS Handhelds P74050...
-
Page 2: Table Of Contents
Introduction ...2 Features and Specifications ...3 Operating the G700 Keyboard Opening the Keyboard ...4 Closing the Keyboard ...5 On-Keyboard Charging ...6 Installation and Operation Installing the G700 Keyboard Driver ...7 Enabling the Driver ...9 Connecting and Removing the PDA...10 Customizing Keyboard Settings ...11 Application and Combination Keys ...13 Assigning Hot Keys ...15 Frequently Asked Questions ...16... -
Page 3: Introduction
Introduction Congratulations! You have just purchased the definitive tool to extend your handheld’s capabilities. The Belkin G700 Portable PDA Keyboard will give you an easy and convenient way to add data to your Pocket PC handheld. Designed for the mobile professional, the G700 weighs in at only seven ounces and closes to a size compact enough to fit easily into a coat pocket. -
Page 4: Features And Specifications
Features and Specifications • Easy connection compatibility with your Pocket PC OS device • Standard QWERTY keyboard layout • Shortcut keys for faster operation • Ultra-portable design • Pass-through charging capability Opened: Closed: Weight: Temperature Endurance: 70º C (158º F) Power Consumption: In Operation: 1mA In Sleep Mode: 1 A... -
Page 5: Operating The G700 Keyboard
Operating the Keyboard Opening the Keyboard Open the keyboard by pressing the button. Raise the lid and stand so that they are fully extended. Flip up the keyboard connector stand to its full upright position. Pull out the left and right section of the keyboard until the middle section pops up. -
Page 6: Closing The Keyboard
Operating the Keyboard (continued) Closing the Keyboard 1. Gently pull the left and then the right section of the keyboard apart. 2. Push the left and right section of the keyboard forward the center of the keyboard. The middle section will automatically move down and make room for the left and right sections. -
Page 7: On-Keyboard Charging
Operating the Keyboard (continued) On-Keyboard Charging The G700 keyboard is designed with an electronic circuit that accepts AC power. The power receptacle is located on the side of the keyboard. A plug adapter is included with your G700 keyboard. This adapter attaches to your PDA’s AC power adapter, allowing you to charge your PDA directly while using the keyboard. -
Page 8: Installation And Operation
Installation and Operation Installing the G700 Keyboard Driver Before Installation 1. Disable any other keyboard applications that you have installed on your Pocket PC handheld. (Refer to the user guide included with your Pocket PC handheld for instructions on this.) 2. -
Page 9: Enabling The Driver
Installation and Operation 3. Insert the CD into an optical drive on the computer. 4. Software installation begins automatically. Follow the on-screen instructions to install the software. If installation does not begin automatically, select “Start > Run” from the “Start” menu on your desktop or notebook computer. - Page 10 Installation and Operation (continued) 3. Select the “Belkin G700 Keyboard” icon. 6700 4. Add a check mark in the check box in front of “Enable Keyboard”.
-
Page 11: Connecting And Removing The Pda
Installation and Operation Connecting and Removing the PDA 1. Align the PDA’s connector with the keyboard’s connector. Gently slide the PDA onto the connector until it is firmly seated on the connector. 2. To remove, hold the keyboard in place and gently pull the PDA up from the connector until it is completely removed from the keyboard. -
Page 12: Customizing Keyboard Settings
Customizing Keyboard Settings Configuring the Keyboard You can configure several features on your Belkin G700 PDA Keyboard. To customize your keyboard: 1. On your Pocket PC handheld, navigate to the “Belkin G700 Keyboard” application and open it. 2. Select the “Setting” tab. - Page 13 Customizing Keyboard Settings (continued) 6. Slide the “Keyboard repeat rate” indicator to speed up or slow down the rate at which the keyboard repeatedly displays a pressed key. The right side of the scale specifies a faster repeat rate. 7. Tap in the “Test string here” field to enter characters from the keyboard.
-
Page 14: Application And Combination Keys
Application and Combination Keys Certain keys on the G700 Keyboard can directly launch applications and perform additional functions in the combinations listed below. Keystroke Combination Shift ( ) + letter key Shift ( ) + number key Fn + Q Fn + W Fn + E Fn + R... - Page 15 Combination Keys Fn + down arrow Fn + left arrow Fn + right arrow Ctrl + C Ctrl + V Ctrl + X Ctrl + A Ctrl + Z Shift ( ) + right arrow Shift ( ) + left arrow Shift ( ) + up arrow Shift ( ) + down arrow (continued)
-
Page 16: Assigning Hot Keys
You can assign specific hot key combinations (Fn + 0 through Fn + 9) to directly launch a variety of applications with just a few keystrokes. 1. On your Pocket PC, tap the “Belkin G700 Keyboard” application and launch it. -
Page 17: Frequently Asked Questions
Frequently Asked Questions A) How do I uninstall the driver? Select “Start > Settings > System tab > Remove Programs”. Select “Belkin G700 Keyboard” from the list of applications and then, select “Remove”. Reset your Pocket PC for several seconds so your new settings can take effect. -
Page 18: Fcc/Ce/Warranty Statement
Belkin Components warrants this product against defects in materials and workmanship for one year. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 19 Belkin Components, Ltd. 7 Bowen Cresent • West Gosford NSW 2250 • Australia Tel: +61 (2) 4372 8600 Fax: +61 (2) 4325 4277 © 2002 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
