TRANSPORTATION INSTRUCTIONS
1. The appliance should be transported only in a vertical upright position. The
packing as supplied must be intact during transportation.
2. If during the course of transport the appliance has been transported
horizontally, it must not be operated for at least 4 hours to allow the system to
settle.
3. Failure to comply with the above instructions could result in damage occuring
to the appliance. The manufacturer will not be held responsible if these
instructions are disregarded.
4. The appliance must be protected against rain, moisture and other
atmospheric influences.
IMPORTANT : Care must be taken while cleaning / carrying the appliance to
avoid touching the bottom of the condenser metal wires at the back of the
appliance as you might injure your fingers and hands.
Important : This appliance is not designed for stacking with any other
appliance.
When positioning your appliance, take care not to damage your flooring, pipes,
wall coverings etc. Do not move the appliance by pulling by the door or handle.
Do not attempt to sit or stand on top of your appliance as it is not designed for
such use. You could injure yourself or damage the appliance.
"IMPORTANT: Make sure that mains cable is not caught under the appliance
during and after carrying / moving the appliance, to avoid the mains cable
becoming cut or damaged."
Do not allow children to play with the appliance or tamper with the controls.
BEKO plc declines to accept any liability should the instructions not be followed.
4
IMPORTANT
INSTALLATION INSTRUCTIONS
1. If possible avoid placing the appliance near cookers, radiators or in direct
sunlight as this will cause the compressor to run for long periods. If installed
next to a source of heat or refrigerator, maintain the following minimum side
clearances:
From Cookers
From Radiators
From Refrigerators or Larder fridges
2. Make sure that sufficient room is provided around the appliance to ensure free
air circulation.
3. Fit the two plastic wall spacers supplied
with the appliance rotating 1/4 turn to
the condenser at the back of the
larder (see diagram).
4. The appliance should be located on a
smooth surface. The two front feet can be
adjusted as required. To ensure that,
your appliance is standing upright adjust
the two front feet by turning clockwise or
anti-clockwise, until the product is in
firm contact with the floor. Correct
adjustment of feet avoids excessive vibration and noise.
5. Refer to "Cleaning and Care" section to prepare your appliance for use.
6. This appliance has been designed to operate in ambient temperatures
beetween +10 and +32 degrees C (50 and 90 degrees F).Therefore if the
appliance is installed in an unheated / cold room (E.g.: Conservatory /
annex / shed / garage etc.) then the appliance may not operate and
as a result the storage time of food may be reduced.
7. A special receptacle is supplied to store
the mains plug during transit.
The receptacle is fixed at the back of the
cabinet, on the left hand side of the
compressor. (See diagram) Gently remove
the plug from the receptacle. Never pull
the mains cord, you may damage the
appliance. In the case of transportation,
ensure you locate the plug in
the receptacle provided to avoid transit
damage.
8. The space in the room where the appliance is installed must not be smaller
than 10 cubic metres.
2" (50 mm)
12" (300 mm)
1" (25 mm)
5
