Sony XS-V1330A Marketing Product Manual

2004 SONY MOBILE
PRODUCT GUIDE
XS-V1330A
3-Way Speaker
Specifications
Speaker Coaxial 3-way
Woofer 13cm (5 1/8 in.) cone type
Midrange 3.0 cm (1 3/16 in.) balance dome type
Tweeter 1.1 cm (13/32 in.) dome type
Peak Power 180 watts
Rated Power 45 watts
Impedance 4 ohms
Sensitivity 91 dB/W/m
Frequency response 40 - 30,000 Hz
Mass Approx. 610 g (1 lb 6 oz) per speaker
Dimensions
25 mm (1")
Design and Specifications subject to change without notice.
4.5 x 10 mm (3/16 x 13/32")
• 5-1/4" HOP woofer cone
• 1-3/16" balanced dome mid
• 7/16" dome tweeter
• 180W peak power (45W RMS)
• Flexible mounting options
14 mm (9/16")
45 mm
(1 13/16")
