Self-Compensating Deburring Tools
Vertical compensation and variable tension allows for clean

Features

and even burr removal
Before burr removal
Series
3 tool types are available
BC10-20
Surface deburring (incremental load)
BC10-10
Surface deburring (exchangeable spring load)
BCT10-10
Inverted (underside) deburring
No float
With float
After burr removal
®
For Barriquan video please
visit us @ www.suginocorp.com

Application Examples

Pipe ports/holes
Casting profile
Brushing applications
Robot applications
Recommended burr
bit configurations:
Pipe port (underside)
deburring
Built in float

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUGINO Barriquan BC10-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for AHB SUGINO Barriquan BC10-20

  • Page 1 ® Self-Compensating Deburring Tools Built in float Vertical compensation and variable tension allows for clean Features and even burr removal No float With float For Barriquan video please visit us @ www.suginocorp.com Before burr removal After burr removal Application Examples Series 3 tool types are available BC10-20...
  • Page 2 Specifications Permissible Float Float Load Dimensions Weight Shank size adjustment speed amount direction 0.84 lbs. 0.394” 1 .25”ΦX4.72” 0.78”ΦX1.57” Incremental BC10-20 5000 rpm (32ΦX120L) (Φ20X40L) (380g) 16 stage dial (10mm) 0.98”ΦX3.94” 0.31 lbs. 0.394” 0.39”ΦX1.38” Exchangeable BC10-10 8000 rpm (25ΦX100L) (140g) spring (10mm)
  • Page 3 Instruction Manual No. BC0104E Manual Thank you for choosing our Barriquan . Please read this Instruction Manual carefully before using this product and keep this at hand whenever the operator can read. If you have any questions on about this product or in this manual, please feel free to contact us at your nearest office.
  • Page 4 ４．Adjustment for Pre-load (1) Spring pre-load can be adjusted to rotate Stem. (2) Detach C-shape Stop Ring inside Stem. For When rotating, keep pulling Stem to Collet side detaching, please use the tool for C-shape Stop (Figure 4); Ring (for Hole, size: No.1) Rotating to “＋”...
  • Page 5 °...
