RH Baby&child EVIE CRYSTAL SCONCE Assembly Instructions

HARDWARE ENCLOSED:

PARTS ENCLOSED:

(a) Wall Screws (2)
(A) Back Plate (1)
(b) Wall Anchors (2)
(B) Glass Shade (1)
(c1) Mounting Plate (1)
(C) Socket (1)
(d) Back Plate Screws (2)
(D) LED Bulb (1)
(E) Cord Cover (1)
(F) Switch (1)
B
c-1
A
b
a
E
E V I E C R Y S T A L S C O N C E - A S S E M B L Y I N S T R U C T I O N S
D
C
d
F

IMPORTANT SAFETY INSTRUCTIONS:

This portable luminaire has a polarized plug (one blade is wider than the other)
as a feature to reduce the risk of electric shock. This plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Never use with an extension
cord unless plug can be fully inserted. Do not alter the plug.
This fixture has been rated for one 4-watt Type G9 LED dimmable lightbulb
(35-watt incandescent bulb equivalent). To avoid the risk
the recommended wattage.

WARNINGS:

All wires are connected.
Do not remove the fixture from its packing by pulling on the power cord,
as a bad connection may result.
Do not connect electricity until your fixture is fully assembled.
To reduce the risk of fire, electrical shock, or personal injury, always turn
off/unplug fixture and allow it to cool prior to replacing lightbulb.
Do not touch bulb when fixture is turned on or look directly at lit bulb.
Keep flammable materials away from lit bulb.
Install the fixture in upright direction, do not install upside down to avoid the
glass shade to fall.

WARNINGS: STRANGULATION HAZARD

Keep cord at least 3 feet away from cribs, bassinets, and toddler beds.
Keep out of reach of children under three years of age.
THIS PRODUCT IS NOT A TOY AND HAS NO PLAY VALUE.
PLUG-IN ASSEMBLY & INSTALLATION:
1. Carefully remove all parts from the box and remove all plastic coverings.
2. Hold the sconce against a wall to determine a desired mounting location. Use a
pencil to mark the general location of the hole cutouts located on the mounting
plate (c1).
3. Drill holes into the wall for inserting the wall anchors (b). Insert an anchor into
each hole in the wall. The wall anchors (b) are meant for concrete wall mounting
only. If the wall is made of materials other than concrete, please consult your
local hardware store for assistance.
4. Attach the mounting plate (c1) on the wall. Use the screwdriver to secure a wall
screw (a) into each wall anchor (b). Tighten the wall screws (a) until mounting
plate (c1) is secured.
5. Align the two side holes of the back plate (A) with the corresponding holes on
the mounting plate (c1). Screw the back plate screws (d) to tighten the back plate
until the sconce is secured to the wall.
6. Screw the cord cover (E) into the hole underneath the back plate (A).
7. Insert the bulb (D) into the socket (C).
8. Place the shade (B) onto the socket.
9. Installation is complete.
10. Plug into proper electrical outlet and turn switch (F) clockwise to turn on or turn
off to test the fixture.

CARE INSTRUCTIONS:

Do not use polishes or cleaners on the fixture.
Wipe clean with a soft, dry cloth.
Page 1 of 2
of fire, do not exceed
