Beyerdynamic Iris EF Quick Start Manual

Iris EF
Infrared Radiator
Order # 722.839
F
EATURES
• DQPSK digital modulation technology
• Band IV operation between 2 and 6 MHz
• For the use in conference rooms, even in daylight
• Switch to compensate the signal delay when using several
radiators in one system
• Radiation angle ± 25°
• Stand-by function
• Connection to connect further radiators in a daisy chain
• Half-power / full-power
the operating mode can be selected with a switch
D
ESCRIPTION
The Iris EF radiator belongs to the latest generation of infrared
system high power radiators for the wireless Iris audio system.
An electrical signal supplied from the Iris TS infrared control unit is
converted into infrared light invisible to people and radiated into
the room. The signal to be transmitted can comprise up to 16
channels in the range of 2 to 6 MHz (band IV). For installation a
separate mounting bracket is available. Up to 30 Iris EF radiators
can be connected to a total of four signal outputs of one Iris TS
control unit in a daisy chain. If the Iris EF radiator does not receive
a signal, it automatically turns into the standby mode. When the
temperature of the radiator is too high, the system will auto-
matically switch from full power to half power. If the temperature
is still too high, the radiator will be switched to stand-by mode.
1 of 2
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. +49 (0) 71 31 / 617 - 0 | Fax +49 (0) 71 31 / 617 - 204
info@beyerdynamic.de | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E3 / Iris EF (08.14)
T S
ECHNICAL PECIFICATIONS
Number of IR LEDs. . . . . . . . . . . . . . . . . 275
Total IR output at 20 °C . . . . . . . . . . . . . 8 Wrms 16 Wpp
Total optical peak intensity. . . . . . . . . . . 9 W/sr
Modulation . . . . . . . . . . . . . . . . . . . . . . DQPSK
Modulation frequency . . . . . . . . . . . . . . 2 to 6 MHz
IR wavelength. . . . . . . . . . . . . . . . . . . . . λp = 850 nm
Angle of radiation . . . . . . . . . . . . . . . . . ± 25°
RF input. . . . . . . . . . . . . . . . . . . . . . . . . Nominal 2 Vpp,
RF output . . . . . . . . . . . . . . . . . . . . . . . 1 Vpp, 0 V DC, 75 Ω
Supply voltage. . . . . . . . . . . . . . . . . . . . 110 - 240 V, 50 to 60 Hz
Power consumption. . . . . . . . . . . . . . . . max. 36 W
Power consumption (stand-by) . . . . . . . 3 W
Dimensions (H x W x D) . . . . . . . . . . . . . 228 x 452 x 218 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . 4.95 kg
Colour. . . . . . . . . . . . . . . . . . . . . . . . . . black
S A
UPPLIED CCESSORIES
1 power cable, 4 m / 12.5 ft
1 BNC connecting cable, 3.5 m / 11 ft
1 terminating resistor, 75 Ω
O A
PTIONAL CCESSORIES
CA 5111 Connecting cable BNC male-male,
length 10 m, 75 ohms . . . . . . . . . Order # 723.096
CA 5121 Connecting cable BNC male-male,
length 20 m, 75 ohms . . . . . . . . . Order # 723.118
CA 5302 Bracket for wall mounting
of Iris EF . . . . . . . . . . . . . . . . . . . . Order # 722.871
minimum 20 mVpp,
75 Ω
