Summary of Contents for Xytronic ContrilByWeb DirekTronik X11S
- Page 2 X-11s™ Users Manual X-11s User Manual Revisions Revision Description Initial release Page 2 Xytronix Research & Design, Inc.
-
Page 3: Section 1: Introduction
X-11s™ Users Manual Introduction Section 1: Introduction The X-11s™ 2-relay expansion module is used in conjunction with the X-600M™ controller. The X-11s has two high-current relays. Both relays have Form-C contacts (SPDT). A rugged, high-current connector provides connections to the relays. One or more X-11s expansion modules can be connected to a X-600M control module with a ribbon cable. - Page 4 Introduction X-11s™ Users Manual ribbon cable expansion bus provides both power and communications connections. Power Supply The expansion bus can provide up to 1.7 Amps for powering up to 32 expansion modules; however, the maximum number of expansion modules depends on the module type and power source attached to the X-600M.
-
Page 5: Section 2: Installation And Connections
X-11s™ Users Manual Installation and Connections Section 2: Installation and Connections Installation consists of mounting the X-11s and connecting it to an X-600M controller with a 10-conductor ribbon cable. Programming and testing is done by using a web browser to configure the web pages, inputs, and outputs for your specific needs. - Page 6 Installation and Connections X-11s™ Users Manual 2.3 Making Connections CAUTION: Make sure the power is shut off before making connections CAUTION: This unit should be installed by a qualified technician. CAUTION: Miswiring or misconfiguration could cause permanent damage to the X-11s, the equipment to which it is connected, or both.
- Page 7 X-11s™ Users Manual Installation and Connections Wire Specification: Use wire rated for 90ºC (min) for connections to the terminal blocks Connector Specifications: Type: 6-position, removable, 7.62 mm pitch, with tool-free snap-lock latches Stripping Length: 10mm Connection capacity: stranded, 10mm solid Conductor minimum: 24AWG (UL/CUL) Conductor maximum:...
-
Page 8: Section 3: Example Applications
Example Applications X-11s™ Users Manual Section 3: Example Applications 3.1 Control a device over an IP network The illustration below shows a simple example of how to use the X-11s to control a device over an IP network. The device to be controlled is wired in series with the relay contacts. Note: A fuse or circuit breaker is shown to limit current overload. -
Page 9: Section 4: Configuration And Setup
X-11s™ Users Manual Configuration and Setup Section 4: Configuration and Setup 4.1 Setup Example The Quick Start Demo After making the power and Ethernet connections, the X-600M can automatically scan for the presence of any ControlByWeb™ Ethernet devices (on the same sub-net) and also for any expansion modules connected to the X-600M via the ribbon-cable connector. - Page 10 Configuration and Setup X-11s™ Users Manual 3. In the Select column, click the checkboxes of the I/O components you would like to configure and select the Create Device Widget checkbox (This will display the status of the I/O on the Dashboard). Click Add Checked I/O to submit these changes.
- Page 11 X-11s™ Users Manual Configuration and Setup 5. On the main menu, click the View Dashboards menu tab. The View Dashboards page shows a display similar to what users will see when accessing the X-600M's control page. A button and status display for both relays should appear.
-
Page 12: Appendix A: Specifications
Appendix A: Specifications X-11s™ Users Manual Appendix A: Specifications Power Requirements Input Voltage: 9-28 VDC (power is supplied via the X-600M controller, 24V recommended) Current: See table below for typical values at 25°C Power Supply Relays OFF Relays ON 9 VDC 15 mA 260 mA 12 VDC... - Page 13 X-11s™ Users Manual Appendix A: Specifications Operating Temperature: -40ºC to 65.5ºC (-40ºF to 150ºF) Storage Temperature: -40ºC to 85ºC (-40ºF to 185ºF) Humidity: 5-95%, non-condensing Mechanical Size: 1.41 x 3.88 x 3.1 in. (35.7 x 98.5 x 78 mm), (not including connector) Weight: 4.8 oz (136 g) Electromagnetic Compliance...
-
Page 14: Appendix B: Trademark And Copyright Information
Appendix B: Trademark and Copyright Information X-11s™ Users Manual Appendix B: Trademark and Copyright Information This document is Copyright ©2014 by Xytronix Research & Design, Inc. All rights reserved. X-600M™, WebRelay™, ControlByWeb™, and Xytronix Research & Design™ are trademarks of Xytronix Research &... -
Page 15: Appendix C: Warranty
X-11s™ Users Manual Appendix C: Warranty Appendix C: Warranty This Xytronix Research & Design, Inc. product has a warranty against defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, Xytronix Research &... -
Page 16: Appendix D: Fcc Statement
Appendix D: FCC Statement X-11s™ Users Manual Appendix D: FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: - This device may not cause harmful interference. - This device must accept any interference received, including interference that may cause undesired operation. -
Page 17: Appendix E: Mechanical Dimensions
X-11s™ Users Manual Appendix E: Mechanical Dimensions Appendix E: Mechanical Dimensions Xytronix Research & Design, Inc. Page 17...
