Summary of Contents for SANUP TPR 3E PLUS
- Page 1 Vol. 0404E1 2004. 04. 15 Thyristor Power Regulators and Remote Controller USER MANUAL...
-
Page 2: Table Of Contents
4-4. Parameters 4-5. Wiring and Operating According To Control Signal Remote Control 5-1. Wiring for Remote Controller 5-2. TPR 3E PLUS Parameter Setting Connected Remote Controller 5-3. Remote Controller Specification 6-1. Specification of TPR-3E PLUS 6-2. Specification of Remote Controller... - Page 3 ━━━━━━━━━━━━━ Caution for Your Safety ━━━━━━━━━━━━━━ Please keep these instructions and review before using this controller. This instruction manual uses WARNING and CAUTION as signal words for safety. WARNING WARNING indicates a potentially hazardous situation which, if not avoided, will result in death or serious injury. CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury and at other times will result in death or serious...
- Page 4 CAUTION indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury and at other times will result in death or serious injury. I may also be used to alert against unsafe practice. Installation Guidelines Ensure the surrounding ambient operating temperature is between 0~50°C (32~122°F) •...
- Page 5 10) Built-in watchdog timer ® 11) RS-485 interface (MODBUS protocol) (Optional) 12) Remote control function by Remote Controller (Optional) 13) Compact Size Note) TPR 3E PLUS can be replacement with TPR 3E and if you don’t use function, need not parameter setting.
-
Page 6: Installations And Wiring
3. Installations and Wiring 3.1 Installation Guidelines 1) Ensure the surrounding ambient operating temperature is between 0~50℃. 2) Ensure the power supply for the unit does not fluctuate greatly. 3) Install the unit where there is no dust, corrosive or explosive gas present. 4) Install the unit where there is no risk of mechanical vibration or shock. - Page 7 Output of line R Output power line to Output of line S load Output of line T 2) Wiring for control signals The control signals terminals are located at the front left of the unit. They are used to connect: -the control signal 4~20mA and the run contact -the external V.R and the alarm output contact -the interface terminals and power supply...
- Page 8 1. Supplement +12V power. 2. Suitableness for ON-OFF Supplement current control. is 40mA max. 3. Suitableness for external V.R. input. Output enables or disable. 1. Suitableness for ON-OFF control. 2. Suitableness emergency stop. Connecting external V.R., 1. Suitableness for output limit V.
-
Page 9: Operating
4. Operation 4.1 Controller Description 4.2 Indicating Upon connecting power the unit is in a state of automatic operation and the input signal or load current capacity is indicated on the front display. If press [ENT] Key more than 2 second change display to input signal and load current capacity R and T line. -
Page 10: Parameters
the parameter has not been accepted. 4) By pressing [ENT] key this value is accepted and entered into EEPROM (nonvolatile memory). When the accepted the decimal point disappears. Enter password to access parameters setting group. Password is “5”. Enter password to access interface parameters setting group. Password is “15”. -
Page 11: Wiring And Operating According To Control Signal
If set to ‘0’ stop the Soft Start time 1~250 sec. function. ALm: Alarm only Operation over OFF: Cut off output current limit alarm. Cnt: Output control Operation line ALm: Alarm only failed alarm. OFF: Cut off output Operation over ALm: Alarm only temperature alarm. - Page 12 Figure 2. Wiring for current input signal 2) ON-OFF Contact Input Signal Output will be un-continuous ON-OFF by dry contact signal. Maximum output voltage limit by output limit parameter [OUt] or external V.R. Figure 3. Wiring for contact input signal...
- Page 13 3) Manual control by external V.R Output power will be control by turn angle of output limit V.R or output limit parameter (Symbol: OUt). Figure 4. Wiring for non-control input signal 4) RS 485 Interface (Optional) TPR-3E PLUS will be control by RS-485 interface signals. Apply power to the TPR-3EPLUS and go to parameter (Symbol: Smd).
-
Page 14: Remote Control
Figure 5. Control by RS 485 Interface 5. Remote Control (Optional) -Changing parameter by interface function -Display to operating condition -Display power current value Wiring for Remote Controller (RC-1000) 1) Short distance installation In case of Install distance is less than 10m: Use main unit power. (Terminal Vcc) 2) Long distance installation In case of install distance is more than 10m till 1200m: Select remote controller power option. -
Page 15: Tpr 3E Plus Parameter Setting Connected Remote Controller
Figure 7. Wiring Remote Controller 5.2 TPR-3E PLUS Parameter Setting Connected Remote Controller Table 5. Parameter Setting Symbol Setting Data Range Set Value Description PASS Refer to set remote Analog, Select input Controller for control type Address 0~31 No. 1 2400, 4800, Speed 9600bps... -
Page 16: Remote Controller
5.3 Remote Controller RC-1000 All remote controller functions are almost same with main unit controller function except below. 1) Reset key function from front panel 2) Fixed interface parameters: Address; 1, Speed; 9600 BPS, Delay Time; 1 Figure 6. Front of Remote Controller Table 4. - Page 17 ALm: Alarm only Operation over OFF: Cut off output current limit high Cnt: Output control Operation line ALm: Alarm only failed OFF: Cut off output Operation over ALm: Alarm only temp. OFF: Cut off output Input filter 0~10 sec. Against for fluctuation If set to ‘0’...
-
Page 18: Specification
6. Specification 6.1 Specification of TPR 3E PLUS Voltage: One of AC 220V, 380V, 440V (AC 100V, 110V, 120V, 200V, 240V, 400V are made by order) . ±10% Cycle: 50/60Hz Current capacity: 35A, 50A, 80A, 100A, 120A, 150A, 190A, 240A, 500A. - Page 19 SANUP ELECTRIC CO. 1407...
