Summary of Contents for Hexagon HxGN MineProtect OAS-LV 202
- Page 1 MINING SAFETY HxGN Mine Operator Alertness System – Light Vehicles User Reference Manual Version No. 3.0 Issued February 2020 English...
- Page 2 This document and any information or descriptive matter contained therein is communicated in confidence and is the copyright property of Hexagon Mining. Neither the whole, nor any extract may be disclosed, loaned, copied, or used in manufacturing or tendering purposes without their written consent.
- Page 3 Carvalho 06 Mar 2020 Gustavo Adding the MPE Calculations, Severino Label Variants, adding all units 13 Apr 2020 Gustavo Updating the Labels, Severino statements to ANATEL and NOM/IFT compliance and the item 3.2 with the RF Exposure Caution. ©Hexagon Mining...
-
Page 4: Table Of Contents
Upgrade Software ...................... 20 Care and Transport .................. 20 Transport ........................20 Storage ........................20 Cleaning and Drying ....................20 4.3.1 Product and Accessories................. 20 4.3.2 Connectors and Plugs ..................20 Safety Directions ..................21 General Introduction ....................21 © Hexagon Mining... - Page 5 Environment ..................... 21 Responsibilities ......................22 5.4.1 Manufacturer of the Product ................22 5.4.2 Manufacturers of Non-Hexagon Mining Accessories ........22 5.4.3 Persons in Charge of the Product ..............22 Hazards of Use ......................22 5.5.1 General Hazards ....................22 5.5.2...
-
Page 6: Document Introduction
Document Introduction The HxGN Mine Operator Alertness System – Light Vehicles User Reference Manual is part of Hexagon Mining’s Documentation Suite. This manual is intended to serve as a guide to the Mine Operator Alertness System – Light Vehicles (OAS- LV) module. -
Page 7: Overview
⚫ Four IR Illuminators ⚫ Digital Camera with optical size of 1/4" and 5 Megapixel. ⚫ Multicolor LED ⚫ SIM card holder to support 4G LTE cellular communication. ⚫ One internal 3-axis accelerometer. ⚫ Multi-Function Push Button switch ©Hexagon Mining... -
Page 8: Cellular Modem Specs
LTE – Band 3, 7, 20 and E-GSM 900MHz and DCS 1800MHz ⚫ Model 280 – Cellular modem specs 2.1.3.4 One Cellular Modem (4G LTE, 3G UTMS) LTE – Band 3, 8, 28 and UTMS Band 1 ⚫ 2.1.4 OAS-LV System Diagram © Hexagon Mining... -
Page 9: Connector Description
(examples??) Sim Card Micro SIMM Card Cellular carrier SIM card connector, Push-Push interface Push Button Push Button Switch Push Button Switch to control Wi-Fi operation mode External GPS SMA, Female External GPS Antenna Antenna ©Hexagon Mining... -
Page 10: Multifunction Led
Details of the LED status codes are shown below: State Notes Color/Status Power off Turned off System running, or powered off Booting Initial on-boot BLINK process Flashing Starting up or loading software BLINK Yellow from microSD System System failure, typically GPS BLINK Failure not available © Hexagon Mining... -
Page 11: Speaker
"caution, rear left" "caution_rear_right" "caution, rear right" "collision" "collision alert" "collision_stop" "collision alert, stop" "collision_slow_down" "collision alert, slow down" "cornering_event" "hard cornering detected" "dispatch_1" "please contact dispatch" "distraction_1" "distraction noticed, please keep your eyes on the road" "distraction_2" "distraction alert" ©Hexagon Mining... - Page 12 "heavy_machinery" "heavy machinery" "hello" "hello" "id_not_found" "operator ID not found" "id_not_found_2" "your operator ID cannot be found" "illuminator_ok" "IR illuminator OK" "light_vehicle" "light vehicle" "left" , "left" "logged_in" "logged in" "logged_off" "logged off" "mesh_network_ok" "mesh network, OK" © Hexagon Mining...
- Page 13 "please_login" please login" "proximity" "proximity alert" "radar_1" "radar alert, slow down" "radar_2" "radar alert, stop" "radar alert” "radar_3" "rear" "rear" "right" "right" "speed_1" "speeding alert, please slow down" "speed_2" "speeding alert" "speed_3" "caution, your speed is too high" ©Hexagon Mining...
- Page 14 "warning, front right" "warning_rear" "warning, rear" "warning_rear_left" "warning, rear left" "warning_rear_right" "warning, rear right" "welcome" "welcome" "wifi_ok" "wireless network is online" "wifi_start" "Wi-Fi hotspot enabled" "wifi_stop" "Wi-Fi hotspot disabled" "seatbelt" "please fasten your seatbelt" "format_sdcard" "formatting backup video storage" © Hexagon Mining...
-
Page 15: Label
The label layout is the same for all variants available. The information will change according to the article number and its certifications. ⚫ Product: HxGN MineProtect OAS-LV ⚫ Model: 202, 204, 211, 280 ⚫ Article Number: 898411, 905058, 905059, 905060 ⚫ Compliance requirements: FCC, IC, CE, ANATEL, NOM, IFT, ICASA, RMC ©Hexagon Mining... -
Page 16: Label Examples
2.5.3 Label Examples 2.5.3.1 FCC Certification Labels Model: 202 Note This model includes the NOM Certification. Model: 204 2.5.3.2 CE Certification Labels Model: 211 Note This model includes ANATEL Certification and ICASA Certification. © Hexagon Mining... -
Page 17: Rcm Certification Labels
2.5.3.3 RCM Certification Labels Model: 280 Note This model includes R-NZ Certification. ©Hexagon Mining... -
Page 18: Hardware Installation
Hardware Installation Before Installation Installation requires specialized knowledge and must be installed by a Hexagon Mining Authorized Installer. Hexagon Mining recommends that installation of the OAS-LV equipment be performed by a qualified technician. The average installation time varies, and the time of installation will be dependent on vehicle type and options purchased. -
Page 19: Regular Installation
Connect the cigarette plug connector side in the supplied power cable to the vehicle cigarette socket Route and secure all cables and wiring to meet Hexagon Mining requirements and ensure that there is no rubbing, which can cause premature failure. -
Page 20: Gnss Antenna Installation
Configuration manual for detailed instructions regarding how to update software on the OAS-LV module. Care and Transport Transport When transporting the product by rail, air, or sea, always use the complete original Hexagon Mining packaging, cardboard box, or an equivalent, to protect the product against shock and vibration. Storage Ensure the temperature limits are followed when storing the equipment, particularly in summer if the equipment is inside a vehicle. -
Page 21: Safety Directions
⚫ Use of products with obviously recognizable damage or defects. ⚫ Use with accessories from other manufacturers without the prior explicit approval of Hexagon Mining. ⚫ Inadequate safeguards at the working site (e.g. when using on the intended site). Limits of Use 5.3.1 Environment... -
Page 22: Responsibilities
Responsibilities 5.4.1 Manufacturer of the Product Hexagon Mining is responsible for supplying the product, including the User Manual and original accessories, in a completely safe condition. 5.4.2 Manufacturers of Non-Hexagon Mining Accessories The manufacturers of non-Hexagon Mining accessories for the product are responsible for developing, implementing, and communicating safety concepts for their products, and are also responsible for the effectiveness of those safety concepts in combination with the Hexagon Mining product. -
Page 23: Lightning Hazards
CAUTION The product must not be disposed of with household waste. Dispose of the product appropriately in accordance with the national regulations in force in your country. ©Hexagon Mining... -
Page 24: Electromagnetic Compatibility (Emc)
Disturbances caused by electromagnetic radiation can result in erroneous measurements. Although the product meets the strict regulations and standards which are enforced in this respect, Hexagon Mining cannot completely exclude the possibility that the product may be disturbed by very intense electromagnetic radiation produced by, for example, nearby transmitters, two-way radios, or diesel generators. -
Page 25: Technical Data
1 x USB 2.0 (480 MB/s) USB OTG 1 x USB 2.0 (480 MB/s) GNSS external antenna GPS L1C/A; GLONASS L1OF; BeiDou B1I SIM card 1 x SIM card Push Button 1 x Push Button Accelerometer 1 x Internal sensor, 3-axis accelerometer ©Hexagon Mining... -
Page 26: Environmental Specifications
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ⚫ Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Hexagon Mining for compliance could void the user’s authority to operate the equipment. ANATEL Statement (Applicable for Brazil) -
Page 27: Appendix A - Connector Pinout
5POS, Type Card connector, Dual Row Push-Push 5POS, Type B Push-Push pin# HOST SIM CARD IGNITION (*1) PWR IN (*2) standard standard pinout pinout standard pinout standard pinout *1 Ignition voltage range 9-36V *2 Input voltage range 9-36V ©Hexagon Mining... -
Page 28: Appendix B: Fcc Maximum Permissible Exposure Calculations
8.2.2 Wi-Fi MPE and LTE (LTE, 4G) Calculations 8.2.2.1 LTE 300 to 1500 MHz Referring to The FCC Guide to MPE document, Appendix A, Table 1 (B) Limits for General Population/Uncontrolled exposure (300 MHz to 1500 MHz). © Hexagon Mining... - Page 29 8.2.2.2 Wi-Fi and LTE 1.5 GHz to 15 GHz Referring to The FCC Guide to MPE document, Appendix A, Table 1 (B) Limits for General Population/Uncontrolled exposure (1.5 GHz to 15 GHz). ©Hexagon Mining...
-
Page 30: Simultaneous Transmission (Wlan And Gsm) Mpe Calculations
8.2.3 Simultaneous Transmission (WLAN and GSM) MPE Calculations MPE, S <= 1.0mW/cm at R = 20cm Where S WLAN Using formula S = P.G / 4.π.R © Hexagon Mining... -
Page 31: Glossary
Navigation System with Time and Ranging Global Positioning System. Unit of measure of force or acceleration due to gravity, where g is a unit of force (g = gravity) and rms is root mean square. Light-Emitting Diode Maximum Permissible Exposure ©Hexagon Mining... - Page 32 About Hexagon Mining Hexagon is a global leader in sensor, software and Hexagon is the only company to solve these challenges autonomous solutions. We are putting data to work to with proven technologies for planning, operations and boost efficiency, productivity, and quality across safety.
