Preface
Respected users:
How are you! Thank you for purchasing our instrument. In order to use it in
a better manner, we remind you to read the instruction for use carefully
before use and keep it properly so as to look up in the future use.
Limited warranty and limited responsibility
Xintai Instruments and Apparatus Co., Ltd guarantees that the product
enjoys warranty service of one year from the purchase date.
But the warranty is not applicable to fuse and disposable battery or the
damage caused by improper operation, accidents, negligence, misuse,
remodeling, pollution and abnormal condition of the operation environment.
The distributor has no right to provide any warranty in the name of Xintai
Instruments and Apparatus Co., Ltd.
Xintai Instruments and Apparatus Co., Ltd authorizes the retail dealers to
provide new products or unused products to final customers but does not
authorize them to provide guarantee with wider scope or different contents.
Only the products that are purchased through distributors authorized by
Xintai Instruments and Apparatus Co., Ltd or products that the purchaser
paid according to proper international price can enjoy the warranty support
of our company. When the product bought in a country is sent to another
country for repair, Xintai Instruments and Apparatus Co., Ltd reserves the
right to charge the import fees for the parts and components to be repaired
or replaced from the purchasers.
www.xintest.com.cn
When warranty service is repaired, please contact the service center
authorized by Xintai Instruments and Apparatus Co., Ltd to obtain the
authorization information for return. Then post the product together with
problem description to the service center with postage and insurance
expenses prepaid. Our company will not undertake any responsibility for
any damage occurred during the process of transportation. The product will
be posted to the purchaser after repair with the transportation expenses
paid by the purchasers.
If the product failure is verified by negligence, misuse, pollution, change,
accidents or improper operation or handling after inspection, including the
over voltage failure caused by use without following the rated value
stipulated by the product or daily service wear the of the parts, our
company will estimate the repair expenses and carry out repair after
obtaining the consent of the purchasers. The product will be posted back to
the purchaser after repair with the transportation expenses paid by the
purchasers.
The guarantee is the only compensation that users can be obtained and
does not include other express or implied guarantees. Xintai Instruments
and Apparatus Co., Ltd will not undertake any responsibility for any special,
indirect, accidental or subsequent damage or loss, including any data loss
caused by any reasons or inference.
Because some countries or states do not allow implied warranties and
incidental or consequential damages.Restrictions, so the above limitation of
liability and regulations may not apply to every buyer.
The users shall make promise that they familiarize with the application field
and occasi on. The purchase indicates that the users are deemed to know
the suitability for the products.
1
www.xintest.com.cn
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT H8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xintai HT H8

  • Page 1 The product will be posted back to The distributor has no right to provide any warranty in the name of Xintai the purchaser after repair with the transportation expenses paid by the Instruments and Apparatus Co., Ltd.
  • Page 2: Safety Instruction

    If the product case is damaged, don’t use it continuously. Please observe the following guide in order not to damage the product: Please contact the local distributors or agents of Xintai under such Don’t assemble or dismantle the product without permission.
  • Page 3 Don’t weld the battery without permission. Do not touch the electric wire with wet hands. It is possible to cause electric shock when touching the electric wire Such operation may damage the battery and result in leakage and with wet hands. When pulling out the electric wire, hold the electric wire explosion of the battery.
  • Page 4 Preliminary Acquaintance with Infrared The product temperature may increase after a long time of Thermal Imager charging. For a long time, infrared thermal imaging detection technology has become You may feel scorching heat when the hands touch the sensors. an important means to ensure Industrial safety in developed countries. The Problem caused by water condensation application field includes electric power, metallurgy, petro-chemistry, Don’t bring the instrument into low temperature environment from high...
  • Page 5: Lens Maintenance

    Overview Cleaning of the Products This product is an infrared camera that integrates surface temperature Please use damp cloth or weak soap to clean the enclosure of the device. measurement and real-time thermal image. The traditional inferred Don’t use abradant, isopropanol or solvent to clean. The lens and screen thermometer needs to measure every component one by one while it is not should be cleaned with use of cleaning agents for professional optical necessary for infrared imaging camera, thus saving time.
  • Page 6: Performance Index

    Charging of the Battery and Description Performance Index Use USB data line to charge: Display screen 3.5-inch full-view TFT display The product has built-in chargeable 26650 lithium batteries. Infrared image resolution 384×288 When the battery level is low, the top right of the screen will display Visible image resolution 300000pixel “...
  • Page 7: Product Description

    Product Description Storage capacity Built-in 8G (Actually available 6.6G) 1. Instruction to Structure File format Micro USB 2.0 Built-in chargeable 26650 battery Display screen Power supply Detachable Working time 3-4 hours Setting command Unit、language、date、time、information Keypad Language English、Chinese、Italian、German Selectable: 5 minutes/20 minutes/ Automatic power-off time not power off automatically Product size...
  • Page 8 2. Display Description Micro USB Please open the cap in use Range WiFi Current emissivity Central point Battery temperature power Infrared imaging sensor The highest The lowest temperature temperature cursor cursor Temperature cursor at Color code central point Time Image capture key Maximum value/minimum value of field temperature Range: The range of temperature measurements.
  • Page 9: Initial Operation

    LCD screen display The lowest temperature cursor: used to indicate the lowest temperature position in the screen area. It will move with the movement of the lowest After turning on the power, the screen shows the thermal imaging temperature. The cursor displays red. The temperature value is displayed at status.
  • Page 10 Introduction to the Menu Read images Press the left of “ /MENU” key and the menu bar appears. They are Open the USB protective cover as shown in . Use USB line to “Image overlapping”, “Image”, “Color palette”, “Emissivity” and “Setting” connect the USB port and then computer to read the images or submenus.
  • Page 11 1.2. Delete Images While viewing the image, press the “ ” button, the screen will display “Delete photo?” Select “Yes” or “No” to delete the image, press the Rainbow Iron oxide red Cold color White heat Black heat “ ”“ ”button to Switch the selection, then press the “SELECT/ENTER”...
  • Page 12 3.2. Emissivity Setting 3. Introduction to “Emissivity” Sub-menu The product is provided with four types of object measurement modes: 3.1. Emissivity Description Coarse object (0.95) The emissivity of the product can be adjusted from 0.01 to 1.00 with the Semi-matte object (0.85) default value of 0.95.
  • Page 13 3.3. The Emissivity Value of Common Materials As shown in the figure, press “ / MENU” key to enter the main menu and select “ ”(emissivity) option and press “ ” key to enter Substance Thermal radiation Thermal radiation Substance the emissivity list.
  • Page 14 4.1. Auto Shutdown Setting 4. Introduction to “Setting” Sub-menu After entering the "Settings" sub-menu, select " / MENU" (automatic Press “ /MENU” key to select the “ ”(setting) option in the main shutdown), press navigationThe “ ” button in the button enters the menu.
  • Page 15 4.6. Time Setting 4.7. Enable/Disable of the Highest and Lowest Temperature Cursor As shown in the figure, after selecting “ ” (set time), press “ ” in the navigation key to enter the setting time. As shown in the figure, after selecting “ ”...
  • Page 16 After enabling WIFI, use the mobile device to search for WIFI. The hotspot 4.8. Wireless WIFI on and off name is ThermalCamera-xxxxxx (xxxxxx is the last six digits of the MAC); access the device through the IP address 192.168.230.1. As shown in the figure, after selecting “ ”...
  • Page 17: Troubleshooting

    Troubleshooting Click “Image” in the mobile device to enter the image view, press the image to download the image, long press the image to save to the mobile device, If you encounter with any problem when using the thermal image device, click “Infrared Video Stream”...
  • Page 18 After-sale Service of the Product Considerations: 1. If the product malfunction, repair or replacement with new or good Respected customers: product is made according to the condition after the product is inspected. Thank you for purchasing the product of our company. The product carries a 2.
