RECEIPT OF GOODS
Your device has been packaged with care.
Make sure, ON RECEPTION, that the package is COMPLETE and in GOOD
CONDITION.
If you notice an anomaly, immediately make all reservations with your carrier, this is
PRIMORDIAL.
Before leaving, your device has been thoroughly tested.
It must be used for a long time, provided that you follow the installation, operating
and installation instructions. To help you do this, comply with the data in this leaflet.
CAUTION: The warranty certificate provided with the invoice automatically loses its
validity to cover any damage resulting from non-compliance with the instructions.
Always devoted to your orders, our commercial and technical services remain entirely
yours.
WE WISH YOU GOOD DEALS! !
ELECTRICAL CONNECTION
wo operating voltages:
230 V + T) EARTH
400 V + N + T)
- Check if the mains voltage corresponds to
- that indicated on the machine.
IN ALL CASES, DON'T FORGET TO
CONNECT THE EARTH.
FOR MACHINES PLACED OUTSIDE:
DON'T FORGET TWO THINGS
- A WATERPROOF CONNECTION SOCKET
- A PROTECTION ROOF
DON'T FORGET TO EQUIP THESE DEVICES
OF A PROTECTIVE ROOF
USER MANUAL
"DECO" MODELS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DOREGRILL Deco Series
Summary of Contents for DOREGRILL Deco Series
- Page 1 USER MANUAL “DECO” MODELS RECEIPT OF GOODS Your device has been packaged with care. Make sure, ON RECEPTION, that the package is COMPLETE and in GOOD CONDITION. If you notice an anomaly, immediately make all reservations with your carrier, this is PRIMORDIAL.
- Page 2 GETTING STARTED LEGEND OF THE CONTROL PANELM A: White LED indicating power on (when the device is connected to the mains this LED lights up) B: Yellow light indicating the heating operation C: 3-position selector switch ECL : lighting (light only) ROT : Lighting + heater MOT : Lighting + heater + engine D: thermostat: for regulating the resistance at the top...
- Page 3 b) Heating with controlled temperature - Selection switch C in ROT or MOT position - Thermostat E at zero - Thermostat D: regulate to the desired temperature (between 70 ° and 90 °) - Timer F: depending on the time required for the product to cook. VERY IMPORTANT: POSITIONING CROSSING SWING MOUNT The support cross member located along the side window has a square: this square is directed towards the inside of the oven to support the grid.
- Page 4 IMPORTANT: NEVER USE ALU PAPER TO PROTECT THE DEFLECTORS (RISK OF FIRE) It is however possible to use aluminum foil for the central crosspiece of the swing star. To facilitate cleaning, the whole of the support-swing star is removable. Proceed as follows: - Open the side door - Slightly lift the end of the star - Clear the lateral cross member from its housings...
- Page 5 PLAN DE CABLAGE 380V + N + T...
