Summary of Contents for OPlus OP-6502IP
-
Page 2: Table Of Contents
Contents Summary........................................... 1 Safety precautions ......................................1 Product introduction......................................2 Features ..........................................2 Hardware interface introduction..................................3 Introduction........................................5 Packing list......................................... 5 Basic network settings...................................... 7 Wiring..........................................8 User-defined terminal parameters ................................9 Login web interface......................................9 Network parameters ....................................... 10 Device parameters...................................... -
Page 3: Summary
IP Digital Window Intercom User Manual Summary Safety precautions • Please abide by the warning and the relevant safety tips. • Please take this manual in convenient place for future reference. Warning and Reminding This symbol means there are potential safety issues, it may cause death or serious injury when incorrectly operating. This symbol draws the attention to important operation and maintenance instructions. -
Page 4: Product Introduction
IP Digital Window Intercom User Manual Product introduction The IP digital window intercom uses embedded IP Audio digital network audio technology with intellectual property rights to realize digital full-duplex intercom. The set is made of an internal and external window intercom module, equipped with power input, communication interface, recording output port. -
Page 5: Hardware Interface Introduction
IP Digital Window Intercom User Manual Hardware interface introduction. 【Front】 Internal window intercom Module ① Network status indication: red light is offline, green light is online ② Gooseneck microphone socket: plug the gooseneck microphone and fix the screw. ③ Loudspeaker: amplify the audio from the external window intercom. ④... - Page 6 IP Digital Window Intercom User Manual 【connection wiring】 Power interface: connect with 12V/1.5A power. ① Network interface: insert the cable to switcher ② Analog audio output interface: output analog audio, connect with DVR or IP camera. ③ External window intercom interface. ④...
-
Page 7: Introduction
IP Digital Window Intercom User Manual Introduction Packing list The Window intercom system includes the following accessories. Please check following parts. Contact your reseller if any parts are missing. （1）Internal window intercom module 1 set （2）External window intercom module 1 set （3）Gooseneck microphone (DC-300B) 1 PCS （4）Power adapter（12V/1.5A）... - Page 8 IP Digital Window Intercom User Manual （7）Wire terminal (3.81-2P) 1 PCS （8）Bushings (cable guidance) 1 PCS （9）EV-cotton （SPEV-63） 1PCS （10）Installation manual 1 PCS （11）Certification 1 PCS www.opus-technologie.fr...
-
Page 9: Basic Network Settings
IP Digital Window Intercom User Manual Basic network settings Using the Terminal Scanning Tool Locate and run “DevConfigTool.exe” in the folder [optical disc:\tool software\ ]. Enter the default password “123456”. Select the right tab【Mandatory config】, and fill out the correct parameters in the【terminal parameters】section. Click "send parameters"... -
Page 10: Wiring
IP Digital Window Intercom User Manual Wiring Connect the connector of the power adapter to the power interface of internal window intercom (red colored connector). Connect the connector of the external window intercom module with the corresponding connector of the internal window intercom module. -
Page 11: User-Defined Terminal Parameters
IP Digital Window Intercom User Manual User-defined terminal parameters Login web interface Use a web browser and navigate to the IP address of the IP internal window intercom module (factory default is http://192.168.1.101), then press Enter. Enter user name and password in the login window of the Web page (the default is : admin, password : Rdc070#*). After pressing Enter, you arrive in the configuration web page of the IP internal window intercom module. -
Page 12: Network Parameters
IP Digital Window Intercom User Manual Network parameters The parameters have the following meanings: You can choose to set a static IP manually or obtain an IP automatically from Connection type DHCP server MAC address The physical address of the terminal. This cannot be modified IP address Terminal IP address, factory default is 192.168.1.101 Subnet mask... -
Page 13: Server Parameters
IP Digital Window Intercom User Manual Server parameters The parameters have the following meanings: The IP address of the preferred server for this intercom, the factory default is 192.168.1.13. Preferred server Most of the advanced functions of the intercom depend on the server to work properly. -
Page 14: Intercom Parameters
IP Digital Window Intercom User Manual of internal and external units. Only inside: When broadcasting, the sound is being output on the speaker of the internal unit only. Only outside: When broadcasting, the sound is being output on the speaker of the external unit only. -
Page 15: Monitor Parameters
IP Digital Window Intercom User Manual Left-click call: when offline, enter the IP address corresponding to the remote intercom (left) button; Right-click call: when offline, enter the IP address corresponding to the remote intercom (right) button; Port cannot be modified except for special situations (the defaults is 2046) Monitor parameters Input volume: The volume of the host during monitoring. -
Page 16: Password Modification
IP Digital Window Intercom User Manual Analog Output Volume Set the output volume for analog recording. Digital Output Volume Set the output volume for digital recording. Check “Enable Digital Recorder” to enable intercom 24-hour digital recording. Recording server: Enter the IP address and port of the digital recording server. -
Page 17: Language Settings
IP Digital Window Intercom User Manual Language settings You can switch the Web page language between Chinese and English, save the modification and restart the intercom to activate the changes. Restart device Restart the device Note: the all modified parameters on the web page will be effective after restarting the device. www.opus-technologie. -
Page 18: Upgrade The Firmware (Note: Please Do Not Upgrade The Firmware Without Any Special Needs)
IP Digital Window Intercom User Manual Upgrade the firmware (Note: please do not upgrade the firmware without any special needs) Click “System Tools” and “Upgrade Firmware” to enter the firmware upgrade page. Click on “Into Firmware Upgrade” to put the device in firmware upgrade mode. System log The logfile contains all system events. -
Page 19: Basic Functions
IP Digital Window Intercom User Manual Basic functions Local intercom After connecting the internal and external window intercom modules, turn on the power. Press the intercom button of internal window intercom (the blue light goes ON). The internal window intercom can perform digital full-duplex HD intercom with the external window intercom. -
Page 20: Receiving Broadcasts
IP Digital Window Intercom User Manual Receiving broadcasts Are automatically answered without pressing any button. Recording Analog recording The internal window intercom can output analog audio and be connected to a DVR to automatically record on the hard disk of the recorder recorder. -
Page 21: Troubleshooting
IP Digital Window Intercom User Manual Troubleshooting Why can’t the terminal talk to others? 1. Check the internal window intercom logs with regards to the server. 2. Check whether the mapping settings of the server are correct. Why is the terminal "offline"? Check the server software and the firewall. -
Page 22: Copyright Statement
Opus Technologies 9 Chemin de la Vieille Ferme 33650 MARTILLAC 09 81 24 00 06 contact@opus-technologies.fr... - Page 23 Notes:...
- Page 24 Tél : 09.81.24.00.06 Mail: contact@opus-technologies.fr Opus Technologies — ZI Lagrange II — 9 Chemin de la Vieille Ferme — 33650 MARTILLAC...
