Summary of Contents for Cornelius UC-40
- Page 1 REMOTE COOLING UNIT UC-40 and UCC-40 Installation and Service Manual Release Date: September 28, 2004 Publication Number: 710160089 Revision Date: N/A Revision: N/A Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.
- Page 2 800-238-3600 Trademarks and copyrights: Aurora, Cornelius, Decade, Hydro Boost, Sitco, Spirit, UF-1, Vanguard, Venture, Olym- pus, and Vista are registered trademarks of IMI Cornelius Inc. Optifill trademark is pending. This document contains proprietary information and it may not be reproduced in any way without permission from Cornelius.
- Page 3 WARNING: Before attempting to remove the refrigeration deck, disconnect all electrical power. Melt the ice bank and thoroughly drain the water bath. See additional notes in Water Bath Cleaning Section in the manual. © 2004, IMI Cornelius Inc. - 1 - Publication Number: 710160089...
-
Page 4: Specifications
241 lbs. (109.5 kg) LECTRICAL ATING 115 VAC/60HZ/14.6 AMPS; 220VAC/50-60HZ/7.3 AMPS Transformer: (Built In) 24VAC Secondary EFRIGERATION 1/3 HP (Lift Out Type) Condenser: Air Cooled Refrigerant: R134a PPROVAL U.L., C.S.A., N.S.F. Publication Number: 710160089 - 2 - © 2004, IMI Cornelius Inc. - Page 5 Recommended setting 75 psi (5.17 bar). A minimum CO2 gas supply pressure 15 psi (1.05 bar) greater than the incoming water pressure will ensure that flooding of the carbonator tank will not occur. © 2004, IMI Cornelius Inc. - 3 - Publication Number: 710160089...
- Page 6 Only stainless steel or plastic, barb or compression type fittings should be used on any syrup or soda water connections. Optional bag-in-box system is also suitable for use with this beverage cooler. Publication Number: 710160089 - 4 - © 2004, IMI Cornelius Inc.
-
Page 7: Installation And Start Up Procedure
“RECIRC. PUMP SWITCH”. This switch is now turned “ON”. The dispensing valves should be adjusted in accordance to the instructions of the dispensing tower or valve manufacturer. © 2004, IMI Cornelius Inc. - 5 - Publication Number: 710160089... - Page 8 Install new ice bank control by pushing probe down into the 3/4” tube until it stops on the bottom of the tube. Secure probe with tape. Fill water bath with fresh water. Replace dispenser top and secure with two screws. Connect dispenser to power source and turn ON. Publication Number: 710160089 - 6 - © 2004, IMI Cornelius Inc.
-
Page 9: Cleaning And Maintenance
Recommended sanitizer: A.C. Fergusson Company SuperChlor (1 ounce in 5 gallons of water) or any sanitizer which provides a minimum of 200 parts per million of available chlorine. Solution should be room temperature. © 2004, IMI Cornelius Inc. - 7 - Publication Number: 710160089... - Page 10 It is recommended that the water bath be cleaned two to four times annually, depending upon local conditions and/or required by state and local health departments. The water bath should be clean to obtain maximum cooling efficiency. Publication Number: 710160089 - 8 - © 2004, IMI Cornelius Inc.
- Page 11 Place cabinet top back onto the unit in its original position and secure. Clean and sanitize product lines and valves per number 4 above before placing dispenser into service. © 2004, IMI Cornelius Inc. - 9 - Publication Number: 710160089...
- Page 12 CTC-40, and located on the top left corner of the front valve mounting plate of the model CTC-20. The timer can be reset by turning this rocker switch “off” and then “on” again. Publication Number: 710160089 - 10 - © 2004, IMI Cornelius Inc.
- Page 13 Installation and Service Manual IRING IAGRAM 60439011 230V/50H 60439010 115V/60H 60439013 230V/50 60439012 115V/60 © 2004, IMI Cornelius Inc. - 11 - Publication Number: 710160089...
- Page 14 Installation and Service Manual FLUIDS/GAS DIAGRAM Publication Number: 710160089 - 12 - © 2004, IMI Cornelius Inc.
-
Page 15: Wiring Diagram
Installation and Service Manual WIRING DIAGRAM UCC-40 W IRING IAGRAM © 2004, IMI Cornelius Inc. - 13 - Publication Number: 710160089... - Page 16 Installation and Service Manual UCC-40 PARTS EXPLODED DIAGRAM Publication Number: 710160089 - 14 - © 2004, IMI Cornelius Inc.
- Page 17 Wrapper Electrical Box 115v 119-465-006 23-0783 Wrapper Electrical Box 220v 119-465-001 35-0062 Control - Liquid Level 115v 110-863-000 35-0065 Control - Liquid Level 220v 50/60hz 110-863-220 60439010 40-0288 Screw 103-462-000 © 2004, IMI Cornelius Inc. - 15 - Publication Number: 710160089...
- Page 18 64560 55-0011 Seat Fitting - Back Check 115-048-000 40-0207 O Ring 103-122-000 31525003 55-0010 Body - Single Back Check 1/4 Flare 115-046-000 55-0016 Body - Double Back Check 115-449-000 Publication Number: 710160089 - 16 - © 2004, IMI Cornelius Inc.
- Page 19 IMI Cornelius Inc. www.cornelius.com...
