This product is a split-screen monitor that can use two PCs on one monitor at the
same time, and is particularly suitable for physical network separation environments.
It is a product that eliminates harmful electromagnetic waves while providing
high-definition image quality and power saving functions along with simple design.
In addition, this product is designed to be safe, easy to use, saves installation space,
Physical screen split monitor for two PCs
TOV-271M
Monitor User Manual
(Please read carefully before using the product.)
and provides clear picture quality.
Techonvision Co., Ltd.
Advertisement
Summary of Contents for Technovision TOV-271M
- Page 1 Physical screen split monitor for two PCs TOV-271M Monitor User Manual (Please read carefully before using the product.) This product is a split-screen monitor that can use two PCs on one monitor at the same time, and is particularly suitable for physical network separation environments.
- Page 2 Chapter. 1 [ S a f e t y P r e c a u t i o n s ] Failure to read the safety precautions may result in serious injury or material damage. caution Please read it carefully and use it properly to protect your safety and prevent damage to property.
- Page 3 Chapter. 2 [ Installation 1 ] 1-1 Components Please make sure that the following components are included when opening the box. If any components are missing, contact your dealer immediately to receive the parts. Please use monitor. Depending on the product, additional accessories (DVI cable, remote controller, HDMI cable) may be enclosed.
- Page 4 Chapter. 2 [ Installation 2 ] 1-3 Cable Connection Monitor Configuration/Connection - REAR Power PC-1 PC-2 HDMI Terminal Terminal Terminal Terminal Terminal Terminal 1. Connect the 220V power outlet to the power input terminal of the adapter with the power cord. Plug the DC output jack of the adapter into the power input terminal on the back of the monitor.
- Page 5 Chapter. 3 [ Trouble Shooting ] Problems Solutions Please execute initialization in the product menu after purchasing. Did you connect the monitor for Because the graphics cards are all different, it is recommended to the first time? make the initial settings. Please connect the computer connection cable again.
-
Page 6: How To Use The Buttons
Chapter. 4 [TOV-270, 271M Monitor Installation] order part explanation Check the Check the monitor parts in the product box, take out the monitor, contents first insert the monitor base and fix it with screws. Connect the Connect the DVI cable to the monitor’s “DVI” terminal. DVI cable Connect the Connect the HDMI cable to the monitor “HDMI”... - Page 7 Chapter. 4 [ How to use K eyboard & Mouse ] ♣ How to move the Keyboard & Mouse When using the full screen, the mouse can be moved according to the output screen and used immediately. In the split screen mode, the DVI-connected computer is recognized as 1 and the HDMI-connected computer is recognized as number 2.
- Page 8 Chapter. 5 [ Screen adjustment ] Press the M button to display the OSD menu window and use the ▲,▼ button to go to the desired mode. Press the S button to select the submenu to adjust using the ▲,▼ buttons. (Items may be disabled depending on the input signal.) 6-1 Screen Brightness, Contrast Description...
- Page 9 Chapter. 5 [ Screen adjustment ] 6-2 Screen Color Format Settings Description HDMI Resolution : 1920x100@60Hz Brightness/Contrast Input Color Format Auto Select Color Format Settings Color Domain YUV Domain Color Settings Picture Quality Settings Display Settings Audio Settings Other Settings Input Color Format Select the color format for the screen.
-
Page 10: Screen Display Settings
Chapter. 5 [ Screen adjustment ] 6-4 Screen Picture Quality Settings Description HDMI Resolution : 1920x100@60Hz Brightness/Contrast Sharpness Color Format Settings Color Settings Picture Quality Settings Display Settings Audio Settings Other Settings Sharpness Adjust the sharpness of the screen. (Default : 50) 6-5 Screen Display Settings Description HDMI... - Page 11 Chapter. 5 [ Screen adjustment ] 6-6 Screen Audio Settings(Not for using this product.) Description HDMI Resolution : 1920x100@60Hz Brightness/Contrast Power Save Audio Color Format Settings Volume Color Settings Picture Quality Settings Display Settings Audio Settings Other Settings Power Save Audio Audio Sleep Mode (Default : Off) Volume Adjust the Audio Volume.
- Page 12 Chapter. 6 [ Product Specification ] ToV - 270M/271M LCD Panel 68.6cm(27type) Wide 0.3111mm x 0.3111mm Pixel size 1920 x 1080 (Full HD) Optimal resolution Viewing angle Right and left : 178, Upper and Lower : 178 Contrast 1,000 : 1 ( infinite : 1 DCR) brightness 300cd/m2 5ms (GTG)
- Page 13 Chapter. 7 [ Warranty Guide ] This product has passed thorough quality control and inspection. If any malfunction occurs during normal use, we will warrant it in accordance with this warranty. When you want a guarantee Please check the warranty first. Please recheck the fault and contact the service center.
-
Page 14: Product Warranty
Product Warranty Product Name Model Name Warranty Product Serial No. After purchase Date of purchase 1 year Purchase Agent Phone No 1. This product is made by our technicians through strict quality control and process. 2. If any trouble occurs within the warranty period (1 year after purchasing), you can get free repair service from our service center.
