- Page 1 USER GUIDE D-BOX LIFESTYLE Instructions...
- Page 2 GET READY Unpack the box - Remove all packaging from your seat. You should have in your Jaymar Experience box: 1seat base, 1 seat back and hidden in the seat base, your plastic bag with accessories. A plastic bag with: 1 x Power Cord 1 x CAT.5E Shielded Cable 9.10 ft...
- Page 3 STEP 1 Ensure that back clip is properly aligned with the anchoring of the base on both sides. Slip the anchors into the clips and moving the back slightly back from left to right to lower it and engage it. Clip Anchor...
- Page 5 STEP 4 Insert the IEC Plug Lock (yellow block) on the male end of the power cord (black cable). Connect the power cord to the back panel.
- Page 6 STEP 5 You can now recline your D-BOX Lifestyle seat! STEP 6 Place the flap inside the back using the velcro...
- Page 7 STEP 7 Install the three D-BOX Stabilization Cups (under foot). Lift one corner and slide the cupola under the white tip of the actuator. Repeat for the second actuator and the rear pivot. ACTUATORS FRONT BACK PIVOT...
- Page 8 IMPORTANT NOTICE IMPORTANT , never move your furniture by sliding it on the floor. This could damage the actuators or your floor. Never operate the D-BOX technology without the Stabilization cups. INSTALLATION IN YOUR ROOM Leave a clearance of 4'' between each D-BOX chair no tot block the range of motion. If the chair is near a wall, allow 6'' of clearance.
