2004 SONY MOBILE
PRODUCT GUIDE
XS-V1635X
3-Way Speaker
Specifications
Speaker
Peak Power
Rated Power
Impedance
Sensitivity
Frequency response
Mass
Dimensions
5 x 7 mm (7/32 x 9/32")
28 mm (1 1/18")
Design and Specifications subject to change without notice.
Coaxial 3-way
Woofer 16 cm (6 3/8 in.) cone type
Midrange 3.0 cm (1 3/16 in.) balance dome type
Tweeter 1.1 cm (13/32 in.) dome type
250 watts
65 watts
4 ohms
91 dB/W/m
30 - 30,000 Hz
Approx. 1,050 g (2 lb 6 oz) per speaker
4.5 mm (3/16")
153 mm (6 1/8")
163 mm (6 1/2")
• 6-1/2" HOP woofer cone
• 1-3/16" Nano-fine mid
• 7/16" dome tweeter
• 250W peak power (65W RMS)
• Flexible mounting options
15 mm (19/32")
54 mm
(2 1/4")
