Key Features
12" Polypropylene Cone
1300W Peak Power (380W RMS)
Unique cone design offers
superior rigidity
12" Polypropylene Cone
1300W Peak Power (380W RMS)
Unique cone design offers
superior rigidity
Gold-plated Binding Posts
Specifications
Audio
Sensitivity: 89 dB/W/m
Frequency Response: 18-2,000 Hz
Impedance: 4 ohms
Speaker
Subwoofer: Ported Enclosure- 23.5
(Net. Lit.), .82 (Net Cu. ft.)
Power
Power Consumption (in Operation):
1300 Watts
Rated Output: 380W RMS
Dimensions
Weight: 11 lbs, 0 oz (5 Kg)
Measurements: 12" (305mm)
UPC Code: 027242688117
Small sealed/bandpass
enclosure optimized
4-Ohm Voice Coil
2005 Subwoofer Parameters
XS-L123P5B
Subwoofer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sony XS-L123P5B Marketing
Summary of Contents for Sony XS-L123P5B Marketing
- Page 1 Key Features 12" Polypropylene Cone 1300W Peak Power (380W RMS) Unique cone design offers superior rigidity 12" Polypropylene Cone 1300W Peak Power (380W RMS) Unique cone design offers superior rigidity Gold-plated Binding Posts Specifications Audio Sensitivity: 89 dB/W/m Frequency Response: 18-2,000 Hz Impedance: 4 ohms Speaker Subwoofer: Ported Enclosure- 23.5...
- Page 2 Sony is a trademark of Sony. All other trademarks are property of their respective owners. Features and specifications are subject to change without notice. Non-metric weights and measures are approximate. Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com Last Updated: 02/02/2007...
