Installation Manual | ACINV Series 1RU Rack Mount Inverters Contents 1. Features ................................4 1.1 Applications .............................4 1.2 Specifications ............................5 Product Support 1.3 Mechanical Drawings ..........................6 Product support can be obtained using the following addresses and telephone numbers. 2. Introduction ..............................7 2.1 Front Panel Description ...........................7 Phone: +1-208-635-6400 2.2 Rear Panel Description ..........................8...
Installation Manual | ACINV Series 1RU Rack Mount Inverters 1. Features 1.2 Specifications • R load Pure sine wave output (THD <3%) MODEL NUMBER ACINV1-1KVA ACINV2-2KVA • By-pass function (when external AC source connected) • Programmable output frequency, 50/60Hz (front panel DIP switch) 100-120VAC Models Inverter Section •...
Installation Manual | ACINV Series 1RU Rack Mount Inverters 1.3 Mechanical Drawings 2. Introduction ACINV Series is an advanced range of pure sine wave output power inverters employing microprocessor technology. For optimum performance and life expectancy they must be installed and used properly. Please read the instructions in this manual BEFORE installing the unit and switching it on.
Installation Manual | ACINV Series 1RU Rack Mount Inverters 2.2 Rear Panel Description 2.2.5 DC Input Terminals. Used to connect to a -48V battery or other suitable DC source. [+] must be connected to the positive terminal of the battery or DC source. 115VAC OUTPUT MODELS AC MAINS [-] must be connected to the negative terminal of the battery or DC source.
Installation Manual | ACINV Series 1RU Rack Mount Inverters 2.3.1 Dry - Do not allow water to drip or splash on the inverter. 2.3.17 Aluminium conductors must not be used for protective earthing connections. 2.3.2 Elevated Operating Ambient - if the inverter is installed in a closed or multi-unit rack assembly the operating 2.3.18 For supply connections, use wires suitable for at least 105°C since, from test results, cable temperatures ambient temperature of the rack environment may be greater than the room ambient.
Installation Manual | ACINV Series 1RU Rack Mount Inverters 2.4.4 Before proceeding further, carefully check that the cables you have just connected to the negative terminal of inverter are connected to the negative DC power source. The longer and narrower these cables, the greater the voltage drop. CAUTION! WARNING! Reverse polarity connection will blow a fuse in inverter and may...
Installation Manual | ACINV Series 1RU Rack Mount Inverters 2.8.1 Controls and indicators: 2.8.9 Under voltage protection indicator: (UVP) The ON/OFF switch turns the control circuit in the power inverter on and off. When UVP is indicated on the display the unit has shut itself down due to the input voltage falling below the limits shown above.
Installation Manual | ACINV Series 1RU Rack Mount Inverters • Make sure that the chassis ground lug at the rear of the unit is solidly connected to the ground system of the rack or 5.2.2 NEVER smoke or allow a spark or flame in the vicinity of batteries. cabinet in which it is installed. •...
Page 10
