Teeter X Series Repacking Manual

X SE R I E S REPACKING G UID E
Please be sure to include all components of the inversion table in your returned order, including the
accessories and instructions, otherwise you may not be eligible for a complete refund.
Begin by using the original box and bags that came with the inversion table. If you do not have the original
box, contact Teeter Customer Service at 800-847-0143. Product returned in an unauthorized packing
container may not be eligible for a complete refund.
NOTE: Figures do not show all bags used in repacking for easier viewing of box assembly.

Disassembling the Inversion Table

Figure 1: Start by disconnecting the inversion
table into its primary components: Table Bed,
A-Frame, Main Shaft with Ankle System, Accessories,
Hardware, Handles*, and Roller Hinges. DO NOT
disassemble the product into more components
than the parts listed below.
1
Table Bed
2
A-Frame
3
Main Shaft with
Ankle System
*For Stretch Max Handle disassembly on the X2
and X3: ONLY untighten the bolt on the spreader
arm enough to lift the bottom of the handle off
the spreader arm bolt (Figures 1a & 1b). DO NOT
fully untighten the bolt as this will de-stabilize the
A-frame.

Disassembling the Table Bed

Figure 2: Ensure all the accessories have been
removed from the Table Bed and place the Table Bed
face-down on the floor. Remove the two Bolts from
the Support Beam by using the 6mm Allen Wrench
to steady the bolts, and then loosen the Nuts from
the Bolts with the 10/13mm Open-Ended Wrench.

Repacking the Table Bed

Figure 3: Start repacking the inversion table by
placing the Table Bed face-down into the box off
to one side as shown.
Specifications subject to change without notice.
EN
© COPYRIGHT 2020 Teeter; International law prohibits any copying. 0920-0
4
Accessories & Hardware
5
Handles
6
Roller Hinges
1
2
Figure 1a
4
3
5
6
Figure 1
Figure 1b
Figure 2
Figure 3
