Summary of Contents for dough Xpress DXP-GF001
- Page 1 DXP - GF001 BREAD SLICER OPERATIONS MANUAL For Customer Service, Call 1-800-835-0606 or Visit www.doughxpress.com CONTENTS Warning Page Installation and Setup Parts List Equipment Explode Image Warranty BEFORE warranty repair you MUST get Prior Authorization: 11100 RV A_022020...
- Page 2 INSTALLATION & SETUP 1. INSTALLATION Put the Slicer on a stable table and make sure the Slicer seats firmly on the table. If the Slicer vibrates seriously during operation, put paper or rubber underneath the frame of the Slicer. 2. ELECTRICAL CONNECTION Before making electrical connections, check the specifications on the name plate to make sure they agree with those of your electrical service.
- Page 3 INSTALLATION & SETUP TO REMOUNT THE BLADES 1. Compress Spring (29) to put the Blades onto the Frames (25) and (26) one by one. 2. Put Frames (25) and (26) into position and lightly tighten bolts that screw into (40) that secure Blade Frames, insert the Guide Rod (35) into Top of Frames.
- Page 4 PARTS LIST DXP-GF001 Parts List S.NO Description Qty. Machine Wall (left) Machine Wall (right) Screw Nut Handle Fixed lever Plastic Lock Bolt Outfeed Guide L Plate Fixed Block Front / Top Cover Plate for Receiving Bread Pressing Plate for Toast...
- Page 5 PARTS LIST DXP-GF001 Parts List S.NO Description Qty. Lock Bolt Guide Bolt Slide Bar Shaft Slide Board Shaft Slide Board Shaft Knife Shelf / Blade Frame Knife Shelf / Blade Frame Knife Fixed Pin Knife Blade Fixed Block Spring Tee Tube...
- Page 6 PARTS LIST DXP-GF001 Parts List S.NO Description Qty. Joint Bar Bush Linking Bar Seat (right) Drive Pulley Belt Motor Capacitor Motor Seat (front) Motor Seat (right) Joint Pin Drive Pulley Drive Pulley Screw Nut Plastic Linking Rod Live Axle Switch Plate...
- Page 7 PARTS VIEW...
- Page 8 WARRANTY BEFORE warranty repair you MUST get Prior Authorization: Call 1-800-835-0606 Warranty will be voided otherwise. WARRANTY & SERVICE DOUGHXPRESS will automatically register the equipment on the date it was shipped, please keep a copy of their sales invoice showing the serial number and date it was sold/shipped to you with this warranty. We will use the distributor’s invoice date as the beginning warranty date.
