DSE DS-N4 Installation Manual

4 hd-sdi channels

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

INSTALLATION MANUAL

DS-N4 - HD-SDI Video

Page: 1

Video DS-N4

4 HD-SDI channels

Manual for the installer and for the user

DSE SRL - ITALY - WWW.DSE.EU

Table of Contents

Need help?

Do you have a question about the DS-N4 and is the answer not in the manual?

Questions and answers

Summary of Contents for DSE DS-N4

Page 1 INSTALLATION MANUAL DS-N4 - HD-SDI Video Page: 1 Page: 1 Video DS-N4 4 HD-SDI channels Manual for the installer and for the user DSE SRL - ITALY - WWW.DSE.EU...
Page 2: Product Description
Based on Linux operating system, DS-N4 is a simple and stable DVR but also very powerful. It 'able to record video and audio from 4 HD-SDI cameras with Full HD 1920x1080 resolution at 25 f / sec for a perfect real-time viewing.
Page 3: Main Technical Data
Protocol Pelco P / D, Samsung, Panasonic etc. video Backup AVI format, IFV Supply 12VDC power supply provided Absorption 10-15W Temperature - 10 + 40 ° C Humidity 10% -90% RH Dimensions mm. 400x310x55 DSE SRL - ITALY - WWW.DSE.EU...
Page 4: Description Of The Front Panel
In PTZ mode they are used to control the movements of the camera (PAN / TILT). 14-15 USB: There are 2 USB 2.0 ports. One to connect storage devices for video backup and to connect the mouse in the box. DSE SRL - ITALY - WWW.DSE.EU...
Page 5: Back Panel Description
VGA monitor connector for PC. This video output is in FullHD 1080p. audio Outputs RCA connector for external speakers Connect to TV with HDMI input. This video output is in FullHD 1080p. HDMI LINE IN External Audio Input for intercom system DSE SRL - ITALY - WWW.DSE.EU...
Page 6: Making Connections
Connect HD-SDI cameras The cameras are connected to the BNC Video IN. DS-N4 is not suitable for connecting analog or web cameras on the contrary, it is absolutely not able to play, but is designed to handle HD-SDI cameras in Full HD 1080p resolution. These cameras can be connected with the same RG59 coaxial cable and BNC connectors that are used for analog cameras.
Page 7 Because the DVR is capable of recording, you need to install the hard drive inside the equipment. The DVR is supplied without a hard disk, so the first necessary step is the install disk. DS-N4 can accommodate 1 or 2 hard drives inside of SATA type and a maximum capacity of 3000 GB. Proceed with the installation of the hard disk as follows: 1.
Page 8: Other Connections
12VDC. In programming it is possible to define whether to consider the presence of voltage alarm (HIGH LEVEL) or absence of voltage (LOW LEVEL). DSE SRL - ITALY - WWW.DSE.EU...
Page 9 +/- instead of A / B). The communication settings (protocol, speed, etc. of the bus) is operating in the DVR configuration menu and must be consistent with the commands accepted by the cameras used. The DR series DVR support PelcoD protocol used by DSE speed dome cameras, and various other protocols from other manufacturers.
Page 10: Basic Operations
After the LOGIN you can proceed with the system configuration and advanced controls. VISION REAL-TIME The main screen shown on the monitor after booting the system is multi-image of the live cameras as shown in the figure below. DSE SRL - ITALY - WWW.DSE.EU...
Page 11 By clicking on the icon among those viewing it will appear in a window screen to choose which channel to full screen. DSE SRL - ITALY - WWW.DSE.EU...
Page 12 The icon REC starts manual recording. E 'can choose which camera to send in the registration icon PLAY on the right leads to the quick The icon REC starts manual recording. E 'can choose which camera to send in the registration icon PLAY on the right leads to the quick playback of the latest recorded images. DSE SRL - ITALY - WWW.DSE.EU...
Page 13 RECORD ON MOTION DETECTION - Initiated the occurrence of a movement in the image ALARM RECORD - Initiated following the activation of an alarm input ALARM RECORD - Initiated following the activation of an alarm input DSE SRL - ITALY - WWW.DSE.EU...
Page 14: Configuration Options
To access the programming of the DVR, click the main menu icon . Will appear screen a window like the following Clicking on "SETUP" will open the following screen which includes all the options of the DVR DSE SRL - ITALY - WWW.DSE.EU...
Page 15 Date and time. WINDOW SYSTEM (SYSTEM) DEVICE NAME - User customizable name to help the user to recognize the device remotely. DEVICE NAME - User customizable name to help the user to recognize the device remotely. DSE SRL - ITALY - WWW.DSE.EU...
Page 16 LOCK TIME - Set after how much downtime the DVR will exit the log in and request your password again. Press the "Default" button to restore the factory default settings. Press the "Apply" button to save your changes. Press the "Exit" button to close the window. WINDOW DATE & TIME (DATE & TIME) DSE SRL - ITALY - WWW.DSE.EU...
Page 17 LIVE (live video) In the menu "Setup" LIVE click on the item to enter the configuration of the live camera view. The LIVE setup menu is divided into two submenus: Live and Mask. WINDOW LIVE DSE SRL - ITALY - WWW.DSE.EU...
Page 18 MASK WINDOW In this section the user can activate and define any privacy masks used to mask a particular you do not want to see during recording and adjusts the playback to protect personal privacy. DSE SRL - ITALY - WWW.DSE.EU...
Page 19 To save and exit by clicking the right mouse button and click APPLY. To clear the mask created, double click with the left mouse button on the created mask. RECORD (recording) In this section you set the recording options. The recording menu is divided into five folders: Enable, Stream, Alarm Rec Time, stamps, Loop Record. WINDOW ENABLE DSE SRL - ITALY - WWW.DSE.EU...
Page 20 Resolution 1080P, 720P, D1, CIF 1-25 (PAL) CBR / VBR bitrate Management Quality Best, Better, Good, Normal, Bad, Worse 64Kb, 128Kb, 256Kb, 512Kb, 1024Kb, 1536Kb, 2048KB, 3072Kb, 4096Kb, 5120Kb, 6144Kb, Maximum bitrate 7168Kb, 8192Kb DSE SRL - ITALY - WWW.DSE.EU...
Page 21: Loop Record
The last line of the screen is to select quickly the record setting same on all channels. LOOP RECORD If this function is enabled, the recording will continue out of disk space by overwriting the oldest files. By disabling the recording function stops out of disk space. DSE SRL - ITALY - WWW.DSE.EU...
Page 22 Page: 22 SCHEDULE (time programmer) In this section you set the timer recording. The menu is divided into 3 folders: TIMER (timer recording) MOTION (recording of motion detection) SENSOR (registration of external alarm input) DSE SRL - ITALY - WWW.DSE.EU...
Page 23 (Motion), external sensors connected to the terminal and Video loss. On the back of the DVR there is an alarm output with which it is possible to control external devices in case of alarm. The ALARM section is therefore divided into 4 sub-menus: SENSOR, MOTION, VIDEO LOSS, ALARM OUT DSE SRL - ITALY - WWW.DSE.EU...
Page 24 LOW LEVEL means that the alarm occurs in the absence of voltage between the terminals. NAME - E 'can set an identifying name of the alarm input. NAME - E 'can set an identifying name of the alarm input. 2> Alarm handling DSE SRL - ITALY - WWW.DSE.EU...
Page 25 Managing by motion detection alarms. The DVR can generate alarms based on the analysis of the images from the cameras if an intrusion occurs in the visual field. This detection is known in the industry as CCTV Motion Detection. The page consists of two sections: Motion and Schedule DSE SRL - ITALY - WWW.DSE.EU...
Page 26 AREA - Pressing this button you can define the portion of the image on which to operate the motion detection. AREA - Pressing this button you can define the portion of the image on which to operate the motion detection. DSE SRL - ITALY - WWW.DSE.EU...
Page 27 - Quit without saving In addition there is the slider to adjust the sensitivity of detection from 1 to 5 to be settled according to the environmental situation in order to avoid untimely detections. 2> Schedule DSE SRL - ITALY - WWW.DSE.EU...
Page 28: Video Loss
SHOW FULL SCREEN - Defines whether to automatically select the full screen the camera that triggered the alarm TO ALARM OUT - Defines whether to activate the alarm output on the back of the DVR DSE SRL - ITALY - WWW.DSE.EU...
Page 29: Alarm Out
The riquadrino blue means action enabled, the gray color means disabled action. In the selection of time slots is supported dragging the mouse. 2> Buzzer E 'you can be associated with the activation of the release of the buzzer sound for a defined period of time DSE SRL - ITALY - WWW.DSE.EU...
Page 30: Network (Network)
For example, if the call brwaser DVR typing http://192.168.0.110 the call will take place on port 80. If you have changed the http port in the DVR for example. in 81, you will have the address of the brawaser indicate http://192.168.0.110:81 DSE SRL - ITALY - WWW.DSE.EU...
Page 31 25 f / sec. Because mobile devices are often used via the internet with limited bandwidth availability is used to always enable the sub-stream pleasant that you do not use cell phones only on wi-fi internal networks. DSE SRL - ITALY - WWW.DSE.EU...
Page 32 MAX. BITRATE - If you have chosen the management of CBR bandwidth Here you set the maximum bandwidth you want to occupy WINDOW E-MAIL The DVR can send e-mail on alarm. In this section we set the parameters required for sending the emails. DSE SRL - ITALY - WWW.DSE.EU...
Page 33 To connect through the Internet is highly advisable to have a fixed IP address so that you always know the exact address to connect. If you can not get from your provider, the DS-N4 DVR supports DDNS service (Dynamic DNS) that allow you to constantly monitor the machine's IP address.
Page 34 REGISTER - To test the functionality REGISTER - To test the functionality USERS (users) Access to DVR, both locally and remotely is password protected to prevent unauthorized access. In this section we set managed users from DVR DSE SRL - ITALY - WWW.DSE.EU...
Page 35 BINDING PC MAC ADDRESS - E 'can match the user with a MAC address of a PC so as to enable access only through that machine BINDING PC MAC ADDRESS - E 'can match the user with a MAC address of a PC so as to enable access only through that machine DSE SRL - ITALY - WWW.DSE.EU...
Page 36 (PTZ speed dome control) DS-N4 is able to control the movement of speed dome cameras directly through the RS422 / RS485 rear door. If you have motorized cameras control via DVR is a big advantage in that in addition to saving on the purchase of a control console for speed dome is possible to control the movements of the cameras via the network and also to perform automatic movements according to the alarms detected by the DVR .
Page 37: Serial Window
PROTOCOL - And 'the communication language to be used which must obviously be supported by the cameras. For speed dome cameras DSE use Pelco D Protocol The DVR supports the following communication standards from other manufacturers: HY, Panasonic, Pelco 9750, Pelco D / P, Philips, Samsung, Sharp, Sony, Yaan.
Page 38: System Reset
EXPORT THE CONFIGURATION - Insert a USB stick in the port of the DVR and click NEW to create a new configuration file that will appear in the list. Highlight it and click DSE SRL - ITALY - WWW.DSE.EU...
Page 39 This section allows you to schedule periodic restarts of programmable DVR with daily, weekly or monthly. This feature, although required in some applications and therefore permitted by the DVR, it is not necessary for the smooth stable operation of the system. DSE SRL - ITALY - WWW.DSE.EU...
Page 40 In this section you can search for video files stored on the DVR. You can also access this window by pressing the SEARCH button on the DVR's keyboard or the SEARCH button on the remote. There are two types of research BY TIME: by time BY TYPE: Depending on the type of recording BY TIME DSE SRL - ITALY - WWW.DSE.EU...
Page 41 6 - Door to the previous minute (analogous to the other end of the timeline to advance button) 7 - Indicates the type of reproduction that is in progress (forward / backward and speed) 8 - Digital zoom - By clicking this button you can drag the mouse on the screen and DSE SRL - ITALY - WWW.DSE.EU...
Page 42 Finally press SEARCH to search the DVR memory. The events were found they will be listed in the grid. START Press PLAY to start playback from the first event, or double-click on a single event. During playback you can use the same commands just seen in the search for time / date. DSE SRL - ITALY - WWW.DSE.EU...
Page 43 The AVI format is universal and easily reproducible by any player such as Windows Media Player, VLC etc. The IFV format you can only play with the reader on the CD supplied with the DVR which nevertheless contains some playback controls more than the general reader. DSE SRL - ITALY - WWW.DSE.EU...
Page 44: Information (Information)
Formatting the drive will erase all data on it. UPGRADE (update) In this section you can update the system firmware after loading it on a USB stick. This operation is required only on the instructions of the DSE technicians. DSE SRL - ITALY - WWW.DSE.EU...
Page 45: Shut Down (Off)
DVR. The unit will make the closure of all processes and will turn off automatically. Wait until the unit turned off, then bring the ON / OFF button back to the OFF position. RESTART (Restart) This button is used to restart the DVR. DSE SRL - ITALY - WWW.DSE.EU...
Page 46: Setting The Network Parameters
DHCP auto configuration that automatically regard by swicth network (or other DHCP server) IP address, subnet mask and gateway which are the basic communication parameters. If DHCP was disabled should turn it on and restart the DVR to get the network parameters at startup. DSE SRL - ITALY - WWW.DSE.EU...
Page 47: Communication Ports
PORT FORWARDING. These instructions are fundamental for connecting to the Internet and must be made in the router. Consult the manual of Router on how to do port forwarding, also called port mapping or NAT. DSE SRL - ITALY - WWW.DSE.EU...
Page 48: Port Forwarding
Each router has its own configuration, usually accessed by calling the browser's internal IP address of the router, so there is not possibie to provide instructions on how to do the mapping. Consult the instructions for your router for details or contact your ISP service that supplied it. DSE SRL - ITALY - WWW.DSE.EU...
Page 49 DVR. Access all'interfacia graphics program that is capable of managing a split-screen with up to 64 quadrants. It is a powerful centralized tool through which you can control multiple DVRs from a single location. DSE SRL - ITALY - WWW.DSE.EU...
Page 50 Settings - Adding a DVR The first thing to do is insert a link to a first DVR. To do this, press the SET button in the top bar and the first voice DEVICE MANAGER. DSE SRL - ITALY - WWW.DSE.EU...
Page 51 At this point you can add the DVR for the individual areas. Click the right mouse button to select ADD DEVICE. Enter data as in the example. DSE SRL - ITALY - WWW.DSE.EU...
Page 52 Click OK to add the DVR in your chosen Do the same to add more DVR in other areas. Finally press PREVIEW top to exit the program and return to live viewing. We will find the right tree equipment just realized. DSE SRL - ITALY - WWW.DSE.EU...
Page 53 LIVE Vision camera To see real-time cameras just drag the camera icon in the tree on the right to one of the viewing panes on the left. At the bottom there are the control buttons DSE SRL - ITALY - WWW.DSE.EU...
Page 54 The DVR client program also allows you to play back recorded images in both the hard disk of the PC it is installed on both the remote DVR. PLAYBACK Click on the button at the top you can choose between LOCAL and REMOTE PLAYBACK PLAYBACK. DSE SRL - ITALY - WWW.DSE.EU...
Page 55 The options in this section are the same as those seen in the DVR configuration. To operate select the DVR tree on the right and configure the options of the various tables. DSE SRL - ITALY - WWW.DSE.EU...
Page 56 Page: 56 Page: 56 Settings - Client settings Here we are enclosed all client DVR program settings. The section is divided into three folders: LOCAL SETTING RECORD SETTING and WARNING LINKAGE which we explain below. DSE SRL - ITALY - WWW.DSE.EU...
Page 57: Local Setting
AUTOMATIC LOGON - Accesses the program without checking password alla'avvio wether TO OPEN ... - Enabling this option at the end of the program is memorized the layout of the screen cameras that will be repeated automatically to restart DSE SRL - ITALY - WWW.DSE.EU...
Page 58: Record Setting
PC has more HDD. E 'can also set the maximum size of each video file. PLAN RECORD - For each camera you can define if you record continuously (ALL DAY RECORDS) or only at certain times of the day. E 'can define 4 time slots. DSE SRL - ITALY - WWW.DSE.EU...
Page 59 Here you've set new users who may have access to the program with their access level. Press ADD USER to add a user to assign name and password. Once you created the user can take action in the tree on the right to set the level of access DSE SRL - ITALY - WWW.DSE.EU...
Page 60 DS-N4 - HD-SDI Video Page: 60 Page: 60 assigned depending on the DVR and the camera. It enables you to browse the event log of remote DVR searching by date / time and type of event. DSE SRL - ITALY - WWW.DSE.EU...
Page 61 INSTALLATION MANUAL DS-N4 - HD-SDI Video Page: 61 Page: 61 Function currently not available. DSE SRL - ITALY - WWW.DSE.EU...
Page 62 In the folder PROTECTION to choose In the folder PROTECTION to choose the area INTERNET and click LEVEL the area INTERNET and click LEVEL the area INTERNET and click LEVEL the area INTERNET and click LEVEL DSE SRL - ITALY - WWW.DSE.EU...
Page 63 To access the DVR with Internet Explorer, type in the address box, the IP address of the camera. In the example in figure we provide such as a link on the internal network to the DVR with IP address 192.168.2.30. DSE SRL - ITALY - WWW.DSE.EU...
Page 64 Press ENTER and you present the log-in DVR window This is the stage where, only that the first access is made from the computer, the activeX components are installed. If you have properly set the security settings of the components DSE SRL - ITALY - WWW.DSE.EU...
Page 65 Alternatively you can also click START ALL to start viewing of all 4 cameras and STOP ALL to stop it. On the right of the screen are a few different controls DSE SRL - ITALY - WWW.DSE.EU...
Page 66 PC performance or failure for a modest bandwidth available (for example in the Internet), you can elect to receive in lieu of the main stream in high resolution sub-more "light stream" in standard resolution. DSE SRL - ITALY - WWW.DSE.EU...
Page 67: Camera Controls
FULL SCREEN - Bring the camera in full screen. FULL SCREEN - Bring the camera in full screen. Remote DVR Configuration Pushing the CONFIGURE button you can program all of the remote DVR configuration options. DSE SRL - ITALY - WWW.DSE.EU...
Page 68 The options available in this section are the same as we described in the section of the manual dedicated to the DVR programming. remote Play Pressing the Playback button you can search for movies stored on the DVR hard drive. DSE SRL - ITALY - WWW.DSE.EU...
Page 69 Define high the object of the search camera, the time period and the type of recording and press SEARCH. The window will list all the recordings in the DVR memory and you can play them or download them to your PC. DSE SRL - ITALY - WWW.DSE.EU...
Page 70: Windows Mobile
PDA following the instructions of the equipment. For installation you need to set SOFTWARE INSTALLATION - ALL and CERTIFIED ONLINE CHECK - OFF Run the program and click TMeye SETTING to set the address of your DVR. DSE SRL - ITALY - WWW.DSE.EU...
Page 71 Moving speed dome cameras Zoom Focus Iris and speed dome cameras Play and Stop Full screen hides the menu buttons Take a picture and saves it into memory Accesses settings following cameras Group Exit DSE SRL - ITALY - WWW.DSE.EU...
Page 72: Iphone / Ipad
Then press the + button to add a DVR to which you can connect. Enter your login credentials (default Admin / -), the machine's IP address and the port to use that default is 101. Finally specify the number of channels on the DVR. DSE SRL - ITALY - WWW.DSE.EU...
Page 73 INSTALLATION MANUAL DS-N4 - HD-SDI Video Page: 73 Page: 73 Click SAVE and then BACK. Click to start monitoring screen DSE SRL - ITALY - WWW.DSE.EU...
Page 74 Choose DEVICE LIST and then the + button add the DVR as soon as the visa application TMeye. Below the installed application on iPhone DSE SRL - ITALY - WWW.DSE.EU...
Page 75 Page: 75 Below the application installed on iPad Click + to add the DVR and enter the access data. They fit as already seen for the TMeye address, port, log-in and the number of channels. DSE SRL - ITALY - WWW.DSE.EU...
Page 76 DS-N4 - HD-SDI Video Page: 76 Page: 76 E 'can store multiple DVRs and cameras to choose which one they see on the screen. And 'you can display up to 9 cameras simultaneously from different DVR. DSE SRL - ITALY - WWW.DSE.EU...
Page 77 They serve to hide or show the channel list on the left accesses the movement control of speed dome cameras Closes all channels Closes the selected channel Play Stop multivision Button (4/6/9 channels) Capture a frame to be saved in memory DSE SRL - ITALY - WWW.DSE.EU...
Page 78 If you have a BlackBerry PDA you have to copy on a PC and TMeye.cod TMeye.alx files that you will find in the CD supplied with the DVR. To be able to install applications on BlackBerry requires that your PC is running BlackBerry Desktop Manager. Open the Desktop Manager: DSE SRL - ITALY - WWW.DSE.EU...
Page 79 INSTALLATION MANUAL DS-N4 - HD-SDI Video Page: 79 Page: 79 Click APPLICATION LOADER Choose ADD / REMOVE APPLICATIONS clicking START DSE SRL - ITALY - WWW.DSE.EU...
Page 80 Now Desktop Manager will display the new TMEye application and you can start the installation. Start the program from the Click to open the settings window. Enter your login credentials (default Admin / -), the machine's IP address and the port to use that default is 101. DSE SRL - ITALY - WWW.DSE.EU...
Page 81 Click LOGIN. The DEVICE LIST button gives you access to other DVR that has had access in the past. Click to start monitoring screen The control buttons are: Play and Stop Full screen hides the menu buttons Take a picture and saves it into memory DSE SRL - ITALY - WWW.DSE.EU...
Page 82 INSTALLATION MANUAL DS-N4 - HD-SDI Video Page: 82 Page: 82 Accesses settings About This App Opens the channel selection window. Commands Move - Zoom - Focus - Iris to Speed d ome cameras DSE SRL - ITALY - WWW.DSE.EU...
