Summary of Contents for Xtreme 61038
-
Page 2: Specifications
Specifications TABLE OF CONTENTS Item No. 36060 Introduction Chipping Capacity 70 mm Specifications Disc Size 375 × 8 mm Symbols Disc Speed 2600 rpm Safety Knives Two 76 × 36 × 6 mm General Safety Rules 155 × 60 mm Specific Safety Rules Infeed Throat Opening 115 ×... -
Page 3: General Safety Rules
Do not force the machine. Use the correct machine for your application. The correct Wear safety footwear. machine will do the job more efficiently and safer at the rate it was designed. Do not remove or tamper with the Personal Safety protection and safety devices. - Page 4 Never operate the machine when it is in need Fuel Safety of repair or is in poor mechanical condition. Fuel is highly flammable, and its vapors can Replace damaged, missing, or failed parts explode if ignited. Take precautions when using before using it.
-
Page 5: Specific Safety Rules
Specific Safety Rules Never operate this machine without the feed hopper or discharge chute properly attached. Identify hazards and take preventive steps to Operating Zone avoid accidents and minimize risk. Possible hazards include, but are not limited to, moving parts, thrown objects, weight of the machine and components, and the operating environment. - Page 6 Never attempt to unclog either the feed observe these safety instructions could result hopper or discharge chute while the engine is in serious injury or death. running. Immediately shut off the engine, allow Avoid contact with hot fuel, oil, exhaust fumes the cutting disk to come to a complete stop, and hot surfaces.
-
Page 7: Contents Supplied
CONTENTS SUPPLIED The wood chipper comes partially assembled and is shipped in carefully packed package. After all the parts have been removed from the package, you should have: OPTIONAL 1. Main Machine ASSEMBLY 2. Wheels (1 pair) 3. Chipper Cone Following the assembly directions below, you 4. - Page 8 Kickstand Rod Wheel Shaft Align the top of the kickstand rod holes with the two holes on the engine mount plate. Use the two M8×50 bolts, flat washer, and nuts from hardware bag C to secure the kickstand. Assembly Hole M8×50 (×2) ×...
- Page 9 Deflector Collection Bag (Optional) Align the holes in the deflector bracket with 1. Loosen the adjusting wing nut to set the the holes in the rotor disc housing. Secure with discharge shoot door. two M8×20 bolts from the hardware bag E. 2.
-
Page 10: Features And Controls
KNOW YOUR Wood Chipper Features and Controls Feed Hopper Grip Handle Collection Bag (Optional) Deflector Cone Engine Transport Wheels Kickstand Rod Recoil Starter Handle Engine On/Off Switch Throttle Control Choke Control Fuel Shut-Off Valve WOOD CHIPPER 36060UK00M100_BS.indd 10 2019/8/28 14:44:23... - Page 11 Feed Hopper Throttle Control The Feed Hopper is on top the unit. Always The throttle control regulates the speed of load leaves and other light waste into the the engine and will shut off the engine when hopper opening. Never insert hands into the it is moved to the STOP position.
- Page 12 CLOSED OPEN 1. The engine must be off and allowed to cool 3. Move choke at least two minutes before adding fuel. lever to the CLOSED position. 2. Remove the fuel filler cap and fill the tank. I f t h e e n g i n e (See engine manual for fuel capacity, fuel is hot, closing recommendation, and location of fuel cap.)
- Page 13 The chipper can clog up with soft, wet, or fibrous materials. However, if you feed soft materials intermittently with branches, there should be no problem, as the chipper tends Feed Hopper to clean out any residue left in the machine. If any stringy material wraps around the rotor shaft, remove it before it works its way into the bearing.
-
Page 14: Maintenance
engine speed will help extend the life of the MAINTENANCE engine, as well as conserve fuel and reduce noise level. Stop Engine Maintaining your chipper will ensure long life to the machine and its components. To stop the engine in an emergency, simply turn the engine switch to the OFF position. - Page 15 Procedure Before each use Every 8-10 Hours Every 40 Hours Check engine oil level Check general equipment condition Check that cutting disk turns freely (with a long stick only) Visually inspect knife for damage Check knife for sharpness Check knife attachment screws Check for any loose nut and bolts Change engine oil time 5 hours...
- Page 16 KNIFE REMOVAL AND REPLACEMENT 5. Using Allen key S4 to remove the two screws on top of engine shaft bushing. This chipper is equipped with two chipper knives that are mounted on the cutting disk. When the 6. Using Allen key S8 to remove the socket knives are dulling or show nicks, the machine will head cap screw fixing the engine shalt.
- Page 17 If knife show signs of wear, replace it. Using STORAGE the 8mm hex wrench, reach into the main housing and remove the two socket head cap screws and the chipper knife. If your chipper will not be used for more than 30 days, follow the steps below to prepare M8×16 (×4)
-
Page 18: Troubleshooting
TROUBLE SHOOTING Problem Cause Remedy 1. Attach spark plug wire securely to 1. Spark plug wire is spark plug disconnected 2. Fill with clean, fresh gasoline 2. Out of fuel or stale fuel 3. Engine and Fuel valve must be in 3. -
Page 19: Parts Schedule
PARTS SCHEDULE WOOD CHIPPER 36060UK00M100_BS.indd 19 2019/8/28 14:44:34... -
Page 20: Parts List
Parts List Description Q'ty Description Q'ty Wheel Locknut M8 Bolt M8×12 Chipper Cone Wheel Axle Locknut M6 Washer 14 Rubber Flap Cotter Pin 3.2×18 Top Panel Rotating Cover Plate Bolt M6×16 Rotor Housing Cover Rotor Disc Seat Rotor Housing Bolt M8×20 Fan Housing Bolt M10×16 Screw 3/8-24UNF×31.75...
