First Alert CO511 User Manual

REGULAR MAINTENANCE HOW CAN I PROTECT MY FAMILY FROM
This unit has been designed to be as maintenance-free as possible, but there
CO POISONING?
are a few simple things you must do to keep it working properly.
A CO Alarm is an excellent means of protection. It monitors the air and sounds
a loud alarm before Carbon Monoxide levels become threatening for average,
Use only the replacement batteries listed below. The unit may not healthy adults.
operate properly with other batteries. Never use rechargeable batteries
A CO Alarm is not a substitute for proper maintenance of home
since they may not provide a constant charge.
appliances.
• Test it at least once a week. To help prevent CO problems and reduce the risk of CO poisoning:
• Clean chimneys and flues yearly. Keep them free of debris, leaves, and
• Clean the CO Alarm at least once a month; gently vacuum the outside
nests for proper air flow. Also, have a professional check for rust and
of the CO Alarm using your household vacuum's soft brush attachment.
corrosion, cracks, or separations. These conditions can prevent proper
A can of clean compressed air (sold at computer or office supply stores)
air movement and cause backdrafting. Never "cap" or cover a chimney
may also be used. Follow manufacturer instructions for use. Test the CO
in any way that would block air flow.
Alarm. Never use water, cleaners or solvents since they may damage the
unit. • Test and maintain all fuel-burning equipment annually. Many local gas
or oil companies and HVAC companies offer appliance inspections for
• If the CO Alarm becomes contaminated by excessive dirt, dust and/or
a nominal fee.
grime, and cannot be cleaned to avoid unwanted alarms, replace the unit
immediately. • Make regular visual inspections of all fuel-burning appliances. Check
appliances for excessive rust and scaling. Also check the flame on the
• Relocate the unit if it sounds frequent unwanted alarms. See "Where CO
burner and pilot lights. The flame should be blue. A yellow flame means
Alarms Should Not Be Installed" for details.
fuel is not being burned completely and CO may be present. Keep the
Choosing a replacement battery: blower door on the furnace closed. Use vents or fans when they are
available on all fuel-burning appliances. Make sure appliances are
Your CO Alarm requires two standard AA batteries. The following batteries are
vented to the outside. Do not grill or barbecue indoors, or in garages
acceptable as replacements: Energizer E91. These batteries are available at
or on screen porches.
many local retail stores.
• Check for exhaust backflow from CO sources. Check the draft hood on
an operating furnace for a backdraft. Look for cracks on furnace heat
Actual battery service life depends on the CO Alarm and the environment in exchangers.
which it is installed. All the batteries specified above are acceptable replace-
• Check the house or garage on the other side of shared wall.
ment batteries for this unit. Regardless of the manufacturer's suggested
• Keep windows and doors open slightly. If you suspect that CO is
battery life, you MUST replace the battery immediately once the unit starts
escaping into your home, open a window or a door. Opening windows
"chirping" (the "low battery warning").
and doors can significantly decrease CO levels.
To replace the batteries (without removing Alarm from the ceiling or wall): In addition, familiarize yourself with all enclosed materials. Read this
manual in its entirety, and make sure you understand what to do if your
1. Open the battery compartment.
CO Alarm sounds.
2. Press tabs A and B as shown in the
diagram and remove each battery.
REGULATORY INFORMATION FOR CO ALARMS
3. Insert the new batteries, making sure
they snap completely into the battery
UNDERWRITERS LABORATORIES INC. UL2034
compartment. Match the terminals on
A B
the ends of the batteries with the
WHAT LEVELS OF CO CAUSE AN ALARM?
terminals on the unit.
Underwriters Laboratories Inc. Standard UL2034 requires residential CO
Alarms to sound when exposed to levels of CO and exposure times as
4. Close the battery compartment, and
then test the unit by pressing the described below. They are measured in parts per million (ppm) of CO over
time (in minutes).
Test/Silence button.
UL2034 Required Alarm Points*:
• If the alarm is exposed to 400 ppm of CO, IT MUST ALARM BETWEEN
WHAT YOU NEED TO KNOW ABOUT CO 4 and 15 MINUTES.
• If the alarm is exposed to 150 ppm of CO, IT MUST ALARM BETWEEN
WHAT IS CO?
10 and 50 MINUTES.
CO is an invisible, odorless, tasteless gas produced when fossil fuels do not • If the alarm is exposed to 70 ppm of CO, IT MUST ALARM BETWEEN
burn completely, or are exposed to heat (usually fire). Electrical appliances 60 and 240 MINUTES.
typically do not produce CO.
* Approximately 10% COHb exposure at levels of 10% to 95% Relative
Humidity (RH).
These fuels include: Wood, coal, charcoal, oil, natural gas, gasoline, kerosene,
and propane. The unit is designed not to alarm when exposed to a constant level of
30 ppm for 30 days.
Common appliances are often sources of CO. If they are not properly main-
tained, are improperly ventilated, or malfunction, CO levels can rise quickly. CO
is a real danger now that homes are more energy efficient. "Air-tight" homes
CO Alarms are designed to alarm before there is an immediate life threat.
with added insulation, sealed windows, and other weatherproofing can "trap"
Since you cannot see or smell CO, never assume it's not present.
CO inside.
• An exposure to 100 ppm of CO for 20 minutes may not affect average,
healthy adults, but after 4 hours the same level may cause headaches.
SYMPTOMS OF CO POISONING
• An exposure to 400 ppm of CO may cause headaches in average, healthy
These symptoms are related to CO POISONING and should be discussed adults after 35 minutes, but can cause death after 2 hours.
with ALL household members.
Mild Exposure: Slight headache, nausea, vomiting, fatigue ("flu-like"
This CO Alarm measures exposure to CO over time. It alarms if CO levels
symptoms).
are extremely high in a short period of time, or if CO levels reach a certain
Medium Exposure: Throbbing headache, drowsiness, confusion, fast heart
minimum over a long period of time. The CO Alarm generally sounds an alarm
rate. before the onset of symptoms in average, healthy adults.
Extreme Exposure: Convulsions, unconsciousness, heart and lung failure.
Why is this important? Because you need to be warned of a potential CO
Exposure to Carbon Monoxide can cause brain damage, death.
problem while you can still react in time. In many reported cases of CO
exposure, victims may be aware that they are not feeling well, but become dis-
oriented and can no longer react well enough to exit the building or get help.
Some individuals are more sensitive to CO than others, including people
Also, young children and pets may be the first affected. The average healthy
with cardiac or respiratory problems, infants, unborn babies, pregnant
adult might not feel any symptoms when the CO Alarm sounds. However,
mothers, or elderly people can be more quickly and severely affected by
people with cardiac or respiratory problems, infants, unborn babies, pregnant
CO. Members of sensitive populations should consult their doctors for
mothers, or elderly people can be more quickly and severely affected by CO.
advice on taking additional precautions.
If you experience even mild symptoms of CO poisoning, consult your doctor
immediately!
FINDING THE SOURCE OF CO AFTER AN ALARM
Carbon monoxide is an odorless, invisible gas, which often makes it difficult to
locate the source of CO after an alarm. These are a few of the factors that can
make it difficult to locate sources of CO:
• House well ventilated before the investigator arrives.
• Problem caused by "backdrafting." If the Alarm...
• Transient CO problem caused by special circumstances.
Horn "chirps" about once per minute.
Because CO may dissipate by the time an investigator arrives, it may be
difficult to locate the source of CO. BRK Brands, Inc. shall not be obligated Horn does three rapid "chirps" every minute;
to pay for any carbon monoxide investigation or service call. LED has 3 rapid flashes with "chirps".
POTENTIAL SOURCES OF CO IN THE HOME
The Alarms are linked but do not communicate with
each other.
CO Alarm goes back into alarm 4 minutes after you
Silence it.
CO Alarm sounds frequently even though no high
levels of CO are revealed in an investigation.
*For a list of acceptable replacement batteries, see "Regular Maintenance."
If you have questions that cannot be answered by reading this manual, call Consumer Affairs at 1-800-323-9005, M-F 7:30 a.m. to 5:00 p.m. (CST)
Fuel-burning appliances like: portable heater, gas or wood burning fireplace,
gas kitchen range or cooktop, gas clothes dryer. BRK Brands, Inc., ("BRK") the maker of First Alert
that for a period of five years from the date of purchase, this product will be
Damaged or insufficient venting: corroded or disconnected water heater
free from defects in material and workmanship. BRK, at its option, will repair
vent pipe, leaking chimney pipe or flue, or cracked heat exchanger, blocked
or replace this product or any component of the product found to be
or clogged chimney opening.
defective during the warranty period. Replacement will be made with a new or
Improper use of appliance/ device: operating a barbecue grill or vehicle in remanufactured product or component. If the product is no longer available,
an enclosed area (like a garage or screened porch).
replacement may be made with a similar product of equal or greater value.
This is your exclusive warranty.
Transient CO Problems: "transient" or on-again-off-again CO problems can
be caused by outdoor conditions and other special circumstances. This warranty is valid for the original retail purchaser from the date of initial
retail purchase and is not transferable. Keep the original sales receipt. Proof
The following conditions can result in transient CO situations:
of purchase is required to obtain warranty performance. BRK dealers, service
centers, or retail stores selling BRK products do not have the right to alter,
1. Excessive spillage or reverse venting of fuel appliances caused by outdoor
conditions such as: modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from
• Wind direction and/or velocity, including high, gusty winds. Heavy air in
any of the following: negligent use or misuse of the product, use on improper
the vent pipes (cold/humid air with extended periods between cycles).
voltage or current, use contrary to the operating instructions, disassembly,
• Negative pressure differential resulting from the use of exhaust fans.
repair or alteration by anyone other than BRK or an authorized service center.
Further, the warranty does not cover Acts of God, such as fire, flood,
• Several appliances running at the same time competing for limited
fresh air. hurricanes and tornadoes or any batteries that are included with this unit.
• Vent pipe connections vibrating loose from clothes dryers, furnaces,
or water heaters.
• Obstructions in or unconventional vent pipe designs which can amplify
the above situations.
For your records, please record:
2. Extended operation of unvented fuel burning devices (range, oven,
fireplace).
Date Purchased: _______________Where Purchased: __________________
3. Temperature inversions, which can trap exhaust close to the ground.
Date Installed: ____________/____________Month/Year
4. Car idling in an open or closed attached garage, or near a home.
These conditions are dangerous because they can trap exhaust in your home.
Replacement date is five years after installation:
Since these conditions can come and go, they are also hard to recreate during
a CO investigation.
_____________/____________Month/Year
NOTE: End of Life Signal — Once the unit reaches the end of its
lifecycle, the MALFUNCTION SIGNAL will sound once a minute to
indicate the need to immediately replace the Alarm.
First Alert ® is a registered trademark of the First Alert Trust used under license.
ONELINK ® is a trademark of BRK Brands, Inc.
5
REGULATORY INFORMATION FOR CO ALARMS, Continued
Standards: Underwriters Laboratories Inc. Single and Multiple Station carbon
monoxide alarms UL2034.
According to Underwriters Laboratories Inc. UL2034, Section 1-1.2: "Carbon
monoxide alarms covered by these requirements are intended to respond to
the presence of carbon monoxide from sources such as, but not limited to,
exhaust from internal-combustion engines, abnormal operation of fuel-fired
appliances, and fireplaces. CO Alarms are intended to alarm at carbon
monoxide levels below those that could cause a loss of ability to react to the
dangers of Carbon Monoxide exposure." This CO Alarm monitors the air at the
Alarm, and is designed to alarm before CO levels become life threatening. This
allows you precious time to leave the house and correct the problem. This is
only possible if Alarms are located, installed, and maintained as described in
this manual.
Gas Detection at Typical Temperature and Humidity Ranges: The CO
Alarm is not formulated to detect CO levels below 30 ppm typically. UL tested
for false alarm resistance to Methane (500 ppm), Butane (300 ppm), Heptane
(500 ppm), Ethyl Acetate (200 ppm), Isopropyl Alcohol (200 ppm) and Carbon
Dioxide (5000 ppm). Values measure gas and vapor concentrations in parts
per million.
Audible Alarm: 85 dB minimum at 10 feet (3 meters).
GENERAL LIMITATIONS OF CO ALARMS
This CO Alarm is intended for residential use. It is not intended for use
in industrial applications where Occupational Safety and Health
Administration (OSHA) requirements for carbon monoxide detectors
must be met.
CO alarms may not waken all individuals. If children or others do not readily
waken to the sound of the CO alarm, or if there are infants or family members
with mobility limitations, make sure that someone is assigned to assist them in
the event of an emergency.
CO Alarms will not work without power. This alarm requires a two (2) AA
batteries to operate.
CO Alarms for Solar or Wind Energy users and battery backup power
systems: AC powered CO Alarms should only be operated with true or pure
sine wave inverters. Operating this Alarm with most battery-powered UPS
(uninterruptible power supply) products or square wave or "quasi sine wave"
inverters will damage the Alarm. If you are not sure about your inverter or
UPS type, please consult with the manufacturer to verify.
This CO Alarm will not sense carbon monoxide that does not reach the
sensor. This CO Alarm will only sense CO at the sensor. CO may be present
in other areas. Doors or other obstructions may affect the rate at which CO
reaches the CO Alarm. For this reason, if bedroom doors are usually closed
at night, we recommend you install a CO Alarm in each bedroom and in the
hallway between them.
CO Alarms may not sense CO on another level of the home. For example,
a CO Alarm on the second level, near the bedrooms, may not sense CO in the
basement. For this reason, one CO Alarm may not give adequate warning.
Complete coverage is recommended. Place CO Alarms on each level of the
home.
CO Alarms may not be heard. The alarm horn loudness meets or exceeds
current UL standards of 85 dB at 10 feet (3 meters). However, if the CO Alarm
is installed outside the bedroom, it may not wake up a sound sleeper or one
who has recently used drugs or has been drinking alcoholic beverages. This is
especially true if the door is closed or only partly open. Even persons who are
awake may not hear the alarm horn if the sound is blocked by distance or
closed doors. Noise from traffic, stereo, radio, television, air conditioner, or
other appliances may also prevent alert persons from hearing the alarm horn.
This CO Alarm is not intended for people who are hearing impaired.
CO Alarms are not a substitute for a smoke alarm. Although fire is a
source of carbon monoxide, this CO Alarm does not sense smoke or fire. This
CO Alarm senses CO that may be escaping unnoticed from malfunctioning
furnaces, appliances, or other sources. Early warning of fire requires the
installation of smoke alarms.
CO Alarms are not a substitute for life insurance. Though these CO Alarms
warn against increasing CO levels, BRK Brands, Inc. does not warrant or imply
in any way that they will protect lives from CO poisoning. Homeowners and
renters must still insure their lives.
CO Alarms have a limited life. Although the CO Alarm and all of its parts
have passed many stringent tests and are designed to be as reliable as
possible, any of these parts could fail at any time. Therefore, you must test
your CO Alarm weekly.
CO Alarms are not foolproof. Like all other electronic devices, CO Alarms
have limitations. They can only detect CO that reaches their sensors. They
may not give early warning to rising CO levels if the CO is coming from a
remote part of the home, away from the CO Alarm.
TROUBLESHOOTING GUIDE
Problem... You should...
Low battery warning. Install two new AA batteries*.
MALFUNCTION SIGNAL. Device is not working Units under warranty should be returned to
properly, and needs to be replaced. manufacturer for replacement. See "Limited
Warranty" for details.
Possible interference. Reference the Wireless Move Alarms to different locations. Add an additional
Operation section of this manual. Alarm between the unresponsive Alarms to route the
signal around obstructions.
CO levels indicate a potentially dangerous IF YOU ARE FEELING SYMPTOMS OF CO
situation. POISONING, EVACUATE your home and call 911
or the Fire Department. Refer to "If The CO Alarm
Sounds" for details.
The CO Alarm may be improperly located. Refer to Relocate your Alarm. If frequent alarms continue,
"Where to Install CO Alarms" for details. have home rechecked for potential CO problems.
You may be experiencing an intermittent CO problem.
LIMITED WARRANTY
® brand products warrants BRK shall not be liable for any incidental or consequential damages caused
by the breach of any express or implied warranty. Except to the extent
prohibited by applicable law, any implied warranty of merchantability or fitness
for a particular purpose is limited in duration to the duration of the above
warranty. Some states, provinces or jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long
an implied warranty lasts, so the above limitations or exclusion may not apply
to you. This warranty gives you specific legal rights, and you may also have
other rights that vary from state to state or province to province.
How to Obtain Warranty Service
Service: If service is required, do not return the product to your retailer.
In order to obtain warranty service, contact the Consumer Affairs Division at
1-800-323-9005, 7:30 AM - 5:00 PM Central Standard Time, Monday through
Friday. To assist us in serving you, please have the model number and date of
purchase available when calling. For Warranty Service return to:
BRK Brands, Inc., 25 Spur Drive, El Paso, TX 79906
Battery: BRK Brands, Inc. make no warranty, express or implied, written or
oral, including that of merchantability or fitness for any particular purpose with
respect to battery.
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Basic Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Wireless Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Where to Install This Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Where CO Alarms Should NOT Be Installed . . . . . . . . . . . . . . . . . . . . . .2
How to Install This Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Step By Step Guide to Programming This Alarm . . . . . . . . . . . . . . . . . .2-3
Adding and Linking Additional ONELINK ® Alarms . . . . . . . . . . . . . . . . . .3
What You Will See and Hear With This Alarm . . . . . . . . . . . . . . . . . . . . .3
Optional Locking Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
If Your CO Alarm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Using the Silence Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Silencing the Low Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Latching Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Weekly Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
What You Need To Know About CO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
What is CO? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Symptoms of CO Poisoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Finding the Source of CO after an Alarm . . . . . . . . . . . . . . . . . . . . . . . .5
Potential Sources of CO in the Home . . . . . . . . . . . . . . . . . . . . . . . . . . .5
How Can I Protect My Family From CO Poisoning? . . . . . . . . . . . . . . . . . .6
Regulatory Information For CO Alarms . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Underwriters Laboratories Inc. UL 2034 . . . . . . . . . . . . . . . . . . . . . . .6-7
General Limitations Of CO Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Printed in Mexico M08-0195-000 Q 03/07
6 7
INSTALLATION
WHERE TO INSTALL CO ALARMS
USER'S MANUAL
The National Fire Protection Association (NFPA) recommends that a CO Alarm
should be centrally located outside of each separate sleeping area in the
ONELINK ® BATTERY OPERATED
immediate vicinity of the bedrooms. For added protection, install additional
CARBON MONOXIDE ALARM
CO Alarms in each separate bedroom, and on every level of your home.
If your bedroom hallway is longer than 40 feet (12 meters), install a CO Alarm
at BOTH ends of the hallway.
Features:
Refer to state and local building codes for additional requirements.
ONELINK ® Enabled
Voice with Programmable Location
Two Latching Features
Two Silence Features
BEDROOM
LIVING ROOM
UL STANDARD 217 UL STANDARD
2034
3055574
Model CO511 REQUIRED TO MEET NFPA RECOMMENDATIONS
SUGGESTED AREAS FOR INSTALLING ADDITIONAL CO ALARMS
Printed in Mexico
M08-0195-000 Q 03/07
In a Single-level Home:
• Install at least one CO Alarm near or within each separate sleeping area.
• For added protection, install an additional CO Alarm at least 20 feet
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
(6 meters) away from the furnace or fuel burning heat source.
This user's manual contains important information about your Carbon
In a Multi-level Home:
Monoxide Alarm's operation. If you are installing this Alarm for use by others,
• Install at least one CO Alarm near or within each separate sleeping area.
you must leave this manual—or a copy of it—with the end user.
• For added protection, install at least one CO Alarm on each level of the
home. If you have a basement, install that CO Alarm at the top of the
INTRODUCTION basement stairs.
Thank you for choosing First Alert ® for your Carbon Monoxide Alarm needs. • For added protection, install an additional CO Alarm at least 20 feet
You have purchased a state-of-the-art Alarm designed to provide you with (6 meters) away from the furnace or fuel burning heat source.
early warning of a carbon monoxide danger. Key features include:
In Mobile Homes:
ONELINK ® Enabled. Alarm automatically communicates with other ONELINK ® • Install CO Alarms on inside walls ONLY . Uninsulated outside walls and
enabled alarms when installed.
roofs of mobile homes often transfer heat and cold from outdoors.
Exclusive Voice Warning with Location will tell you the preprogrammed
location of the initiating unit and danger detected. Programmable up to 11
WHERE CO ALARMS SHOULD NOT BE INSTALLED
locations (ex. "basement"). When alarms sounds, if programmed for basement
it will say "Warning, evacuate, carbon monoxide in basement" along with all Do NOT locate this CO Alarm:
other installed ONELINK ® Voice alarms.
• In garages, kitchens, furnace rooms, or in any extremely dusty, dirty or
greasy areas.
Spread Spectrum Horn Tone. Lower and varying horn frequency makes it
easier for elderly with normal age related hearing loss to hear horn. Sweeps
• Closer than 15 feet (4.6 meters) from a furnace or other fuel burning heat
through the 2200 – 3400 Hz range. source, or fuel burning appliances like a water heater.
RF Interconnect. Reliable and secure radio frequency communication • Within 5 feet (1.5 meters) of any cooking appliance.
between alarms. 915MHz frequency with 65,000 security codes and 3 channel
• In areas where temperature is colder than 40˚ F (4˚ C) or hotter than 100˚ F
frequency hopping.
(38˚ C). These areas include unconditioned crawl spaces, unfinished attics,
Single Button Test/Silence eliminates confusion. Depending on what mode uninsulated or poorly insulated ceilings, porches, and garages.
the alarm is in, pushing the button provides different functions such as testing
• In turbulent air, like near ceiling fans, heat vents, air conditioners, fresh air
the alarm, silencing the alarm, re-testing the alarm when in silence and clearing
returns, or open windows. Blowing air may prevent CO from reaching the
the Latching features.
sensors.
Two Silence Features. Temporarily silence low battery chirp for up to eight
• In direct sunlight.
hours before replacing low battery or silence an unwanted alarm for several
minutes.
Two Latching Features. Alarm Latch: Easily identifies initiating alarm even • This CO Alarm is designed for use inside a single-family home
or apartment. It is not meant to be used in common lobbies, hall-
after alarm condition has subsided. Low Battery Latch: Identifies which unit is
in low battery condition. ways, or basements of multi-family buildings unless working CO
Alarms are also installed in each family living unit. CO Alarms in
Perfect Mount System includes a gasketless base for easy installation and a
common areas may not be heard from inside individual family
mounting bracket that keeps the alarm secure over a wide rotation range to
living units.
allow for perfect alignment.
• This CO Alarm alone is not a suitable substitute for complete
6 Year End of Life Timer. Every 24 hours of operation a counter stored in detection systems in places which house many people, like hotels
memory is updated. When the count equals 6 years of true operation meaning or dormitories, unless a CO Alarm is also placed in each unit.
actually powered-up, a malfunction chirp (triple chirp) will sound once a minute
• DO NOT use this CO Alarm in warehouses, industrial or commercial
at the time of the 45 second Power-LED flash.
buildings, special-purpose non-residential buildings, RVs, boats, or
airplanes. This CO Alarm is specifically designed for residential
© 2007 BRK Brands, Inc., a subsidiary of Jarden Corporation
use, and may not provide adequate protection in non-residential
3901 Liberty Street Road, Aurora, IL 60504-8122
applications.
All rights reserved.
Consumer Affairs: (800) 323-9005 • www.firstalert.com
HOW TO INSTALL THIS ALARM
BASIC SAFETY INFORMATION
For quick installation instructions see the "Quick Installation Instructions"
included.
• Dangers, Warnings, and Cautions alert you to important operating
instructions or to potentially hazardous situations. Pay special
This CO Alarm was designed to be mounted on the ceiling or wall. It is not
attention to these items.
a tabletop device. You must install this device on the ceiling or wall as outlined
• This CO Alarm is approved for use in single-family residences.
below. Read "Where To Install CO Alarms" before starting.
• The CO Alarm is not designed to detect fire or any other gas. It will
only indicate the presence of carbon monoxide gas at the sensor.
Carbon monoxide gas may be present in other areas.
• This CO Alarm cannot operate without working batteries.
Removing the batteries for any reason, or failing to replace the
batteries at the end of their service life, removes your protection.
• NEVER ignore any alarm. See "If Your CO Alarm Sounds" for more
information on how to respond to an alarm. Failure to respond can
result in injury or death.
• The Silence Features are for your convenience only and will not
correct a problem. See "Using the Silence Features" for details. Tools you will need: pencil, drill with 3/16" (5mm) drill bit,
Always check your home for a potential problem after any alarm. Phillips screwdriver, hammer.
Failure to do so can result in injury or death.
1. Hold the mounting bracket against the ceiling (or wall) so the vertical
• Test this CO Alarm once a week. If the Alarm ever fails to test mounting slot is aligned in the 12 o'clock position and trace around the
correctly, have it replaced immediately! If the Alarm is not working inside of the mounting slots (vertical and horizontal mounting).
properly, it cannot alert you to a problem.
2. Put the unit where it won't get covered with dust when you drill the
• This product is intended for use in ordinary indoor locations of mounting holes.
family living units. It is not designed to measure CO levels in com-
3. Using a 3/16" (5 mm) drill bit, drill a hole through the center of the oval
pliance with Occupational Safety and Health Administration (OSHA)
outlines you traced.
commercial or industrial standards. Individuals with medical condi-
tions that may make them more sensitive to carbon monoxide may 4. Insert the plastic screw anchors (in the plastic bag with screws) into the
consider using warning devices which provide audible and visual holes. Tap the screw anchors gently with a hammer, if necessary, until they
signals for carbon monoxide concentrations under 30 ppm.
are flush with the ceiling or wall.
For additional information on carbon monoxide and your medical
5. Line the mounting bracket up over the plastic screw anchors.
condition contact your physician.
6. Screw the mounting bracket to the ceiling or wall through the mounting
slots using the two screws provided.
WIRELESS OPERATION
7. Attach the CO Alarm to the mounting
bracket. Line up the guides on the alarm's
First Alert ® ONELINK ® Technology is the easy, cost-effective way to provide
base with the guides on the mounting
your family with whole-home safety. All ONELINK ® Alarms communicate with
bracket. When guides are lined up, turn
each other without wires or connectors. When one Alarm sounds, they all
the base clockwise (right) until it snaps
sound. This provides your family with an earlier warning of potential danger,
into place.
and gives you more time to react.
NOTE: Once the Alarm is snapped onto
The communication distance (range) between any two ONELINK Alarms is
® the mounting bracket, you can rotate
typically 50 feet (15 meters) inside of a home. Some features of a home, such
the Alarm to adjust the alignment.
as the number of floors, number/size of rooms, furniture and types of building
8. Test the CO Alarm. See "Weekly Testing"
materials used may reduce the range of the Alarms. Examples include: sus-
for details.
pended ceilings, ductwork, large metallic appliances (refrigerators) and metal
studs. A feature of ONELINK ® Alarms is that they operate as a mesh network.
All Alarms will repeat any alarm signal that is received to all other ONELINK ®
Alarms. Interference from structural conditions can be overcome by adding
additional Alarms to route the wireless signal around obstructions.
STEP BY STEP GUIDE TO PROGRAMMING
THIS ALARM
• The range and proper operation of any wireless device will vary
depending on its surroundings. It is very important that each
FOR FIRST TIME AND WHEN CHANGING BATTERIES
Alarm is tested individually before and after installation to make
Action:
sure that all Alarms respond properly.
• The ONELINK ® Alarms are not to be used outdoors or to transmit 1. Insert batteries (2, AA batteries).
between buildings. The Alarms will not communicate properly
under these conditions.
• Metal objects and metallic wallpaper may interfere with signals
from wireless Alarms. Alarms should be tested after changes to
your home such as remodeling, moving furniture, and with metal
doors opened and closed.
Your First Alert ® ONELINK ® CO Alarm will automatically communicate both
potential fires and carbon monoxide presence with all other First Alert ®
2. Press & Hold Test Button if you
ONELINK ® Smoke/CO Alarms.
would like to program the location
FCC NOTICE: This device complies with Part 15 of the FCC Rules. or change the location of the
Operation is subject to the following two conditions: (1) This device may not Alarm. Release button after Alarm
responds.
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC ID: M7U5001L 3. After you hear the location of where
you are placing the Alarm, Press &
Hold the Test Button.
Changes or modifications not expressly approved by BRK Brands, Inc.
could void the user's authority to operate the equipment.
Your Alarm has now been programmed for the location of your choice.
Available locations:
Basement
Living Room
Family Room
Office
1
OPTIONAL LOCKING FEATURES
The optional locking features are designed to prevent unauthorized removal of the battery or alarm. It is not necessary to activate the locks in
single-family households where unauthorized battery or alarm removal is not a concern.
These CO Alarms have two separate locking features: one to lock the battery compartment, and the other to lock the CO Alarm
to the mounting bracket. You can choose to use either feature independently, or use them both.
Tools you will need: • Needle-nose pliers • Standard flathead screwdriver.
Both locking features use locking pins, which are molded into the mounting bracket. Depending on which locking features you
use, remove one or both pins from the mounting bracket using needle-nose pliers.
To permanently remove either locking pin, insert a flathead screwdriver between the locking pin and the lock, and pry
the pin out of the lock.
TO LOCK THE BATTERY COMPARTMENT
Do not lock the battery compartment until you install the batteries and
BEDROOM BEDROOM
test the CO Alarm.
KITCHEN
GARAGE
HALL
If the unit does not alarm during testing,
DO NOT lock the battery compartment!
Install new batteries and test again.
If the CO Alarm still does not alarm, replace
BASEMENT
it immediately.
1. Using needle-nose pliers, detach one
locking pin from the mounting bracket.
2. After batteries are inserted, then push
the locking pin through the hole near the
battery door latch on the back of the CO
Alarm.
TO LOCK THE MOUNTING BRACKET
1. Using needle-nose pliers, detach one
locking pin from the mounting bracket.
2. Insert the locking pin through the hole on
the back of the CO Alarm as shown in the
diagram.
3. When you attach the CO Alarm to the
mounting bracket, the locking pin's head
will fit into a notch on the bracket.
ADDING AND LINKING ADDITIONAL ONELINK
NOTE: Steps 1 through 3 need to be completed within two minutes. If
more than two minutes pass, the Green power LED will stop blinking.
Simply open the battery drawer of the second Alarm and repeat
steps 1 through 3.
1. Insert the batteries into the battery
drawer of the next Alarm.
DO NOT CLOSE THE DRAWER.
2. Press and hold the test button and
then close the battery drawer.
3. Once you hear the unit chirp,
release the test button.
The Green power LED will start
to blink indicating the ONELINK ®
Alarm is waiting for program data
from one of the other setup ONELINK ® Alarms.
4. Press and hold the test button on the first Alarm, until the second Alarm
chirps and its Green power LED stops blinking. Then release the test button.
5. If you have purchased the hardwired battery back-up ONELINK
you can now connect the hardwired Alarm by installing the three-wire
connector on the ceiling to the Alarm.
6. Repeat steps 1-5 for additional ONELINK ® Alarms.
You have now successfully linked your new ONELINK ® Alarms. To add
additional Alarms at a later time, follow steps 1 through 5.
WHAT YOU WILL SEE AND HEAR WITH THIS ALARM
Under Normal Operations
Voice: Silent
Horn: Silent
Power LED: Flashes Green once/minute
When You Test the Alarm
PARTS OF THIS CO ALARM
Voice: "Testing." Horn: 4 fast beeps, pause, 4 fast beeps;
1 Test/Silence Button Voice: "Warning, evacuate carbon monoxide in [Location, example:
"Basement"]. Evacuate." Pause. "Highest carbon monoxide level
2 Battery Compartment
was [CO level example: _0_ ppm]" .
3 Power LED
CO LED: Flashes Red in sync with the horn pattern
4 CO Alarm LED
If Battery Becomes Low or is Missing
Voice: "Replace battery in [Location, example "Basement"]."
Repeated every 5 hours
Horn: chirps once a minute
Power LED: Flashes Green On for 2 seconds/Off for 2 seconds.
Low Battery Latch is now engaged.
If Alarm is Not Operating Properly (MALFUNCTION SIGNAL)
Voice: "Detector error in [Location, example "Basement"], please see
manual." Repeated every 5 hours
Horn: Three rapid chirps every minute
CO LED: Flashes approximately once a minute
Alarm Levels of CO are Detected
Horn: 4 fast beeps, pause, 4 fast beeps, pause*
Voice: "Warning, evacuate carbon monoxide in [Location, example:
"Basement"]. Evacuate." Pause. "Highest carbon monoxide level
was [CO level example: ___ ppm]" .
Horn: 4 beeps, pause, 4 beeps, pause repeating 2 times followed by Voice
Warning above.
CO LED: During Alarm: Flashes Red in sync with the horn pattern. After
Alarm: Flashes Red On for 2 seconds/Off for 2 seconds. CO
Alarm Latch is now engaged.
*NOTE: If unit goes into CO alarm, the regular 4 beeps-brief pause cycle will
repeat for fifteen minutes. After fifteen minutes, the pause will increase to one
minute.
CO Alarm is Silenced
Horn: Off
CO LED: Flashes Red
IF YOUR CO ALARM SOUNDS
What You See and Hear
Refer to section "What You Will See and Hear With This Alarm" .
Actuation of your CO Alarm indicates the presence of carbon monoxide
(CO) which can kill you. In other words, when your CO Alarm sounds,
Alarm Will Say: you must not ignore it!
"Welcome, First Alert Carbon
IF THE ALARM SIGNAL SOUNDS
Monoxide Alarm."
1. Operate the Test/Silence button.
"No location programmed" if first
2. Call your emergency services, fire department or 911. Write down the
time or "[Location, example:
"Basement"] location programmed" number of your local emergency service here:
when changing batteries. ________________________________________________________________
"To select location, press and hold
3. Immediately move to fresh air—outdoors or by an open door or window.
test button now."
Do a head count to check that all persons are accounted for. Do not re-
enter the premises, or move away from the open door or window until the
"To save location, press and hold test
emergency services responder has arrived, the premises have been aired
button after location is heard." Alarm
out, and your CO Alarm remains in its normal condition.
will speak list of locations (see
below). 4. After following steps 1-3, if your CO Alarm reactivates within a 24-hour
period, repeat steps 1-3 and call a qualified appliance technician to investi-
gate for sources of CO from fuel-burning equipment and appliances, and
"[Location, example: "Basement"] inspect for proper operation of this equipment. If problems are identified
location saved."
during this inspection have the equipment serviced immediately. Note any
If no location is chosen: combustion equipment not inspected by the technician, and consult the
manufacturers' instructions, or contact the manufacturers directly, for more
"No location saved."
information about CO safety and this equipment. Make sure that motor
vehicles are not, and have not, been operating in an attached garage or
adjacent to the residence. Write down the number of a qualified appliance
Kitchen Child's Bedroom technician here:
Dining Room Master Bedroom
________________________________________________________________
No Location Guest Bedroom
Hallway Utility Room
Alarms have various limitations. See "General Limitations of CO Alarms"
for details.
2 3
TO UNLOCK THE BATTERY COMPARTMENT
1. Remove the CO Alarm from the
mounting bracket. If the unit is locked
to the bracket, see the section
"To Unlock the Mounting Bracket."
2. Insert a flathead screwdriver under the
head of the locking pin, and gently pry
it out of the battery compartment lock.
(If you plan to relock the battery
compartment, save the locking pin.)
3. To relock the battery compartment,
close the battery door and reinsert
locking pin in lock.
4. Reattach the CO Alarm to the mounting
bracket.
When replacing the batteries, always test
the Alarm before relocking the battery
compartment.
TO UNLOCK THE MOUNTING BRACKET
1. Insert a flathead screwdriver into the
rectangular cut-out on the mounting
bracket nearest to the locking pin.
2. Pry the CO Alarm away from the
bracket by pushing up on the screw-
driver and turning the CO Alarm
counterclockwise (left) at the same
time.
® ALARMS
"ALARM—MOVE TO FRESH AIR"
If you hear the CO alarm horn and the CO red light is flashing,
move everyone to a source of fresh air.
DO NOT remove the batteries!
USING THE SILENCE FEATURES
Never remove the batteries to quiet an unwanted alarm. Removing the
batteries disables the alarm and removes your protection.
The Silence Feature is intended to temporarily silence the horn while you
identify and correct the problem. Do not use the Silence Feature in emergency
situations. It will not correct a CO problem.
The Silence Feature can temporarily quiet an unwanted alarm for several
minutes. You can silence this Alarm by pressing the Test/Silence button on
the alarm cover for at least 3-5 seconds.
After the Test/Silence button is released, the Red LED blinks during the silence
mode.
® Alarm,
When the CO Alarm is Silenced the CO Alarm will remain silent for up to
4 minutes. After 4 minutes, if CO levels remain potentially dangerous the horn
will start sounding again.
SILENCING THE LOW BATTERY WARNING
This silence feature can temporarily quiet the low battery warning "chirp" for
up to 8 hours. You can silence the low battery warning "chirp" by pressing the
Test/Silence button on the alarm cover.
Once the low battery warning "chirp" silence feature is activated, the unit
continues to flash the Green light twice a minute for 8 hours. After 8 hours, the
low battery "chirp" will resume. Replace the batteries as soon as possible;
this unit will not operate without battery power!
To deactivate this feature: Press the Test/Silence button again. The unit will
go into Test Mode and the low battery warning will resume (LED flashes and
unit sounds "chirp" once a minute).
LATCHING FEATURES
Alarm Latch is activated after an Alarm is exposed to alarm levels of carbon
monoxide. After CO levels drop below alarm levels, the "CO" Red LED will
begin to flash On for 2 seconds/Off for 2 seconds. It will continue to flash or
"latch" for about 15 minutes, to give you time to determine which unit initiated
the alarm.
Low Battery Latch is activated when the Alarm is in the "low battery condition".
When this occurs, the Power LED flashes Green On for 2 seconds/Off for 2
seconds for about 15 minutes. This feature is designed to help you identify
which Alarm needs to have the battery replaced. Although, the Alarm will
sound the low battery chirp approximately once every minute, sometimes
during the initial stages of "low battery", the Alarm will chirp in greater intervals
than one minute, sometimes up to several hours, until the battery reaches a
steady low battery level. This innovative feature eliminates the frustration of
waiting for and/or identifying which unit is chirping.
WEEKLY TESTING
• Test the CO Alarm once a week. If the CO Alarm ever fails to test
properly, have it replaced immediately! If the CO Alarm is not
working properly, it cannot alert you to a problem.
• DO NOT stand close to the Alarm when the horn is sounding.
Exposure at close range may be harmful to your hearing.
When testing, step away when horn starts sounding.
It is important to test this unit every week to make sure it is working
properly. Using the test button is the recommended way to test this CO
Alarm.
You can test this CO Alarm by pressing and holding the Test/Silence button
on the Alarm cover (typically 3-5 seconds).
During testing, you will see and hear the following sequence:
• The Horn will sound 4 beeps, pause, 4 beeps. The Power LED will be
Off and the CO LED flashes Red.
If the unit does not alarm, make sure the batteries are correctly installed, and
test again. If the unit still does not alarm, replace it immediately.
4
