- Page 1 BELLE 870/60000/0 10/17 RANGE Operators Manual • Spare Parts Book...
-
Page 2: Table Of Contents
ALWAYS wear or use the proper safety items required for your personal protection. If you have ANY QUESTIONS about the safe use or maintenance of this unit, ASK YOUR SUPERVISOR OR CONTACT: Altrad Belle (UK): +44 (0) 1298 84606 Contents How to use this manual .....................................4... -
Page 3: Machine Description
Machine Description Throttle Lever (Petrol version shown). Choke Lever. Fuel ON / OFF Lever. Engine ON / OFF Switch. Air Filter Housing. Fuel Tank. Exhaust. Recoil Starter Handle. Pump Inlet Filter. 10. Pump Inlet Quick-Release Coupling. 11. High Pressure Outlet (Non-Hose Reel versions only) 12. -
Page 4: Technical Data
Technical Data 1462 1155 1087 Model PWX 08/180 PWX 13/230 PWX 15/250 PWX 15/250D Weight (Kg) Yanmar L100 Engine Honda GX200 Honda GX270 Honda GX390 Electric Start Engine Power (Hp-kW) 5.8 - 4.3 8.5 - 6.3 11.7 - 8.7 8.9 - 6.6 Electric Start Water Flow (lpm) Max. -
Page 5: Decals
Decals A. Altrad Logo Decals. B. Model Identifi cation Decals. C. Information Decal. D. Safety Decal. E. High Pressure Outlet Decal Lifting Point Decal A. Altrad Logo Decal. B. Model Identifi cation Decal - Identifi es the model of Pressure Washer. C. -
Page 6: General Safety
It is the responsibility of the operator to ensure that he/she fully understands how to operate this equipment safely. If you are unsure about the safe and correct use of the Pressure Washer, consult your supervisor or Altrad Belle. -
Page 7: Start & Stop Procedure
Start and Stop Procedure STOPPING - HONDA GX200, GX240 & GX390 • Switch OFF the loads. • Switch OFF the engine. • Turn the fuel tap to the CLOSED position. Throttle Lever STARTING - HONDA GX200, GX240 & GX390 • Remove all objects placed on, or within one metre of the Pressure Washer. -
Page 8: Operating Instructions
This equipment is could emit a Sound Power Level (LWA) of up to 110dB(A). See Technical Data section for more details and wear appropriate ear defenders. • Your Altrad Belle Pressure Washer comes preset and NO adjustment is necessary. • Be aware of how to stop the Pressure Washer by use of the On/Off switch or throttle lever. -
Page 9: Service And Maintenance
Service and Maintenance The following schedule details the attentions considered necessary to ensure satisfactory operation of the Pressure Washer. NOTE:- The attentions and periods summarised in the schedule are the initial recommendations and should be revised to suit the Power Unit working conditions. Only authorised dealers should repair the Pressure Washer, and within the requirements of the CE mark (where applicable), where no deviation from the original specifi... -
Page 10: Warranty
ALTRAD BELLE Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB Tel. +44 (0)1298 84606 - Fax +44 (0)1298 84722 - Email: sales@altrad-belle.com www.Altrad-Belle.com...
