Environics Series 2xxx Operating Manual
AUGUST 2011 REV 8
OWNER'S MANUAL
SERIES 2000 COMPUTERIZED MULTI-COMPONENT GAS MIXER
SERIES 2020 COMPUTERIZED GAS DILUTION SYSTEM
SERIES 2010 COMPUTERIZED AUTOMOTIVE GAS DIVIDER
SERIES 2014 COMPUTERIZED VOC (VOLATILE ORGANIC
COMPOUNDS) GAS DILUTION SYSTEM
WARNING
READ THIS MANUAL CAREFULLY BEFORE USING THE INSTRUMENTS.
FAILURE TO DO SO MAY VOID THE WARRANTY,
DAMAGE THE INSTRUMENTS AND CAUSE
SERIOUS INJURY OR DEATH.
ENVIRONICS INC. 69 Industrial Park Road East, Tolland, CT 06084
Phone: 860-872-1111 Fax: 860-870-9333
http://www.environics.com
Email: info@environics.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Environics 2000 Series

  • Page 1 READ THIS MANUAL CAREFULLY BEFORE USING THE INSTRUMENTS. FAILURE TO DO SO MAY VOID THE WARRANTY, DAMAGE THE INSTRUMENTS AND CAUSE SERIOUS INJURY OR DEATH. ENVIRONICS INC. 69 Industrial Park Road East, Tolland, CT 06084 Phone: 860-872-1111 Fax: 860-870-9333 http://www.environics.com Email: info@environics.com...

  • Page 2: Table Of Contents

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 TABLE OF CONTENTS CLICK TO BE LINKED TO SECTION FORWARD ................................... 5 THEORY OF OPERATION ..............................5 RECEIVING ..................................5 UNPACKING ................................. 5 POWER CONNECTION ............................6 FRONT PANEL ..................................7 POWER SWITCH ..............................
  • Page 3 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.8.1.2 SOFT KEY DESCRIPTIONS ....................29 5.8.1.3 OPERATION ..........................30 5.8.2 PROCEDURE ............................30 5.8.2.1 FIELD DESCRIPTIONS ......................31 5.8.2.2 SOFT KEY DESCRIPTIONS ....................32 5.8.2.3 OPERATION ..........................33 PURGE MODE ..............................33 5.9.1...
  • Page 4 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 COMM/DRIVER BOARD (PC204) ........................52 MOTHERBOARD (PC208)........................... 52 OZONE BOARD (PC210) ............................ 52 STATUS I/O BOARD (PC216) ..........................52 OZONE MODULE ..............................52 DESCRIPTION OF THE DISPLAY ............................. 52 POWER SUPPLIES AND POWER ENTRY MODULE ...................... 53 PLUMBING ..................................

  • Page 5: Forward

    AUGUST 2011 REV 8 FORWARD The Environics Series 2000 is designed to be the finest instrument available for producing highly precise blends of gases and optional Ozone. With the use of a powerful 32 bit microprocessor, user friendly software, mass flow controllers (MFC's) and our optional custom designed Ozone module we are able to give the user the power of precision without complex operation.

  • Page 6: Power Connection

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 POWER CONNECTION OPERATING THE S-2000 AT AN INCORRECT LINE VOLTAGE WILL DAMAGE THE INSTRUMENT AND VOID THE MANUFACTURER'S WARRANTY. CHECK THE LINE VOLTAGE BEFORE YOU PLUG THE INSTRUMENT INTO ANY POWER SOURCE. LINE VOLTAGES BETWEEN 100-120 VAC (OPTIONAL 220-240 VAC) ARE ACCEPTABLE.

  • Page 7: Front Panel

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 FRONT PANEL POWER SWITCH To turn the system on, push the power switch firmly up against the keyboard. The switch and display should illuminate and the start-up message should appear. CONTRAST The contrast knob, located on the lower left side of the front panel, is used to adjust the display for optimum viewing.

  • Page 8: Cursor Keys

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 4.4.2 CURSOR KEYS The cursor keys, a group of arrows located in the lower right portion of the keyboard, are used to move between the different fields and cells located on the different entry screens. When you move the cursor from any cell, the data in that cell will be accepted.
  • Page 9 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 The instrument was designed with emphasis on simplicity and ease of use. The menu driven software guides users through all operating routines and provides on-screen mode specific help with the simple press of the "help" key. The main menu offers 13 primary options;...

  • Page 10: Common Soft Keys

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 STATUS OUTPUT Allows the user to setup the eight status output lines. These lines can be instructed to turn on when a selected MFC, port, ozone, or a saved setup is in operation.

  • Page 11: Field Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.3.1 FIELD DESCRIPTIONS This is a display only field which indicates the MFC being commanded. All information on this line will be related to the indicated MFC. PORT The "Port" field tells the system which port should be connected to which MFC. The instrument will display an error if the selected port is not available to the corresponding MFC.

  • Page 12: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.3.2 SOFT KEY DESCRIPTIONS START This soft key is used to begin the mix described on the display. If any errors are detected, the system will not allow the mix to start.

  • Page 13: Flow Mode

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 FLOW MODE In the concentration mode, the user enters the desired concentration of each gas and the total flow. In the flow mode, the user is allowed to control the exact flow through each MFC.

  • Page 14: Soft Key Descriptions

    The nature of the reaction is such that when the concentration of "NO" or "O " is known, the concentration of "NO " can be determined. The Environics recommended method of Gas Phase Titration is the excess Nitric Oxide Transfer Standard Procedure (GPT-NO). When O...
  • Page 15 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 To perform GPT-NO on the instrument, follow the subsequent procedure: Determine the flow required by all the analyzers connected to the output. To this value, add 10 to 20% for excess so that all of the analyzers are assured of drawing NO .

  • Page 16: Maintain Ports

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 MAINTAIN PORTS Extreme care should be taken to assure the information entered in MAINTAIN PORTS is correct. information entered here is carried throughout the system and can seriously affect the systems performance.

  • Page 17: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 CYLINDER GAS CONCENTRATION The CGC field is where you enter the concentration of each cylinder. This can be done in either PPM or percent by using the "PPM OR %" soft key to select the mode of entry. If a cylinder contains pure gas, or a single gas component in a balance gas, the CGC is the concentration of the component (or 100% for pure gas).

  • Page 18: Compute K Screen

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 SELECT GAS SYSTEM USER Gas Library Selection Soft Keys The SELECT GAS soft key will first display a sub-menu, giving the user the option of selecting a gas from the system or user libraries.

  • Page 19: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 CONCENTRATION This is where the concentrations of different components are entered. The data can be entered in either PPM or percent with the use of the PPM OR % soft key. Any component containing a concentration of 0.0 will be removed from the final K-factor calculation.

  • Page 20: User Gas Library Editing

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 CYL ID Use this soft key to enter a cylinder identification using the system text editor (See ENTER GAS pg. 17 for instructions on the text editor). INIT This key will initialize the COMPUTE K screen to concentrations of 0.0 and Nitrogen for the types. The cylinder identification and reference gas entries will be left unchanged.

  • Page 21: Mfc Size

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.7.1 MFC SIZE FLOW CONTROLLER SIZE Mfc# Max Flow of MFC 20.0 5000.0 CCM CCM/LPM PRT SCRN EXIT Calibrate Mode - MFC SIZE The MFC SIZE screen is used to enter the size of each MFC and in which units, CCM or LPM, the system will display all the MFC's data.

  • Page 22: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 SET FLOW This field is used to enter calibration set points. These are the values the MFC was, or is to be, commanded TRUE FLOW The true flow field is where the actual flow of the associated set point, determined by a flow standard, is entered.

  • Page 23: Flow Calibration Data Swap Registers

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.7.2.3 FLOW CALIBRATION DATA SWAP REGISTERS 12 "Swap Registers" are provided to allow saving additional sets of MFC flow calibration data (data). The method of saving and recalling data with these registers is through the "SWAP CAL" soft key. The user may choose not to use the swap registers unless more than one set of data is needed for an MFC.

  • Page 24: Default Flow

    Unlike calibrating a flow controller, the system cannot be run from this screen. When the system is first received it will have been calibrated with the Environics measurement standard at regular ozone and flow intervals. When target values are entered, the system uses the previous calibration data to determine what the system really commanded and associates it with the true data.
  • Page 25 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 relate them back to the ozone module flow which is typically 500 sccm, and the maximum ozone, which is typically 26 ppm at 500 sccm. For example, an Ozone setting of 1 ppm @ 13.0 slpm is equivalent to 26 ppm @ 500.0 sccm.

  • Page 26: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.7.4.2 SOFT KEY DESCRIPTIONS INIT ALL The INIT ALL soft key will initialize the screen to a target and true flow of 13.0 slpm, a pressure of 24.69, and ozone values in 10 percent increments with the first point at 5 percent.

  • Page 27: Device - Dac (Digital To Analog Converter)

    WARNING NOTE: If battery power is lost the system will have to be PROPERLY CONFIGURED before any calibration data is entered. Contact your dealer or ENVIRONICS for instructions on how to configure your system. 5.7.7.1 MFC and ADC/DAC DEVICES MFC, ADC, and DAC calibration data is the easiest to recover. First, obtain copies of all the latest calibration data.

  • Page 28: Automatic Sequencer Mode

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 AUTOMATIC SEQUENCER MODE The instrument incorporates a powerful automatic sequencer mode, which gives the user the ability to program the instrument for independent and unattended operation. The function section of the manual makes reference to the CONC, FLOW, and PURGE modes and a thorough understanding of these modes is required before proceeding.

  • Page 29: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.8.1.2 SOFT KEY DESCRIPTIONS START The START soft key will begin the function described on the screen. Once the function has begun, the display will show the setup which is running in its native screen.

  • Page 30: Operation

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.8.1.3 OPERATION SEQUENCER - FLOW VIEW Port Target Flow Actual Flow Gas Type 5000.0 5001.2 CCM NITROGEN 2500.0 2500.5 CCM CARBON DIOXIDE 2500.0 2499.9 CCM ARGON Total Flow 10000.0 CCM 10001.6 CCM...

  • Page 31: Field Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 SEQUENCER - PROCEDURE Item Start Time Function 14:50 14──────┐ 14:50 22──────┼─── Three different weeks running dif- 14:50 08───┬──┘ ferent functions. │ ├────── The same week. │ 10:00 01───┴──┐ ├─── Two different weeks running the 22:00 01──────┘...

  • Page 32: Soft Key Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.8.2.2 SOFT KEY DESCRIPTIONS START The START soft key will start the procedure described on the screen. After the key is pressed the system will ask which item to start with. Once the item number is entered the system will go to that item and wait for its start day and time.

  • Page 33: Operation

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.8.2.3 OPERATION SEQUENCER - PROCEDURE Item Start Time Function Item Start Time Function 14:50 14:37:41 Wednesday 29 December 10 Next item to run is STOP Automatic Sequencer - Procedure - Waiting to run a function...

  • Page 34: Field Descriptions

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 PURGE MODE Purge Purge Flow Actual Flow 5000.0 CCM START SAVE RECALL TOGGLE ALL YES PRT SCRN EXIT Purge Mode 5.9.1 FIELD DESCRIPTIONS This is a display only field which indicates the MFC being commanded. All information on this line will be related to the indicated MFC.

  • Page 35: Computer Remote

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 option to select "ALL YES" which will instruct the instrument to purge the entire system. After selecting YES for the MFC's to be purged, the purge flow should be entered for each MFC with a YES. Once the screen is as desired, the user should press the "START"...

  • Page 36: Format Of Numeric Data

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.10.3.2 Format Of Numeric Data If the command requires an integer, no preceding zero is required, even if the command could take more than one number. So "01" is the same as "1." If the command requires a floating point number to be sent, E notation is not required.

  • Page 37: Conc Mode

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 FLOW SAVE XX Save all the work space flow settings to location XX. FLOW QUERY XX Read all the stored flow settings location XX. The data will be returned in the format of "Port for MFC 1, OGC for MFC 1, Port for MFC 2, OGC for MFC 2, ...".

  • Page 38: Maintain Ports

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Read all the present actual OGC's. CONC A LL TARGET ? Read all the present target OGC's. 5.10.6.3 MAINTAIN PORTS PORT X TYPE ? Read the present gas name assigned to port X.

  • Page 39: Flow Calibrate Mode

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.10.6.5 FLOW CALIBRATE MODE CAL X SET Y ? Read the present set calibration point Y for MFC X. CAL X TRUE Y ? Read the present true calibration point Y for MFC X.

  • Page 40: Miscellaneous

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 FUNC QUERY XX YY Read the present stored function XX item YY. The data returned will follow the FUNC = X TT M SS command. FUNC SAVE XX Save the work space function to location XX.

  • Page 41: Computer Remote Error

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 DATE ? Read the present date in the system. The data returned will follow the DATE = command. WARNINGS ? Read the present list of warnings from the last or present running CONC or FLOW. The data returned will be "MFC 1 code, MFC 2 code, ..."...
  • Page 42 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 "FLOW ** ..." Flow command flow controller number out of range. "FLOW X TARGET = **" Flow target value out of range. "FLOW **" Unknown flow command. "CONC UPDATE" Trying to update a concentration mode with a flow or purge already in progress.
  • Page 43 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 "PURGE QUERY **" Purge query location out of range. "PURGE ** ..." Purge command flow controller number out of range. "PURGE **" Unknown purge command. "PORT ** ..." Port number out of range.
  • Page 44 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 "DATE **" Unknown date command. "FUNC ** = TT M SS" Function item number out of range (Assignment). "FUNC XX = ** M SS" Function run time out of range (Assignment).

  • Page 45: Reverse Video

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 "FUNC **" Unknown function command. "PROC **" Unknown procedure command. "PROC XX = ** ** D FF" Procedure start time is greater than 24:00 hours. "PURGE ALL **" Unknown purge all command.

  • Page 46: New Password

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.12 NEW PASSWORD PASSWORD EDITOR Entering CONCENTRATION MODE =NONE Entering FLOW MODE =NONE Entering PORT MAINTENANCE =NONE Entering CALIBRATION MODE =NONE Entering SEQUENCER MODE =NONE Entering PURGE MODE =NONE Entering REMOTE MODE...

  • Page 47: Connecting Communications Equipment

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 BAUD RATE The baud rates available are 300, 1200, 2400, 4800, 9600, 19.2K, 38.4K, and 56K. For short distances under 5 meters, a high baud rate can be used without any problems. In a noisy environment, a slower rate is strongly recommended.

  • Page 48: Using Terminal Remote

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 rating (ie. V.22, bell 212A, V.32). If the modem connected to the system has error correction capabilities (Usually this capability is available in modems with a CCITT rating above V.32) they might have to be disabled if the error codes are sent to the system (NOTE: Some modems will have the command "AT&Q0"...

  • Page 49: Status Setup

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.15 STATUS SETUP 5.15.1 INPUT STATUS INPUT ASSIGNMENT EDITOR Type Setup# Status in #1 = STOP Status in #8 =FUNCTION Idle timer =PROCEDURE Time for idle timer = 00 (0 to 24 hours, 0 = OFF)
  • Page 50 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 The instrument has eight assignable status output lines available for contact closure or switching of 24 volts on the rear panel. To switch between contact closure and 24 volts control, the user must remove the cover to the system and move the position of the switches, between A and B, at the top of the status board on the back panel.

  • Page 51: Volts Mode

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 5.16 VOLTS MODE VOLTS MODE Port Target Volts Actual Volts 0.25 0.25 1.75 1.75 ────────────────────────────────────────────────────────────────────────── Ozone 1.05 Ozone block flow 500.0 Ozone block temperature 50.0 Ozone lamp drive voltage 12.56 START...

  • Page 52: Appendix

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 APPENDIX USER SAFETY - Operator's Responsibilities The operator of the system must keep safety in mind when using the instrument. Danger to the operator or serious damage to the system can occur if the operator does not consider all the warnings listed in this manual or displayed by the system.

  • Page 53: Dpower Supplies And Power Entry Module

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 POWER SUPPLIES AND POWER ENTRY MODULE Two open frame linear power supplies are used to supply power to the electronics and to the solenoids. These power supplies were chosen to operate on most AC power sources found worldwide, provided the power entry module is set to...
  • Page 54 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 CYANOGEN CHLORIDE ClCN CYCLOPROPANE C3H5 DEUTERIUM DIBORANE B2H6 DIBROMODIFLOUROMETHANE CBr2F2 DIBROMETHANE CH2Br2 DICHLORODIFLOUROMETHANE CCl2F2 DICHLOROFLOUROMETHANE CHCl2F DICHLOROMETHYLSILANE (CH3)2SiCl2 DICHLOROSILANE SiH2Cl2 DICHLOROTETRAFLOUROETHANE C2Cl2F4 DIFLUOROETHYLENE C2H2F2 DIMETHYLAMINE (CH3)2NH DIMETHYL ETHER (CH3)2O DIMETHYLPROPANE C3H12...
  • Page 55 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 NEON NITRIC OXIDE NITROGEN NITROGEN DIOXIDE NITROGEN TRIFLUORIDE NITROSYL CHLORIDE NOCl NITROUS OXIDE OCTAFLUOROCYCLOBUTANE C4Fe OXYGEN OXYGEN DIFLUORIDE PENTABORANE B5H9 PENTANE C5H12 PERCHLORYL FLUORIDE CLO3F PERFLUOROPROPANE C3F8 PHOSGENE COCL2 PHOSPHINE PHOSPHOROUS OXYCHLORIDE...

  • Page 56: Hspecifications

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 SPECIFICATIONS FLOW Size Ranges of MFC: 0 - 10 sccm to 0 - 30 slpm; up to 1500 slpm (optional) Performance Performance* as a Percent of Set point From 10 to 100 %...

  • Page 57: Electrical

    Remove the "cam wheel" and rotate it such that the proper voltage shows through the opening. If you have any questions, please call Environics for assistance. Improper line voltage can cause serious damage to the instrument. Users must make sure that line voltages are compatible with the operating voltage of the instrument.

  • Page 58: Troubleshooting

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 TROUBLESHOOTING I.1.1 TEST POINTS The test points are color coded loops of wire soldered to their board. A spring tension test hook should be used to connect to the test point of interest. Care should be taken so not to short the test hook to any adjacent components.

  • Page 59: Pc210 Ozone Board (Optional)

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 TP17 - Command volts F TP18 - Response volts F TP19 - Command volts G TP20 - Response volts G TP21 - Command volts H TP22 - Response volts H TP23 - Command volts I TP24 - Response volts I I.1.1.6 PC210 OZONE BOARD (Optional)

  • Page 60: Problems And Solutions

    I.1.2 PROBLEMS AND SOLUTIONS The Environics 2000 Series, with few moving parts and a durable electronics package, should provide a high level of reliability. In the event that there is a failure, the following troubleshooting guide may be useful in isolating and solving the problem.

  • Page 61: Ozone Lamp Replacement (Optional Ozone Generator)

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Check +24 volts. No Flow Check flow controller cable. Check response and command test points on the motherboard (PC208) and analog board (PC202). Check calibration tables. Use volts mode to command flow controller and then check command and response points test points.

  • Page 62: Jprinted Circuit Board Schematics

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 PRINTED CIRCUIT BOARD SCHEMATICS All Printed Circuit Board Schematics are included with new systems on a CD along with this manual. They are provided in PDF file format in a folder labeled "Gen2 schematics." The below chart will guide you as to which file/s corresponds to each circuit board.

  • Page 63: Kparts List

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 PARTS LIST Description Qty. Part No. S-2000 Computerized Ambient Calibrator S-2000 Flow Controllers (all 1/4" fittings) Mass flow controller MA01-005-020000 Mass flow controller MA01-006-00100 Screw, (8/32 x 3/8) HA0101-0832C06 Front panel subassy...
  • Page 64 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Description Qty. Part No. Fuse, 2 amp FJ02-002-0022 Fan subassy A012 BA01-003 Connector HJ10-008 Pins AJ06-003 Fan guard GA101 Filter Washer, flat (7/16 ID, 7/8 OD) HA0601-E300258 Screws (6/32 x 1.5")
  • Page 65 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Description Qty. Part No. Base M082 Detector holder/seal M084 Detector cap M085 Bulkhead connector M086 Thermistor, subassy A028 O ring, lamp KA01-BA2110-01 Window AA01-001 O ring, window KA01-BA2014-01 5-hole disk 100-E58...

  • Page 66: Pc Board Parts List

    Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Description Qty. Part No. Ozone Generator board, subassy PC210-D 1.10 Harnesses Line cord (120 VAC) VJ10-003-H5167 Harness, RS-232 E015 Harness, Printer E015 Harness, data bus E009 Harness, 24 volt, motherboard E013...
  • Page 67 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SOC9 HJ07-Z84 Socket, 84 pin PLCC U1,U35 SOC10 HJ07-A10 Socket, 10 pin SIP (for RN1 & RN2) AJ99-001 Test point, black UK17-002 Transputer...
  • Page 68 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- R10-13,17,18 RK2-5114 Resistor, M.F., 5.11 Meg R21,22 RK2-1501 Resistor, M.F., 1.5 K RK1-010 Resistor, M.F., 1 Ù SOC1 HJ07-001-R08 Socket, 8 pin DIP, .300...
  • Page 69 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Subassy P/N: PC204 Description: Comm/Driver Board Revision: Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- C1,3-23, C25-27 CK20-104B Cap., Ceramic, 0.1 uf CK11-101A Cap., Tant., 100 uf CK10-00135C107 Cap., Al El,...
  • Page 70 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CGD01-10 A003 Card Guide, subassy. DCC1 PJ03-001 DC-DC Converter, +5 to +22V J1-5 HJ12-002 Edge Card Conn, 100 pin HJ01-022 Conn, double row, 25 x 2...
  • Page 71 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- D3-8 DK01-00-4148 DIODE 1N4148 FOAM TAPE HK02-003-T220 HEAT SINK, TO220 HK01-004-T003 HEAT SINK, TO3 UK22-010 OP AMP, QUAD LM324AJ UK22-014 OP AMP, SINGLE...
  • Page 72 Environics Series 2xxx Operating Manual AUGUST 2011 REV 8 Item Ref. Qty. Part number Description Value ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- HJ13-003 CONNECTOR (MATE) HJ14-003 CONNECTOR HJ13-001 CONNECTOR (MATE) HJ14-001 CONNECTOR HJ13-002 CONNECTOR (MATE) HJ14-002 CONNECTOR RK2-4750 RESISTOR 4.7K RN1-4 HJ07-A10 10 PIN SIP SOCKET...

This manual is also suitable for:

2020 series2010 series2014 series

Table of Contents
