Pneumatic Division R10 Installation & Service Instructions

Pneumatic Division
Richland, Michigan 49083
269-629-5000
!
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to this
product before installation, servicing, or conversion.
• Operate within the manufacturer's specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered by
paint, etc. If masking is not possible, contact your local representative
for replacement labels.
WARNING
!
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Safety Guide
For more complete information on recommended application guidelines, see
the Safety Guide section of Pneumatic Division catalogs or you can download
the Pneumatic Division Safety Guide at: www.parker.com/pneumatics
Introduction
Follow these instructions when installing, operating, or servicing the
product.
Application Limits
These products are intended for use in general purpose compressed
air systems only.
Operating Pressure Maximum
Operating Temperature Range
ANSI Symbol
Installation
1. The Regulator should be installed with reasonable accessibility for
service whenever possible – repair service kits are available. Keep
pipe or tubing lengths to a minimum with inside clean and free of
dirt and chips. Pipe joint compound should be used sparingly and
applied only to the male pipe – never into the female port. Do not
use PTFE tape to seal pipe joints – pieces have a tendency to
break off and lodge inside the unit, possibly causing malfunction.
Also, new pipe or hose should be installed between the Filter /
Regulator and equipment being protected.
kPa PSIG bar
2068 300 21.0
(40° to 150°F) 4°C to 66°C
Installation & Service Instructions:
IS-R10-R11/M3
R10 & R11 General Purpose
Regulators
ISSUED: November, 2008
Supersedes: September, 2006
Doc. #ISR10R11M3, EN #080848, Rev. 4
2. The upstream pipe work must be clear of accumulated dirt and
liquids.
3. Select a Regulator location as close as possible to the equipment
being protected.
4. Install Regulator so that air flows into port labelled "IN" on body.
5. Gauge ports are located on both sides of the Regulator body for
your convenience. It is necessary to install a gauge or socket pipe
plugs into each port during installation.
Operation
1. Before turning on the air supply, engage the R10 Adjusting
Knob by pushing down. Turn R10 Adjusting Knob or R11
T-handle counterclockwise until the compression is released from
the Pressure Control Spring.
2. Then turn R10 Knob or R11 T-handle clockwise and adjust
regulator to desired downstream pressure. This permits pressure
to build up slowly in the downstream line.
3. To decrease regulated pressure settings, always reset from a
pressure lower than the final setting required. Example, lowering
the secondary pressure from 550 to 410 kPa (80 to 60 PSIG) is
best accomplished by dropping the secondary pressure to 350
kPa (50 PSIG), then adjusting upward to 410 kPa (60 PSIG).
4. When desired secondary pressure setting has been reached, pull
the R10 Knob up or tighten the R11 Lock Nut to lock this pressure
setting.
Maintenance
To clean regulator, it is not necessary to remove the unit from the
airline. Use a filter in line prior to the regulator to keep the air supply
clean. If using compressed air to blow dry, be sure to wear appropriate
eye protection. Wipe parts clean with soapy water or denatured
alcohol. Torque Spring Cage and Bottom Plug before using.
Caution: Never use solvents like carbon tetrachloride,
!
acetone or thinner to clean parts.
WARNING
!
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications for
these products or systems, the user, through its own analysis and testing, is
solely responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE
.
