Summary of Contents for Explo RX2-Wave-Player
- Page 1 RX2-Wave-Player Manual 2.0 As of February 2017 explo GmbH – Völkermarkterstrasse 240, 9020 Klagenfurt am Wörthersee, Österreich wwww.explo.at office@explo.at +43(0)463/3224...
- Page 2 PREAMBLE Dear Explo Customer, Please read through these sets of instructions carefully, before using your devices. It contains many Informations which are to help you getting to know your system. We ask you to follow the safety and usage notes carefully.
- Page 3 OVERVIEW The following manual describes the bidirectional music player RX2-Wave Player and is laid out over these chapters. About the RX2-Wave-Player Function of the RX2-Wave-Player Description of the RX2-Wave-Player Build and components of the Hardware Menu and settings Using the RX2-Wave-Player...
-
Page 4: Table Of Contents
INDEX 1 About the RX2-Wave-Player ........................ 5 1.1 Function of the RX2-Wave-Player ....................5 1.2 Controlling the RX2-Wave-Player ....................5 1.2.1 Boxnumber ..........................5 1.2.2 channelnumber / Trackname ....................5 2 receiver RX2-Wave-Player ........................6 2.1 components of the receiver......................6 2.1.1 Front overview ......................... -
Page 5: About The Rx2-Wave-Player
1.2 CONTROLLING THE RX2-WAVE-PLAYER The RX2-Wave Player can be started via radio or manually. When using radio control, use box and channelnumber, the same way as with other Explo receivers. The following settings must be checked before using the device in a show: 1.2.1 BOXNUMBER... -
Page 6: Receiver Rx2-Wave-Player
2 RECEIVER RX2-WAVE-PLAYER 2.1 COMPONENTS OF THE RECEIVER 2.1.1 FRONT OVERVIEW Components of the RX2-Wave-Player Front Buttons SD-slot Display Radio Status LED... -
Page 7: Back Overview
2.1.2 BACK OVERVIEW Components of the RX2-Wave-Player backside On- / Off switch Activate button Charging- / Programmingsocket Audio-outputs XLR BNC-Antennasocket Audio-output 3.5mm stereo jack... -
Page 8: Description Of Components
2.1.3 DESCRIPTION OF COMPONENTS 2.1.3.1 BUTTONS These buttons allow direct control of the player.They are used to navigate the menu, change settings and manually starting the device without radio signals. Buttons Play / Pause Stop Back Forward 2.1.3.2 SD-SLOT Houses the reader for SD-cards. 2.1.3.3 DISPLAY Shows the receivers status as well as its menu structure. - Page 9 Pins on the RX2-Wave-Player Pin 1 Pin 2 Pin 3 Pin 4 Battery 1 Pin 5 Battery 2 Pin 6 Not connected Pin 7 Not connected 2.1.3.8 BNC-ANTENNA SOCKET Used to connect the provided antenna with the device. The RX2-Wave Player also features a protective cap for this socket, to prevent dirt or moisture from entering.
-
Page 10: Menu Of The Rx2-Wave-Player
2.2 MENU OF THE RX2-WAVE-PLAYER By pressing the Stop and Play/Pause button at the same time, you can access the menu of the receiver. Within the menu, you can use the Play/Pause button to confirm selections and the Stop button to cancel or leave the menu. Using the Forward and Back buttons you can change settings. - Page 11 CH-CONTROL Allows you to set which channelnumbers access special functions of the Player. The following special functions can be started with the following channels: Special channels RX2-Wave-Player Play / Pause Track Stop (Track time will be set to 0) Previous track will be started...
- Page 12 CH-TRACK Allows you to set the channelnumbers that will start single tracks. Standard: Channel 1 = Track 01, Channel 2 = Track 02, etc... 2.2.1.9 SYS SETTINGS Here you can change different settings for the radio control, as well as see the Players ID number. SYS ADDR Allows you to change the systemadress that will control the Player.
-
Page 13: Using The Device In A Show
2.3 USING THE DEVICE IN A SHOW 2.3.1 PREPARING THE SD-CARD AND TRACKS Before uploading the tracks, the SD-card should be formatted. This can be done by right-clicking it, and selecting "Format". The following settings should be taken: IMPORTANT: For the track to be correctly read by the SD module, it should be set to adhere to the following: Only WAV-files can be used(PCM 16Bit, 44.1kHz;... -
Page 14: Manually Ignited Shows
The following steps should be adhered to correctly control the receiver: Preparing the RX2-Wave-Player Set the RX2-Wave-Player to the preferred boxnumber (Recommendation is 50). Correctly label the music tracks and save them to the SD-card. Test playing the tracks with the transmitter. -
Page 15: Other
3 OTHER 3.1 TIPPS & TRICKS 3.1.1 RADIO CONNECTIVITY: A good radio connectivity is an essential part of a trouble free usage of a radio controlled system. Taking note of these few hints can improve the connection between transmitter and receiver drastically. -
Page 16: Technical Data
3.2 TECHNICAL DATA Here you can find the technical data for the receiver: Receiver RX2-Wave-Player Measurements 222 x 155 x 65 mm Weight 1.800 g Case Aluminium case Radio range 800 m Power supply 2x NiMH-battery 12V Standby 7 hours... - Page 17 Declaration of Conformity appropriate to the Directive 2014/53/EU (RED) Die alleinige Verantwortung für die Ausstellung dieser Konformitätserklärung trägt der Hersteller. Hersteller / Verantwortliche Person: explo GmbH, Völkermarkterstraße 240, 9020 Klagenfurt am Manufacturer / responsible person: Wörthersee, Österreich (AUT) Erklärt, dass das Produkt: Funkgesteuertes Musikabspielgerät...
