Ferguson FS2CO User Manual

Smart Carbon Monoxide Sensor
EN
User Manual
FS2CO
*Please read the user manual carefully before operation.
1. This product can not be used for detecting natural
gas(methane), propane, butane and other combustible
gas.
2. Clean once a month, users may use household vacuum
cleaner and soft brush when cleaning.
3. Do not use cleanser or solvent wipe sensors, please
avoid spraying air freshener, hair spray, oil paint or other
aerosol near sensors.
4. Effective working life span is 5 years, suggest replace
every 5 years no matter there is fault or not. (Battery life
span is 3 years).
5. Please be attention when alarm happens. Shut-off
valves immediately, opening the window, make sure indoor
airiness. Besides using sensors correctly, users should
strengthen the consciousness of fire protection.
Anticlockwise rotating the bracket out from the installation
base, then remove the battery insulating strip to make detector
on power.
This product is a smart carbon monoxide sensor, adopts super
low power consumption Zigbee
technology, used for detecting carbon monoxide. Sensor
adopts high performance electrochemical sensor, support
sound and flash alarm, It has high stability, super low power
consumption, little sensitivity drift and many other features.
Free installation design, support instant bonding.
Networking Hole
LED indicator
Sensor
4
1.Install the sensor in bedroom and living area or anywhere CO
may leak, make sure each sleeping area can hear sound alarm
when choose installation position.
2.Avoid suppressing or falling down sensors, keep sensors
away from humid, high voltage, strong magnetic and children.
3.Do not suggest install sensors in garage, kitchen, boiler and
places where sensor may false alarm. Do not install in dirty,
dusty or greasy places, oily, dust or household chemicals may
damage internal sensor, and make sensor can not work
normally.
4.Sensors can support wall mounted or placing on the table,
household and travel essential.
7
Adding device
Select the Smart Hub from the list of devices to which you want to
add a new device (sensor) or device with factory settings restored.
1.Click add devices on APP, entering networking mode.
When the LED in the control
panel blinks blue, we confirm
and go to pairing devices.
2
1. Working Voltage ： DC3V(CR123A Lithium Battery)
2.Static Current ： ≤ 20uA
wireless networking 3.Alarm Current ： ≤ 60mA
4.Alarm Sound ： 85dB/1m
5.Alarm Sensitivity ：
6.Networking ： ZigBee Ad-Hoc Networking
7.Wireless Networking Distance ： ≥ 70m （open area）
8.Working Temperature ： -10
Installation Base
9.Environment Humidity ： 95%RH
10.Dimension ： 60*60*49.2mm
5
To increase safety factors in single-layer house, suggest to
install at least a sensor in each bedroom and install a sensor
at 6m from chimney and gas fixture.
factors in multi-layer house, suggest to install at least a
sensor in each bedroom, install at least one sensor in
basement. Please install a sensor at 6m from chimney and
gas fixture.
8
2. According to the tips on APP, keep pressing networking
button, green LED flash quickly, tips appear on APP, green
LED keep on for 3 seconds, network success,
Delete device
In the application, click and hold the selected device, the "delete
device" command will be displayed. After removed it, disconnect
the network connection device by pressing and holding the pairing
button. 6-fold LED blink in green means disconnection of the
sensor network from the HUB.
30ppm 120mins alarm
50ppm 60-90mins alarm
100ppm 10-40mins alarm
300ppm 3mins alarm
C ；
C〜 +50
o o
To increase safety
Bedroom Bedroom
Bedroon
Kitchen Gagrage
Aisle
Livingroom
minimum
Basement
opcjonal
3
6
9
