Summary of Contents for Alemite 343530
- Page 1 User and maintenance instructions AFCS Enterprise controller Model 343530 Date of issue September 2017 Form number 671097 Version...
-
Page 2: Table Of Contents
Contents Explanation of safety signals Explanation of safety signals Safety Introduction Controller overview DANGER Mounting dimensions Indicates a hazardous situation that will Cat 5 ethernet network wiring result in death or serious injury if not Wiring diagram avoided Conigure controller Tank monitor functions AFCS Enterprise controller parts/kits Troubleshooting... -
Page 3: Safety
Introduction WARNING For indoor use only Read and carefully observe installation AFCS Enterprise controller model 343530 Failure to comply may result in instructions before installing, operating or controller integrates with other AFCS serious personal injury and/or damage troubleshooting referenced equipment... - Page 4 Fig. 1 AFCS Enterprise network Item Description AFCS Enterprise web server AFCS Enterprise database Oil tank Pump Tank level sensor AFCS controller Combo unit Hose reel PC/web browser Fig. 2 AFCS Enterprise Hardware Item Description System line with wall- mounted pump System line with tank- mounted pump Line to hose reels...
-
Page 5: Controller Overview
Controller overview Fig. 3 Item Description Quantity in universal bushing Electrical enclosure PCB mounting bracket and power supply AC power entry module with fuse Controller PCB Ethernet port PCB wire terminal Touchscreen LCD display Solenoid test button... -
Page 6: Mounting Dimensions
Mounting dimensions Fig. 4 shows unit dimensions and wall mounting hardware Fig. 4 Ø.185 in (4,7 mm) 1.22 in (31 mm) 1.22 in (31 mm) Ø.287 in (7,3 mm) 7.24 in (183,8 mm) 0.61 in 6.06 in (154 mm) (15,4 mm) 11.23 in (285,3 mm) - Page 7 Combo unit Fig. 5 Combo unit Model 343539 all in one combo unit includes solenoid, pulse meter and 150 micron ilter Refer to form 671102 for further speciications Ready light – 343546 Fig. 6 Optional ready light illuminates when luid Ready light solenoid is open and station is ready to dispense Ready light is hard wired into...
- Page 8 Tank monitor probe Fig. 7 NOTE 2 in dimension must remain 2 in or less Moving sensor tip further from threaded end of adapter can cause sensor to work improperly Use 2 in NPT mounting assembly to mount sensor to standard 2 in bung for optimal results Sensor assembly comes conigured for mounting solution and can be mounted to standard 2 in NPT tank...
- Page 9 Fig. 10 Fig. 10 shows if luid level is at or above NOTE blind zone, tank monitor system will read it Sensor range: 86 in (2 200 mm) to as 100% full 8 in (200 mm) from tip of sensor A - Fluid level in tank B - Blind zone for ultrasonic sensor - All non-contact ultrasonic sensors have...
- Page 10 Coniguration of tank monitor NOTE NOTE If AFCS Enterprise controller is using Password is pin number used to log into To fully conigure AFCS Enterprise controller static IP addressing, computer must menu system accessible from LCD tank monitor features connect to computer have same base IP address (irst three screen on controller (Default: 5148) that is on same network as controller and...
- Page 11 Please reference tank for people not using Alemite tank monitor Select tank to conigure Conigure tanks shape diagram to ind the ields sensor In this case, maximum range and individually or all the same Refer to Fig.
- Page 12 Fig. 12...
-
Page 13: Cat 5 Ethernet Network Wiring
Monitor If you are an Enterprise software customer, all coniguration options will be automatically sent to Enterprise software Fig. 13... - Page 14 Cat 5 or 6 ethernet network wiring for networking controllers Table 2 RJ45 PIN # Wire color (T568B) Wire diagram (T568B) 10 base–T signal 100 base TX signal 1000 base–T signal White/orange Transmit+ BI_DA+ Orange Transmit – BI_DA– White/green Receive + BI_DB+ Blue Unused...
-
Page 15: Wiring Diagram
Wiring diagram NOTE DANGER Apply power and conigure controller Disconnect all power supplied to Fig. 16 shows wiring connections from before connecting to network via controller before performing installation hardware to controller wiring terminals ethernet networking cable or wiring Four conductor 18AWG shielded cable (A) Failure to comply will result in death is recommended... - Page 16 Fig. 17 MAC Address 00:50:C2:77:D1:01 Controller: 1 Site: 1 Enter This is this currently dispense IP Address DHCP: Off unit #1 unit’s number (1-30) Tank Monitor Password DELETE Enter this This is Enter dispense currently your unit’s site #1 password site number (1-30)
- Page 17 Fig. 18 To conigure controller: 1 Power on controller and wait for start up Unit Number 1 is online at 10.10.10.1 screen to display (Fig. 18) 2 Select top screen button (11) 1: Hose 1 2: Hose 2 3: Hose 3 3 Enter password Default password is 1234 10W40 10W30...
- Page 18 Unit network settings (static NOTE mode) Controllers function by default in static If network is running in static mode, enter mode network settings for each controller • Fixed IP address Fig. 19 • Subnet mask • Default gateway Unit : 1 Site: 1 To enter unit network settings: 1 Power on controller and wait for start up...
-
Page 19: Tank Monitor Functions
Tank monitor functions Fig. 21 Select a Tank Sensor Tank Sensor Calibration To get accurate tank levels, you must measure the Sensor Standoff distance. Tank: #1 Tank: #2 Tank: #3 This is the distance from the bottom tip of Fluid: Name Fluid: Name Fluid: Name the sensor to the highest point inside the... -
Page 20: Troubleshooting
Troubleshooting Condition Cause Solution Fluid will not come out of meter Master air solenoid is not opening Check if air solenoid opens after dispense is initiated Red light will be visible on controller board for port assigned to air solenoid Air solenoid will make easily detectable air release sound when solenoid shifts from open to close No air supplied to pump... -
Page 21: Ec Declaration Of Conformity
Designation: Controller Type: AFCS Enterprise Model: 343530 Year of construction: (see type identiication plate) Furthermore, the following directives and harmonized standards were applied in the respective applicable areas:... - Page 22 This page intentionally left blank...
- Page 23 This page intentionally left blank...
-
Page 24: Warranty
® Alemite, LLC is a registered trademark The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted Every care has been taken to ensure the accuracy...
