Home Accents Holiday 1002 377 664 Assembly Instructions

OMS THD SKU # 1002 377 664
Model # TY230-1614-1
Thank you!
We appreciate the trust and confidence you have placed in Home Accents
through the purchase of this 58in 180 Light LED Carriage + 43in 120 Light
LED Horse. We strive to continually create quality products designed to
enhance your home. Visit us online to see our full line of products available
for your home decoration needs. Thank you for choosing Home Accents!
1-877-527-0313
HOMEACCENTSHOLIDAY.COM
Parts List
Locater Name
A Head/Neck
B Collar
C Mane
D Body
E
F Front Leg
G Hind Leg
H Roof
I Carriage Body Panel R
Right Side Body Panel
J
Trim
K Carriage Body Panel L
L Decorative Topper
M Wheels
N Support Base
Horizontal Stabilizing
O
Hardware List
Locater Name
P Ground Stake
Q Plastic Tie
R Spare Fuse
S Spare Bulb
Qty.
1
1
1
1
Tail 1
2
2
1
1
1
1
1
4
1
2
Bar
Qty.
10
20
6
10
ASSEMBLY INSTRUCTIONS
58in 180 Light LED Carriage + 43in 120
Light LED Horse
USE AND CARE GUIDE
PLANNING ASSEMBLY
Carefully remove all the parts from the box and place them on a flat surface. Please
note that many of the parts are connected by the lighting string that runs throughout
the item. Remove the parts with care not to damage the lighting string or parts. Read
the entire manual prior to assembly and identify all the parts included in the package
against the parts list. If any parts are missing or damaged do not attempt assembly.
Contact our customer service center or return the item to place of purchase with
purchase receipt. Assembly of this product may require more than one person.
Pre-Operation
CAUTION:
Grasp the plug to insert or remove from the power source.
Do not unplug by pulling on cord.
CAUTION:
The lighting string on this product is rated at 25.2 Watts (0.21
Amps) for Horse and rated at 30 Watts (0.25 Amps) for Carriage. Do not overload.
Do not connect to another lighting string, decorative outfit or other electrical products.
Before you use or re-use this product, inspect it carefully. Discard or return to place
of purchase with purchase receipt if the product has cuts, damage, frayed wire
insulation on cords, cracks in the socket enclosures, loose connections or exposed
copper wire.
Care and Cleaning
a. Carefully remove the product from wherever it is placed. This helps to avoid any
undue strain or stress on the product connections and wires. If the product is placed
somewhere other than the ground it should be well secured and stable.
b. Wipe the unit with a damp cloth and allow the unit to dry before storing.
c. Store the product neatly in a cool, dry location protected from sunlight.
Guarantee
What is Covered
The product is intended for residential seasonal use for 90 days per year. This
product is covered by a 90 days limited guarantee due to defects in material and
workmanship. Return the product with purchase receipts to the location of purchase
for refund within 90 days of purchase.
What is Not Covered
This warranty does not cover commercial use, normal wear and tear, products not
used in accordance with directions provided on or with the product, burn out of bulbs
or LEDS, batteries, products that have been subjected to unauthorized repair and/or
modification and damage caused by shipping and improper handling, alterations,
misuse or accidents. Questions, problems, missing parts? Before returning to the
store, call Home Accents Holiday Customer Service 8 a.m.-6 p.m., EST,
Monday-Friday
C
B
J
A
E
D
F
G
P
Diagram of Parts
H
I
M
N
Hardware
Q R S
K
O
L
