Fitting/replacing bulbs
• Slide off the end panel as shown below, and slide out
the diffuser.
• Twist 90 degrees and remove from slots to remove.
• Refit by locating the pins in the lampholder slots,
and twisting 90 degrees to engage the pins with the
contacts.
• When changing a bulb, always switch off at the mains
and allow the bulb to cool before handling.
• Used bulbs should not be disposed of with household
waste. Please recycle where facilities exist. Always
use the correct type and wattage bulb. Using the
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Safety information
For your safety, always switch off the supply before changing lightbulbs, cleaning or removing shades.
www.saxbylighting.com
incorrect wattage bulb will damage the bulb and
ballast.
• Reslide the diffuser back into position, and refit the
end panel.
• Replace with: 10785 - 2 x 35W T5 Fluorescent
35W G5 T5
Iss.1 24062013
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
Reed
10785
Advertisement
Summary of Contents for Saxby Lighting Reed 10785
- Page 1 Fitting/replacing bulbs Instruction leaflet • Slide off the end panel as shown below, and slide out incorrect wattage bulb will damage the bulb and the diffuser. ballast. Reed • Twist 90 degrees and remove from slots to remove. • Reslide the diffuser back into position, and refit the end panel. • Refit by locating the pins in the lampholder slots, and twisting 90 degrees to engage the pins with the • Replace with: 10785 - 2 x 35W T5 Fluorescent 10785 contacts. 35W G5 T5 • When changing a bulb, always switch off at the mains and allow the bulb to cool before handling. • Used bulbs should not be disposed of with household waste. Please recycle where facilities exist. Always use the correct type and wattage bulb. Using the We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish. Recycling advice Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. Safety information For your safety, always switch off the supply before changing lightbulbs, cleaning or removing shades.
- Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before screw on the side. Feed the wire through the hole installation of a new product. Before removing the at the end, ensuring that the grommet is correctly existing fitting or ceiling rose, carefully note the located in the hole. Warning position of each set of wires. • Ensure that the ceiling can support the weight of the This is a Class 1 product and must be earthed. Always use the correct type and wattage bulb. Using product. the incorrect wattage bulb will damage the bulb and Please read these instructions carefully before • Drill holes 800mm apart, and fit the supplied ballast. commencing any work. hooks into the ceiling using the fixings supplied. When changing a bulb, always switch off at the mains Other fixings may be required, depending upon the Supply Cable This unit must be fitted by a competent and qualified and allow the old bulb to cool down before handling. surface. electrician. Dispose of used bulbs carefully and responsibly.
