CONTENTS
INCLUDED:
DUMP BIN
QTY: 1
RH BRACKET
LH BRACKET
HORIZ MOUNT
HORIZ MOUNT
(5 HOLES)
(5 HOLES)
QTY 1
QTY 1
LH BRACKET
RH BRACKET
VERT MOUNT
VERT MOUNT
(4 HOLES)
(4 HOLES)
QTY 1
QTY 1
LH BRACKET
RH BRACKET
65 DEG MOUNT
65 DEG MOUNT
(4 HOLES)
(4 HOLES)
QTY 1
QTY 1
PAN HEAD SCREW
QTY 10
BAKERY /WINE WALL DUMP BIN
SIDE VIEW
SCALE 1 : 12
SIDE VIEW
DETAIL B
SCALE 1 : 12
SIDE VIEW
assembly instructions
HORIZONTAL MOUNT
A
DETAIL A
VERTICAL MOUNT
B
HORIZONTAL MOUNT
TO DISPLAY DUMP BIN HORIZONTALLY,
ATTACH THE LH&RH HORIZ BRACKETS TO
THE BOTTOM SIDE OF THE BIN AND
ATTACH USING 5 SCREWS EACH INTO
PROVIDED PILOT HOLES.
VERTICAL MOUNT
TO DISPLAY DUMP BIN VERTICALLY,
ATTACH THE LH&RH VERT BRACKETS TO
THE BOTTOM SIDE OF THE BIN AND
ATTACH USING 5 SCREWS EACH INTO
PROVIDED PILOT HOLES.
PAGE 1 OF 2
rev date:12/14/16
Advertisement
Summary of Contents for DGS BAKERY/WINE WALL DUMP BIN
- Page 1 BAKERY /WINE WALL DUMP BIN assembly instructions HORIZONTAL MOUNT CONTENTS INCLUDED: DUMP BIN HORIZONTAL MOUNT QTY: 1 TO DISPLAY DUMP BIN HORIZONTALLY, ATTACH THE LH&RH HORIZ BRACKETS TO THE BOTTOM SIDE OF THE BIN AND ATTACH USING 5 SCREWS EACH INTO PROVIDED PILOT HOLES.
- Page 2 BAKERY /WINE WALL DUMP BIN assembly instructions 65 DEG MOUNT 65 DEG MOUNT TO DISPLAY DUMP BIN WITH 65 DEG SETBACK, ATTACH THE LH&RH 65 DEG BRACKETS TO THE BOTTOM SIDE OF THE BIN AND ATTACH USING 4 SCREWS EACH (SCREWS MAY NOT ALIGN WITH PILOT HOLES).
